2002 CADILLAC SEVILLE air conditioning

2-94
CHECK WASHER FLUID - 25: This message means
that your vehicle is low on windshield washer fluid.
DRIVER DOOR AJAR
- 140: This message will
display anytime the key is in ON, the transaxle is not
in PARK (P) and the driver's door is open or ajar.
A chime will sound when the vehicle's speed is greater
than 3 mph (4.8 km/h).
DRIVER NO. X (1 OR 2): This message will be
displayed with the key in ON and while entering
FEATURE PROGRAMMING, but only if the vehicle
is equipped with memory seats. The message will show
which driver is activating the personalization feature.
It will only stay on for five seconds. This message can
be customized for you by your dealer.
ENGINE COOLANT HOT, IDLE ENGINE
- 44:
This message will appear when the engine coolant
temperature is over 262
F (128
C). Stop and allow
your vehicle to idle in PARK (P) until it cools down and
the message is removed. Do not increase engine speed
above a normal idle. If it does not cool down, turn off
the engine and have it serviced before driving it again.
Severe engine damage can result from an overheated
engine. See ªEngine Overheatingº in the Index.ENGINE HOT
-AC OFF - 16: This message displays
when the engine coolant becomes hotter than the normal
operating temperature. To avoid added strain on a hot
engine, the air conditioning compressor is automatically
turned off. When the coolant temperature returns to
normal, the A/C operation will automatically resume.
You can continue to drive your vehicle. If this message
continues to appear, have the system repaired as soon as
possible to avoid compressor damage.
ENGINE OVERHEATED, STOP ENGINE
- 42:
This message will appear when the engine has
overheated. Stop and turn the engine off immediately to
avoid severe engine damage. See ªEngine Overheatingº
in the Index. A multiple chime will also sound when this
message is displayed.
ENGINE POWER REDUCED
- 41: This message
informs you that the vehicle is reducing engine power
because the transaxle is being placed in gear under
conditions that may cause damage to the vehicle's
engine, transaxle or ability to accelerate.
FUEL LEVEL LOW
- 11 : This message serves as
a warning that the fuel level in the tank is critically low.
Stop for fuel soon. A single chime will sound when this
message is displayed.

2-95
HEADLAMPS SUGGESTED - 23: If it's dark enough
outside and the headlamps and Twilight Sentinel

controls are off, this message will display on the DIC.
This message informs the driver that turning on the
exterior lamps is recommended even though the DRL
are still illuminated. It has become dark enough outside
to require the headlamps and/or other exterior lamps.
This message will also appear if the optional
Rainsense wiping feature is on and the Twilight
Sentinel is off.
ICE POSSIBLE
- 13: This message appears when
the outside air temperature is cold enough to create
icy road conditions.
LEFT REAR DOOR AJAR
- 142: The left rear door
is open or ajar when this message appears. The ignition
must be in ON and the transaxle not in PARK (P) for
this message to display. A chime will sound if the
vehicle's speed is greater than 3 mph (5 km/h).
OIL PRESSURE LOW STOP ENGINE
- 35: If this
message appears while the engine is running, stop the
engine and do not operate it until the cause of low oil
pressure is corrected. Severe damage to the engine can
result. A multiple chime will sound when this message
is displayed.PASSENGER DOOR AJAR
- 141: The passenger's
door is open or ajar when this message appears.
The ignition must be in ON and the transaxle not in
PARK (P) for this message to display. A chime
will sound if the vehicle's speed is greater than
3 mph (5 km/h).
RIGHT REAR DOOR AJAR
- 143: The right
rear door is open or ajar when this message appears.
The ignition must be in ON and the transaxle not in
PARK (P) for this message to display. A chime
will sound if the vehicle's speed is greater than
3 mph (5 km/h).
SERVICE AC SYSTEM
- 14: This message
appears when the electronic sensors that control the air
conditioning and heating systems are no longer working.
Have the climate control system serviced if you notice a
drop in heating and air conditioning efficiency.
SERVICE AIR BAG
- 83: There is a problem with
the supplemental inflatable restraint (air bag) system
when this message appears. Let only a qualified
technician work on your vehicle. Have your vehicle
serviced by your dealership immediately.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control Panel
3
-6 Air Conditioning
3
-6 Heating
3
-6 Defogging and Defrosting
3
-7 Rear Window Defogger
3
-8 Ventilation System
3
-10 HVAC Steering Wheel Controls
3
-10 Climate Control Personalization (If Equipped)
3
-12 Audio Systems
3
-12 Setting the Clock
3
-12 AM-FM Stereo with Cassette Tape and
Compact Disc Player
3
-17 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
Systems (RDS), Digital Signal
Processing (DSP) and XM
Satellite
Radio Service (If Equipped)3
-27 Navigation/Radio System (Option)
3
-28 Console-Mounted CD Changer (Option)
3
-30 Radio Personalization with Home and
Away Feature (If Equipped)
3
-31 Theft-Deterrent Feature
3
-31 Audio Steering Wheel Controls
3
-32 Understanding Radio Reception
3
-33 Tips About Your Audio System
3
-34 Care of Your Cassette Tape Player
3
-35 Care of Your Compact Discs
3
-35 Care of Your Compact Disc Player
3
-36 Diversity Antenna System
3
-36 XM Satellite Radio Antenna (If Equipped)

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
Climate Control Panel
Your vehicle is equipped with a dual-zone electronic
climate control system. This system can automatically
adjust and control temperature, fan speed, air delivery
mode, air conditioning operation and air intake. You can
use the AUTO (automatic) setting or override the
automatic operation by manually altering the settings.If your vehicle is equipped with the climate control
personalization feature, you will be able to program
your preferred climate control settings and recall them
using your remote keyless entry transmitter. See
ªClimate Control Personalizationº in the Index.
TEMP (Temperature): These knobs adjust the air
temperature coming through the system. Turn a TEMP
knob clockwise to increase the temperature and
counterclockwise to decrease the temperature.
Both TEMP knobs adjust from 60
F (16
C) to
90
F (32
C) independent of each other. It is
recommended that the passenger's setting stay no more
than four degrees warmer or cooler in temperature from
the driver's setting.

3-4
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to cool the air quickly or
limit odors entering your vehicle. Press this button again
to turn off the recirculation feature.
If you notice the windows fogging, press the
recirculation button to exit the recirculation mode.
Recirculation is not available in the defrost mode.
A/C (Air Conditioning): Press this button to turn the
air conditioning compressor on and off. The system will
cool and dehumidify the air inside the vehicle.
When the compressor is off, A/C OFF appears on the
climate control panel display. Press the button again and
the compressor will turn back on.
The A/C OFF feature is not available in the
defrost mode.
AUTO (Automatic): The AUTO button will turn on the
system and automatically adjust the fan speed, air
delivery mode and temperature to your previously
programmed settings.When the system is set for automatic operation, sensors
will control the air delivery mode. Air will come from
the floor ducts, the instrument panel or windshield
outlets. The fan speed will vary as the system maintains
the selected temperature setting.
To find your comfort zone, start with the 75
F (24
C)
setting and allow about 30 minutes for the system to
regulate. Turn the TEMP knob to adjust the temperature if
necessary. If you choose 60
F (16
C), the system will
remain at that maximum cooling setting and will not
regulate fan speed. If you choose 90
F (32
C), the system
will remain at that maximum heating setting and will not
regulate fan speed. Choosing either maximum setting will
not cause the system to heat or cool any faster.
With the automatic setting, the air conditioning
compressor cycles on and off when needed to cool the
air. In cold weather, when the system senses the need for
heat, the airflow will be directed out the floor ducts. As
the interior temperature approaches a desired setting, the
fan speed will decrease. To maintain interior comfort,
the airflow may move to the instrument panel air outlets
and floor ducts. On bright sunny days in cold weather,
the airflow may come out of the instrument panel outlets
to maintain comfort and prevent stuffiness.

3-6 Air Conditioning
On hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best. Your A/C setting
may be adjusted automatically or manually. It may also
be set separately on the passenger's side from the
driver's side. See ªClimate Control Panelº earlier in this
section for more information.
Heating
Adjust the interior temperature to a comfortable level.
If the fan speed needs adjusting, press the up or down
arrow on the fan switch. Adjusting the fan speed will
cancel the cold air delay.
Outside air will be brought in and sent through the floor
ducts and the instrument panel outlets. The heater works
best if you keep your windows closed while using it. In
automatic operation, your fan will not run at high speed
to minimize warm
-up time.
Defogging and Defrosting
Use FRONT (defrost) on cool and humid days to keep
the windshield and side windows clear. This setting will
remove fog or ice from the windshield quickly in
extremely humid or cold conditions. If you desire to
have more air on your feet, turn the control to the defog
mode. You may do this by pressing the right or left
arrow on the MODE button.
Press the up or down arrow on the fan switch to control
the fan speed. You may also adjust the temperature by
turning a TEMP knob.
Recirculation and the A/C OFF feature are not available
in the defrost mode.

3-10 HVAC Steering Wheel Controls
(If Equipped)
Some heating and cooling
controls can be adjusted at
the steering wheel. Other
touch controls operate some
audio controls. See ªAudio
Steering Wheel Controlsº in
the Index.
~TEMP !(Temperature): Press the up arrow on
the control to increase the temperature and the down
arrow to decrease temperature.
!~
(Fan): Press the up arrow on the control to increase
the fan speed and the down arrow to decrease fan speed.
Climate Control Personalization
(If Equipped)
This feature allows two different drivers to store and
recall their own climate control settings. These settings
include the set temperatures for the driver and front
passenger, the air conditioning, the mode and the
fan speed. (This feature does not recall recirculation
or defrost).
Each driver (1 or 2) has a corresponding number located
on the back of the remote keyless entry transmitter.
Settings recalled by the system are determined by which
transmitter is used to unlock the vehicle. After the
button with the unlock symbol is pressed, the settings
are automatically recalled.
The settings can also be recalled when the key is placed
in the ignition. If the settings are recalled this way, the
system will recall the settings of the last driver. If these
are not the correct settings, you must press the button
with the unlock symbol on remote keyless entry
transmitter that was used when you saved your settings.

3-11
The settings can be changed by briefly pressing the
corresponding memory button (1 or 2) located on the
driver's door panel.
Further programming for recalling climate control
personalization settings can be done using the DIC.
You can select or not select the following:

Automatic recall of the climate control settings when
the vehicle is unlocked with the remote keyless entry
transmitter, or

Automatic recall of the climate control settings when
a key is placed in the ignition.For programming information, see ªVehicle
Programming and Personalization Featuresº in
the Index.
Your vehicle is equipped with a dual
-zone electronic
climate control system. This system can automatically
adjust and control temperature, fan speed, air delivery
mode, air conditioning operation and air intake. You can
use the AUTO (automatic) setting or override the
automatic operation by manually altering the controls.
