Further safe-riding points8Be sure to signal clearly when making turns.
8Braking can be extremely difficult on a wet road. Avoid hard braking, because the scooter could
slide. Apply the brakes slowly when stopping on a wet surface.
8Slow down as you approach a corner or turn. Once you have completed a turn, accelerate slowly.
8Be careful when passing parked cars. A driver might not see you and open a door in your path.
8Railroad crossings, streetcar rails, iron plates on road construction sites, and manhole covers
become extremely slippery when wet. Slow down and cross them with caution. Keep the scooter
upright, otherwise it could slide out from under you.
8The brake pads could get wet when you wash the scooter. After washing the scooter, check the
brakes before riding.
8Always wear a helmet, gloves, trousers (tapered around the cuff and ankle so they do not flap),
and a bright colored jacket.
8Do not carry too much luggage on the scooter. An overloaded scooter is unstable.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 9

3-2
134
2
EAU00056
Indicator lights
EAU03734
Oil change indicator light Ò
7
Ó
This indicator light comes on at the
initial 1,000 km and every 3,000 km
thereafter to indicate that the engine
oil should be changed.
After changing the engine oil, reset
the oil change indicator light.(See
page 6-17 for the resetting proce-
dure.)The electrical circuit of the indicator
light can be checked according to the
following procedure.
1.Set the engine stop switch to Ò#Ó
and turn the key to ÒONÓ.
2.Check that the indicator comes
on for a few seconds and then
goes off.
If the indicator light does not
come on, have a Yamaha dealer
check the electrical circuit.
NOTE:
The oil change indicator light may
flash when the engine is revved with
the scooter on the centerstand, but
this does not indicate a malfunction.
1.Oil change indicator light Ò
7
Ó
2.High beam indicator light Ò&Ó
3.Left turn signal indicator light Ò4Ó
4.Right turn signal indicator light Ò6Ó
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00063
High beam indicator light Ò&Ó
This indicator light comes on when
the high beam of the headlight is
switched on.
EAU03299
Turn signal indicator lights
Ò4Ó/Ò6Ó
The corresponding indicator light
flashes when the turn signal switch is
pushed to the left or right.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 17

3-5
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
2
3
1
1.Digital clock
2.Hour setting button ÒhÓ
3.Minute setting button ÒmÓ
EAU03800
ClockThe digital clock shows the time
regardless of the main switch posi-
tion.
To set the clock:
1.Turn the key to ÒONÓ.
2.Push or hold the hour setting
button ÒhÓ to change the hours.
3.Push or hold the minute setting
button ÒmÓ to change the min-
utes.
NOTE:
To set the clock after the power
source has been cut, first set the time
to 1:00 AM, and then set the clock to
the correct time.
1
2
3
4
EAU00118
Handlebar switches
EAU00119
Pass switch Ò&
Ó
Press this switch to flash the head-
light.
EAU00121
Dimmer switch
Set this switch to Ò&Ó for the high
beam and to Ò%Ó for the low beam.1.Pass switch Ò&Ó
2.Dimmer switch
3.Turn signal switch
4.Horn switch Ò*Ó
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 20

3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
2
3
EAU01871
Light switch
Set this switch to Ò
'
Ó to turn on
the auxiliary light, meter lighting, tail-
light and license plate light. Set the
switch to Ò:Ó to turn on the headlight
also.
1.Engine stop switch
2.Light switch
3.Start switch Ò,Ó
EAU00127
Turn signal switch
To signal a right-hand turn, push this
switch to Ò6Ó. To signal a left-hand
turn, push this switch to Ò4Ó. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after
it has returned to the center position.
EAU00129
Horn switch Ò*Ó
Press this switch to sound the horn.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 21

5-2
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9
EAU00433
Starting offNOTE:
Before starting off, allow the engine
to warm up.1.While pulling the rear brake lever
with your left hand and holding
the grab bar with your right hand,
push the scooter off the center-
stand.
2.Sit astride the seat, and then
adjust the rear view mirrors.
3.Switch the turn signal on.4.Check for oncoming traffic, and
then slowly turn the throttle grip
(on the right) in order to take off.
5.Switch the turn signal off.
1
1.Grab bar
NOTE:
If the engine does not start, release
the start switch, wait a few seconds,
and then try again. Each starting
attempt should be as short as possi-
ble to preserve the battery. Do not
crank the engine more than 10 sec-
onds on any one attempt. If the
engine does not start, try with the
throttle open 1/8 turn.
ECA00045
cCFor maximum engine life, never
accelerate hard when the engine is
cold!
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 39

PERIODIC MAINTENANCE AND MINOR REPAIR
OwnerÕs tool kit.......................................................6-1
Periodic maintenance and lubrication chart............6-3
Removing and installing cowlings and panel..........6-6
Checking the spark plug.......................................6-12
Engine oil..............................................................6-14
Final gear oil.........................................................6-17
Coolant..................................................................6-18
Air filter and V-belt case air filter elements...........6-20
Air flow louver.......................................................6-22
Tires......................................................................6-23
Wheels..................................................................6-25
Adjusting the front and rear brake lever
free play..............................................................6-25
Checking the front and rear brake pads................6-26
Checking the brake fluid level...............................6-27
Changing the brake fluid.......................................6-28
Checking and lubricating the cables.....................6-28
Lubricating the front and rear brake levers...........6-28
Checking and lubricating the
centerstand and sidestand..................................6-29
Checking the front fork..........................................6-29
Checking the steering...........................................6-30
Checking the wheel bearings................................6-31
Removing the battery cover..................................6-31Battery...................................................................6-31
Replacing the fuses..............................................6-33
Replacing a headlight bulb....................................6-34
Replacing a front turn signal light bulb..................6-35
Replacing a rear turn signal light bulb...................6-36
Replacing a tail/brake light bulb............................6-37
Replacing the license plate light bulb....................6-37
Troubleshooting....................................................6-38
Troubleshooting charts.........................................6-39
6
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 43

2.Remove the blown fuse, and
then install a new fuse of the
specified amperage.
EC000103
cCDo not use a fuse of a higher
amperage rating than recommend-
ed to avoid causing extensive
damage to the electrical system
and possibly a fire.3.Turn the key to ÒONÓ and turn on
the electrical circuit in question to
check if the device operates.
6-33
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
94.If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
Specified fuses:
Main fuse:30 A
Clock fuse:10 A
Radiator fan fuse:4 A
Ignition fuse:7.5 A
Headlight fuse:15 A
Signaling system fuse:15 A
4
5
67
1
32
78
EAU03622
Replacing the fusesThe fuse boxes are located under the
battery cover. (See page 6-31 for bat-
tery cover removal and installation
procedures.)
If a fuse is blown, replace it as fol-
lows.
1.Turn the key to ÒOFFÓ and turn
off all electrical circuits.1.Main fuse
2.Clock fuse
3.Radiator fan fuse
4.Ignition fuse
5.Headlight fuse
6.Signaling system fuse
7.Spare fuse (´4)
8.Spare main fuse
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 76

6-35
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
5.Place a new bulb into position,
and then secure it with the bulb
holder.
EC000105
cCDo not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the
bulb, and the bulb life will be
adversely affected. Thoroughly
clean off any dirt and fingerprints
on the headlight bulb using a cloth
moistened with alcohol or thinner.6.Install the bulb cover, and then
connect the headlight coupler.
7.Install the panel.
8.Have a Yamaha dealer adjust
the headlight beam if necessary.
a
a.Do not touch this area.
