2002 CADILLAC ESCALADE CD player

Section
3
Comfort Controls and Audio Systems
Section
4
Section
5
Table of Contents (cont'd)
Defensive Driving
Drunken Driving
Control of a Vehicle
Braking
SteeringDriving Tips for Various Road Conditions
Off-Road Driving
Loading Your Vehicle
Towing a Trailer Heating and Air Conditioning
Radio/Cassette Player/CD ChangerRadio Theft-Deterrent Feature
Steering Wheel Controls
Hazard Warning Flashers
Jump Starting
Towing Your VehicleEngine Overheating
Changing a Flat Tire
If You're Stuck
Problems on the Road Your Driving and the Road
iii

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Electronic Climate Control System
3
-7 Air Conditioning
3
-7 Heating
3
-8 Defogging and Defrosting
3
-8 Rear Window Defogger
3
-9 Ventilation System
3
-10 Audio Systems
3
-11 AM-FM Stereo with Cassette Tape
Player (Bose
)3
-15 Rear Seat Audio (RSA)
3
-17 Compact Disc Changer
3
-20 Theft-Deterrent Feature
3
-22 Audio Steering Wheel Control
3
-23 Understanding Radio Reception
3
-23 Tips About Your Audio System
3
-24 Care of Your Cassette Tape Player
3
-26 Care of Your Compact Discs
3
-26 Care of Your Compact Disc Changer
3
-26 Diversity Antenna

3-11 AM-FM Stereo with Cassette Tape
Player (Bose

)
Included with the AM-FM Stereo with Cassette Tape
Player is a six disc CD changer. It is equipped with
ten Bose

high performance speakers, an Acoustimass

bass module and a seven channel Bose amplifier.
Please see your dealer for details.Playing the Radio
PWR VOL: Press this knob to turn the system on
and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume. The knob
is capable of being turned continuously.
SCV: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Turn the control ring behind the upper
knob clockwise to adjust the SCV. Then, as you drive,
SCV automatically increases the volume, as necessary,
to overcome noise at any particular speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, turn the control all the
way down. Each notch on the control ring allows for
more volume compensation at faster vehicle speeds.
REAR DSPL: When the main radio is turned on, press
this button to turn on the rear seat audio display on the
main radio. Press it again to turn the rear seat audio
display off.
PR: Press this button to turn rear seat audio on or off.
The light to the right of the button will illuminate to
indicate that rear seat audio is on.

3-13
Setting the Tone
BASS: Press lightly on this knob to release it from its
stored position. Turn the knob clockwise to increase
bass and counterclockwise to decrease bass.
TREB: Press lightly on this knob to release it from its
stored position. Turn the knob clockwise to increase
treble and counterclockwise to decrease treble. If a
station is weak or noisy, you may want to decrease
the treble.
Push these knobs back into their stored positions when
you're not using them.
Adjusting the Speakers
FADE: Press lightly on this knob to release it from its
stored position. Turn the control clockwise to adjust the
sound to the front speakers and counterclockwise for the
rear speakers. The middle position balances the sound
between the speakers.
BAL: Press lightly on this knob to release it from its
stored position. Turn the control clockwise to adjust
sound to the right speakers and counterclockwise to
adjust sound to the left speakers. The middle position
balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in
this player.
To load a cassette tape with the ignition off, press
EJECT. Then, insert the cassette tape. If the ignition is
on but the radio is off, the tape will begin playing.
Once the tape is playing, use the volume, balance, fade,
bass and treble controls just as you do for the radio. The
tape symbol and a direction arrow will be on the display
whenever a tape is being played. Anytime a tape is
inserted, the top side is selected for play first.
The player automatically senses if the cassette tape is
metal or CrO
2 and adjusts for best playback sound.
1 PREV: Press this button or the SEEK left arrow to
search for the previous selection. A minimum
three
-second blank gap is required for the player to stop
at the beginning of the selection. The tape direction
arrow will blink during the SEEK operation.
2 PROG: Press this button to switch from one side of
the tape to the other.

3-14
3 NEXT: Press this button or the SEEK right arrow to
search for the next selection. A minimum three
-second
blank gap is required for the player to stop at the
beginning of the selection. The tape direction arrow will
blink during the SEEK operation. The sound will mute
while searching for the next selection.
4 REV: Press this button to rapidly reverse the tape to
the beginning of the cassette or until you press REV 4
again. The radio will play the last selected station while
reversing the tape. The tape direction arrow will blink
during the reverse operation.
5
: Press this button to reduce cassette tape noise.
The double
-D symbol will appear on the display while
the player is in this mode.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
6 FWD: Press this button to rapidly forward the tape to
the end of the cassette or until you press FWD again.
The radio will play the last selected station while
forwarding the tape. The tape direction arrow will blink
during the forward operation.
AM FM: Press this button to switch from a tape to
the radio.TAPE: Press this button to play a tape if you have a tape
loaded in the cassette tape player and the radio is turned
on. When a tape is playing, a lighted arrow will appear
on the display and show the direction of play. If the
radio is turned off, the tape will remain in the player and
resume playing at the point where it stopped.
EJECT: Press this button to remove the tape. The radio
will now play. Eject can be used with either the ignition
or radio off. To load a cassette tape with the ignition or
radio off, press EJECT before loading the cassette.
CHANGER: Press this button to play a CD if you have
a CD loaded in the CD changer. When a CD is playing
the disc number and track number will be displayed.
Press this button again and elapsed time will appear on
the display. See ªCompact Disc Changerº later in
this section.
CLN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold EJECT for five seconds to
reset the CLN indicator. The radio will display
--- to
show the indicator was reset.

3-15
CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, perform the
following steps:
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE button for five seconds.
The tape symbol on the display will flash for
two seconds, indicating the feature is active.
4. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until EJECT
is pressed.Rear Seat Audio (RSA)
This feature allows rear seat passengers to listen to and
control any of the music sources, including AM FM,
cassette tapes and CDs, through the Rear Seat Audio
(RSA) controller. However, the rear seat passengers can
only control the music sources that the front seat
passengers are not listening to.

3-17
VOL: Press this knob lightly so it extends. Turn
the knob clockwise to increase volume and
counterclockwise to decrease volume. Push the knob
back into its stored position when you're not using it.
The upper VOL knob controls the upper headphone and
the lower VOL knob controls the lower headphone.
TAPE CD: Press this button to switch between the tape
and CD changer if all are loaded. Press AM FM to
return to the radio when a cassette tape or CD is playing.
The inactive tape or CD will remain safely inside the
radio for future listening.
P.SET PROG: The front passengers must be listening
to something different for each of these functions
to work:

Press this button to seek through the preset radio
stations set on the pushbuttons on the main radio.

When a cassette tape is playing, press this button to
go to the other side of the tape.

When a CD is playing in the CD changer, press this
button to select a disc.Compact Disc Changer
The compact disc changer plays up to six standard size
CDs continuously. Individual CDs may be loaded into or
ejected from any position.
A green light on each numbered button indicates a CD is
loaded in the respective position. An amber light on a
numbered button indicates that a CD is playing. When
loading CDs, the loading slot indicators turn amber to
indicate that the player is ready to accept a CD. CDs can
be loaded or ejected with the radio or the ignition being
on or off.

3-18
You must load CDs with the label side up. If you do not,
the player will automatically eject the CDs.
NOTICE:
Loading CDs with adhesive labels will damage
the player.
To load a CD perform the following steps:
1. Press the LOAD button. Available positions will
blink amber.
2. Select a position by pressing the desired numbered
button with the amber blinking light. If a button is
not pressed within five seconds, the changer will go
to the lowest available position.
3. Load the CD when the loading slot indicators turn
amber. An internal door will open allowing a single
CD to be inserted into the changer. After
approximately ten seconds the changer will be
ready to play.To load two or more CDs perform the
following steps:
1. Press and hold the LOAD button. The first CD will
be loaded into the lowest numbered empty position.
2. Load a single CD when the loading slot indicators
turn amber. After about ten seconds the changer will
cycle to the next available position.
3. Repeat Step 2 until all CDs are loaded into all of the
desired positions. If you do not wish to load all of the
positions, you can cancel the load all function by
pressing a button with a green flashing indicator light
or by waiting 20 seconds for the changer to time out.
To eject a single CD perform the following steps:
1. Press the eject symbol (upward pointing arrow
button). The buttons with loaded CDs will
blink amber.
2. Press one of the amber blinking buttons to select the
location of the CD you want to eject. The changer
will move to that location and eject the CD. If you
do not remove the CD from the player within
ten seconds, it will be reloaded. If the eject button
is pressed and a numbered location button is not
pressed within five seconds, the current or last
played CD will be ejected.
To eject all CDs, press and hold the eject button.
