2002 JEEP LIBERTY relay

JUNCTION BLOCK C2 - GREEN 42 WAY
CAV CIRCUIT FUNCTION
1 F37 14RD/LB (MIDLINE/HIGHLINE) FUSED B(+)
2- -
3 C15 12BK/WT DEFOGGER RELAY OUTPUT
4 F89 18OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
5 P37 20LG (EXCEPT BASE) DOOR LOCK SWITCH GROUND
6 P33 18OR/BK (EXCEPT BASE) DOOR LOCK RELAY OUTPUT
7 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
8 P34 18PK/BK (EXCEPT BASE) DRIVER DOOR UNLOCK RELAY OUTPUT
9 P35 18OR/VT (EXCEPT BASE) PASSENGER DOOR UNLOCK RELAY OUTPUT
10 P36 20PK/VT (EXCEPT BASE) DOOR LOCK SWITCH MUX
11 P37 20LG (EXCEPT BASE) DOOR LOCK SWITCH GROUND
12 M20 20BR COURTESY LAMP LOAD SHED
13 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
14 P36 20PK/VT (EXCEPT BASE) DOOR LOCK SWITCH MUX
15 P30 16OR/WT TAILGATE LOCK DRIVER
16 F70 18PK/BK FUSED B(+)
17 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
18 M1 20PK FUSED B(+)
19 M1 20PK FUSED B(+)
20 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
21 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
22 - -
23 V23 20BR/PK (HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN)
24 V23 20BR/PK (EXCEPT BASE) FUSED IGNITION SWITCH OUTPUT (RUN)
25 V23 20BR/PK (MIDLINE/HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN)
26 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
27 - -
28 A6 16RD/BK (PREMIUM GAS) FUSED B(+)
29 - -
30 M2 18YL COURTESY LAMP DRIVER
31 C16 18LB/YL (EXCEPT BASE) FUSED DEFOGGER RELAY OUTPUT
32 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
33 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
34 L38 18BR/WT (HIGHLINE) REAR FOG LAMP RELAY OUTPUT
35 P31 16PK/WT TAILGATE UNLOCK DRIVER
36 - -
37 F60 16DG/RD (PREMIUM) FUSED B(+)
38 F87 20WT/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
39 C16 18LB/YL (EXCEPT BASE) FUSED DEFOGGER RELAY OUTPUT
40 F85 16VT/WT (MIDLINE/HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
41 F41 16PK/VT FUSED B(+)
42 A3 16RD/WT (HIGHLINE) FUSED B(+)
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-67

JUNCTION BLOCK C3 - LT. BLUE 42 WAY
CAV CIRCUIT FUNCTION
1 A12 10RD/TN FUSED B(+)
2 A13 10PK/WT FUSED B(+)
3 A4 12BK/PK FUSED B(+)
4 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
5 L43 18VT FUSED LEFT LOW BEAM OUTPUT
6- -
7 V55 16TN/RD FRONT WIPER PARK SWITCH SENSE
8 F1 18DB (LHD) FUSED IGNITION SWITCH OUTPUT (RUN-START)
8 F1 20DB (RHD) FUSED IGNITION SWITCH OUTPUT (RUN-START)
9 V6 14DB/YL (RHD) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
9 VG 16DB/YL (LHD) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 - -
11 A12 10RD/TN FUSED B(+)
12 - -
13 - -
14 - -
15 V14 18RD/VT FRONT WIPER ON/OFF RELAY CONTROL
16 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
17 - -
18 V16 18VT/YL WIPER HIGH/LOW RELAY CONTROL
19 F20 18WT FUSED IGNITION SWITCH OUTPUT (RUN)
20 - -
21 - -
22 - -
23 - -
24 L50 18WT/TN (ABS) BRAKE LAMP SWITCH OUTPUT
25 - -
26 - -
27 - -
28 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
29 M1 18PK FUSED B(+)
30 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
31 - -
32 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
33 L39 18LB FRONT FOG LAMP RELAY OUTPUT
34 A18 10PK FUSED B(+)
35 - -
36 - -
37 L33 18LG/BR FUSED LEFT HIGH BEAM OUTPUT
38 F22 18DB/PK (ABS) FUSED IGNITION SWITCH OUTPUT (RUN)
39 X2 18DG/RD HORN RELAY OUTPUT
40 A18 10PK FUSED B(+)
41 - -
42 A7 10RD/BK FUSED B(+)
8Wa - 80 - 68 8W-80 CONNECTOR PIN-OUTSKJ

LEFT DOOR LOCK SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 P36 20PK/VT DOOR LOCK SWITCH MUX
2 Z350 18BK/LG GROUND
3 F89 20OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 P37 20LG DOOR LOCK SWITCH GROUND
LEFT FOG LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z141 18BK GROUND
B L39 18LB FRONT FOG LAMP RELAY OUTPUT
LEFT FRONT DOOR AJAR SWITCH (BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G75 20TN DRIVER DOOR AJAR SWITCH SENSE
2 Z350 20BK/LG GROUND
LEFT FRONT DOOR LOCK MOTOR/AJAR SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G74 20TN/WT (RHD) PASSENGER DOOR AJAR SWITCH SENSE
1 G75 20TN (LHD) DRIVER DOOR AJAR SWITCH SENSE
2 Z350 20BK/LG GROUND
3 P35 18OR/VT (RHD) PASSENGER DOOR UNLOCK RELAY OUTPUT
3 P34 18PK/BK (LHD) DRIVER DOOR UNLOCK RELAY OUTPUT
4 P33 18OR/BK DOOR LOCK RELAY OUTPUT
LEFT FRONT DOOR SPEAKER (BASE)-2WAY
CAV CIRCUIT FUNCTION
1 X53 18DG LEFT FRONT SPEAKER (+)
2 X55 18BR/RD LEFT FRONT SPEAKER (-)
8Wa - 80 - 70 8W-80 CONNECTOR PIN-OUTSKJ

LEFT FRONT DOOR SPEAKER (PREMIUM) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 X53 18DG LEFT FRONT SPEAKER (+)
2 X55 18BR/RD LEFT FRONT SPEAKER (-)
3 Z9 16BK GROUND
4 X81 18YL/BK AMPLIFIED HIGH LEFT FRONT SPEAKER (-)
5 X91 18WT/BK AMPLIFIED LOW LEFT REAR SPEAKER (-)
6 X57 18BR/LB LEFT REAR SPEAKER (-)
7 X51 18BR/YL LEFT REAR SPEAKER (+)
8 X13 16BK/RD RADIO CHOKE OUTPUT
9 X83 18YL/RD AMPLIFIED HIGH LEFT FRONT SPEAKER (+)
10 X93 18WT/RD AMPLIFIED LOW LEFT REAR SPEAKER (+)
LEFT FRONT IMPACT SENSOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 R47 18DB/LB LEFT FRONT IMPACT SENSOR GROUND
4 R49 18LB LEFT FRONT IMPACT SENSOR SIGNAL
LEFT FRONT PARK/TURN SIGNAL LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L63 18DG/RD LEFT TURN SIGNAL
2 L77 18BK/YL (EXCEPT BUILT-UP-EX-
PORT)PARK LAMP RELAY OUTPUT
3 Z141 18BK GROUND
LEFT FRONT POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q21 16WT LEFT FRONT WINDOW DRIVER DOWN
2 Q11 16LB LEFT FRONT WINDOW DRIVER UP
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-71

LEFT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X53 18DG (BASE) LEFT FRONT SPEAKER (+)
1 X83 18YL/RD (PREMIUM) AMPLIFIED HIGH LEFT FRONT SPEAKER (+)
2 X55 18BR/RD (BASE) LEFT FRONT SPEAKER (-)
2 X81 18YL/BK (PREMIUM) AMPLIFIED HIGH LEFT FRONT SPEAKER (-)
LEFT LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z141 18BK GROUND
2 L13 18BR/YL HEADLAMP ADJUST SIGNAL
3 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
LEFT POSITION LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
2 Z141 18BK GROUND
LEFT POWER MIRROR (EXCEPT BASE) - WHITE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 20YL/DG LEFT MIRROR UP DRIVER
2 P76 20OR/YL MIRROR COMMON DRIVER
3 P75 20LB/WT LEFT MIRROR LEFT DRIVER
4- -
5 C16 20LB/YL FUSED DEFOGGER RELAY OUTPUT
6 Z350 20BK/LG GROUND
7 P99 20GY (WITH FOLD) FOLDING MIRROR FEED
8 P110 20YL (WITH FOLD) FOLDING MIRROR RETURN
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-73

LEFT POWER SEAT MOTORS (MIDLINE/HIGHLINE) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 P11 14YL/WT DRIVER SEAT REAR UP DRIVER
2 P13 14RD/WT DRIVER SEAT REAR DOWN DRIVER
3 P19 14YL/LG DRIVER SEAT FRONT UP DRIVER
4 P21 14RD/LG DRIVER SEAT FRONT DOWN DRIVER
5 P17 14RD/YL DRIVER SEAT HORIZONTAL REARWARD DRIVER
6 P15 14YL/LB DRIVER SEAT HORIZONTAL FORWARD DRIVER
LEFT POWER SEAT SWITCH (MIDLINE/HIGHLINE) - GREEN 10 WAY
CAV CIRCUIT FUNCTION
1 Z238 14BK/WT GROUND
2- -
3 P15 14YL/LB DRIVER SEAT HORIZONTAL FORWARD DRIVER
4- -
5 F37 14RD/LB FUSED B(+)
6 P17 14RD/YL DRIVER SEAT HORIZONTAL REARWARD DRIVER
7 P13 14RD/WT DRIVER SEAT REAR DOWN DRIVER
8 P21 14RD/LG DRIVER SEAT FRONT DOWN DRIVER
9 P19 14YL/LG DRIVER SEAT FRONT UP DRIVER
10 P11 14YL/WT DRIVER SEAT REAR UP DRIVER
LEFT REAR DOOR AJAR SWITCH (BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z350 20BK/LG GROUND
LEFT REAR DOOR LOCK MOTOR/AJAR SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z350 20BK/LG GROUND
3 P35 18OR/VT PASSENGER DOOR UNLOCK RELAY OUTPUT
4 P33 18OR/BK DOOR LOCK RELAY OUTPUT
8Wa - 80 - 74 8W-80 CONNECTOR PIN-OUTSKJ

LEFT SIDE MARKER LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
2 L63 18DG/RD LEFT TURN SIGNAL
LEFT SIDE REPEATER LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L63 18DG/RD LEFT TURN SIGNAL
2 Z141 18BK GROUND
LEFT SPEED CONTROL SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2 K4 20BK/LB SENSOR GROUND
3 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
4- -
LEFT TAIL/STOP LAMP - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 L38 18BR/WT (BUILT-UP-EXPORT) REAR FOG LAMP RELAY OUTPUT
2 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
3 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
4 L10 18BR/LG BACK-UP LAMP FEED
5 Z151 18BK/WT GROUND
6 L63 18DG/RD LEFT TURN SIGNAL
LEFT VISOR/VANITY LAMP (EXCEPT BASE) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M20 20BR COURTESY LAMP LOAD SHED
8Wa - 80 - 76 8W-80 CONNECTOR PIN-OUTSKJ

LICENSE LAMP (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
2 Z235 18BK GROUND
LICENSE LAMP (EXCEPT BUILT-UP-EXPORT) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BR/YL FUSED PARK LAMP RELAY OUTPUT
2 Z151 18BK/WT GROUND
LINE PRESSURE SENSOR (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 Z112 18BK GROUND
2 T39 18GY/LB 5 VOLT SUPPLY
3 T38 18VT/TN LINE PRESSURE SENSOR SIGNAL
4- -
LOW NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z141 18BK GROUND
MANIFOLD ABSOLUTE PRESSURE SENSOR - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K1 18DG/RD MANIFOLD ABOLUTE PRESSURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-77
