2002 JEEP GRAND CHEROKEE sensor

OXYGEN SENSOR 2/2 DOWNSTREAM-4WAY
CAV CIRCUIT FUNCTION
1 K200 18VT/OR (4.0L) OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT
1 K200 18BR/WT (4.7L) OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT
2 Z186 18BK GROUND
3 K4 18BK/LB SENSOR GROUND
4 K341 18TN/WT (4.0L) OXYGEN SENSOR 2/2 SIGNAL
4 K341 18PK/WT (4.7L) OXYGEN SENSOR 2/2 SIGNAL
PARK/NEUTRAL POSITION SWITCH (4.0L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L1 18VT/BK BACK-UP LAMP FEED
2 T41 18BK/WT PARK/NEUTRAL POSITION SWITCH SENSE (T41)
3 F22 18WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
PARK/NEUTRAL POSITION SWITCH (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L1 18VT/BK BACK-UP LAMP FEED
2 T41 18BR/YL PARK/NEUTRAL POSITION SWITCH SENSE (T41)
3 F22 18WT/TN FUSED IGNITION SWITCH OUTPUT (RUN)
PASSENGER AIRBAG - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R42 20BK/YL PASSENGER SQUIB 1 LINE 1
2 R44 20DG/YL PASSENGER SQUIB 1 LINE 2
3 R64 20TN/YL PASSENGER SQUIB 2 LINE 1
4 R62 20OR/YL PASSENGER SQUIB 2 LINE 2
PASSENGER BLEND DOOR MOTOR/ACTUATOR (LHD) (AZC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A C96 20WT/DB (LHD) PASSENGER BLEND DOOR DRIVER (B)
B C94 20WT/DG (LHD) PASSENGER BLEND DOOR DRIVER (A)
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 101

PASSENGER DOOR MODULE C2 - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 P95 20OR MIRROR HORIZONTAL DRIVER
2 C118 20BK/WT MIRROR HEATER GROUND
3 P64 20VT MIRROR VERTICAL POSITION SIGNAL
4 P69 20GY MIRROR SENSOR GROUND
5 P65 20DG MIRROR HORIZONTAL POSITION SIGNAL
6 C117 20BK MIRROR HEATER 12 VOLT SUPPLY
7 P91 20WT MIRROR COMMON DRIVER
8 P93 20RD MIRROR VERTICAL DRIVER
9 M21 20PK/DG COURTESY LAMP DRIVER
10 P110 20YL (BUILT-UP-EXPORT) FOLDING MIRROR RETURN
11 P99 20DB (BUILT-UP-EXPORT) FOLDING MIRROR FEED
12 L121 20BK/RD COURTESY LAMP GROUND
PASSENGER FRONT DOOR COURTESY LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 M21 20PK/DG COURTESY LAMP DRIVER
2 L121 20BK/RD COURTESY LAMP GROUND
PASSENGER FRONT POWER WINDOW MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Q22 16VT PASSENGER WINDOW DRIVER (DOWN)
2 Q12 16BR PASSENGER WINDOW DRIVER (UP)
PASSENGER HEATED SEAT BACK (PREMIUM I/III)-3WAY
CAV CIRCUIT FUNCTION
1 P88 16BK/BR HEATED SEAT DRIVER
2 Z5 16BK/VT GROUND
3- -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 103

PASSENGER HEATED SEAT CUSHION (PREMIUM I/III)-4WAY
CAV CIRCUIT FUNCTION
1 P130 16DG/WT PASSENGER SEAT HEATER B(+) DRIVER
2 P88 16BK/BR HEATED SEAT DRIVER
3 P86 20DG/YL PASSENGER SEAT TEMPERATURE SENSOR INPUT
4 P29 20BR/WT SEAT SENSOR 5 VOLT SUPPLY
PASSENGER HEATED SEAT SWITCH - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 P134 20TN/LG PASSENGER SEAT HEATER SWITCH MUX
2 E2 20OR PANEL LAMPS DRIVER
3 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
4- -
5 Z300 20BK GROUND
6 P132 20OR/BK SEAT HEATER SWITCH SENSOR GROUND
PASSENGER LUMBAR MOTOR (MIDLINE/PREMIUM) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 P105 16LG/DG LUMBAR FORWARD SWITCH SENSE
2 P104 16YL/RD LUMBAR REARWARD SWITCH SENSE
PASSENGER LUMBAR SWITCH (MIDLINE/PREMIUM) - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 Z1 16BK GROUND
3 P104 16YL/RD (RHD) LUMBAR REARWARD SWITCH SENSE
3 P105 16LG/DB (LHD) LUMBAR FORWARD SWITCH SENSE
4 P105 16LG/DB (RHD) LUMBAR FORWARD SWITCH SENSE
4 P104 16YL/RD (LHD) LUMBAR REARWARD SWITCH SENSE
5 Z1 16BK GROUND
6 F37 16RD/LB FUSED B(+)
8W - 80 - 104 8W-80 CONNECTOR PIN-OUTWJ

PASSENGER POWER MIRROR - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 C117 20BK MIRROR HEATER 12 VOLT SUPPLY
2 P65 20DG MIRROR HORIZONTAL POSITION SIGNAL
3 P69 2GY MIRROR SENSOR GROUND
4 P64 20VT MIRROR VERTICAL POSITION SIGNAL
5 C118 20BK/WT MIRROR HEATER GROUND
6 P95 20OR MIRROR HORIZONTAL DRIVER
7- -
8 P99 20DB (BUILT-UP-EXPORT) FOLDING MIRROR FEED
9 P110 20YL (BUILT-UP-EXPORT) FOLDING MIRROR RETURN
10 - -
11 P93 20RD MIRROR VERTICAL DRIVER
12 P91 20WT MIRROR COMMON DRIVER
PASSENGER POWER SEAT FRONT RISER MOTOR - RED 2 WAY
CAV CIRCUIT FUNCTION
1 P18 16YL/LG PASSENGER SEAT FRONT UP DRIVER
2 P20 16RD/LG PASSENGER SEAT FRONT DOWN DRIVER
PASSENGER POWER SEAT HORIZONTAL MOTOR - RED 2 WAY
CAV CIRCUIT FUNCTION
1 P16 16RD/YL PASSENGER SEAT HORIZONTAL REARWARD DRIVER
2 P14 16YL/LB PASSENGER SEAT HORIZONTAL FORWARD DRIVER
PASSENGER POWER SEAT REAR RISER MOTOR - RED 2 WAY
CAV CIRCUIT FUNCTION
1 P10 16YL/WT PASSENGER SEAT REAR UP DRIVER
2 P12 16RD/WT PASSENGER SEAT REAR DOWN DRIVER
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 105

PASSENGER SIDE IMPACT SENSOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 R134 20LB/BR PASSENGER SIDE IMPACT SENSOR GROUND
4 R132 20LG/VT PASSENGER SIDE IMPACT SENSOR SIGNAL
POWER AMPLIFIER C1 (PREMIUM RADIO) - WHITE 18 WAY
CAV CIRCUIT FUNCTION
1 D25 18YL/VT PCI BUS
2 F60 16RD/WT FUSED B(+)
3 Z9 16BK GROUND
4- -
5 X58 18DB/OR RIGHT REAR SPEAKER (-)
6 X57 18DG/WT LEFT REAR SPEAKER (-)
7 X56 18DB/PK RIGHT FRONT SPEAKER (-)
8 X55 18BR/RD LEFT FRONT SPEAKER (-)
9- -
10 F60 16RD/WT FUSED B(+)
11 Z9 16BK GROUND
12 - -
13 X64 18BR/WT ENABLE SIGNAL TO AMPLIFIER
14 - -
15 X52 18DB/WT RIGHT REAR SPEAKER (+)
16 X51 18WT/DG LEFT REAR SPEAKER (+)
17 X54 18VT RIGHT FRONT SPEAKER (+)
18 X53 18DG/OR LEFT FRONT SPEAKER (+)
POWER AMPLIFIER C2 (PREMIUM RADIO) - WHITE 12 WAY
CAV CIRCUIT FUNCTION
1 X90 18WT/VT RIGHT REAR DOOR SPEAKER (+)
2 X92 18TN/DG RIGHT REAR DOOR SPEAKER (-)
3 X85 18LG/DG LEFT FRONT DOOR SPEAKER (-)
4 X83 18YL/RD LEFT INSTRUMENT PANEL SPEAKER (+)
5 X84 18OR/GY RIGHT INSTRUMENT PANEL SPEAKER (-)
6 X93 18DG/WT LEFT REAR DOOR SPEAKER (+)
7 X91 18WT/DG LEFT REAR DOOR SPEAKER (-)
8 X87 18LG/RD LEFT FRONT DOOR SPEAKER (+)
9 X80 18LB/BK RIGHT FRONT DOOR SPEAKER (-)
10 X82 18LB/RD RIGHT FRONT DOOR SPEAKER (+)
11 X81 18YL/BK LEFT INSTRUMENT PANEL SPEAKER (-)
12 X86 18OR/RD RIGHT INSTRUMENT PANEL SPEAKER (+)
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 107

POWER CONNECTOR - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 F85 16VT/WT FUSED B(+)
2 Z234 16BK GROUND
POWERTRAIN CONTROL MODULE C1 (GAS) - BLACK 32 WAY
CAV CIRCUIT FUNCTION
1 K93 14TN/OR COIL DRIVER NO. 3
2 F991 18OR/DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
3 K94 14TN/LG (4.7L) COIL DRIVER NO. 4
4 K4 18BK/LB SENSOR GROUND
5 K96 14TN/LB (4.7L) COIL DRIVER NO. 6
6 T41 18BK/WT PARK/NEUTRAL POSITION SWITCH SENSE (T41)
7 K91 14TN/RD COIL DRIVER NO. 1
8 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
9 K98 14LB/RD (4.7L) COIL DRIVER NO. 8
10 K60 18YL/BK IDLE AIR CONTROL NO. 2 DRIVER
11 K40 18BR/WT IDLE AIR CONTROL NO. 3 DRIVER
12 - -
13 - -
14 K77 18LG/BK TRANSFER CASE POSITION SENSOR INPUT
15 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
17 K7 18OR 5 VOLT SUPPLY
18 K44 18TN/YL CAMSHAFT POSITION SENSOR SIGNAL
19 K39 18GY/BK IDLE AIR CONTROL NO. 1 DRIVER
20 K59 18VT/BK IDLE AIR CONTROL NO. 4 DRIVER
21 K95 14TN/DG (4.7L) COIL DRIVER NO. 5
22 A7 14RD/BK FUSED B(+)
23 K22 18OR/RD THROTTLE POSITION SENSOR SIGNAL
24 K41 18BK/DG OXYGEN SENSOR 1/1 SIGNAL
25 K141 18TN/WT OXYGEN SENSOR 1/2 SIGNAL
26 K241 18LG/RD (EXCEPT 4.0L
BUILT-UP-EXPORT)OXYGEN SENSOR 2/1 SIGNAL
27 K1 18DG/RD MAP SENSOR SIGNAL
28 - -
29 K341 18TN/WT (4.0L EXCEPT
BUILT-UP-EXPORT)OXYGEN SENSOR 2/2 SIGNAL
29 K341 18PK/WT (4.7L) OXYGEN SENSOR 2/2 SIGNAL
30 - -
31 Z82 14BK/WT GROUND
32 Z81 14BK/TN GROUND
8W - 80 - 108 8W-80 CONNECTOR PIN-OUTWJ

POWERTRAIN CONTROL MODULE C2 (GAS) - WHITE 32 WAY
CAV CIRCUIT FUNCTION
1 T54 18VT (4.0L) TRANSMISSION TEMPERATURE SENSOR SIGNAL
2 K26 18VT (4.7L) FUEL INJECTOR NO. 7 DRIVER
3- -
4 K11 18WT/DB FUEL INJECTOR NO. 1 DRIVER
5 K13 18YL/WT FUEL INJECTOR NO. 3 DRIVER
6 K38 18GY FUEL INJECTOR NO. 5 DRIVER
7 K97 14BR (4.7L) COIL DRIVER NO. 7
8 K88 18PK (4.0L) GOVERNOR PRESSURE SOLENOID CONTROL
9 K92 14TN/PK COIL DRIVER NO. 2
10 K20 18DG GENERATOR FIELD DRIVER
11 T20 18LB (4.0L) TORQUE CONVERTER CLUTCH SOLENOID CONTROL
12 K58 18BR/DB FUEL INJECTOR NO. 6 DRIVER
13 K28 18GY/LB (4.7L) FUEL INJECTOR NO. 8 DRIVER
14 - -
15 K12 18TN FUEL INJECTOR NO. 2 DRIVER
16 K14 18LB/BR FUEL INJECTOR NO. 4 DRIVER
17 K173 18LG RADIATOR FAN RELAY CONTROL
18 - -
19 C18 18DB A/C PRESSURE SIGNAL
20 - -
21 T60 18BR (4.0L) 3-4 SHIFT SOLENOID CONTROL
22 - -
23 G60 18GY/YL ENGINE OIL PRESSURE SENSOR SIGNAL
24 - -
25 T13 18DB/BK (4.0L) SPEED SENSOR GROUND
26 - -
27 B22 18DG/YL VEHICLE SPEED SENSOR SIGNAL
28 T14 18LG/WT (4.0L) OUTPUT SPEED SENSOR SIGNAL
29 T25 18LG/RD (4.0L) GOVERNOR PRESSURE SENSOR SIGNAL
30 K30 18PK/YL (4.0L) TRANSMISSION CONTROL RELAY CONTROL
31 K6 18VT/BK 5 VOLT SUPPLY
32 - -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 109

POWERTRAIN CONTROL MODULE C3 (GAS) - GRAY 32 WAY
CAV CIRCUIT FUNCTION
1 C13 18DB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
2- -
3 K51 18DB/YL AUTO SHUT DOWN RELAY CONTROL
4 V36 18TN/RD SPEED CONTROL VACUUM SOLENOID CONTROL
5 V35 18LG/RD SPEED CONTROL VENT SOLENOID CONTROL
6- -
7 K42 18DB/LG (4.7L HIGH OUTPUT) KNOCK SENSOR NO. 1 SIGNAL
8 K99 18BR/OR OXYGEN SENSOR 1/1 HEATER CONTROL
9 K512 18RD/YL (EXCEPT 4.0L
BUILT-UP-EXPORT)OXYGEN SENSOR DOWNSTREAM RELAY CONTROL
10 K106 18WT/DG (EXCEPT
BUILT-UP-EXPORT)LEAK DETECTION PUMP SOLENOID CONTROL
11 V32 18OR/DG SPEED CONTROL SUPPLY
12 F42 18DG/LG FUSED AUTO SHUT DOWN RELAY OUTPUT
13 T10 18YL/DG (4.7L RHD) TORQUE MANAGEMENT REQUEST SENSE
13 T6 18OR/WT (4.0L LHD) OVERDRIVE OFF SWITCH SENSE
13 T10 18DG/LG (4.7L LHD) TORQUE MANAGEMENT REQUEST SENSE
13 T6 18OR/BK (4.0L RHD) OVERDRIVE OFF SWITCH SENSE
14 K107 18OR/PK (EXCEPT
BUILT-UP-EXPORT)LEAK DETECTION PUMP SWITCH SENSE
15 K25 18VT/LG BATTERY TEMPERATURE SENSOR SIGNAL
16 K299 18BR/WT OXYGEN SENSOR 1/2 HEATER CONTROL
17 - -
18 K142 18GY/BK (4.7L HIGH OUTPUT) KNOCK SENSOR NO. 2 SIGNAL
19 K31 18BR FUEL PUMP RELAY CONTROL
20 K52 18PK/BK DUTY CYCLE EVAP/PURGE SOLENOID CONTROL
21 - -
22 - -
23 - -
24 K29 18WT/PK SECONDARY BRAKE SWITCH SIGNAL
25 K125 18WT/DB GENERATOR SOURCE
26 K226 18LB/YL FUEL LEVEL SENSOR SIGNAL
27 D21 18PK SCI TRANSMIT
28 - -
29 D32 18LG (LHD) SCI RECEIVE
29 D32 18LG/DG (RHD) SCI RECEIVE
30 D25 18VT/YL PCI BUS
31 - -
32 V37 18RD/LG SPEED CONTROL SWITCH SIGNAL
RADIATOR FAN MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C23 12DG RADIATOR FAN RELAY OUTPUT
2 Z4 12BK/PK GROUND
8W - 80 - 110 8W-80 CONNECTOR PIN-OUTWJ
