2002 JEEP LIBERTY headlamp

C100 (RHD) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 L43 18VT
2 F1 18DB
3 M1 18PK
4 B22 18DG/YL
5 L44 18VT/RD
6 V16 18VT/YL
7 V55 16TN/RD
8 G32 18DB/OR
9 D20 18LG
10 D25 18YL/VT
11 V14 18RD/VT
12 L13 18BR/YL
13 G70 18BR/TN
14 G11 18WT/BK
15 K4 18BK/LB
16 L50 18WT/TN (ABS)
17 L62 18BR/RD
18 L63 18DG/RD
19 V30 18DB/RD
20 D32 18LG
21 V32 18YL/RD
22 G29 18BK/TN
23 X2 18DG/RD
24 F15 18DB/WT
25 -
26 D24 18WT/DG (ABS)
27 B1 18YL/DB (EXCEPT ABS)
27 B12 18DG/OR (ABS)
28 R46 18BR/LB
29 R48 18TN
30 R47 18DB/LB
31 R49 18LB
32 -
33 -
34 -
35 B2 18YL (EXCEPT ABS)
35 F512 18PK/OR (ABS)
36 -
37 Z252 18BK/GY
38 Z252 18BK/GY
39 V10 18BR
40 -
41 T6 18VT/WT
42 V37 18RD/LG
43 V20 18BK/WT
44 K29 18WT/PK
45 D25 18YL/VT (ABS)
45 D25 18YL/VT (EXCEPT ABS)
46 -
47 X75 18DG
48 L10 18BR/LG
49 D21 18PK
50 F22 18DB/PK (ABS)
8Wa - 80 - 16 8W-80 CONNECTOR PIN-OUTSKJ

C100 (RHD) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
51 L33 18LG/BR
52 L39 18LB
53 L78 18DG/YL
54 F20 18WT
55 V6 16DB/YL
56 G31 18VT/LG
57 -
58 L34 18RD/OR
59 L77 18BK/YL
60 A32 14RD/DB (A/T)
61 A41 12YL
62 A21 12RD/DB (M/T)
63 A1 12RD
64 A111 12RD/LB
65 A12 10RD/TN
66 A13 10PK/WT
67 A18 10PK
68 A7 10RD/BK
69 A2 12PK/BK
70 A25 12DB
71 A4 12BK/PK
72 A99 14RD/VT
C101 (2.4L) - BLACK (ENGINE TO HEADLAMP
AND DASH SIDE)
CAV CIRCUIT
1 K59 18VT/BK
2 K40 18BR/WT
3 K60 18YL/BK
4 K39 18GY/RD
5 K21 18BK/RD
6 K2 18TN/BK
7 K1 18DG/RD
8 K22 18OR/DB
9 K6 18VT/WT
10 G60 18GY/YL
11 K24 18GY/BK
12 K7 18OR
13 -
14 -
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-17

C101 (2.4L) - BLACK (ENGINE TO FUEL INJEC-
TOR SIDE)
CAV CIRCUIT
1 K59 18VT/BK
2 K40 18BR/WT
3 K60 18YL/BK
4 K39 18GY/RD
5 K21 18BK/RD
6 K2 18TN/BK
7 K1 18DG/RD
8 K22 18OR/DB
9 K6 18VT/WT
10 G60 18GY/YL
11 K24 18GY/BK
12 K7 18OR
13 -
14 -
C102 (RHD) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 K226 18DB/WT
2 K512 18PK/OR
3 A141 16DG/WT (GAS)
4 B1 18YL/DB
5 B2 18YL
6 K4 18BK/LB
7 B12 18DG/OR
8 K125 18WT/DB (GAS)
9 K107 18OR (GAS)
10 K106 18WT/DG (GAS)
C102 (RHD) - GRAY (FRONT BODY SIDE)
CAV CIRCUIT
1 K226 18DB/WT
2 F512 18PK/OR
3 A141 16DG/WT
4 B1 18YL/DB
5 B2 18YL
6 K4 18BK/LB
7 B12 18DG/OR
8 K125 18WT/DB
9 K107 18OR
10 K105 18WT/DG
8Wa - 80 - 18 8W-80 CONNECTOR PIN-OUTSKJ

C103 (GAS) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 F142 18OR/DG
2-
3 K299 18BR/WT
4-
5 K173 18LG
6-
7-
8-
9 K99 18BR/OR
10 -
C103 (GAS) - BLACK (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 F142 18OR/DG
2-
3 K299 18BR/WT
4-
5 K173 18LG
6-
7-
8-
9 K99 18BR/OR
10 -
C104 (DIESEL) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 K90 20TN
2 K132 20DG/LB
3 K152 20WT
4 C3 18DB/BK
5-
6-
7 D21 20PK
8 D25 20VT/YL
9 F15 18DB/WT
10 -
11 F1 20DB
12 L50 20WT/TN
13 -
14 -
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-19

C104 (DIESEL) - BLACK (HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
1 K90 18TN
2 K132 18DG/LB
3 K152 18WT
4 C3 18DB/BK
5-
6-
7-
8-
9 F15 18DB/WT
10 -
11 F1 18DB
12 L50 18WT/TN
13 -
14 -
C104 (GAS) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 A14 16RD/WT
2 F18 18LG/BK (3.7L)
3-
4 C3 18DB/BK
5-
6 D20 18LG (A/T)
7 D21 18PK (A/T)
8 D25 18VT/YL (A/T)
9 F15 18DB/WT
10 F45 18YL/BR (A/T)
11 F1 18DB
12 T10 18YL/DG (A/T)
13 K20 18DG
14 T6 18OR/WT (A/T)
C104 (GAS) - BLACK (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 A14 16RD/WT (GAS)
2 F18 18LG/BK (GAS)
3-
4 C3 18DB/BK
5-
6 D20 18LG
7 D21 18PK
8 D25 18YL/VT
9 F15 18DB/WT
8Wa - 80 - 20 8W-80 CONNECTOR PIN-OUTSKJ

C104 (GAS) - BLACK (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
10 F45 18YL/BR
11 F1 18DB
12 T10 18YL/DG
13 K20 18DG
14 T6 18VT/WT
C105 (DIESEL) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1 B22 20DG/YL
2 K4 18BK/LB
3 L10 18BR/LG
4 C21 18DB/OR
5 A71 18DG/RD
6-
7-
8-
9 A142 14DG/OR
10 -
11 -
12 A93 16RD/BK
13 Z252 18BK/GY
14 Z252 18BK/GY
C105 (DIESEL) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 B22 18DG/YL
2 K4 18BK/LB
3 L10 18BR/LG
4 C21 18DB/OR
5 A71 18DG/RD
6-
7-
8-
9 A142 16DG/OR
10 T138 18GY/LB
11 -
12 A93 16RD/BK
13 Z252 18BK/GY
14 Z252 18BK/GY
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-21

C105 (GAS) - GRAY (ENGINE SIDE)
CAV CIRCUIT
1-
2 K4 18BK/LB
3 L10 18BR/LG
4-
5 A71 18DG/RD
6 T16 14RD (A/T)
7 T41 18BK/WT (A/T)
8 K30 18PK (A/T)
9-
10 T141 18YL/RD (M/T)
11 -
12 A30 14RD/WT (A/T)
13 -
14 -
C105 (GAS) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1-
2 K4 18BK/LB
3 L10 18BR/LG
4-
5 A71 18DG/RD
6 T16 14RD (A/T)
7 T41 18BK/WT (A/T)
8 K30 18PK (A/T)
9-
10 T141 18YL/RD (M/T)
11 -
12 A30 14RD/WT (A/T)
13 -
14 -
C106 - BLACK (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 G31 18VT/LG
2 G32 18DB/OR
3 L33 18LG/BR
4 L43 18VT
5 L63 18DG/RD
6 L39 18LB
7 L78 18DG/YL
8 Z141 18BK
9 L13 18BR/YL (BUILT-UP-EXPORT))
10 L34 18RD/OR
8Wa - 80 - 22 8W-80 CONNECTOR PIN-OUTSKJ

C106 - BLACK (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
11 L44 18VT/RD
12 L62 18BR/RD
13 L77 18BK/YL
14 Z142 18BK/WT
C106 - BLACK (FRONT END LIGHTING SIDE)
CAV CIRCUIT
1 G31 18VT/LG
2 G32 18DB/OR
3 L33 18LG/BR
4 L43 18VT
5 L63 18DG/RD
6 L39 18LB
7 L78 18DG/YL
8 Z141 18BK
9-
10 L34 18RD/OR
11 L44 18VT/RD
12 L62 18BR/RD
13 L77 18BK/YL
14 Z142 18BK/WT
C107 - BLACK (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 Z141 18BK
2 L77 18BK/YL
3-
4 L78 18DG/YL
5 Z142 18BK/WT
6 L62 18BR/RD
7-
8 L39 18LB
9-
10 L63 18DG/RD
C107 - BLACK (FRONT END LIGHTING SIDE)
CAV CIRCUIT
1 Z141 18BK
2 L77 18BK/YL
3-
4 L78 18DG/YL
5 Z142 18BK/WT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-23
