2001 YAMAHA XVS125 light

EAU00009
TABLE OF CONTENTS
GIVE SAFETY THE RIGHT OF WAY..................1-1
DESCRIPTION....................................................2-1
Left view.............................................................2-1
Right view..........................................................2-2
Controls and Instruments...................................2-3
INSTRUMENT AND CONTROL
FUNCTIONS........................................................3-1
Main switch/steering lock...................................3-1
Indicator lights....................................................3-2
Speedometer unit..............................................3-2
Anti-theft alarm (optional)...................................3-3
Handlebar switches............................................3-3
Clutch lever........................................................3-5
Shift pedal..........................................................3-5
Brake lever.........................................................3-5
Brake pedal........................................................3-6
Fuel tank cap.....................................................3-6
Fuel....................................................................3-7
Fuel cock............................................................3-7
Starter (choke) lever..........................................3-8
Helmet holder.....................................................3-9
Adjusting the shock absorber assemblies..........3-9
Sidestand.........................................................3-10
Ignition circuit cut-off system............................3-10PRE-OPERATION CHECKS...............................4-1
Pre-operation check list.....................................4-1
OPERATION AND IMPORTANT RIDING
POINTS................................................................5-1
Starting the engine.............................................5-1
Starting a warm engine......................................5-2
Shifting...............................................................5-3
Recommended shift points
(for Switzerland only).......................................5-3
Tips for reducing fuel consumption....................5-4
Engine break-in..................................................5-4
Parking...............................................................5-5
PERIODIC MAINTENANCE AND MINOR
REPAIR................................................................6-1
OwnerÕs tool kit..................................................6-1
Periodic maintenance and lubrication chart.......6-2
Removing and installing panels.........................6-5
Checking the spark plugs...................................6-7
Engine oil and oil filter element..........................6-9
Cleaning the air filter element..........................6-12
Adjusting the carburetor...................................6-14
Adjusting the engine idling speed....................6-14
Adjusting the throttle cable free play................6-15
Adjusting the valve clearance..........................6-15
123
456
5JX-9-E1 9/27/00 10:45 AM Page 5

Tires.................................................................6-15
Spoke wheels..................................................6-18
Adjusting the clutch lever free play..................6-19
Adjusting the brake lever free play...................6-20
Adjusting the brake pedal position and
free play.........................................................6-20
Adjusting the rear brake light switch................6-22
Checking the front brake pads and
rear brake shoes............................................6-22
Checking the brake fluid level..........................6-23
Changing the brake fluid..................................6-24
Drive chain slack..............................................6-25
Lubricating the drive chain...............................6-27
Checking and lubricating the cables................6-27
Checking and lubricating the brake and
shift pedals.....................................................6-28
Checking and lubricating the brake and
clutch levers...................................................6-28
Checking and lubricating the sidestand...........6-29
Checking the front fork.....................................6-29
Checking the steering......................................6-30
Checking the wheel bearings...........................6-30
Battery..............................................................6-31
Replacing the fuses.........................................6-32
Replacing the headlight bulb...........................6-33
Replacing a turn signal light bulb.....................6-35Replacing the tail/brake light bulb....................6-36
Supporting the motorcycle...............................6-37
Front wheel......................................................6-37
Rear wheel.......................................................6-39
Troubleshooting...............................................6-41
Troubleshooting chart......................................6-42
MOTORCYCLE CARE AND STORAGE.............7-1
Care...................................................................7-1
Storage..............................................................7-4
SPECIFICATIONS...............................................8-1
Specifications.....................................................8-1
Conversion table................................................8-5
CONSUMER INFORMATION..............................9-1
Identification numbers........................................9-1
Key identification number...................................9-1
Vehicle identification number.............................9-1
Model label.........................................................9-2
TABLE OF CONTENTS
789
5JX-9-E1 9/27/00 10:45 AM Page 6

EAU00026
DESCRIPTION
2
2-1
1.Headlight (page 6-33)
2.Fuel cock (page 3-7)
3.Fuses (page 6-32)
4.Helmet holder (page 3-9)
5.Shock absorber spring preload
adjusting ring (page 3-9)6.Shift pedal (page 3-5)
1234
5
6
Left view
5JX-9-E1 9/27/00 10:45 AM Page 8

EAU00027
INSTRUMENT AND CONTROL FUNCTIONS
3
3-1
EAU00029
Main switch/steering lockThe main switch/steering lock con-
trols the ignition and lighting systems,
and is used to lock the steering. The
various positions are described
below.
EAU00036
ON
All electrical systems are supplied
with power, and the engine can be
started. The key cannot be removed.
EAU00038
OFF
All electrical systems are off. The key
can be removed.
EAU00040
LOCK
The steering is locked, and all electri-
cal systems are off. The key can be
removed.
To lock the steering1.Turn the handlebars all the way
to the left.
2.Push the key in from the ÒOFFÓ
position, and then turn it to
ÒLOCKÓ while still pushing it.
3.Remove the key.
To unlock the steeringPush the key in, and then turn it to
ÒOFFÓ while still pushing it.
OFFON
LOCKPPUSH
IGNITION
ON
OFF
LOCK
(Parking)
.
EW000016
wNever turn the key to ÒOFFÓ or
ÒLOCKÓ while the motorcycle is
moving, otherwise the electrical
systems will be switched off,
which may result in loss of control
or an accident. Make sure that the
motorcycle is stopped before turn-
ing the key to ÒOFFÓ or ÒLOCKÓ.
EAU01590
.
(Parking)
The steering is locked, and the tail-
light and auxiliary light are on, but all
other electrical systems are off. The
key can be removed.
The steering must be locked before
the key can be turned to Ò
.Ó.
ECA00043
cCDo not use the parking position for
an extended length of time, other-
wise the battery may discharge.
1.Push.
2.Turn.
ab
5JX-9-E1 9/27/00 10:45 AM Page 11

3-2
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03034
Indicator and warning lights
EAU00063
High beam indicator light Ò&Ó
This indicator light comes on when
the high beam of the headlight is
switched on.
EAU00057
Turn signal indicator light Ò5Ó
This indicator light flashes when the
turn signal switch is pushed to the left
or right.
2040
600
km/h80
100
120140160
1234
EAU00061
Neutral indicator light ÒNÓ
This indicator light comes on when
the transmission is in the neutral
position.
EAU03182
Engine trouble warning light ÒÓ
This warning light comes on or flash-
es when an electrical circuit monitor-
ing the engine is defective. When this
occurs, have the Yamaha dealer
check the self-diagnosis system.NOTE:
This warning light comes on for a few
seconds when the key is turned to
ÒONÓ, but this does not indicate a
malfunction.
1.High beam indicator light Ò&Ó
2.Turn signal indicator light Ò5Ó
3.Neutral indicator light ÒNÓ
4.Engine trouble warning light ÒÓ
EAU01087
Speedometer unit The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero
with the reset knob. The tripmeter
can be used to estimate the distance
that can be traveled with a full tank of
fuel. This information will enable you
to plan future fuel stops.1.Speedometer
2.Odometer
3.Tripmeter
4.Reset knob
2040600
km/h80
100
120140160
1
23
4
5JX-9-E1 9/27/00 10:45 AM Page 12

INSTRUMENT AND CONTROL FUNCTIONS
3
3-3
NOTE:
Only for the German model equipped
with a speed limiter:
The speed limiter prevents the motor-
cycle from exceeding a riding speed
of 80 km/h.
EAU00109
Anti-theft alarm (optional)This motorcycle can be equipped
with an optional anti-theft alarm by a
Yamaha dealer. Contact a Yamaha
dealer for more information.
EAU00118
Handlebar switches
EAU00119
Pass switch
Press this switch to flash the head-
light.
EAU00121
Dimmer switch
Set this switch to Ò&Ó for the high
beam and to Ò%Ó for the low beam.1.Pass switch
2.Dimmer switch
3.Turn signal switch
4.Horn switch Ò*Ó
1
2
3
4
5JX-9-E1 9/27/00 10:45 AM Page 13

3-4
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU00134
Light switch
Set this switch to Ò
'
Ó to turn on the
auxiliary light, meter lighting and tail-
light. Set the switch to Ò:Ó to turn on
the headlight also.
EAU00138
Engine stop switch
Set this switch to Ò$Ó to stop the
engine in case of an emergency,
such as when the motorcycle over-
turns or when the throttle cable is
stuck.1.Engine stop switch
2.Light switch
3.Start switch Ò,Ó
1
2
3
EAU00143
Start switch Ò,Ó
Push this switch to crank the engine
with the starter.
EC000005
cCSee page 5-1 for starting instruc-
tions prior to starting the engine.
EAU00127
Turn signal switch
To signal a right-hand turn, push this
switch to Ò6Ó. To signal a left-hand
turn, push this switch to Ò4Ó. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after
it has returned to the center position.
EAU00129
Horn switch Ò*Ó
Press this switch to sound the horn.1.Pass switch
2.Dimmer switch
3.Turn signal switch
4.Horn switch Ò*Ó
1
2
3
4
5JX-9-E1 9/27/00 10:45 AM Page 14

PRE-OPERATION CHECKS
1
2
34
5
6
7
8
9
4-2
Throttle grip¥Make sure that operation is smooth.
¥Lubricate throttle grip, housing and cables if necessary.
¥Check free play.
¥If necessary, have Yamaha dealer make adjustment.6-15
Control cables¥Make sure that operation is smooth.
¥Lubricate if necessary.6-27
Drive chain¥Check chain slack.
¥Adjust if necessary.
¥Check chain condition.
¥Lubricate if necessary.6-25Ð6-27
Wheels and tires¥Check for damage.
¥Check tire condition and tread depth.
¥Check air pressure.
¥Correct if necessary.6-15Ð6-18
Brake and shift pedals¥Make sure that operation is smooth.
¥Lubricate pedal pivoting points if necessary.6-28
Brake and clutch levers¥Make sure that operation is smooth.
¥Lubricate lever pivoting points if necessary.6-28
Sidestand¥Make sure that operation is smooth.
¥Lubricate pivot if necessary.6-29
Chassis fasteners¥Make sure that all nuts, bolts and screws are properly tightened.
¥Tighten if necessary.Ñ
Instruments, lights,
signals and switches¥Check operation.
¥Correct if necessary.3-2Ð3-4, 6-33Ð6-36
Sidestand switch¥Check operation of ignition circuit cut-off system.
¥If system is defective, have Yamaha dealer check vehicle.3-10Ð3-11 ITEMCHECKSPAGE
5JX-9-E1 9/27/00 10:45 AM Page 23
