2002 CHEVROLET BLAZER Owners Manual

3-18
Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press this knob lightly so it extends.
Turn the knob clockwise to adjust sound to the right
speakers and counterclockwise to adjust sound to the
left speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in
this player.
To load a cassette tape with the ignition off, press
EJECT or RECALL. Then, insert the cassette tape.
If the ignition is on but the radio is off, the tape will
begin playing.Once the tape is playing, use the VOL, AUTO TONE,
BAL, FADE, BASS and TREB controls just as you do
for the radio. The tape symbol and a direction arrow will
be on the display whenever a tape is being played.
Anytime a tape is inserted, the top side is selected for
play first.
The player automatically senses if the cassette tape is
metal or CrO
2 and adjusts for best playback sound.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.
1 PREV (Previous): Press this pushbutton or the left
SEEK arrow to search for the previous selection. A
minimum three
-second blank gap is required for the
player to stop at the beginning of the selection. The tape
direction arrow will blink while in previous mode.
2 PROG (Program): Press this pushbutton to switch
from one side of the tape to the other.
3 NEXT: Press this pushbutton or the right SEEK
arrow to search for the next selection. A minimum
three
-second blank gap is required for the player to stop
at the beginning of the selection. The tape direction
arrow will blink while in next mode. The sound will
mute while searching for the next selection.

3-19
REV 4 (Reverse): Press this pushbutton to rapidly
reverse the tape. Press this pushbutton again to stop
reversing the tape. The radio will play the last selected
station while reversing the tape. The tape direction
arrow will blink while in reverse mode.

5 (Dolby): Press this pushbutton to reduce cassette
tape noise. The double
-D symbol will appear on the
display while the player is in this mode.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
FWD 6 (Forward): Press this pushbutton to rapidly
forward the tape. Press this pushbutton again to stop
forwarding the tape. The radio will play the last selected
station while forwarding the tape. The tape direction
arrow will blink while in forward mode.AM FM: Press this button to listen to the radio when
playing a tape.
TAPE AUX (Auxiliary): Press this button to play a
tape when listening to the radio. The lighted arrow will
appear and show the direction of play when a tape is in
the active mode.
EJECT: Press this button to stop a tape when it is
playing or to eject a tape when it is not playing. Eject
may be activated with the radio off. Cassette tapes may
be loaded with the radio and vehicle off if this button is
pressed first.
Cassette Tape Messages
CLN (Clean): If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.

3-20
CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds, indicating the feature is active.
4. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until the EJECT
button is pressed.AM-FM Stereo with Cassette Tape Player
(Bose
) (If Equipped)
Included with this audio system are six Bose
speakers
and a six channel Bose amplifier. Please see your dealer
for details.
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
The knob is capable of being turned continuously.

3-21
MUTE: Press this button to silence the system. Press it
again to turn on the sound.
RECALL: Press this button to display the station being
played or to display the clock. Clock display is available
with the ignition turned off.
SCV (Speed
-Compensated Volume): With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Each notch on the
control ring allows for more volume compensation at
faster vehicle speeds. Then, as you drive, SCV
automatically increases the volume, as necessary, to
overcome noise at any speed. The volume level should
always sound the same to you as you drive. If you don't
want to use SCV, turn the control ring counterclockwise.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display will show your selection.
TUNE: Press this knob lightly so it extends. Turn it to
choose radio stations. Push the knob back into its stored
position when you're not using it.
SEEK : Press the right or left arrow to seek to the
next or previous station and stay there. The sound will
mute while seeking.
To scan stations, press and hold either SEEK arrow for
two seconds until SCAN appears on the display. The
radio will scan to a station, play for a few seconds, then
go on to the next station. Press either SEEK arrow again
to stop scanning. The radio will scan to stations with a
strong signal only. The sound will mute while scanning.
P.SCAN (Preset Scan): The preset scan button lets you
scan through your favorite stations stored on your
pushbuttons. Select either the AM, FM1 or FM2 mode
and then press P.SCAN. It will scan through each station
stored on your pushbuttons and stop for a few seconds
before continuing to scan through all of the pushbuttons.
Press P.SCAN again or one of the pushbuttons to stop
scanning and listen to a specific preset station. P.SCAN
will light up on the display while in this mode. If one of
the stations stored on a pushbutton is too weak for the
location you are in, the radio display will show the
channel number (P1 through P6) for several seconds
before advancing to the next preset station.

3-22
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press and hold one of the six pushbuttons. The sound
will mute. When it returns, release the pushbutton.
Whenever you press that numbered pushbutton, the
station you set will return.
5. Repeat the steps for each pushbutton.
Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob clockwise to increase bass and counterclockwise to
decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob clockwise to increase treble and
counterclockwise to decrease treble. If a station is weak
or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press this knob lightly so it extends.
Turn the knob clockwise to adjust sound to the right
speakers and counterclockwise to adjust sound to the left
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Cassette Tape
Your tape player is built to work best with tapes that
are up to 30 to 45 minutes long on each side. Tapes
longer than that are so thin they may not work well in
this player.
To load a cassette tape with the ignition off, press
EJECT or RECALL. Then, insert the cassette tape.
If the ignition is on but the radio is off, the tape will
begin playing.
Once the tape is playing, use the VOL, BAL, FADE,
BASS and TREB controls just as you do for the radio.

3-23
The tape symbol and a direction arrow will be on the
display whenever a tape is being played. Any time a
tape is inserted, the top side is selected for play first.
The player automatically senses if the cassette tape is
metal or CrO
2 and adjusts for best playback sound.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.
1 PREV (Previous): Press this pushbutton or the left
SEEK arrow to search for the previous selection. A
minimum three
-second blank gap is required for the
player to stop at the beginning of the selection. The tape
direction arrow will blink while in previous mode.
2 PROG (Program): Press this pushbutton to switch
from one side of the tape to the other.
3 NEXT: Press this pushbutton or the right SEEK arrow
to search for the next selection. A minimum
three
-second blank gap is required for the player to stop
at the beginning of the selection. The tape direction
arrow will blink while in next mode. The sound will
mute while searching for the next selection.
REV 4 (Reverse): Press this pushbutton to rapidly
reverse the tape. Press this pushbutton again to stop
reversing the tape. The radio will play the last selected
station while reversing the tape. The tape direction
arrow will blink while in reverse mode.
5 (Dolby): Press this pushbutton to reduce cassette
tape noise. The double
-D symbol will appear on the
display while the player is in this mode.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
FWD 6 (Forward): Press this pushbutton to rapidly
forward the tape. Press this pushbutton again to stop
forwarding the tape. The radio will play the last selected
station while forwarding the tape. The tape direction
arrow will blink while in forward mode.
AM FM: Press this button to listen to the radio when
playing a tape or CD.
TAPE AUX (Auxiliary): Press this button to play a
tape when listening to the radio. When a tape is playing,
a lighted arrow will appear on the display and show the
direction of play. (If the radio is turned off, the tape
stays in the player and will resume playing at the point
where it stopped.)
EJECT: Press this button to stop a tape when it is
playing or to eject a tape when it is not playing. Eject
may be activated with the radio off. Cassette tapes may
be loaded with the radio and vehicle off if this button is
pressed first.

3-24
Cassette Tape Messages
CLN (Clean): If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for
five seconds. The tape symbol on the display will
flash for two seconds, indicating the feature is active.
4. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until EJECT
is pressed.AM-FM Stereo with Compact Disc Player
and Automatic Tone Control (If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
The knob is capable of rotating continuously.

3-25
SCV (Speed-Compensated Volume): With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Each notch on the
control ring allows for more volume compensation at
faster vehicle speeds. Then, as you drive, SCV
automatically increases the volume, as necessary, to
overcome noise at any speed. The volume level should
always sound the same to you as you drive. If you don't
want to use SCV, turn the control all the way down.
RECALL: Pressing this button will display the station
being played or it will display the clock. Clock display
is available with the ignition turned off.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display will show your selection.
TUNE: Press this knob lightly so it extends. Turn it to
choose radio stations. Push the knob back into its stored
position when you're not using it. SEEK : Press the right or left arrow to seek to the
next station or previous station and stay there. The radio
will seek to stations with a strong signal only. The sound
will mute while seeking.
To scan stations, press and hold either SEEK arrow for
two seconds until SCAN appears on the display. The
radio will scan to a station, play for a few seconds, then
go on to the next station. Press either SEEK arrow again
to stop scanning. The radio will scan to stations with a
strong signal only. The sound will mute while scanning.
P.SCAN (Preset Scan): Press this button to scan
through your favorite stations stored on your
pushbuttons. P.SCAN will appear on the display. The
radio will scan to the first preset station stored on your
pushbuttons, play for a few seconds, then go on to the
next station. Press this button again or one of the
pushbuttons to stop scanning. The channel number
(P1 through P6) will appear with the frequency. The
radio will scan preset stations with a strong signal only.
The sound will mute while scanning.
