2-18 Entering Programming Mode
To program features, your vehicle must be in the
programming mode. Follow these steps:
1. The optional content theft
-deterrent system must be
disarmed. See ªContent Theft
-Deterrent Systemº in
this section.
2. Remove the BCM PRGRM fuse from the instrument
panel fuse block, located to the right of the glove
box. See ªFuses and Circuit Breakersº in the Index.
3. Close the driver's door.
4. Turn the ignition key to ACCESSORY.
5. Count the number of chimes you hear. You will
hear two to four chimes depending on the features
your vehicle is equipped with. Refer to the chart
shown previously.
You can now program your choices.
To exit the programming mode, follow the steps
listed under ªExiting Programming Modeº later in
this section.
Delayed Illumination and Exit Lighting
This feature allows you to customize the interior lamps
when entering and exiting the vehicle.
Programmable Modes
Mode 1: Both Features Off (The interior lamps will
turn on or off at the same instant that a door is opened
or closed.)
Mode 2: Delayed Illumination Only (The interior lamps
will stay on for about 25 seconds after all the doors and
liftgate are closed, or until you lock the doors.)
Mode 3: Exit Lighting Only (The interior lamps will
come on whenever you remove the key from the ignition
and stay on for about 25 seconds, or until you lock
the doors.)
Mode 4: Both Features On (This combines
Modes 2 and 3.)

2-19
Before your vehicle was shipped from the factory, it
was programmed to one of the modes listed previously.
To determine the mode your vehicle is programmed
to or to program your vehicle to a different mode, do
the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Turn the interior lamps on by turning the instrument
panel brightness control all the way up.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle's current
programmed mode. (If you do not wish to change the
current mode, you can either exit the programming
mode by following the instructions later in this
section or program the next feature available on
your vehicle.)
4. Turn the interior lamps control off to change the
current mode.
5. Turn the interior lamps control from on to off until
you hear the number of chimes corresponding to the
mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Automatic Door Locks
This feature allows you to customize the automatic
locking and unlocking of the doors using the gearshift.
Programmable Modes
Mode 1: Both Features Off (Automatic door locking
and unlocking is disabled. You will always need to
lock your doors manually before driving to increase
occupant safety.)
Mode 2: Automatic Door Locking Only

The automatic door unlock feature is turned off.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
Mode 3: Automatic Unlocking with the Ignition Off

Turn off the ignition with the transaxle in PARK (P);
all doors will unlock automatically.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.

2-20
Mode 4: Automatic Unlocking with Transaxle
in PARK (P)

Shift into PARK (P) with the ignition on; all doors
will unlock automatically.

Shift out of PARK (P) with the ignition on and the
driver's door closed; all doors will lock automatically.
Before your vehicle was shipped from the factory, it was
programmed in Mode 3. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press LOCK on the power door lock switch.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle's current
programmed mode. (If you do not wish to change the
current mode, you can either exit the programming
mode by following the instructions later in this
section or program the next feature available on
your vehicle.)4. Press LOCK to change the current mode.
5. Press LOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Last Door Closed Locking and Lockout
Prevention
This feature allows you to customize the automatic
locking of the doors when exiting the vehicle.
Programmable Modes
Mode 1: Both Features Off (Doors will always lock
immediately when you press LOCK on the power
door lock switch or the optional remote keyless
entry transmitter.)
Mode 2: Lockout Deterrent Only (If you leave your key
in the ignition with the driver's door open, you won't be
able to lock the doors with the power door locks.)

2-21
Mode 3: Last Door Closed Locking Only (If the power
door lock switch or the optional remote keyless entry
transmitter is used to lock the vehicle while any door or
the liftgate is open, you will hear three chimes. The
doors will not lock. Five seconds after the last door is
closed, all doors and the liftgate will lock.)
Mode 4: Both Features On (This combines
Modes 2 and 3.)
Before your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press UNLOCK on the power door lock switch.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle's current
programmed mode. (If you do not wish to change the
current mode, you can either exit the programming
mode by following the instructions later in this
section or program the next feature available on
your vehicle.)4. Press UNLOCK to change the current mode.
5. Press UNLOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Remote Driver's Unlock Control
This feature allows you to customize the UNLOCK
button on the remote keyless entry transmitter.
Programmable Modes
Mode 1: Remote All Doors Unlock (When you press
UNLOCK on your remote keyless entry transmitter, all
doors and the liftgate will unlock.)
Mode 2: Remote Driver's Door Unlock Only (When
you press UNLOCK on your remote keyless entry
transmitter once, the driver's door will unlock. When
you press UNLOCK on your remote keyless entry
transmitter again within five seconds, all doors and the
liftgate will unlock.)

2-22
Before your vehicle was shipped from the factory, it was
programmed in Mode 2. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press UNLOCK on the remote keyless
entry transmitter.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle's current
programmed mode. (If you do not wish to change the
current mode, you can either exit the programming
mode by following the instructions later in this
section or program the next feature available on
your vehicle.)
4. Press UNLOCK to change the current mode.
5. Press UNLOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Remote Lock and Unlock Confirmation
This feature allows you to customize the feedback
received when locking or unlocking your vehicle with
the remote keyless entry transmitter.
Programmable Modes
Mode 1: Both Features Off (Remote lock and unlock
confirmation are disabled.)
Mode 2: Exterior Lamps Flash Only

When you use the remote keyless entry transmitter to
lock your vehicle, your parking lamps will flash to
let you know the command has been received.

When you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash to let
you know the command has been received.

2-23
Mode 3: Exterior Lamps Flash and Horn Sound

When you use the remote keyless entry transmitter to
lock your vehicle, the horn will sound and your
parking lamps will flash to let you know the
command has been received.

When you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash to let
you know the command has been received.
Mode 4: Exterior Lamps Flash and Horn Sound
(on second LOCK Press)

When you use the remote keyless entry transmitter
to lock your vehicle, your parking lamps will flash
to let you know the command has been received.
The horn will sound and your parking lamps will
flash if you press the LOCK button again within
five seconds.

When you use the remote keyless entry transmitter to
unlock your vehicle or operate your optional power
sliding door(s), your parking lamps will flash to let
you know the command has been received.Before your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Press LOCK on the remote keyless entry transmitter.
3. Count the number of chimes you hear. The number
of chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current
mode, you can either exit the programming mode
by following the instructions later in this section or
program the next feature available on your vehicle.)
4. Press LOCK to change the current mode.
5. Press LOCK until you hear the number of chimes
corresponding to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-25
Arming and Disarming the Content
Theft-Deterrent System
This feature allows you to customize the arming and
disarming of the content theft
-deterrent system.
Programmable Modes
Mode 1: Power Door Lock Switch Arming Off

The system will arm when you lock the doors with
your key or remote keyless entry transmitter. The
key must be removed from the ignition when you
lock the doors or the content theft
-deterrent system
will not arm.

The system will disarm when you unlock the doors
with your key or remote keyless entry transmitter.
Mode 2: Remote Keyless Entry Transmitter
Arm/Disarm Only

The system will arm when you lock the doors with
your remote keyless entry transmitter. The key must
be removed from the ignition when you lock the doors
or the content theft
-deterrent system will not arm.

The system will disarm when you unlock the doors
with your remote keyless entry transmitter.While this mode provides increased security, it can be a
problem if your remote keyless entry transmitter is
damaged, lost or if it fails to operate for any reason
while the content theft
-deterrent system is armed. The
content theft
-deterrent system must be disarmed for the
engine to run while in Mode 2; your key can no longer
disarm the system.
If your vehicle is equipped with the OnStar
 system,
OnStar will not be able to remotely unlock your vehicle
if it has been programmed to Mode 2.
Mode 3: Standard Arming and Disarming

The system will arm when you lock the doors
using either power door lock switch while any door
or the liftgate is open and the key is removed from
the ignition.

The system will arm when you lock the doors with
your key or remote keyless entry transmitter and the
key is removed from the ignition.

The system will disarm when you unlock the doors
with your key or remote keyless entry transmitter.

2-26
Before your vehicle was shipped from the factory, it was
programmed in Mode 1. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Insert your spare key fully into any door key cylinder
and turn it to the unlock position.
This step is necessary to prevent accidental
programming of this feature to Mode 2. Do not
program this feature to Mode 2 without first reading
the description for Mode 2 entirely. The door key
cylinder must remain in the unlock position during
Steps 2 through 4.
3. Press the horn symbol on the remote keyless
entry transmitter.4. Count the number of chimes you hear. The number of
chimes indicates the vehicle's current programmed
mode. (If you do not wish to change the current
mode, you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
5. Press the horn symbol to change the current mode.
6. Press the horn symbol until you hear the number
of chimes corresponding to the mode selection
you want.
7. Remove your key from the door key cylinder.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
next in this section or program the next feature available
on your vehicle.
