2002 JEEP LIBERTY relay

BLEND DOOR ACTUATOR - WHITE 4 WAY
CAV CIRCUIT FUNCTION
1 Z12 18BK/TN GROUND
2 C35 20DG/YL MODE DOOR DRIVER (A)
3 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
4- -
BLOWER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
2 A111 12RD/LB BLOWER MOTOR RELAY OUTPUT
BLOWER MOTOR RESISTOR BLOCK - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
3 C6 12LB BLOWER MOTOR M2 DRIVER
4 C5 14LG BLOWER MOTOR M1 DRIVER
5 C4 14TN BLOWER MOTOR LOW DRIVER
6- -
7- -
8- -
9- -
10 - -
BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 Z103 16BK/OR GROUND
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4 G75 20TN DRIVER DOOR AJAR SWITCH SENSE
5 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
6 G70 20BR/TN (EXCEPT BASE) HOOD AJAR SWITCH SENSE
7 G78 20TN/BK TAILGATE AJAR SWITCH SENSE
8 G26 20LB KEY-IN IGNITION SWITCH SENSE
9 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
10 M3 20PK/DB REAR COURTESY LAMP CONTROL
11 V10 18BR WASHER PUMP DRIVER
12 L91 20DB/PK HAZARD LAMP CONTROL
13 V21 20DB/RD REAR WIPER ON DRIVER
14 Z231 16BK/WT SIGNAL GROUND
15 D25 18YL/VT/WT PCI BUS
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-9

C317 (EXCEPT BUILT-UP-EXPORT) - LT. GRAY
(REAR LIGHTING SIDE)
CAV CIRCUIT
1 L77 18BK/YL
2 Z151 18BK/WT
C317 (EXCEPT BUILT-UP-EXPORT) - LT. GRAY
(LICENSE LAMP SIDE)
CAV CIRCUIT
1 L77 18BR/YL
2 Z151 18BK/WT
CABIN HEATER (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C151 18DB/WT CABIN HEATER RELAY OUTPUT
2 Z186 12BK/OR GROUND
CAMSHAFT POSITION SENSOR (2.4L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K7 18OR 5 VOLT SUPPLY
2 K4 18BK/LB SENSOR GROUND
3 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
CAMSHAFT POSITION SENSOR (3.7L) - LT. GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-47

CAMSHAFT POSITION SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 K944 20BK/LB CAMSHAFT POSITION SENSOR GROUND
2 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
3 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
CAPACITOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
2 Z55 14BK/WT GROUND
CARGO LAMP (EXCEPT BASE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M3 20PK/DB REAR COURTESY LAMP CONTROL
3 M2 20YL COURTESY LAMP DRIVER
CD CHANGER - GREEN 12 WAY
CAV CIRCUIT FUNCTION
1 X41 20WT/DG AUDIO OUT LEFT
2- -
3- -
4 Z17 20BK GROUND
5 X112 20RD IGNITION SWITCH OUTPUT
6 X160 20YL B(+)
7 X40 20WT/RD AUDIO OUT RIGHT
8 Z30 20WT/BK GROUND
9- -
10 - -
11 Z9 20BK/DB GROUND
12 D25 20YL/VT PCI BUS
8Wa - 80 - 48 8W-80 CONNECTOR PIN-OUTSKJ

CENTER HIGH MOUNTED STOP LAMP - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
2 Z309 18BK GROUND
CIGAR LIGHTER - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F30 16RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2- -
3 Z3 16BK/OR GROUND
CLOCKSPRING C1 - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 X3 20BK/RD HORN RELAY CONTROL
3 X20 20RD/BK (PREMIUM) RADIO CONTROL MUX
4 X10 20RD/DB (PREMIUM) RADIO CONTROL MUX RETURN
5 K4 20BK/LB SENSOR GROUND
6 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
CLOCKSPRING C2 - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER SQUIB 1 LINE 2
2 R43 18BK/LB DRIVER SQUIB 1 LINE 1
3 R63 18TN/LB DRIVER SQUIB 2 LINE 2
4 R61 18OR/LB DRIVER SQUIB 2 LINE 1
CLOCKSPRING C3 - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 X3 20BK/RD HORN RELAY CONTROL
3 X20 20RD/BK (PREMIUM) RADIO CONTROL MUX
4 X10 20RD/DB (PREMIUM) RADIO CONTROL MUX RETURN
5 K4 20BK/LB (EXCEPT BASE) SENSOR GROUND
6 V37 20RD/LG (EXCEPT BASE) SPEED CONTROL SWITCH SIGNAL
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-49

CLUTCH INTERLOCK SWITCH (M/T) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T141 18YL/RD CLUTCH SWITCH OVERRIDE RELAY OUTPUT
2 F45 18YL/BR FUSED IGNITION SWITCH OUTPUT (START)
COIL ON PLUG NO. 1 (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K91 14TN/RD COIL ON PLUG DRIVER NO.1
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 2 (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K92 14TN/PK COIL ON PLUG DRIVER NO. 2
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 3 (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K93 14TN/OR COIL ON PLUG DRIVER NO. 3
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 4 (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K94 14TN/LG COIL ON PLUG DRIVER NO. 4
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
8Wa - 80 - 50 8W-80 CONNECTOR PIN-OUTSKJ

COIL ON PLUG NO. 5 (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K95 14TN/DG COIL ON PLUG DRIVER NO. 5
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL ON PLUG NO. 6 (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K96 14TN/LB COIL ON PLUG DRIVER NO. 6
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3- -
COIL RAIL (2.4L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K17 18DB/TN IGNITION COIL DRIVER NO. 2
2 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
3 K19 18BK/GY IGNITION COIL DRIVER NO. 1
COMPASS MINI-TRIP COMPUTER (PREMIUM) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 D25 20YL/VT PCI BUS
3 M1 20PK FUSED B(+)
4 Z2 20BK/LG CLEAN GROUND
5 F87 20WT/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
6- -
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-51

EGR SOLENOID (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K35 18GY/YL EGR SOLENOID CONTROL
ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAY
CAV CIRCUIT FUNCTION
1 Z108 14BK/DG GROUND
2 Z108 14BK/DG GROUND
3 K20 18DG GENERATOR FIELD CONTROL
4 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
5 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
6- -
7 D25 20VT/YL PCI BUS
8 K944 20BK/LB CAMSHAFT POSITION SENSOR GROUND
9 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
10 - -
11 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
12 - -
13 K78 20GY FUEL PRESSURE SENSOR SIGNAL
14 - -
15 K81 20VT/TN ACCELERATOR PEDAL POSITION SENSOR SIGNAL
16 K80 20BK/VT FUEL PRESSURE SENSOR GROUND
17 - -
18 - -
19 F92 20YL/BR BATTERY SENSE (+)
20 Z109 20BK/DB BATTERY SENSE (-)
21 K4 20BK/LB SENSOR GROUND
22 F1 20DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
23 K6 20VT/WT SENSOR REFERENCE VOLTAGE B
24 K3 20LB/BK CRANKSHAFT POSITION SENSOR SIGNAL 2
25 - -
26 - -
27 - -
28 - -
29 K77 20BR/WT TRANSFER CASE POSITION SENSOR INPUT
30 G60 20GY/YL ENGINE OIL PRESSURE SENSOR SIGNAL
31 G123 20DG/WT WATER IN FUEL SENSOR SIGNAL
32 K118 20PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
33 - -
34 K255 20WT/DG ACCELERATOR PEDAL POSITION SENSOR GROUND
35 K852 20VT/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
36 - -
37 - -
38 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
39 K226 20DB/WT FUEL LEVEL SENSOR SIGNAL
40 K2 20TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
41 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
42 Y101 20BK/OR CRANKSHAFT POSITION SENSOR SHIELD
43 K24 20GY/BK CRANKSHAFT POSITION SENSOR SIGNAL 1
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-55

ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAY
CAV CIRCUIT FUNCTION
44 - -
45 - -
46 - -
47 L50 20WT/TN BRAKE LAMP SWITCH OUTPUT
48 K29 20WT/PK BRAKE SWITCH SENSE
49 - -
50 - -
51 - -
52 - -
53 - -
54 - -
55 B22 20DG/YL VEHICLE SPEED SIGNAL
56 - -
57 - -
58 - -
59 - -
60 K7 20OR FUEL PRESSURE SENSOR 5 VOLT SUPPLY
61 K51 20DB/YL AUTO SHUT DOWN RELAY CONTROL
62 - -
63 - -
64 K151 20WT LOW IDLE POSITION SWITCH SENSE
65 - -
66 - -
67 - -
68 - -
69 C13 20DG A/C COMPRESSOR CLUTCH RELAY CONTROL
70 - -
71 - -
72 K236 20GY/PK GLOW PLUG RELAY RELAY NO. 2 CONTROL
73 - -
74 K90 20TN CLUTCH SWITCH OVERRIDE RELAY CONTROL
75 K132 20DG/LB CABIN HEATER RELAY CONTROL
76 - -
77 K152 20WT GLOW PLUG RELAY NO. 1 CONTROL
78 - -
79 - -
80 K46 20OR/BK FUEL PRESSURE SOLENOID CONTROL
81 K46 20OR/BK FUEL PRESSURE SOLENOID CONTROL
ENGINE CONTROL MODULE C2 (DIESEL) - BLACK 40 WAY
CAV CIRCUIT FUNCTION
82 D21 20PK SCI TRANSMIT
83 - -
84 - -
85 - -
86 - -
87 - -
88 - -
89 K35 20GY/YL EGR SOLENOID CONTROL
90 - -
91 - -
92 - -
93 - -
8Wa - 80 - 56 8W-80 CONNECTOR PIN-OUTSKJ
