vi
GENERAL MOTORS, GM and the GM Emblem,
CADILLAC, the CADILLAC Crest & Wreath and
the name ESCALADE are registered trademarks of
General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes after
that time without further notice. For vehicles first sold in
Canada, substitute the name ªGeneral Motors of Canada
Limitedº for Cadillac Motor Car Division whenever it
appears in this manual.
Please keep this manual in your vehicle, so it will
be there if you ever need it when you're on the road.
If you sell the vehicle, please leave this manual in it
so the new owner can use it.
We support voluntary
technician certification.
For Canadian Owners Who Prefer a
French Language Manual:
Aux propri‡taires canadiens: Vous pouvez vous
procurer un exemplaire de ce guide en fran†ais chez
votre concessionaire ou au:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
2-96
Language
English: All information displayed in English.
French: All information displayed in French.
Spanish: All information displayed in Spanish.
Arabic: All information displayed in Arabic.
Display Units
English: Units displayed in English units.
Metric: Units displayed in metric units.
Day/Date/Time
The RESET button will enable the operator to reset
the day/date/time. Each press of the RESET button
will scroll through the following: set year, set month,
set day, set hour, set minutes and set AM/PM.
Whichever is currently selected (i.e. year, month,
day, etc.) will flash. The arrow button is then used to
adjust the value. Each press of the arrow button will
change the value by one. If the arrow button is
pushed and held, the value will keep changing until
the button is released.
While in menu mode, the SIC will display the
day/date if no buttons have been pressed for more
than 15 seconds.Language and Personalization Reset
Press and hold the MENU button. After two seconds,
the display will begin cycling through the languages
at one second intervals. Release the MENU button
when the desired language is displayed.
The previous action will also reset the
personalization values to their factory default
settings which are as follows:
1.Automatic Door Lock: Enabled
2.Automatic Door Unlock: All
3.Remote Lock Feedback: Horn
4.Remote Unlock Feedback: Lamps
5.Headlamp Delay: 30 seconds
6.Perimeter Lamps: Enabled
7.Memory Position Recall: Key In
8.Exit Position of Seat: Enabled
9.Mirror Reverse Tilt: Passenger
10.Alarm Warning: Horn and Lamps
11.Display Units: English
