Page 97 of 158
Loosen the drain plug on the
bottom of the radiator. The
coolant will drain through the
splash guard. Remove the drain
bolt and washer f rom the engine
block.
Openthehood.Makesurethe
engine and radiator are cool to the
touch.
Turn the ignition ON (II). Turn
the temperature control dial to
90°F (32°C). Turn of f the ignition
and remove the key.
Remove the radiator cap.
Turn the ignition ON (II). Turn
the temperature control Dial all
the way clockwise. Turn of f the
ignition and remove the key.
1.
3.
2.
4-cylinder models
EX V-6 model
Except EX V-6 model
Maint enance
Cooling Syst em
258
44--ccyylliinnddeerrmmooddeellss66--ccyylliinnddeerrmmooddeellss44--ccyylliinnddeerrmmooddeellss
DDRRAAIINNBBOOLLTT
DDRRAAIINNPPLLUUGG
Page 98 of 158
Remove the reserve tank f rom its
holder by pulling it straight up.
Drain the coolant, then put the
tank back in its holder.
Loosen the drain plug on the
bottom of the radiator. The
coolant will drain through the
splash guard. Loosen the drain
bolt. When removing the reserve tank,
f irst remove the cruise control cable
and the ground cable f rom their clips.
Af ter installing the tank back in
place, put the cables back in their
clips.
4.
3.6-cylinder models 6-cylinder models
CONT INUED
Cooling Syst em
Maint enance259
66--ccyylliinnddeerrmmooddeellss
RREESSEERRVVEETTAANNKKRREESSEERRVVEETTAANNKKCCAAPP
44--ccyylliinnddeerrmmooddeellssHHOOLLDDEERR
DDRRAAIINNPPLLUUGG
DDRRAAIINNBBOOLLTT66--ccyylliinnddeerrmmooddeellss
Page 99 of 158

When the coolant stops draining,
tightenthedrainplugatthe
bottom of the radiator.
Put a new washer on the drain bolt,
then reinstall the drain bolt in the
engine block. Tighten it securely.
Tightening torque:Tighten the drain bolt at the rear
of the engine cylinder block
securely.
Tightening torque:
Loosen the bleeder bolt on top of
the engine.
Pour Honda All Season
Antif reeze/Coolant Type 2 into
the radiator. This coolant is a
mixture of 50 percent anti-f reeze
and 50 percent water. Pre-mixing
is not required.
Tighten the bleeder bolt when
coolant comes out in a steady
stream with no bubbles.
7.
6.
5.
4-cylinder models 6-cylinder models 4-cylinder models
Cooling Syst em
Maint enance260
FFIILLLLEERRNNEECCKK
44--ccyylliinnddeerrmmooddeellssFFiilllluuppttoohheerree
FFIILLLLEERRNNEECCKK
66--ccyylliinnddeerrmmooddeellssFFiilllluuppttoohheerree
RREESSEERRVVEETTAANNKKCCAAPPRREESSEERRVVEETTAANNKK
66--ccyylliinnddeerrmmooddeellssHHOOLLDDEERR
61 lbf·ft (83 N·m , 8.5 kgf·m)
7 lbf·ft (10 N·m , 1.0 kgf·m)
Page 100 of 158

Start the engine and hold it at
1,500 rpm until the cooling f an
comes on. Turn of f the engine.
Check the coolant level in the
radiator and add coolant if needed.
Start the engine and let it run f or
about 30 seconds. Then turn of f
the engine.
Fill the radiator with coolant up to
the base of the f iller neck.
Fill the reserve tank to the MAX
mark. Install the reserve tank cap.
Install the radiator cap, and
tighten it to the first stop.
Start the engine and let it run until
the radiator cooling f an comes on
at least twice. Then stop the
engine.
Remove the radiator cap. Pour
coolant into the radiator up to the
base of the f iller neck and into the
reserve tank up to the MAX mark. If necessary, f ill the reserve tank
to the MAX mark. Install the
reserve tank cap.
Install the radiator cap, and
tighten it fully.
Pour coolant into the radiator up
to the base of the f iller neck.
The cooling system capacity is: 8. 9.
10. 11.12. 13. 14. 15. 16.
With automatic transmission:
6-cylinder models
With 5-speed manual transmission:
6-cylinder models
Cooling Syst em
Maint enance261
44--ccyylliinnddeerrmmooddeellssBBLLEEEEDDEERRBBOOLLTT
1.45 US gal (5.5, 1.21 Imp gal)
1.43 US gal (5.4
, 1.19 Imp gal)
1.48 US gal (5.6
, 1.23 Imp gal)
Page 101 of 158
Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks.
Check the f luid level with the engine
at normal operating temperature.
Park the car on level ground. Shut
of f the engine.
Remove the dipstick (yellow loop)
f rom the transmission and wipe it
with a clean cloth.
Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
1. 2.3. 4.
6.
6-cylinder models
T ransmission Fluid
Maint enance
Automatic Transmission
264
UUPPPPEERRMMAARRKK
DDIIPPSSTTIICCKKLLOOWWEERRMMAARRKK
Page 102 of 158
If Honda MTF is not available, you
may use an API service SG, SH or SJ
grade motor oil with a viscosity of
SAE 10W-30 or 10W-40 as a
temporary replacement. An SG
grade is pref erred, but an SH or SJ
grade may be used if SG is not
available. However, motor oil does
not contain the proper additives and
continued use can cause stif f er
shif ting. Replace as soon as it is
convenient.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
T ransmission Fluid
Maint enance266
Page 103 of 158
The air cleaner element is inside the
air cleaner housing on the passenger’s
side of the engine compartment.
To replace it:Unsnap the f our hold-down clamps
and remove the air cleaner
housing cover.
Remove the old air cleaner
element.
Caref ully clean the inside of the
air cleaner housing with a damp
rag.Place the new air cleaner element
in the air cleaner housing.
Reinstall the air cleaner housing
cover, snap the four hold-down
clamps back into place.
1. 3. 4. 5.
2.
Replacement
A ir Cleaner Element (4-cylinder Models)
Maint enance270
AAIIRRCCLLEEAANNEERREELLEEMMEENNTT
CCLLAAMMPPSS
Page 104 of 158
Place the new air cleaner element
in the air cleaner housing.
Loosen the f our bolts and remove
the air cleaner housing cover.
Remove the old air cleaner
element. Reinstall the air cleaner housing
cover, tighten the f our bolts.
To replace it:
The air cleaner element is inside the
air cleaner housing on the driver’s
side of the engine compartment.
Caref ully clean the inside of the
air cleaner housing with a damp
rag.
1. 3.
4. 5.
2.
Replacement
A ir Cleaner Element (6-cylinder Models)
Maint enance271
AAIIRRCCLLEEAANNEERREELLEEMMEENNTT
BBOOLLTTSS
