2002 CHEVROLET C3500 HD Owners Manual

3-15
Playing a Cassette Tape
Your tape player is built to work best with tapes
that are up to 30 to 45 minutes long on each side.
Tapes longer than that are so thin they may not work
well in this player.
To load a cassette tape with the ignition off, press
EJECT or RECALL. Then, insert the cassette tape.
If the ignition is on but the radio is off, the tape will
begin playing.
Once the tape is playing, use the VOL, AUTO TONE,
BAL, FADE, BASS and TREB controls just as you do
for the radio. The tape symbol and a direction arrow
will be on the display whenever a tape is being played.
Anytime a tape is inserted, the top side is selected for
play first.
The player automatically senses if the cassette tape is
metal or CrO
2 and adjusts for best playback sound.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.1 PREV (Previous): Press this pushbutton or the
left SEEK arrow to search for the previous selection.
A minimum three
-second blank gap is required for the
player to stop at the beginning of the selection. The tape
direction arrow will blink while in previous mode.
2 PROG (Program): Press this pushbutton to switch
from one side of the tape to the other.
3 NEXT: Press this pushbutton or the right SEEK arrow
to search for the next selection. A minimum three
-second
blank gap is required for the player to stop at the
beginning of the selection. The tape direction arrow will
blink while in next mode. The sound will mute while
searching for the next selection.
REV 4 (Reverse): Press this pushbutton to rapidly
reverse the tape. Press this pushbutton again to stop
reversing the tape. The radio will play the last selected
station while reversing the tape. The tape direction
arrow will blink while in reverse mode.

3-16

5 (Dolby): Press this pushbutton to reduce cassette
tape noise. The double
-D symbol will appear on the
display while the player is in this mode.
Dolby Noise Reduction is manufactured under a
license from Dolby Laboratories Licensing Corporation.
Dolby and the double
-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
FWD 6 (Forward): Press this pushbutton to rapidly
forward the tape. Press this pushbutton again to stop
forwarding the tape. The radio will play the last selected
station while forwarding the tape. The tape direction
arrow will blink while in forward mode.
AM FM: Press this button to listen to the radio when
playing a tape.
TAPE AUX (Auxiliary): Press this button to play a
tape when listening to the radio. The lighted arrow will
appear and show the direction of play when a tape is in
the active mode.
EJECT: Press this button to stop a tape when it is
playing or to eject a tape when it is not playing. Eject
may be activated with the radio off. Cassette tapes may
be loaded with the radio and vehicle off if this button is
pressed first.Cassette Tape Messages
CLN (Clean): If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds, indicating the feature is active.
4. Insert the adapter into the cassette slot. It will
power up the radio and begin playing.
This override routine will remain active until the EJECT
button is pressed.

3-17 AM-FM Stereo with Compact Disc Player
and Automatic Tone Control (If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
The knob is capable of rotating continuously.SCV (Speed
-Compensated Volume): With SCV,
your audio system adjusts automatically to make up for
road and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Each notch on the
control ring allows for more volume compensation
at faster vehicle speeds. Then, as you drive, SCV
automatically increases the volume, as necessary, to
overcome noise at any speed. The volume level should
always sound the same to you as you drive. If you don't
want to use SCV, turn the control all the way down.
RECALL: Pressing this button will display the station
being played or it will display the clock. Clock display
is available with the ignition turned off.
Finding a Station
AM FM: Press this button to switch between AM,
FM1 and FM2. The display will show your selection.
TUNE: Press this knob lightly so it extends. Turn it to
choose radio stations. Push the knob back into its stored
position when you're not using it.

3-18
SEEK: Press the right or left arrow to seek to the
next station or previous station and stay there. The radio
will seek to stations with a strong signal only. The sound
will mute while seeking.
To scan stations, press and hold either SEEK arrow
for two seconds until SCAN appears on the display.
The radio will scan to a station, play for a few seconds,
then go on to the next station. Press either SEEK arrow
again to stop scanning. The radio will scan to stations
with a strong signal only. The sound will mute
while scanning.
P.SCAN (Preset Scan): Press this button to scan through
your favorite stations stored on your pushbuttons.
P.SCAN will appear on the display. The radio will scan
to the first preset station stored on your pushbuttons,
play for a few seconds, then go on to the next station.
Press this button again or one of the pushbuttons to
stop scanning. The channel number (P1 through P6) will
appear with the frequency. The radio will scan preset
stations with a strong signal only. The sound will mute
while scanning.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press AUTO TONE to select the setting you prefer.
5. Press and hold one of the six pushbuttons.
The sound will mute. When it returns, release the
pushbutton. Whenever you press that numbered
pushbutton, the station you set will return and the
tone you selected will be automatically selected for
that pushbutton.
6. Repeat the steps for each pushbutton.

3-19
Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob clockwise to increase treble and
counterclockwise to decrease treble. If a station is weak
or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
AUTO TONE: This feature allows you to choose bass and
treble equalization settings designed for country/western,
jazz, talk, pop, rock and classical stations.
Each time you press the AUTO TONE button, this feature
will switch to one of these program types.
To return the bass and treble to the manual mode,
either press and release the AUTO TONE button until
the display goes blank or press and release the BASS or
TREB knobs and turn them until the display goes blank.Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press this knob lightly so it extends.
Turn the knob clockwise to adjust sound to the right
speakers and counterclockwise to adjust sound to the
left speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.

3-20
Playing a Compact Disc
Insert a disc partway into the slot, label side up.
The player will pull it in. Wait a few seconds and the
disc should play. CD and a CD symbol will also appear
on the display. Anytime you are playing a CD, the letters
CD will be next to the CD symbol.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.
1 PREV (Previous): Press this pushbutton to search for
the previous track. If you hold this pushbutton or press it
more than once, the disc will advance further. Sound is
muted in this mode.
2 RDM (Random): Press this pushbutton to play the
tracks on the disc in random order. RANDOM will
appear on the display. Press this pushbutton again to
return to normal play.
3 NEXT: Press this pushbutton to search for the next
track. If you hold this pushbutton or press it more than
once, the disc will advance further. The next track
number will appear on the display. Sound is muted in
this mode.REV 4 (Reverse): Press and hold this pushbutton to
return rapidly to a favorite passage. You will hear the
disc play at high speed while you press this pushbutton.
This allows you to listen and find out when the disc
is at the desired passage. Release this pushbutton to
resume playing.
FWD 6 (Forward): Press and hold this pushbutton
to advance rapidly within a track. You will hear the disc
play at high speed while you press this pushbutton.
This allows you to listen and find out when the disc
is at the desired passage. Release this pushbutton to
resume playing.
SEEK: The right arrow is the same as NEXT, and
a the left arrow is the same as PREV. If the right or left
arrow is held or pressed more than once, the player will
continue moving forward or backward through the disc.
RECALL: Press this button to see what track is playing.
Press it again within five seconds to see how long the
CD has been playing that track. Elapsed time is
displayed in minutes and seconds. The track number
will also appear when a new track begins to play.
Press this button again to return to the time display.

3-21
AM FM: Press this button to listen to the radio when
playing a CD. The CD symbol will still display but the
word CD will be replaced with either AM, FM1 or FM2.
If the radio is turned off, the disc stays in the player and
will resume playing at the point where it stopped.
CD AUX (Auxiliary): Press this button to play a
CD when listening to the radio. When a disc is playing,
the letters CD and the CD symbol will appear on the
display. If the radio is turned off, the disc stays in
the player and will resume playing at the point where
it stopped.
EJECT: Press this button to eject the disc from the
player and play the radio. When the same or a new
disc is inserted, the disc will start playing on track one.
If a compact disc is left sitting in the opening for more
than a few seconds, the player will pull the CD back in.
The radio will continue playing. When the ignition is
off, press this button to load a CD.Compact Disc Messages
ERR (Error): If this message appears and the disc
comes out, it could be for one of the following reasons:

If you're driving on a very rough road. When the
road becomes smooth the disc should play.

If it's very hot. When the temperature returns to
normal, the disc should play.

The disc is upside down.

It is dirty, scratched or wet.

The air is very humid. (If so, wait about an hour
and try again.)

If the CD is not playing correctly, for any other
reason, try a known good CD.
Press RECALL to make ERR go off of the display.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.

3-22 Theft-Deterrent Feature (If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. It works by using a secret code to disable all radio
functions whenever battery power is removed.
The THEFTLOCK feature for the radio may be used or
ignored. If ignored, the system plays normally and the
radio is not protected by the feature. If THEFTLOCK is
activated, your radio will not operate if stolen.
When THEFTLOCK is activated, the radio will display
LOC to indicate a locked condition anytime battery
power has been interrupted. If your battery loses power
for any reason, you must unlock the radio with the secret
code before it will operate.
Activating the Theft
-Deterrent Feature
The instructions which follow explain how to enter
your secret code to activate the THEFTLOCK system.
It is recommended that you read through all nine steps
before starting the procedure.
If you allow more than 15 seconds to elapse between
any steps, the radio automatically reverts to time and
you must start the procedure over at Step 4.1. Write down any three or four
-digit number from
000 to 1999 and keep it in a safe place separate
from the vehicle.
2. Turn the ignition to ACCESSORY or RUN.
3. Turn the radio off.
4. Press the 1 and 4 pushbuttons at the same time.
Hold them down until
--- shows on the display.
Next you will use the secret code number which
you have written down.
5. Press MN and 000 will appear on the display.
6. Press MN again to make the last two digits agree
with your code.
7. Press HR to make the first one or two digits agree
with your code.
8. Press AM FM after you have confirmed that the
code matches the secret code you have written down.
The display will show REP to let you know that you
need to repeat Steps 5 through 7 to confirm your
secret code.
9. Press AM FM and this time the display will show
SEC to let you know that your radio is secure.
The LED indicator by the volume knob will begin
flashing when the ignition is turned off.
