2-12
Liftgate/Liftglass
CAUTION:
It can be dangerous to drive with the liftgate or
liftglass open because carbon monoxide (CO) gas
can come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the liftgate or liftglass
open or if electrical wiring or other cable
connections must pass through the seal between
the body and the liftgate or liftglass:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on VENT or OUTSIDE AIR. That will
force outside air into your vehicle.
See ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
To open a mechanical lock system from the outside,
insert the key into the lock and turn it counterclockwise
to unlock the liftgate and liftglass.
The liftglass can be opened using the pushbutton on the
liftgate after the doors have been unlocked. This can be
done by using either the power door locks or the remote
keyless entry system.
To open the entire liftgate, lift the handle located in the
center of the door.
To lock a power lock system from the outside, insert the
key into the lock button and turn it clockwise. All doors
will lock. You may also use the keyless entry system or
the power door locks to lock the liftgate and liftglass.

3-2
Comfort Controls
Electronic Climate Control System
Fan Knob
The knob on the left side of the electronic climate control
panel is used to regulate the fan speed. To manually
increase airflow, move the knob clockwise. To manually
decrease airflow, move it counterclockwise.
OFF: If the knob is in OFF, outside air will still enter
the vehicle, and will be directed based on the position of
the mode knob.
AUTO: If the knob is in AUTO, the fan speed will vary
as the system maintains the selected temperature.
When both the fan knob and mode knob are in the AUTO
position, the system will then automatically maintain the
desired cabin temperature as selected by the temperature
knob. Manual operation is also available.Temperature Knob
The middle knob on the control panel is used to select
the desired air temperature in your vehicle. This knob
will allow you to adjust the interior air temperature
independent of the mode knob setting. Move the knob
clockwise toward 82 for warmer air. Move the knob
counterclockwise toward 66 for cooler air. When the
system is set for automatic operation, sensors will
control the fan speed.
Full Hot: If you turn the temperature knob past 82, the
system will go into the ªfull hotº mode. The system will
remain at that maximum heating setting and the fan will
blow at the speed to which the fan knob is set. If the fan
is in AUTO, it will run at full speed.
Full Cold: If you turn the temperature knob past 66, the
system will go into the ªfull coldº mode. The system
will remain at that maximum cooling setting and the fan
will blow at the speed to which the fan knob is set. If the
fan is in AUTO, it will run at full speed.

3-5
Pressing the recirculation button will cancel outside air
operation. To return to normal system operation and to
prevent stale passenger compartment air, be sure to
return to the outside air position.
Recirculation will not be available in floor, blend or
defrost modes. This helps reduce window fogging.
If the recirculation button is pressed in theses modes,
the LED indicator for recirculation will flash three times
indicating that forced outside air is activated and
recirculation is not available.
If the air conditioning system is activated and system
demand is high in situations such as city traffic, idling,
or very hot weather, the system will automatically
switch from outside air to recirculation. The LED
indicator will not change. After the demand on the
system is not so great, the system will return to
outside air.
(A/C): Press this button to turn the air
conditioning on and off. The system will cool and
dehumidify the air inside the vehicle when the A/C light
is on. When in AUTO, the A/C is automatically engaged
when necessary.
Air conditioning will be automatically disabled when
the outside temperature drops below a level which air
conditioning is ineffective.
Rear Air Conditioning and Rear Heater
(With Sunroof)
Your vehicle has the rear air conditioning and rear heater
system combination. Controls are provided to regulate
temperature, location and speed of the airflow.
Front Control
To adjust the airflow speed, turn the fan control knob
located on the left side to the desired setting.
To regulate the airflow direction, adjust the right knob on
the control panel. Turn the knob clockwise for floor vent
airflow or counterclockwise for headliner vent airflow.
Generally, the upper vents are used for air conditioning
and the floor vents for heating. The knob can be set to
any blend setting.
To adjust the air temperature, turn the temperature knob
on the center of the control panel.
For warmer air, turn the knob clockwise toward red. For
cooler air, turn the knob counterclockwise toward blue.

3-6 Rear Air Conditioning and Heating Systems
with Electronic Climate Control System
(Without Sunroof)
Front Control
Rear Control
With this system the rear passengers can control the air
temperature, air flow and air speed. The climate control
has three knobs.To adjust the airflow speed, turn the fan knob located on
the left side of the control panel to the desired setting.
The system can be controlled from the front controls as
well as the rear controls. Choosing AUTO from the front
will control the rear settings. Choosing OFF from the
front control will also turn off the rear climate control.
When the front control is set to REAR, the rear controls
can be used by rear seat passengers.
To adjust the air temperature on either control panel,
turn the temperature knob on the center of the control
panel. For warmer air, turn the knob clockwise
toward 82. Turn the knob counterclockwise toward 66
for cooler air.
To regulate the airflow direction, adjust the right knob
on the control panel. Turn the knob clockwise for floor
vent airflow or counterclockwise for headliner vent
airflow. Generally, the upper vents are used for air
conditioning and the floor vents for heating. The knob
can be set to any blend setting.

3-11 AM-FM Stereo with Cassette Tape
Player (Bose

)
Included with the AM-FM Stereo with Cassette Tape
Player is a six disc CD changer. It is equipped with
ten Bose

high performance speakers, an Acoustimass

bass module and a seven channel Bose amplifier.
Please see your dealer for details.Playing the Radio
PWR VOL: Press this knob to turn the system on
and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume. The knob
is capable of being turned continuously.
SCV: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Then, as you drive,
SCV automatically increases the volume, as necessary,
to overcome noise at any particular speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, turn the control all the
way down. Each notch on the control ring allows for
more volume compensation at faster vehicle speeds.
REAR DSPL: When the main radio is turned on, press
this button to turn on the rear seat audio display on the
main radio. Press it again to turn the rear seat audio
display off.
PR: Press this button to turn rear seat audio on or off.
The light to the right of the button will illuminate to
indicate that rear seat audio is on.

3-13
Setting the Tone
BASS: Press lightly on this knob to release it from its
stored position. Turn the knob clockwise to increase
bass and counterclockwise to decrease bass.
TREB: Press lightly on this knob to release it from its
stored position. Turn the knob clockwise to increase
treble and counterclockwise to decrease treble. If a
station is weak or noisy, you may want to decrease
the treble.
Push these knobs back into their stored positions when
you're not using them.
Adjusting the Speakers
FADE: Press lightly on this knob to release it from its
stored position. Turn the control clockwise to adjust the
sound to the front speakers and counterclockwise for the
rear speakers. The middle position balances the sound
between the speakers.
BAL: Press lightly on this knob to release it from its
stored position. Turn the control clockwise to adjust
sound to the right speakers and counterclockwise to
adjust sound to the left speakers. The middle position
balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in
this player.
To load a cassette tape with the ignition off, press
EJECT. Then, insert the cassette tape. If the ignition is
on but the radio is off, the tape will begin playing.
Once the tape is playing, use the volume, balance, fade,
bass and treble controls just as you do for the radio. The
tape symbol and a direction arrow will be on the display
whenever a tape is being played. Anytime a tape is
inserted, the top side is selected for play first.
The player automatically senses if the cassette tape is
metal or CrO
2 and adjusts for best playback sound.
1 PREV: Press this button or the SEEK left arrow to
search for the previous selection. A minimum
three
-second blank gap is required for the player to stop
at the beginning of the selection. The tape direction
arrow will blink during the SEEK operation.
2 PROG: Press this button to switch from one side of
the tape to the other.

3-17
VOL: Press this knob lightly so it extends. Turn
the knob clockwise to increase volume and
counterclockwise to decrease volume. Push the knob
back into its stored position when you're not using it.
The upper VOL knob controls the upper headphone and
the lower VOL knob controls the lower headphone.
TAPE CD: Press this button to switch between the tape
and CD changer if all are loaded. Press AM FM to
return to the radio when a cassette tape or CD is playing.
The inactive tape or CD will remain safely inside the
radio for future listening.
P.SET PROG: The front passengers must be listening
to something different for each of these functions
to work:

Press this button to seek through the preset radio
stations set on the pushbuttons on the main radio.

When a cassette tape is playing, press this button to
go to the other side of the tape.

When a CD is playing in the CD changer, press this
button to select a disc.Compact Disc Changer
The compact disc changer plays up to six standard size
CDs continuously. Individual CDs may be loaded into or
ejected from any position.
A green light on each numbered button indicates a CD is
loaded in the respective position. An amber light on a
numbered button indicates that a CD is playing. When
loading CDs, the loading slot indicators turn amber to
indicate that the player is ready to accept a CD. CDs can
be loaded or ejected with the radio or the ignition being
on or off.
