Page 169 of 186
169n
OverviewControlsMaintenanceRepairsDataIndex
394us723
Dimensions Ð sedan
All dimensions are given in inches (mm).
Min. turning circle dia.: BMW 525i, 530i: 37.1 ft (11.3 m); BMW 540i: 37.4 ft (11.4 m)
Page 170 of 186
170n
Dimensions Ð sport wagon
392us724
All dimensions are given in inches (mm). Height with roof-mouted luggage rack
*: 57.4 (1,459)
Min. turning circle dia.: BMW 525i: 37.1 ft (11.3 m); BMW 540i: 37.4 ft (11.4 m)
Page 171 of 186
171n
OverviewControlsMaintenanceRepairsDataIndex
Weights Ð sedan
BMW 525i BMW 530i BMW 540i
Curb weight (with one person, ready for operation, full tank of fuel, options not included)
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)3,450 (1,565)
3,505 (1,590)3,494 (1,585)
3,549 (1,610)3,748 (1,700)
3,803 (1,725)
Approved gross vehicle weight
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)4,464 (2,025)
4,520 (2,050)4,509 (2,045)
4,563 (2,070)4,762 (2,160)
4,817 (2,185)
Approved front axle weight lbs. (kg)
2,138 (970)2,138 (970) 2,381 (1,080)
Approved rear axle weight lbs. (kg) 2,579 (1,170) 2,579 (1,170) 2,635 (1,195)
Approved roof load capacity lbs. (kg) 220 (100) 220 (100) 220 (100)
Never exceed either the approved axle weights or the gross vehicle weight.
Luggage compartment capacity cu ft (l) 16.2 (460) 16.2 (460) 16.2 (460)
Page 172 of 186
172n
Weights Ð sport wagon
BMW 525i BMW 540i
Curb weight (with one person, ready for operation, full tank of fuel, options not included)
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)3,682 (1,670)
3,715 (1,695)Ð
4,056 (1,840)
Approved gross vehicle weight
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)4,773 (2,165)
4,828 (2,190)Ð
5,093 (2,310)
Approved front axle weight lbs. (kg)
2,116 (960)2,381 (1,080)
Approved rear axle weight lbs. (kg) 2,844 (1,290) 2,910 (1,320)
Approved roof load capacity lbs. (kg) 220 (100) 220 (100)
Never exceed either the approved axle weights or the gross vehicle weight.
Luggage compartment capacity cu ft (l) 14.5 Ð 53.9 (410 Ð 1,525) 14.5 Ð 53.9 (410 Ð 1,525)
Page 173 of 186
173n
OverviewControlsMaintenanceRepairsDataIndex
Capacities
Notes
Fuel tank
Reservegal. (liters)
gal. (liters)approx. 18.5 (approx. 70)
approx. 2.0 (approx. 8) Ð BMW 525i, 530i
approx. 2.5 (approx. 10) Ð BMW 540iFuel specification: page 25
Windshield washer system
with headlamp washer system
Intensive cleaning systemquarts (liters)
quarts (liters)
quarts (liters)approx. 3.7 (approx. 3.5)
approx. 6.3 (approx 6.0)
approx. 1.1 (approx 1.0)For details: page 139
Cooling system including
heater circuitquarts (liters) 11.1 (10.5) Ð BMW 525i, 530i
12.7 (12.0) Ð BMW 540iFor details: page 142
Engine oil and filter change quarts (liters) 6.9 (6.5) Ð BMW 525i, 530i
7.9 (7.5) Ð BMW 540i"BMW High Performance
Synthetic Oil."
For details: page 141
Manual transmission, automatic
transmission and differentialÐ Ð Lifetime fluid, no fluid
change required
Page 174 of 186
Page 175 of 186
175n
OverviewControlsMaintenanceRepairsDataIndex
Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data
Key words
Page 176 of 186

Everything from A to ZA
ABS (Antilock Brake
System)20, 131
Accessories10
Activated-charcoal
filter112
Active seat52
Adaptive Transmission
Control (ATC)70, 73
Add
antifreeze142t
brake fluid143t
engine coolant142t
engine oil140t
washer fluid139t
Adjusting
backrest50
head restraints52
mirrors57
seats48
steering wheel56
temperature105, 109
thigh support50
Air conditioning104
Air distribution105, 109
Air outlets104, 107
Air pressure26t, 133
Air supply105, 109
Air vent104, 107 Airbags20, 58
Alarm system42
Anchorages to secure the
load126
Antifreeze, disposal142t
Antifreeze, radiator142
Antilock Brake System
(ABS)20, 131
Anti-theft alarm system42
Anti-theft protection34
Approved axle weight171
Approved gross vehicle
weight171
Aquaplaning131, 133
ASC+T (Automatic Stability
Control plus Traction)21
ASC+T/DSC (Automatic
Stability Control plus
Traction/Dynamic Stability
Control)97
Ashtray, front117
Ashtray, rear118
ATC (Adaptive Transmission
Control)70, 73
Attach vacuum cleaner118
AUC (Automatic
recirculated-air
control)110 Automatic climate
control107
removing condensation
from windows109
Automatic cruise control78
Automatic curb monitor55
Automatic rear window
cleaning77
Automatic recirculated-air
control (AUC)110
Automatic Stability Control
plus Traction (ASC+T)21
Automatic Stability Control
plus Traction/Dynamic
Stability Control (ASC+T/
DSC)97
Automatic
transmission20, 70
Automatic transmission with
Steptronic20, 73
Average fuel
consumption86
Average speed86, 94
Avoid false alarms43t
Avoiding unintentional
alarms44
B
Backrest, adjusting50
Backup lamps
bulb replacement154t
Battery160
care160t
charging160t
discharged162t
disposal160t
Belts53
Beverage holder117
Blower105, 109
BMW active seat52
BMW comfort seat51
BMW Maintenance
System144t
BMW Universal
Transmitter113
Bottle holder, refer to
beverage holder117
Brake fluid143
adding143
Brake hydraulic system19
Brake lamps, bulb
replacement154t
Brake malfunctions132
