2002 JEEP LIBERTY headlamp

C107 - BLACK (FRONT END LIGHTING SIDE)
CAV CIRCUIT
6 L62 18BR/RD
7-
8 L39 18LB (FOG LAMPS)
9-
10 L63 18DG/RD
C108 (GAS) - GRAY (BATTERY SIDE)
CAV CIRCUIT
1 K52 18PK/BK
2 K20 18DG
3 K125 18WT/DB
4 T40 12BR
5 F1 18DB
6-
C108 (GAS) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 K52 18PK/BK
2 K20 18DG
3 K125 18WT/DB
4 T40 12BR
5 F1 18DB
6-
C110 (2.4L) - BLACK (ENGINE TO HEADLAMP
AND DASH SIDE)
CAV CIRCUIT
1 F142 18OR/DG
2 C3 18DB/BK
3 Z246 18BK/GY
4 K11 18WT/DB
5 K12 18TN
6 K13 18YL/WT
7 K14 18LB/BR
8 K44 18TN/YL
9 K4 18BK/LB
10 -
8Wa - 80 - 24 8W-80 CONNECTOR PIN-OUTSKJ

C110 (2.4L) - BLACK (ENGINE TO FUEL INJEC-
TORS SIDE)
CAV CIRCUIT
1 F142 18OR/DG
2 C3 18DB/BK
3 Z246 18BK/GY
4 K11 18WT/DB
5 K12 18TN
6 K13 18YL/WT
7 K14 18LB/BR
8 K44 18TN/YL
9 K4 18BK/LB
10 -
C111 (DIESEL) - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 K51 20DB/YL
2 K118 20PK/YL
3 C13 20DG
4-
5 K226 20DB/WT
6 V37 20RD/LG
7 K35 20GY/YL
8 G18 18PK/BK
9 K29 20WT/PK
10 K236 20GY/PK
11 C151 18DB/WT
12 T40 12BR
13 F92 20YL/BR
14 -
C111 (DIESEL) - LT. GRAY (HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 K51 18DB/YL
2 K118 18PK/YL
3 C13 18DG
4-
5 K226 18DB/WT
6 V37 18RD/LG
7 K35 18GY/YL
8 G18 18PK/BK
9 K29 18WT/PK
10 K236 18GY/PK
11 C151 18DB/WT
12 T40 12BR
13 F92 18YL/BR
14 T141 14YL/RD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-25

C112 (GAS) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 K42 18DB/LB (3.7L)
2 K4 18BK/LB (3.7L)
3 Z252 18BK/GY
4 K142 18GY/BK (3.7L)
5 K4 18BK/LB (3.7L)
6 Z252 18BK/GY
7-
8-
9-
10 A142 14DG/OR
C112 (GAS) - BLACK (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 K42 18DB/LB
2 K4 18BK/LB
3 Z252 18BK/GY
4 K142 18GY/BK
5 K4 18BK/LB
6 Z252 18BK/GY
7-
8-
9-
10 A142 14DG/OR
C113 (DIESEL) - LT.GRAY (GLOW PLUG SIDE)
CAV CIRCUIT
1 K154 10GY
2 K104 10RD/WT
C113 (DIESEL) - LT.GRAY (BATTERY SIDE)
CAV CIRCUIT
1 K154 10GY
2 K104 10RD/WT
8Wa - 80 - 26 8W-80 CONNECTOR PIN-OUTSKJ

HEADLAMP LEVELING SWITCH (BUILT-UP-EXPORT)-4WAY
CAV CIRCUIT FUNCTION
1 L13 18BR/YL HEADLAMP ADJUST SIGNAL
2 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
3 Z12 18BK/TN GROUND
4- -
HEATED SEAT MODULE (HIGHLINE) - GREEN 14 WAY
CAV CIRCUIT FUNCTION
1 P133 20TN/DG LEFT SEAT HEATER SWITCH MUX
2 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
3 F98 16RD/WT PASSENGER HEATED SEAT FEED
4 A3 16RD/WT FUSED B(+)
5 F99 16RD/YL DRIVER HEATED SEAT FEED
6 A3 16RD/WT FUSED B(+)
7 P142 20TN/DB PASSENGER HEATED SEAT TEMPERATURE SENSOR
GROUND
8 P141 20TN/LB DRIVER HEATED SEAT TEMPERATURE SENSOR
GROUND
9 P134 20TN/LG RIGHT SEAT HEATER SWITCH MUX
10 P138 20VT/LG RIGHT SEAT LOW HEAT LED DRIVER
11 P140 20VT/BK RIGHT SEAT HIGH HEAT LED DRIVER
12 P137 20VT/DG LEFT SEAT LOW HEAT LED DRIVER
13 Z238 16BK/WT GROUND
14 P139 20VT/WT LEFT SEAT HIGH HEAT LED DRIVER
HIGH NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z141 18BK GROUND
HOOD AJAR SWITCH (EXCEPT BASE)-2WAY
CAV CIRCUIT FUNCTION
1 G70 18BR/TN HOOD AJAR SWITCH SENSE
2 Z142 18BK/WT GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-63

LEFT FRONT WHEEL SPEED SENSOR (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B9 18RD LEFT FRONT WHEEL SPEED SENSOR 12 VOLT SUP-
PLY
2 B8 18RD/DB LEFT FRONT WHEEL SPEED SENSOR SIGNAL
LEFT HEADLAMP (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 L33 18LG/BR FUSED LEFT HIGH BEAM OUTPUT
2 L43 18VT FUSED LEFT LOW BEAM OUTPUT
3 Z141 18BK GROUND
LEFT HEADLAMP (EXCEPT BUILT-UP-EXPORT) - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L43 18VT FUSED LEFT LOW BEAM OUTPUT
B Z141 18BK GROUND
C L33 18LG/BR FUSED LEFT HIGH BEAM OUTPUT
LEFT HEATED SEAT ASSEMBLY (HIGHLINE) - LT. GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 F99 16RD/YL DRIVER HEATED SEAT FEED
2 Z238 16BK/WT GROUND
3 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
4 P141 20TN/LB DRIVER HEATED SEAT TEMPERATURE SENSOR
GROUND
LEFT HEATED SEAT SWITCH (HIGHLINE) - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 P139 20VT/WT LEFT SEAT HIGH HEAT LED DRIVER
3 P133 20TN/DG LEFT SEAT HEATER SWITCH MUX
4 P137 20VT/DG LEFT SEAT LOW HEAT LED DRIVER
5 Z238 20BK/WT GROUND
6- -
7- -
8- -
8Wa - 80 - 72 8W-80 CONNECTOR PIN-OUTSKJ

LEFT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X53 18DG (BASE) LEFT FRONT SPEAKER (+)
1 X83 18YL/RD (PREMIUM) AMPLIFIED HIGH LEFT FRONT SPEAKER (+)
2 X55 18BR/RD (BASE) LEFT FRONT SPEAKER (-)
2 X81 18YL/BK (PREMIUM) AMPLIFIED HIGH LEFT FRONT SPEAKER (-)
LEFT LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z141 18BK GROUND
2 L13 18BR/YL HEADLAMP ADJUST SIGNAL
3 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
LEFT POSITION LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
2 Z141 18BK GROUND
LEFT POWER MIRROR (EXCEPT BASE) - WHITE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 20YL/DG LEFT MIRROR UP DRIVER
2 P76 20OR/YL MIRROR COMMON DRIVER
3 P75 20LB/WT LEFT MIRROR LEFT DRIVER
4- -
5 C16 20LB/YL FUSED DEFOGGER RELAY OUTPUT
6 Z350 20BK/LG GROUND
7 P99 20GY (WITH FOLD) FOLDING MIRROR FEED
8 P110 20YL (WITH FOLD) FOLDING MIRROR RETURN
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-73

MULTI-FUNCTION SWITCH C1 - GRAY 10 WAY
CAV CIRCUIT FUNCTION
1 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
2 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 L305 20LB/WT LEFT TURN SWITCH SENSE
7 L309 20LG/WT HIGH BEAM RELAY CONTROL
8 Z12 18BK/TN GROUND
9 L324 20WT/LG HIGH BEAM SWITCH SENSE
10 L302 20LB/YL RIGHT TURN SWITCH SENSE
MULTI-FUNCTION SWITCH C2 - GRAY 8 WAY
CAV CIRCUIT FUNCTION
1 V21 20DB/RD REAR WIPER ON DRIVER
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 V20 18BK/WT WASHER MOTOR SENSE
4 V52 20DG/RD FRONT WIPER SWITCH MUX
5 F88 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
6- -
7 V10 18BR WASHER PUMP DRIVER
8- -
OUTPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
OVERHEAD MAP/READING LAMP (EXCEPT BASE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL REAR COURTESY LAMP CONTROL
3 M20 20BR COURTESY LAMPS LOAD SHEED
8Wa - 80 - 78 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT FRONT PARK/ TURN SIGNAL LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L62 18BR/RD RIGHT TURN SIGNAL
2 L78 18DG/YL (EXCEPT BUILT-UP-EX-
PORT)FUSED PARK LAMP RELAY OUTPUT
3 Z142 18BK/WT GROUND
RIGHT FRONT POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q22 16VT/WT RIGHT FRONT WINDOW DRIVER DOWN
2 Q12 16BR RIGHT FRONT WINDOW DRIVER UP
RIGHT FRONT WHEEL SPEED SENSOR (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
2 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
RIGHT HEADLAMP (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
2 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
3 Z142 18BK/WT GROUND
RIGHT HEADLAMP (EXCEPT BUILT-UP-EXPORT) - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
B Z142 18BK/WT GROUND
C L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-89
