2002 JEEP LIBERTY Window connector

C301 (LHD) - ORANGE (DRIVER DOOR SIDE)
CAV CIRCUIT
1 Q11 16LB (POWER WINDOWS)
2 F89 20OR/RD (EXCEPT BASE)
3 P33 18OR/BK (EXCEPT BASE)
4 C16 20LB/YL (EXCEPT BASE)
5 P72 18YL/BK (EXCEPT BASE)
6-
7 G73 18LG/OR (EXCEPT BASE)
8 P37 18LG (EXCEPT BASE)
9 X55 18BR/RD
10 Q21 16WT (POWER WINDOWS)
11 V23 20BR/PK (EXCEPT BASE)
12 P34 18PK/BK (EXCEPT BASE)
13 P74 18DB (EXCEPT BASE)
14 P76 18OR/YL (EXCEPT BASE)
15 G75 20TN
16 -
17 Z350 20BK/LG
18 -
19 P36 20PK/VT (EXCEPT BASE)
20 X53 18DG
C301 (RHD) - ORANGE (MAIN BODY SIDE)
CAV CIRCUIT
1 Q12 14BR
2 F89 18OR/RD
3 P33 18OR/BK
4 C16 18LB/YL
5 P71 18YL/DG
6-
7 G73 18LG/OR
8 P37 20LG
9 X56 18DB/RD
10 Q22 14VT/WT
11 V23 20BR/PK
12 P34 18PK/BK
13 P75 18LB/WT
14 P76 18OR/YL
15 G75 20TN
16 -
17 Z351 18BK/LG
18 -
19 P36 20PK/VT
20 X54 18VT
8Wa - 80 - 32 8W-80 CONNECTOR PIN-OUTSKJ

C303 (LHD) - ORANGE (PASSENGER DOOR
SIDE)
CAV CIRCUIT
1 Q12 16BR (POWER WINDOWS)
2 F89 20OR/RD (EXCEPT BASE)
3 P33 18OR/BK (EXCEPT BASE)
4 C16 20LB/YL (EXCEPT BASE)
5 P72 20YL/BK (EXCEPT BASE)
6-
7 G72 18DG/OR (EXCEPT BASE)
8 P37 18LG (EXCEPT BASE)
9 X56 18DB/RD
10 Q22 16VT/WT (POWER WINDOWS)
11 -
12 P35 18OR/VT (EXCEPT BASE)
13 P74 20DB (EXCEPT BASE)
14 P76 20OR/YL (EXCEPT BASE)
15 G74 20TN/WT
16 -
17 Z351 18BK/LG
18 -
19 P36 20PK/VT (EXCEPT BASE)
20 X54 18VT
C303 (RHD) - ORANGE (MAIN BODY SIDE)
CAV CIRCUIT
1 Q11 14LB
2 F89 18OR/RD
3 P33 18OR/BK
4 C16 18LB/YL
5 P71 18YL/DG
6-
7 G72 18DG/OR
8 P37 20LG
9 X55 18BR/RD
10 Q21 14WT
11 -
12 P35 18OR/VT
13 P75 18LB/WT
14 P76 18OR/YL
15 G74 20TN/WT
16 Z21 20BK/LG
17 Z350 18BK/LG
18 -
19 P36 20PK/VT
20 X53 18DG
8Wa - 80 - 36 8W-80 CONNECTOR PIN-OUTSKJ

INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
16 L62 20BR/RD RIGHT TURN SIGNAL
17 G11 20WT/BK RED BRAKE WARNING INDICATOR DRIVER
18 G29 20BK/TN LOW WASHER FLUID SENSE
19 F87 20TN/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
20 - -
INTAKE AIR TEMPERATURE SENSOR (GAS) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
INTRUSION SENSOR (BUILT-UP-EXPORT) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z2 20BK/LG GROUND
2- -
3 X75 20DG SIREN SIGNAL CONTROL
4- -
5 D25 20YL/VT PCI BUS
6 M1 20PK FUSED B(+)
JUNCTION BLOCK BODY CONTROL MODULE-JB - 26 WAY
CAV CIRCUIT FUNCTION
1 X3 (PREMIUM) HORN RELAY CONTROL
2 P334 DOOR UNLOCK RELAY CONTROL
3 L308 PARK LAMP RELAY CONTROL
4 L96 (PREMIUM) REAR FOG LAMP RELAY CONTROL
5 P109 (EXCEPT BASE) DRIVER DOOR UNLOCK RELAY CONTROL
6 C80 REAR WINDOW DEFOGGER RELAY CONTROL
7- -
8 Z300 GROUND
9 F35 FUSED B(+)
10 L309 HIGH BEAM RELAY CONTROL
11 P31 TAILGATE UNLOCK DRIVER
12 P37 DOOR LOCK SWITCH GROUND
13 L94 LOW BEAM RELAY CONTROL
14 F89 FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
15 M1 FUSED B(+)
16 F87 FUSED IGNITION SWITCH OUTPUT (RUN-START)
17 L26 (EXCEPT BASE) FRONT FOG LAMP RELAY CONTROL
18 P333 DOOR LOCK RELAY CONTROL
19 V16 FRONT WIPER HIGH/LOW RELAY CONTROL
20 V55 FRONT WIPER PARK SWITCH SENSE
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-65

LEFT FRONT DOOR SPEAKER (PREMIUM) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 X53 18DG LEFT FRONT SPEAKER (+)
2 X55 18BR/RD LEFT FRONT SPEAKER (-)
3 Z9 16BK GROUND
4 X81 18YL/BK AMPLIFIED HIGH LEFT FRONT SPEAKER (-)
5 X91 18WT/BK AMPLIFIED LOW LEFT REAR SPEAKER (-)
6 X57 18BR/LB LEFT REAR SPEAKER (-)
7 X51 18BR/YL LEFT REAR SPEAKER (+)
8 X13 16BK/RD RADIO CHOKE OUTPUT
9 X83 18YL/RD AMPLIFIED HIGH LEFT FRONT SPEAKER (+)
10 X93 18WT/RD AMPLIFIED LOW LEFT REAR SPEAKER (+)
LEFT FRONT IMPACT SENSOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 R47 18DB/LB LEFT FRONT IMPACT SENSOR GROUND
4 R49 18LB LEFT FRONT IMPACT SENSOR SIGNAL
LEFT FRONT PARK/TURN SIGNAL LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L63 18DG/RD LEFT TURN SIGNAL
2 L77 18BK/YL (EXCEPT BUILT-UP-EX-
PORT)PARK LAMP RELAY OUTPUT
3 Z141 18BK GROUND
LEFT FRONT POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q21 16WT LEFT FRONT WINDOW DRIVER DOWN
2 Q11 16LB LEFT FRONT WINDOW DRIVER UP
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-71

LEFT REAR DOOR SPEAKER-2WAY
CAV CIRCUIT FUNCTION
1 X51 18BR/YL (BASE) LEFT REAR DOOR SPEAKER (+)
1 X93 18WT/RD (PREMIUM) AMPLIFIED LOW LEFT REAR SPEAKER (+)
2 X57 18BR/LB (BASE) LEFT REAR DOOR SPEAKER (-)
2 X91 18WT (PREMIUM) AMPLIFIED LOW LEFT REAR SPEAKER (-)
LEFT REAR POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q23 16DG LEFT REAR WINDOW DRIVER DOWN
2 Q13 16GY LEFT REAR WINDOW DRIVER UP
LEFT REMOTE RADIO SWITCH (PREMIUM) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X10 20RD/DB RADIO CONTROL MUX RETURN
2 X20 20RD/BK RADIO CONTROL MUX
LEFT SIDE IMPACT AIRBAG CONTROL MODULE (LSIACM) - YELLOW 8 WAY
CAV CIRCUIT FUNCTION
1 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
2- -
3 R77 18YL/RD LEFT CURTAIN SQUIB LINE 2
4 R75 18YL/BK LEFT CURTAIN SQUIB LINE 1
5 Z104 18BK/YL GROUND
6- -
7- -
8 D25 18YL/VT PCI BUS
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-75

POWER WINDOW MASTER SWITCH (MIDLINE/HIGHLINE) - LT. GRAY 14 WAY
CAV CIRCUIT FUNCTION
1- -
2 Q1 16YL POWER WINDOW SWITCH FEED
2 Q1 16YL POWER WINDOW SWITCH FEED
3- -
4 Q27 14RD/BK LEFT REAR WINDOW DRIVER DOWN
5 Q17 14DB/WT LEFT REAR WINDOW DRIVER UP
6 Q28 14DG/WT RIGHT REAR WINDOW DRIVER DOWN
7 Q18 14GY/BK RIGHT REAR WINDOW DRIVER UP
8- -
9 Q21 14WT LEFT FRONT WINDOW DRIVER DOWN
10 F81 12TN FUSED B(+)
11 Q11 14LB LEFT FRONT WINDOW DRIVER UP
12 Q12 14BR RIGHT FRONT WINDOW DRIVER UP
13 Q22 14VT/WT RIGHT FRONT WINDOW DRIVER DOWN
14 Z238 12BK/WT GROUND
POWERTRAIN CONTROL MODULE-C1 (2.4L) - BLACK 32 WAY
CAV CIRCUIT FUNCTION
1- -
2 F1 18DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 K4 18BK/LB SENSOR GROUND
5- -
6- -
7 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
8 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
9- -
10 K60 18YL/BK IDLE AIR CONTROL NO. 2 DRIVER
11 K40 18BR/WT IDLE AIR CONTROL NO. 1 DRIVER
12 K10 18DB/OR POWER STEERING PRESSURE SWITCH SENSE
13 - -
14 K77 18BR/WT TRANSFER CASE POSITION SENSOR INPUT
15 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
17 K7 18OR 5 VOLT SUPPLY
18 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
19 K39 18GY/RD IDLE AIR CONTROL NO. 3 DRIVER
20 K59 18VT/BK IDLE AIR CONTROL NO. 4 DRIVER
21 - -
22 A14 16RD/WT FUSED B(+)
23 K22 18OR/DB THROTTLE POSITION SENSOR SIGNAL
24 K41 18BK/DG OXYGEN SENSOR 1/1 SIGNAL
25 K141 18TN/WT OXYGEN SENSOR 1/2 SIGNAL
26 - -
27 K1 18DG/RD MANIFOLD ABOLUTE PRESSURE SENSOR SIGNAL
28 - -
29 - -
30 - -
31 Z107 14BK/DB GROUND
32 Z107 14BK/DB GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-81

REAR POWER WINDOW SWITCH (MIDLINE/HIGHLINE) - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 Q28 14DG/WT RIGHT REAR WINDOW DRIVER DOWN
2 Q14 14GY RIGHT REAR WINDOW DRIVER UP
3 Q24 14DG RIGHT REAR WINDOW DRIVER DOWN
4 Q18 14GY/BK RIGHT REAR WINDOW DRIVER UP
5 Q1 16YL POWER WINDOW SWITCH FEED
6 Q1 16YL POWER WINDOW SWITCH FEED
7 Q17 14DB/WT LEFT REAR WINDOW DRIVER UP
8 Q23 14RD/WT LEFT REAR WINDOW DRIVER DOWN
9 Q27 14RD/BK LEFT REAR WINDOW DRIVER DOWN
10 Q13 14DB LEFT REAR WINDOW DRIVER UP
REAR WHEEL SPEED SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B2 18YL REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
2 B1 18YL/DB REAR WHEEL SPEED SENSOR SIGNAL
REAR WIPER MOTOR - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z235 18BK GROUND
2 V21 20DB/RD REAR WIPER ON DRIVER
3 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
4 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
5 F70 18PK/BK FUSED B(+)
6- -
RED BRAKE WARNING INDICATOR SWITCH - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 G11 18WT/BK RED BRAKE WARNING INDICATOR DRIVER
2 Z142 18BK/WT GROUND
REMOTE KEYLESS ENTRY MODULE (EXCEPT BASE)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 86 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT FRONT PARK/ TURN SIGNAL LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L62 18BR/RD RIGHT TURN SIGNAL
2 L78 18DG/YL (EXCEPT BUILT-UP-EX-
PORT)FUSED PARK LAMP RELAY OUTPUT
3 Z142 18BK/WT GROUND
RIGHT FRONT POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q22 16VT/WT RIGHT FRONT WINDOW DRIVER DOWN
2 Q12 16BR RIGHT FRONT WINDOW DRIVER UP
RIGHT FRONT WHEEL SPEED SENSOR (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
2 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
RIGHT HEADLAMP (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
2 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
3 Z142 18BK/WT GROUND
RIGHT HEADLAMP (EXCEPT BUILT-UP-EXPORT) - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
B Z142 18BK/WT GROUND
C L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-89
