2002 CADILLAC SEVILLE set clock

2-52 Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door switches and to
the exterior lamp control when a door is opened or if
you press the remote keyless entry transmitter unlock
button. If activated due to the transmitter, the lighting
will remain active for about 40 seconds. Since the
illuminated entry system uses the light sensor, it must be
dark outside in order for the courtesy lamps to turn on.
The courtesy lamps turn off approximately 25 seconds
after the last door is closed. They will dim to off if the
ignition key is placed in ON, or immediately deactivate
if the power locks are activated.
Parade Dimming
This feature prohibits dimming of the digital displays
and backlighting during daylight hours when the key is
in the ignition and the headlamps are on. This feature
operates with the light sensor for the Twilight Sentinel
and is fully automatic. When the light sensor reads
darkness outside and the parking lamps are active,
the digital displays can be adjusted by turning the
instrument panel brightness knob counterclockwise
to dim and clockwise to brighten lighting.
Reading Lamps
The front reading lamps are located in the overhead
console. These lamps and the interior courtesy lamps
come on when a door is opened and it is dark outside.
The rear reading lamps will not come on when a front
door is opened.
The rear courtesy lamps are located on the rear headliner
above the rear seat outboard positions. When a rear door
is opened, both the front and rear reading lamps come
on with the courtesy lamps.
Press the button near each lamp to turn it on and off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine
when the battery is in a heavy discharge condition.
During times of high electrical loading, the engine
may idle at a higher revolutions per minute (rpm)
setting than normal to make sure the battery charges.
High electrical loads may occur when several of the
following are on: headlamps, high beams, fog lamps,
rear window defogger, the climate control fan at high
speeds, heated seats and engine cooling fans.

2-89

AVG MPH (Average Miles per Hour): This
message shows the average speed you have traveled
at since the last time you reset the value. To reset the
value, press the INFO button to display AVG MPH
then press and hold the INFO RESET button until
0.0 AVG MPH is displayed.

TIMER: This feature is like a stopwatch, in that
you can clock the time it takes to get from one point
to another.
To operate, press the INFO button to display TIMER.
Each of the fields for the hours, minutes and seconds
are two numeric digits.
Once TIMER 00:00:00 is displayed, press the
ON/OFF button to start the timing feature. Press the
ON/OFF button again to stop it. If you will be starting
and stopping your vehicle, during a trip for instance,
the TIMER feature will automatically start timing
where it left off when you last stopped. To reset it,
press and hold the INFO RESET button until the
display reads TIMER 00:00:00. Press the INFO
button to exit from the TIMER display.
ENGINE OIL LIFE: Press the INFO button to
display ENGINE OIL LIFE, then press and hold the
INFO RESET button until 100% ENGINE OIL
LIFE is displayed. (This only needs to be reset after
you have had the oil changed.)

TRANSMISSION FLUID LIFE MONITOR:
Under normal conditions, the rate of deterioration
of the transmission fluid is slow. See ªMaintenance
Scheduleº in the Index for proper fluid and change
intervals. To reset the transmission fluid life, press
the INFO button to display TRANS FLUID LIFE,
then press and hold the INFO RESET button
until 100% TRANS FLUID LIFE is displayed.
(This only needs to be reset after you have had the
fluid changed.)
ON/OFF: Pressing this button turns the Programming
and Personalization Features on and off. (FEATURE
PROGRAMMING must be displayed on the DIC to
begin actual programming.) This button also starts and
stops the timer.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control Panel
3
-6 Air Conditioning
3
-6 Heating
3
-6 Defogging and Defrosting
3
-7 Rear Window Defogger
3
-8 Ventilation System
3
-10 HVAC Steering Wheel Controls
3
-10 Climate Control Personalization (If Equipped)
3
-12 Audio Systems
3
-12 Setting the Clock
3
-12 AM-FM Stereo with Cassette Tape and
Compact Disc Player
3
-17 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
Systems (RDS), Digital Signal
Processing (DSP) and XM
Satellite
Radio Service (If Equipped)3
-27 Navigation/Radio System (Option)
3
-28 Console-Mounted CD Changer (Option)
3
-30 Radio Personalization with Home and
Away Feature (If Equipped)
3
-31 Theft-Deterrent Feature
3
-31 Audio Steering Wheel Controls
3
-32 Understanding Radio Reception
3
-33 Tips About Your Audio System
3
-34 Care of Your Cassette Tape Player
3
-35 Care of Your Compact Discs
3
-35 Care of Your Compact Disc Player
3
-36 Diversity Antenna System
3
-36 XM Satellite Radio Antenna (If Equipped)

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
Climate Control Panel
Your vehicle is equipped with a dual-zone electronic
climate control system. This system can automatically
adjust and control temperature, fan speed, air delivery
mode, air conditioning operation and air intake. You can
use the AUTO (automatic) setting or override the
automatic operation by manually altering the settings.If your vehicle is equipped with the climate control
personalization feature, you will be able to program
your preferred climate control settings and recall them
using your remote keyless entry transmitter. See
ªClimate Control Personalizationº in the Index.
TEMP (Temperature): These knobs adjust the air
temperature coming through the system. Turn a TEMP
knob clockwise to increase the temperature and
counterclockwise to decrease the temperature.
Both TEMP knobs adjust from 60
F (16
C) to
90
F (32
C) independent of each other. It is
recommended that the passenger's setting stay no more
than four degrees warmer or cooler in temperature from
the driver's setting.

3-12
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock
Press and hold HR or MN until the time display begins
to change. Release the button as you get close to the
correct time. The time may be set anytime the clock is
displayed. There is a two
-second delay before the clock
goes into time
-set mode.
AM-FM Stereo with Cassette Tape and
Compact Disc Player
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.

3-15

RW (Rewind): Press the left arrow to rewind the
tape rapidly. The radio will play while the tape rewinds.
You may use your station pushbuttons to tune to another
radio station while in rewind. Press the left arrow again
to return to playing speed.
FF
 (Fast Forward): Press the right arrow to fast
forward to another part of the tape. The radio will play
while the tape advances. You may use your station
pushbuttons to tune to another radio station while in
fast forward. Press the right arrow again to return to
playing speed.
~' SEEK !': Press the up or down arrow to seek to
the next or previous selection on the tape. Your tape
must have at least three seconds of silence between each
selection for the SEEK arrows to work. The sound will
mute while seeking.
SCAN: Press this button to listen to selections for a
few seconds. The tape will go to a selection, play for a
few seconds, then go on to the next selection. Press this
button again to stop scanning.
SIDE: Press this button to change the side of the tape
that is playing.
(Eject): Press this button to the right of the
cassette tape player to remove a tape. The radio will
play. Eject may be activated with the radio off and/or
the ignition off.
Cassette Tape Messages
If an error occurs while trying to play a cassette tape, it
could be for one of the following reasons:

The cassette tape is tight and the cassette player
cannot turn the hubs of the tape. Hold the cassette
tape with the open end down and try turning the right
hub counterclockwise with a pencil. Flip the tape
over and repeat. If the hubs do not turn easily, your
cassette tape may be damaged and should not be
used in the player. Try a new tape to be sure your
player is working properly.

The cassette tape is broken. (Check to see if your
tape is broken. Try a new tape.)
CLEAN TAPE: If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.

3-17
Compact Disc Messages
If the disc comes out, it could be for one of the
following reasons:

If you're driving on a very rough road. When the
road becomes smooth the disc should play.

If it's very hot. When the temperature returns to
normal, the disc should play.

The disc is upside down.

It is dirty, scratched or wet.

The air is very humid. (If so, wait about an hour and
try again.)

If the CD is not playing correctly, for any other
reason, try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.AM-FM Stereo with Cassette Tape
and Compact Disc Player with Radio
Data Systems (RDS), Digital Signal
Processing (DSP) and XM Satellite
Radio Service (If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.

3-21
HR (Hour) or MN (Minute): When tuned to an RDS
station, press these buttons to display the time for the
current station. STATION TIME IS will be displayed.
If a time has not been sent to the radio, NO STATION
TIME will be displayed. If you have recently tuned to
the station, you may need to wait a minute before the
time is available to the radio. To set the clock to the
current displayed station time, press HR or MN until
TIME UPDATED is displayed. You must be tuned to
an FM RDS station.
RDS Messages
ALERT: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT appears on the display
when an alert announcement plays. The radio uses
TA volume during these announcements. To increase
volume, turn the PWR/VOL knob clockwise. Turn it
counterclockwise to decrease volume. TA VOLUME
will appear on the display while the volume is being
adjusted. When an alert announcement comes on the
current radio station or a related network station, you
will hear it, even if the volume is muted or a cassette
tape or compact disc is playing. If the radio tunes to arelated network station for an alert announcement, it will
return to the original station when the announcement is
finished. If the cassette tape or compact disc player is
playing, play will stop for the announcement and resume
when the announcement is finished.
TA (Traffic Announcement): This feature allows
the radio to receive traffic announcements even with
the volume muted, or when listening to a CD or
cassette tape.
When the TA button is pressed and released, the radio
will search for a station with TA if the current station is
not TA capable. During the search TA will flash on the
display. Once a TA station is found, TA will appear on the
display and the traffic announcement will be played. If no
station broadcasting traffic announcements is found, NO
TRAFFIC STATION FOUND will appear on the display.
If the TA button is pressed and held for two seconds, the
radio will search for the next available TA station.
While a traffic announcement plays, the radio uses a
special type of volume called TA volume. To increase
TA volume, turn the VOL knob clockwise. Turn it
counterclockwise to decrease volume. TA VOLUME will
appear on the display while the volume is being adjusted.
