1- 84 FEATURES OF YOUR HYUNDAI
B970A01Y-AAT AUTOMATIC HEATING AND COOLING CONTROL SYSTEM (If Installed) Your Hyundai is equipped with an au- tomatic heating and cooling control system controlled by simply settingthe desired temperature. B970B01L-GAT Heating and Cooling Controls
1. Blower Fan Control Switch
2. AUTO (Automatic Control) Switch
3. OFF Switch
4. Display Window
5. Temperature Control Button
6. Defroster Switch HXG118-2
7. Air Conditioning Switch
8. Air Flow Control Switch
9. Air Intake Control Switch/Air Qual- ity System Switch (If installed)
10.Ambient Switch
11.Rear Window Defroster Switch
12.Rear Ventilator Switch
1 2
34 5
6 7 8 9 10 11 12

FEATURES OF YOUR HYUNDAI 1- 85
2. Push the "TEMP" button to set the
desired temperature. The temperature will increase to themaximum 32 C(90 F) by pushingon the button. Each push of the button will cause the temperature to increase by 0.5 C(1 F).The temperature will decrease tothe minimum 17 C(62 F) by push-ing on the button. Each push ofthe button will cause the tempera- ture to decrease by 0.5 °C(1 F).
NOTE: If the battery has been discharged or disconnected, the temperaturemode will reset to centigrade de-gree.
The FATC (Full Automatic Tempera- ture Control) system automaticallycontrols the heating and cooling bydoing as follows:
1. Push the "AUTO" switch. The indi- cator light will illuminate confirming that the Face, Floor and/or Bi-Levelmodes as well as the blower speedand, air conditioner will be controlled automatically. Photo sensor
B970C01L
B970C03Y-GAT Automatic Operation
NOTE: Never place things on the sensor which is located in the car on theinstrument panel to ensure bettercontrol of the heating and coolingsystem.
B970C02L
B970C03L
This is a normal condition and youcan adjust the temperature modefrom centigrade to farenheit as fol-lows;Press the TEMP button down 3 sec- onds or more with the AMB button held down. The display shows thatthe unit of temperature is adjustedto contigrade or fahrenheit.( C


F or F


C)

1- 86 FEATURES OF YOUR HYUNDAI
HXG506J
This is used to select fresh outside air or recirculate inside air automatically. : OFF
:ON
Fresh mode :
Air enters the vehicle from the outsideand is heated or cooled according tothe function selected.
Recirculation mode :
Air from within the passenger com-partment will be drawn through theheating system and heated or cooled according to the function selected. B980C02E-GAT Air Intake Control Switch (With A.Q.S) (If Installed)
B980B01Y-AAT Fan Speed Control
B995A01Y-GATAMBIENT SWITCH B980A01Y-AAT MANUAL OPERATION The heating and cooling system can be controlled manually as well as bypushing buttons other than the "AUTO"button. At this state, the system se- quentially works according to the order of buttons selected.The function of the buttons which arenot selected will be controlled auto-matically.Press the "AUTO" button in order to convert to automatic control of the system. HXG507J
Pressing the AMB button displays theambient temperature on VFD. The fan speed can be set to the de-sired speed by pressing the appropri-ate fan speed control button. The higherthe fan speed is, the more air is deliv- ered. Pressing the "OFF" button turns off the fan.B980B01L

FEATURES OF YOUR HYUNDAI 1- 87
Exhaust gas cutoff mode :
Air enters the vehicle from the outside. But if exhaust gas enters the vehiclefrom the outside, the exhaust gas cut-off mode ( ) is automatically con-verted to the ( ) mode, to prevent exhaust gas from entering the vehicle. NOTE:
o It should be noted that prolonged operation of the heating system in recirculation mode ( ) willgive rise to misting of the winds-hield and side windows and the air within the passenger com- partment will become stale. Inaddition, prolonged use of theair conditioning with the recircu-lation mode ( ) selected may result in the air within the pas- senger compartment becomingexcessively dry. B980D01Y-AAT Heating and Cooling System Off Press the "OFF" button to stop the operation of the heating and coolingsystem.o When the ignition switch is turned
"ON", the air intake control willchange to ( ) mode (regardless
of switch position). This is normaloperation. The air intake control operates in "AUTO" mode when turning the ignition to the ON po-sition if the "AUTO" mode wasused before shutting off the en-gine.
CAUTION:
If the windows fog up with the Re-circulation or A.Q.S mode selected, set the air intake control to the Fresh air position or A.Q.S controlto "OFF".
!
B980E01L-GAT Air Flow Control
HXG505J
This is used to direct the flow of air. Air can be directed to the floor, dashboardoutlets, or windshield. Four symbolsare used to represent Face, Bi-Level, Floor and Floor-Defrost air position.

1- 90 FEATURES OF YOUR HYUNDAI
B740D01Y-AAT Operation Tips
o If the interior of the car is hot when
you first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air condi-
tioning system, keep all windows closed to keep hot air out.
o When moving slowly, as in heavy traffic, shift to a lower gear. This increases engine speed, which inturn increases the speed of the airconditioning compressor.
o On steep grades, turn the air condi-
tioning off to avoid the possibility ofthe engine overheating.
o During winter months or in periods when the air conditioning is not usedregularly, run the air conditioning once every month for a few min- utes. This will help circulate thelubricants and keep your system inpeak operating condition.

1- 100 FEATURES OF YOUR HYUNDAI
NOTE:
o To assure proper operation of
the unit, keep the vehicle interior temperature within a normalrange by using the vehicle's airconditioning or heating system.
o When replacing the fuse, replace it with a fuse having the correctcapacity.
o This equipment is designed to
be used only in a 12 volt DCbattery system with negativeground.
o This unit is made of precision
parts. Do not attempt to disas-semble or adjust any parts.
o When driving your vehicle, be sure to keep the volume of theunit set low enough to allow you to hear sounds coming from the outside.

FEATURES OF YOUR HYUNDAI 1- 107
B940L01L-GAT
1. Playing CD
o Insert the CD with the label facing
upward.
o Insert the CD to start CD playback,
during radio operation or cassette tape playing.
o When a disc is in the CD deck, if you
press the play button the CD playerwill begin playing even if the radio or cassette player is being used.
o The CD player can be used when
the ignition switch is in either the "ON" or "ACC" position.
2. FF/REW While the disc is playing, if you hold down the FF button continuously, thetrack number is increased and viceversa.
3. TRACK UP/DOWN
o The desired track on the disc cur- rently being played can be selected using the track number.
o Press once to skip forward to the beginning of the next track.
o Press once to skip back to the beginning of the track. 4. SCAN (If installed)
o Press the SCAN button to playback
the first 10 seconds of each track.
o Press the SCAN button again within
10 sec. when you have reached the desired track.
5. REPEAT
o To repeat the track you are currently listening to, press the RPT button. To cancel , press again.
o If you do not release RPT operation
after all the tracks are played back,the unit will play back again from thefirst track.
6. EQ Button Press the EQ button to select the CLASSIC, JAZZ, ROCK and DEFEATMODE for the desired tone quality.Each press of the button changes thedisplay as follows; NOTE:
o To assure proper operation of the
unit, keep the vehicle interior tem- perature within a normal range by using the vehicle's air condition- ing or heating system.
o When replacing the fuse, replace it with a fuse having the correctcapacity.
o The preset station frequencies are all erased when the car bat-tery is disconnected. Therefore,all data will have to be set againif this should occur.
o Do not add any oil to the rotating parts. Keep magnets, screwdriv- ers and other metallic objects away from the tape mechanismand head.
o This equipment is designed to
be used only in a 12 volt DCbattery system with negative ground.
o This unit is made of precision parts. Do not attempt to disas- semble or adjust any parts.
CLASSIC JAZZ ROCK DEFEAT

FEATURES OF YOUR HYUNDAI 1- 111
NOTE:
o To assure proper operation of the
unit, keep the vehicle interior tem- perature within a normal range byusing the vehicle's air condition-ing or heating system.
o When replacing the fuse, replace it with a fuse having the correctcapacity.
o This equipment is designed to
be used only in a 12 volt DCbattery system with negativeground.
o This unit is made of precision
parts. Do not attempt to disas-semble or adjust any parts.
o When driving your vehicle, be sure to keep the volume of theunit set low enough to allow you to hear sounds coming from the outside.
