2002 JEEP GRAND CHEROKEE sensor

Component Page
RIGHT FRONT WHEEL SPEED
SENSOR....................... 8W-80-115
RIGHT HEADLAMP LEVELING MOTOR
(BUILT-UP-EXPORT)............. 8W-80-115
RIGHT HIGH BEAM HEADLAMP..... 8W-80-116
RIGHT INSTRUMENT PANEL
SPEAKER...................... 8W-80-116
RIGHT LIFTGATE AJAR SWITCH..... 8W-80-116
RIGHT LOW BEAM HEADLAMP..... 8W-80-116
RIGHT MULTI-FUNCTION SWITCH . . . 8W-80-116
RIGHT REAR DOOR LOCK
MOTOR/AJAR SWITCH........... 8W-80-117
RIGHT REAR DOOR SPEAKER....... 8W-80-117
RIGHT REAR LAMP ASSEMBLY...... 8W-80-117
RIGHT REAR WHEEL SPEED
SENSOR....................... 8W-80-117
RIGHT REMOTE RADIO SWITCH.... 8W-80-117
RIGHT SIDE REPEATER LAMP
(BUILT-UP-EXPORT)............. 8W-80-118
RIGHT VISOR/VANITY LAMP........ 8W-80-118
SEAT BELT SWITCH............... 8W-80-118
SEAT MODULE C1 (PREMIUM)...... 8W-80-118
SEAT MODULE C2 (PREMIUM)...... 8W-80-119
SENTRY KEY IMMOBILIZER
MODULE...................... 8W-80-119
SHIFTER ASSEMBLY
(C201 DIESEL).................. 8W-80-119
SHIFTER ASSEMBLY (GAS)......... 8W-80-120
SHIFTER ASSEMBLY C1 (DIESEL).... 8W-80-120
SHIFTER ASSEMBLY C2 (DIESEL).... 8W-80-120
SIREN (BUILT-UP-EXPORT)......... 8W-80-120
SPEED CONTROL SWITCH NO. 1.... 8W-80-120
SPEED CONTROL SWITCH NO. 2.... 8W-80-121
SUNROOF CONTROL MODULE...... 8W-80-121
SUNROOF MOTOR C1.............. 8W-80-121
SUNROOF MOTOR C2.............. 8W-80-121
SUNROOF SWITCH................ 8W-80-121Component Page
TEMPERATURE VALVE
ACTUATOR (MTC)............... 8W-80-122
THROTTLE POSITION
SENSOR (4.0L).................. 8W-80-122
THROTTLE POSITION
SENSOR (4.7L).................. 8W-80-122
TRAILER TOW BRAKE
LAMP RELAY................... 8W-80-122
TRAILER TOW CIRCUIT
BREAKER...................... 8W-80-122
TRAILER TOW CONNECTOR........ 8W-80-123
TRAILER TOW LEFT TURN
RELAY........................ 8W-80-123
TRAILER TOW RIGHT TURN
RELAY........................ 8W-80-123
TRANSFER CASE POSITION
SENSOR....................... 8W-80-123
TRANSMISSION CONTROL
MODULE (4.7L)................. 8W-80-124
TRANSMISSION CONTROL
MODULE C1 (DIESEL)........... 8W-80-125
TRANSMISSION CONTROL
MODULE C2 (DIESEL)........... 8W-80-125
TRANSMISSION SOLENOID (4.0L).... 8W-80-125
TRANSMISSION SOLENOID
ASSEMBLY (DIESEL)............ 8W-80-126
TRANSMISSION SOLENOID/TRS
ASSEMBLY (4.7L)................ 8W-80-126
UNDERHOOD LAMP............... 8W-80-126
VEHICLE INFORMATION CENTER . . . 8W-80-127
VISCOUS/CABIN HEATER
(DIESEL)...................... 8W-80-127
WASHER FLUID LEVEL SWITCH.... 8W-80-127
WASTEGATE SOLENOID
(DIESEL)...................... 8W-80-127
WATER IN FUEL SENSOR
(DIESEL)...................... 8W-80-127
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 5

A/C COMPRESSOR CLUTCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C2 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z18 18BK GROUND
A/C PRESSURE TRANSDUCER - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K6 18VT/WT (DIESEL) SENSOR REFERENCE VOLTAGE B
2 K6 18VT/BK (GAS) 5 VOLT SUPPLY
3 C18 18DB A/C PRESSURE SIGNAL
4- -
ACCELERATOR PEDAL POSITION SENSOR (DIESEL) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 F855 18BR/YL SENSOR REFERENCE VOLTAGE A
3 K22 14RD/DB ACCELERATOR PEDAL POSITION SENSOR 2 SIGNAL
4- -
5- -
6 K225 18BK ACCELERATOR PEDAL POSITION SENSOR 2 GROUND
7 K81 20DB/DG ACCELERATOR PEDAL POSITION SENSOR 1 SIGNAL
8 K255 20WT/DG ACCELERATOR PEDAL POSITION SENSOR 1 GROUND
9- -
10 Y43 20WT/VT ACCELERATOR PEDAL POSITION SENSOR 1 5-VOLT
SUPPLY
ADJUSTABLE PEDALS MODULE (EXCEPT BUILT-UP-EXPORT) - GREEN 14 WAY
CAV CIRCUIT FUNCTION
1 Y151 20LG/BR ADJUSTABLE PEDALS SWITCH SENSE (FORWARD)
2 Y152 20LG/OR ADJUSTABLE PEDALS SWITCH SENSE (REARWARD)
3 Q110 16OR/VT ADJUSTABLE PEDALS MOTOR (FORWARD)
4 F72 16RD/YL FUSED B(+)
5- -
6 Q111 16OR/GY ADJUSTABLE PEDALS MOTOR (REARWARD)
7 Q113 20OR/DB (MEMORY) PEDAL POSITION SENSOR FEED
8 Q112 20OR/YL (MEMORY) PEDAL POSITION SENSOR SENSE
9 Q114 20OR/TN (MEMORY) PEDAL POSITION SENSOR RETURN
10 Z151 16BK GROUND
11 Z155 20BK/OR GROUND
12 L1 18WT/BR BACK-UP LAMP FEED
13 D25 20VT/YL PCI BUS
14 Y153 16DB/RD ADJUSTABLE PEDALS SWITCH FEED
8W - 80 - 6 8W-80 CONNECTOR PIN-OUTWJ

ADJUSTABLE PEDALS MOTOR/SENSOR ASSEMBLY (EXCEPT BUILT-UP-EXPORT)-6WAY
CAV CIRCUIT FUNCTION
1 Q113 20OR/DB PEDAL POSITION SENSOR FEED
2 Q112 20OR/YL PEDAL POSITION SENSOR SENSE
3 Q114 20OR/TN PEDAL POSITION SENSOR RETURN
4- -
5 Q111 16OR/GY AJDUSTABLE PEDALS MOTOR (REARWARD)
6 Q110 16OR/VT ADJUSTABLE PEDALS MOTOR (FORWARD)
ADJUSTABLE PEDALS SWITCH (EXCEPT BUILT-UP-EXPORT) - WHITE 3 WAY
CAV CIRCUIT FUNCTION
1 Y153 20BD/RD ADJUSTABLE PEDALS SWITCH FEED
2 Y152 20LG/OR ADJUSTABLE PEDALS SWITCH SENSE (REARWARD)
3 Y151 20LG/BR ADJUSTABLE PEDALS SWITCH SENSE (FORWARD)
AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 32 WAY
CAV CIRCUIT FUNCTION
1 R72 20LB/WT (SIDE AIRBAGS) PASSENGER CURTAIN SQUIB LINE 2
2 R74 20LB/YL (SIDE AIRBAGS) PASSENGER CURTAIN SQUIB LINE 1
3- -
4- -
5- -
6- -
7- -
8- -
9 R58 20GY PASSENGER SEAT BELT SWITCH SENSE
10 R60 20VT PASSENGER SEAT BELT SWITCH GROUND
11 - -
12 - -
13 - -
14 - -
15 R132 20LG/VT (SIDE AIRBAGS) PASSENGER SIDE IMPACT SENSOR SIGNAL
16 R134 20LB/BR (SIDE AIRBAGS) PASSENGER SIDE IMPACT SENSOR GROUND
17 R131 20LG/YL (SIDE AIRBAGS) DRIVER SIDE IMPACT SENSOR SIGNAL
18 R133 20LB/DG (SIDE AIRBAGS) DRIVER SIDE IMPACT SENSOR GROUND
19 - -
20 - -
21 - -
22 - -
23 R59 20LB DRIVER SEAT BELT SWITCH GROUND
24 R57 20DG DRIVER SEAT BELT SWITCH SENSE
25 R73 20LB/BR (SIDE AIRBAGS) DRIVER CURTAIN SQUIB LINE 2
26 R75 20LB/OR (SIDE AIRBAGS) DRIVER CURTAIN SQUIB LINE 1
27 - -
28 - -
29 - -
30 - -
31 - -
32 - -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 7

AIRBAG CONTROL MODULE C2 (ORC C2) - YELLOW 32 WAY
CAV CIRCUIT FUNCTION
1 R45 20DG/LB DRIVER SQUIB 1 LINE 2
2 R43 20BK/LB DRIVER SQUIB 1 LINE 1
3 R42 20BK/YL PASSENGER SQUIB 1 LINE 1
4 R44 20DG/YL PASSENGER SQUIB 1 LINE 2
5- -
6- -
7- -
8- -
9 R49 20LB LEFT FRONT IMPACT SENSOR SIGNAL
10 R47 20DB/LB LEFT FRONT IMPACT SENSOR GROUND
11 R46 20BR/LB RIGHT FRONT IMPACT SENSOR GROUND
12 R48 20TN RIGHT FRONT IMPACT SENSOR SIGNAL
13 - -
14 - -
15 - -
16 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
17 Z6 20BK/PK GROUND
18 - -
19 - -
20 - -
21 - -
22 - -
23 D25 20YL/VT/OR PCI BUS
24 F14 20LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
25 R63 20TN/LB DRIVER SQUIB 2 LINE 2
26 R61 20OR/LB DRIVER SQUIB 2 LINE 1
27 R62 20OR/YL PASSENGER SQUIB 2 LINE 2
28 R64 20TN/YL PASSENGER SQUIB 2 LINE 1
29 - -
30 - -
31 - -
32 - -
AMBIENT TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G32 20BK/LB SENSOR GROUND
2 G31 20VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
ANTENNA MODULE (BUILT-UP-EXPORT) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X64 18BK/WT ENABLE SIGNAL TO AMPLIFIER
2- -
8W - 80 - 8 8W-80 CONNECTOR PIN-OUTWJ

ASH RECEIVER LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z300 20BK GROUND
2 E2 20OR PANEL LAMPS DRIVER
AUTOMATIC DAY/NIGHT MIRROR - BLACK 7 WAY
CAV CIRCUIT FUNCTION
1 G5 20BK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 Z150 20BK GROUND
3 L1 20BK/VT BACK-UP LAMP FEED
4 P112 20BK/WT AUTO DAY/NIGHT MIRROR (+)
5 P114 20BK/YL AUTO DAY/NIGHT MIRROR (-)
6- -
7- -
AUTOMATIC HEADLAMP LIGHT SENSOR/VTSS LED - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 L109 20WT ULTRALIGHT SENSOR SIGNAL
2 L110 20BK/YL ULTRALIGHT SENSOR RETURN
3 G69 20BK/OR VTSS INDICATOR DRIVER
4 M1 20PK FUSED B(+)
AUTOMATIC ZONE CONTROL MODULE C1 (AZC) - WHITE 16 WAY
CAV CIRCUIT FUNCTION
1 C102 20TN/BK MODE DOOR DRIVER (B)
2- -
3 C32 20GY/DB RECIRCULATION DOOR DRIVER (A)
4 C100 20YL/DB RECIRCULATION DOOR DRIVER (B)
5- -
6 C79 20BK/WT FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
7- -
8 Z118 20BK GROUND
9 C35 20DG/YL MODE DOOR DRIVER (A)
10 C33 20DB/RD DRIVER BLEND DOOR DRIVER (A)
11 - -
12 - -
13 - -
14 C81 20LB/WT REAR WINDOW DEFOGGER SWITCH SENSE
15 - -
16 - -
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 9

AUTOMATIC ZONE CONTROL MODULE C2 (AZC) - WHITE 12 WAY
CAV CIRCUIT FUNCTION
1- -
2 C94 20WT/DG PASSENGER BLEND DOOR DRIVER (A)
3 C95 20WT/BK DRIVER BLEND DOOR DRIVER (B)
4 C96 20WT/DB PASSENGER BLEND DOOR DRIVER (B)
5- -
6 E2 20OR PANEL LAMPS DRIVER
7 C56 20RD/LG BLOWER MOTOR CONTROL
8 D25 20YL/VT/DG PCI BUS
9 C103 20DG A/C SWITCH SIGNAL
10 - -
11 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN)
12 M1 20PK FUSED B(+)
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB (GAS LHD) SENSOR GROUND
1 K4 20BK/LB (DIESEL/RHD) SENSOR GROUND
2 K25 18VT/LG BATTERY TEMPERATURE SENSOR SIGNAL
BLOWER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C1 12DG BLOWER MOTOR SUPPLY
2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
BLOWER MOTOR CONTROLLER (AZC) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
A Z118 12BK GROUND
B C56 20RD/LG BLOWER MOTOR CONTROL
C C1 12DG BLOWER MOTOR SUPPLY
BLOWER MOTOR RESISTOR BLOCK (MTC) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
H C7 12BK/TN BLOWER MOTOR HIGH DRIVER
L C4 16TN BLOWER MOTOR LOW DRIVER
M1 C5 16LG BLOWER MOTOR M1 DRIVER
M2 C6 14LB BLOWER MOTOR M2 DRIVER
8W - 80 - 10 8W-80 CONNECTOR PIN-OUTWJ

BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 Z132 20BK/OR GROUND
2 G52 20YL HEADLAMP SWITCH MUX
3 E19 20RD PANEL LAMPS DIMMER SIGNAL
4- -
5 G70 20BR/TN (BUILT-UP-EXPORT LHD
RHD)HOOD AJAR SWITCH SENSE
6 G26 20LB KEY-IN IGNITION SWITCH SENSE
7 G76 18TN/YL RIGHT REAR DOOR AJAR SWITCH SENSE
8 E2 20OR PANEL LAMPS DRIVER
9 E2 20OR PANEL LAMPS DRIVER
10 E2 20OR PANEL LAMPS DRIVER
11 - -
12 E2 20OR PANEL LAMPS DRIVER
13 E2 20OR PANEL LAMPS DRIVER
14 Z132 20BK/OR GROUND
15 D25 20YL/VT/WT PCI BUS
16 L80 20WT/DG HEADLAMP SWITCH RETURN
17 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
18 - -
19 - -
20 G69 20BK/OR VTSS INDICATOR DRIVER
21 - -
22 V14 20RD/VT WIPER ON/OFF RELAY CONTROL
23 M20 20BR/OR COURTESY LAMP LOAD SHED
24 M2 20YL COURTESY LAMP DRIVER
25 Z234 20BK GROUND
26 - -
BODY CONTROL MODULE C2 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 C103 20DG A/C SWITCH SIGNAL
2 V10 20BR WASHER PUMP SWITCH SENSE
3 V48 20RD/GY WIPER HIGH CONTROL
4 L40 20BR HIGH BEAM SWITCH SENSE
5 V11 20BK/TN WASHER FLUID SWITCH SENSE
6 P134 20TN/LG PASSENGER SEAT HEATER SWITCH MUX
7 P133 20TN/DG DRIVER SEAT HEATER SWITCH MUX
8 X20 20RD/YL RADIO CONTROL MUX
9 G31 20VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
10 L109 20WT ULTRALIGHT SENSOR SIGNAL
11 V52 20DG/RD WINDSHIELD WIPER SWITCH MUX
12 C81 20LB/WT REAR WINDOW DEFOGGER SWITCH SENSE
13 - -
14 - -
15 L27 20WT/TN FOG LAMP SWITCH SENSE
16 C201 20LB/YL EVAPORATOR TEMPERATURE SENSOR SIGNAL
17 G18 20PK/BK COOLANT LEVEL SWITCH SENSE
18 P132 20OR/BK SEAT HEATER SWITCH SENSOR GROUND
19 X10 20RD/BK RADIO CONTROL MUX RETURN
20 G32 20BK/LB SENSOR GROUND
21 L110 20BK/YL ULTRALIGHT SENSOR RETURN
22 V9 20WT/BK WINDSHIELD WIPER SWITCH RETURN
WJ8W-80 CONNECTOR PIN-OUT 8W - 80 - 11

BOOST PRESSURE SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K4 20BK/LB SENSOR GROUND
2 Y53 20BK/YL BOOST PRESSURE SENSOR SIGNAL
3 K6 20VT/WT SENSOR REFERENCE VOLTAGE B
BRAKE LAMP SWITCH - GRAY 6 WAY
CAV CIRCUIT FUNCTION
1 K29 18WT/PK SECONDARY BRAKE SWITCH SIGNAL
2 Z238 18BK (LHD) GROUND
2 Z243 18BK (RHD) GROUND
3 V32 22OR/DG (GAS) SPEED CONTROL POWER SUPPLY
4 V30 22DB/RD (GAS) SPEED CONTROL BRAKE SWITCH OUTPUT
5 L50 20VT/TN (LHD) PRIMARY BRAKE SWITCH SIGNAL
5 L50 20WT/TN (RHD) PRIMARY BRAKE SWITCH SIGNAL
6 F32 20PK/DB FUSED B(+)
C100 - BLACK (RIGHT HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 T40 12LG
2 K125 18WT/DB
3 K20 18DG
C100 - BLACK (BATTERY SIDE)
CAV CIRCUIT
1 T40 12LG
2 K125 18WT/DB
3 K20 18DG
C101 (4.0L RHD) - LT. GRAY (ENGINE SIDE)
CAV CIRCUIT
1 B22 18DG/YL
2 K99 18BR/OR
3 K299 18BR/WT
4 K6 18VT/BK
5 C18 18DB
6-
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTWJ
