2002 ISUZU AXIOM ESP

6E±313
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
will require three or more 50-sample tests to report a
failure.
Test Description
Number(s) below refer to the step number(s) on the
Diagnostic Chart.
7. Difficulty completing the DTC P0420 ªStatus This
Ignº, test may be encountered in areas where test
conditions cannot be maintained easily, especially in
urban areas. To minimize the amount of driving
required to complete the DTC P0420 ªStatus This
Ignº, test, use the following procedure:

Allow the engine to warm up completely.

With the vehicle in ªParkº, monitor mass air flow on
the Tech 2 and hold part throttle to maintain a
reading of over 12 g/second for at least 2 minutes.
This will achieve the ªwarm catalystº required for
running the test.

Operate the vehicle in second or third gear to remain
in the DTC P0420 test conditions described in
ªConditions for Setting the DTCº as much as
possible. If you must stop the vehicle, maintain the
ªwarm catalystº criteria as follows:
± Place the vehicle in ªParkº or ªNeutralº,
± Hold part throttle to maintain a mass air flow
reading of over 15 g/second for the duration of the
stop.

6E±316
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Aids
Check for the following conditions:

Poor connection at PCM ± Inspect harness connectors
for backed-out terminals, improper mating, broken
locks, improperly formed or damaged terminals, and
poor terminal-to-wire connection.

Damaged harness ± Inspect the wiring harness for
damage. If the harness appears to be OK, observe the
display on the Tech 2 while moving connectors and
wiring harnesses related to the sensor. A change in the
display will indicate the location of the fault.
Reviewing the Failure Records vehicle mileage since the
diagnostic test last failed may help determine how often
the condition that caused the DTC to be set occurs. This
may assist in diagnosing the condition.
Test Description
Number(s) below refer to the step number(s) on the
Diagnostic Chart.
7. Difficulty completing the DTC P0430 ªStatus This
Ignº, test may be encountered in areas where test
conditions cannot be maintained easily, especially in
urban areas. To minimize the amount of driving
required to complete the DTC P0430 ªStatus This
Ignº, test, use the following procedure:

Allow the engine to warm up completely.

With the vehicle in ªParkº, monitor mass air flow on
the Tech 2 and hold part throttle to maintain a
reading of over 12 g/second for at least 2 minutes.
This will achieve the ªwarm catalystº required for
running the test.

Operate the vehicle in second or third gear to remain
in the DTC P0430 test conditions described in
ªConditions for Setting the DTCº as much as
possible. If you must stop the vehicle, maintain the
ªwarm catalystº criteria as follows:
± Place the vehicle in ªParkº or ªNeutralº,
± Hold part throttle to maintain a mass air flow
reading of over 15 g/second for the duration of the
stop.
The ªTWC Monitor Test Counterº displayed on the Tech 2
may be used to monitor the progress of the TWC
diagnostic. To complete the TWC diagnostic with a good
catalyst, the counter must be allowed to increment to 49
samples and roll over to 0 at least twice.

6E±344
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Trouble Code (DTC) P0461 Fuel Level Sensor Performance
060RY00163
Circuit Description
The fuel level sensor is an important input to powertrain
control module (PCM) for the enhanced evaporative
system diagnostic. Fuel level information is needed for
the PCM to know the volume of fuel in the tank. The fuel
level affects the rate of change in air pressure in the
evaporative system.
The sending unit is a float in the fuel tank which moves a
wiper arm across a variable resistor. Low fuel level
causes high resistance in the sending unit, and this is
recognized by the PCM because the circuit operates at a
corresponding low voltage. When the circuit is
continuously open or has a high resistance connection,
DTC P0461 is set.
Conditions for Setting the DTC

Sensor output change is more than 2% within 200km.
Or Sensor movement position change is less than
15% within 200km.

IAT is more than 0
C.

MAP changing in 3 sec is less than 10kPa.

Engine speed changing in 3 sec is less than 50rpm.When there are 12 test failures within 80 test samples, it is
stored.
Action Taken When the DTC Sets

The PCM will illuminate the malfunction indicator lamp
(MIL) after the second consecutive trip in which the
fault is detected.

The PCM will store conditions which were present
when the DTC was set as Freeze Frame and in the
Failure Records data.
Conditions for Clearing the DTC

DTC P0461 can be cleared by using the scan tool
ªClear Infoº function or by disconnecting the PCM
battery feed.
Diagnostic Aids

Damaged harness±Inspect the wiring harness for
damage. If the harness appears to be OK, observe the
fuel level display on the scan tool while moving
connectors and wiring harnesses related to the sensor.
A change in the display will indicate the location of the
fault.

6E±346
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Trouble Code (DTC)
P0462 Fuel Level Sensor Circuit±Low Voltage
060RY00163
Circuit Description
The fuel level sensor is an important input to powertrain
control module (PCM) for the enhanced evaporative
system diagnostic. Fuel level information is needed for
the PCM to know the volume of fuel in the tank. The fuel
level affects the rate of change in air pressure in the
evaporative system. Several of the enhanced
evaporative system diagnostic sub-tests are dependent
upon correct fuel level information. The diagnostic will not
run when the tank is more than 85% or less than 15% full.
Fuel level DTCs should be diagnosed before other
evaporative system DTCs because they can cause other
DTCs to be set.
The sending unit is a float in the fuel tank which moves a
wiper arm across a variable resistor. Low fuel level
causes high resistance in the sending unit, and this is
recognized by the PCM because the circuit operates at a
corresponding low voltage. When the circuit is
continuously open or has a high resistance connection,
DTC P0462 is set.
Conditions for Setting the DTC

Fuel tank level ªslosh testº is completed.

Fuel tank level ªmain testº is completed.

Fuel tank level data is valid.

Fuel tank level signal is less than a specified value.

There are 100 test failures within a 200-test sample.
Action Taken When the DTC Sets

The PCM will ON the MIL after second trip with
detected the fault.

The PCM will store conditions which were present
when the DTC was set as Freeze Frame and in the
Failure Records data.
Conditions for Clearing the DTC

The PCM will turn the MIL ªOFFº after three
consecutive trips without a fault condition present. A
history DTC will be cleared if no fault conditions have
been detected for 40 warm-up cycles (engine coolant
temperature has risen 4
C (40
F) from the start-up
ECT, and ECT exceeds 71
C (160
F) during that
same ignition cycle).

DTC P0462 can be cleared by using the scan tool
ªClear Infoº function or by disconnecting the PCM
battery feed.
Diagnostic Aids

Damaged harness±Inspect the wiring harness for
damage. If the harness appears to be OK, observe the
fuel level display on the scan tool while moving
connectors and wiring harnesses related to the sensor.
A change in the display will indicate the location of the
fault.

6E±349
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Trouble Code (DTC)
P0463 Fuel Level Sensor Circuit±High Voltage
060RY00163
Circuit Description
The fuel level sensor is an important input to powertrain
control module (PCM) for the enhanced evaporative
system diagnostic. Fuel level information is needed for
the PCM to know the volume of fuel in the tank. The fuel
level affects the rate of change in air pressure in the
evaporative system. Several of the enhanced
evaporative system diagnostic sub-tests are dependent
upon correct fuel level information. The diagnostic will not
run when the tank is more than 85% or less than 15%, full.
Fuel level DTCs should be diagnosed before other
evaporative system DTCs because they can cause other
DTCs to be set.
The sending unit is a float in the fuel tank which moves a
wiper arm across a variable resistor. High fuel level
causes low resistance in the sending unit. This is
recognized by the PCM because the circuit operates at a
corresponding high voltage. When the circuit is
continuously shorted to a voltage source greater than a
specified value, or when the 5 volt signal is shorted to
ground, DTC P0463 is set.
Conditions for Setting the DTC

Fuel tank level ªslosh testº is completed.

Fuel tank level ªmain testº is completed.

Fuel tank level data is valid.

Fuel tank level signal is greater than a specified value.

There are 100 test failures within a 200-test sample.
Action Taken When the DTC Sets

The PCM will ON the MIL after second trip with
detected the fault.

The PCM will store conditions which were present
when the DTC was set as Freeze Frame and in the
Failure Records data.
Conditions for Clearing the DTC

The PCM will turn the MIL ªOFFº after three
consecutive trips without a fault condition present. A
history DTC will be cleared if no fault conditions have
been detected for 40 warm-up cycles (engine coolant
temperature has risen 4
C (40
F) from the start-up
ECT, and ECT exceeds 71
C (160
F) during that
same ignition cycle) or the scan tool clearing function
has been used.

DTC P0463 can be cleared by using the scan tool
ªClear Infoº function or by disconnecting the PCM
battery feed.

6E±351
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Trouble Code (DTC) P0462 Fuel Level Sensor Noisy Signal
060RY00163
Circuit Description
The fuel level sensor is an important input to powertrain
control module (PCM) for the enhanced evaporative
system diagnostic. Fuel level information is needed for
the PCM to know the volume of fuel in the tank. The fuel
level affects the rate of change in air pressure in the
evaporative system.
The sending unit is a float in the fuel tank which moves a
wiper arm across a variable resistor. Low fuel level
causes high resistance in the sending unit, and this is
recognized by the PCM because the circuit operates at a
corresponding low voltage. When the circuit is
continuously open or has a high resistance connection,
DTC P0464 is set.
Conditions for Setting the DTC

Sensor output changing is more than 15%.

Fuel volume level is more than 0.01%.

IAT is more than 0
C.

Vehicle speed is more than 1km/h.

Throttle position is more than 2%.When there are 12 test failures within 80 test samples, it is
stored.
Action Taken When the DTC Sets

The PCM will illuminate the malfunction indicator lamp
(MIL) after the second consecutive trip in which the
fault is detected.

The PCM will store conditions which were present
when the DTC was set as Freeze Frame and in the
Failure Records data.
Conditions for Clearing the DTC

DTC P0464 can be cleared by using the scan tool
ªClear Infoº function or by disconnecting the PCM
battery feed.
Diagnostic Aids

Damaged harness±Inspect the wiring harness for
damage. If the harness appears to be OK, observe the
fuel level display on the scan tool while moving
connectors and wiring harnesses related to the sensor.
A change in the display will indicate the location of the
fault.

6E±356
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Trouble Code (DTC) P0506 Idle Air Control System Low RPM
060R200057
Circuit Description
The powertrain control module (PCM) controls engine
speed by adjusting the position of the throttle control
valve (DC motor). The throttle motor is a DC motor driven
by one coil. The PCM applies current to the DC motor coil
in position (%) to adjustment the throttle valve into a
passage in the throttle body to air flow. This method
allows highly accurate control of engine speed and quick
response to changes in engine load.
If the PCM detects a condition where too low of an idle
speed is present and the PCM is unable to adjust idle
speed by increasing the throttle position, DTC P0506 will
set, indicating a problem with the idle control system.
Conditions for Setting the DTC

No TPS, VSS, ECT, EGR, MAF, MAP, IAT, low voltage,
fuel system, canister purge, injector control, or ignition
control DTCs are set.

MAP is less than 60 kPa.

Canister purge duty cycle is above 10%.

Engine running time is more than 125 seconds.

Vehicle speed is less than 1 mph.

Engine coolant temperature (ECT) is above 50
C
(122
F).

Ignition voltage is between 9.5 volts and 16.7 volts.

The throttle is closed.

EVAP purge duty cycle more than 10%.

All conditions are met for 10 seconds.

Barometric pressure is more than 74.5 kPa.
Engine speed is more than 100-200 RPM lower than
desired idle based upon coolant temperature.
Action Taken When the DTC Sets

The PCM will illuminate the malfunction indicator lamp
(MIL) after the second consecutive trip in which the
fault is detected.

The PCM will store conditions which were present
when the DTC was set as Freeze Frame and in the
Failure Records data.
Conditions for Clearing the MIL/DTC

DTC P0506 can be cleared by using the Tech 2 ªClear
Infoº function or by disconnecting the PCM battery
feed.
Diagnostic Aids
Check for the following conditions:

Poor connection at PCM or throttle DC motor ± Inspect
harness connectors for backed-out terminals,
improper mating, broken locks, improperly formed or
damaged terminals, and poor terminal-to-wire
connection.

Damaged harness ± Inspect the wiring harness for
damage.

Restricted air intake system ± Check for a possible
collapsed air intake duct, restricted air filter element, or
foreign objects blocking the air intake system.

Throttle body ± Check for objects blocking the ETC
passage or throttle bore, excessive deposits in the

6E±359
6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS
Diagnostic Trouble Code (DTC)
P0507 Idle Air Control System High RPM
060R200057
Circuit Description
The powertrain control module (PCM) controls engine
speed by adjusting the position of the throttle control
valve (DC motor). The throttle motor is a DC motor driven
by one coil. The PCM applies current to the DC motor coil
in position (%) to adjustment the throttle valve into a
passage in the throttle body to air flow. This method
allows highly accurate control of engine speed and quick
response to changes in engine load.
If the PCM detects a condition where too high of an idle
speed is present and the PCM is unable to adjust idle
speed by increasing the throttle position, DTC P0507 will
set, indicating a problem with the idle control system.
Conditions for Setting the DTC

No TPS, VSS, ECT, EGR, MAF, MAP, IAT, low voltage,
fuel system, canister purge, injector control or ignition
control DTCs are set.

Barometric pressure is above 75 kPa.

Canister purge duty cycle is above 10%.

Engine running time is more than 125 seconds.

Vehicle speed is less than 1 mph.

Engine coolant temperature (ECT) is above 50
C
(122
F).

Ignition voltage is between 9.5 volts and 16.7 volts.

The throttle is closed.

EVAP purge duty cycle is more than 10%.
All conditions are met for 10 seconds.

Engine speed is more than 100-200 RPM higher than
desired idle based upon coolant temperature.

Barometric pressure is more than 74.5 kPa.
Action Taken When the DTC Sets

The PCM will illuminate the malfunction indicator lamp
(MIL) after the second consecutive trip in which the
fault is detected.

The PCM will store conditions which were present
when the DTC was set as Freeze Frame and in the
Failure Records data.
Conditions for Clearing the MIL/DTC

The PCM will turn the MIL ªOFFº on the third
consecutive trip cycle during which the diagnostic has
been run and the fault condition is no longer present.

A history DTC P0507 will clear after 40 consecutive
warm-up cycles have occurred without a fault.

DTC P0507 can be cleared by using the Tech 2 ªClear
Infoº function or by disconnecting the PCM battery
feed.
Diagnostic Aids
Check for the following conditions:

Poor connection at PCM or throttle DC motor ± Inspect
harness connectors for backed-out terminals,
improper mating, broken locks, improperly formed or
