5-4
EAU03123
0Ð1,000 km
Avoid operation above 1/3 throttle.
1,000Ð1,600 km
Avoid cruising speeds in excess of
1/2 throttle.
ECA00054
cCAfter 1,000 km of operation, be
sure to replace the engine oil and
final gear oil.1,600 km and beyond
Proceed with normal riding.
EC000049
cCIf any engine trouble should occur
during the engine break-in period,
immediately have a Yamaha dealer
check the vehicle.
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9
EAU01128
Engine break-inThere is never a more important peri-
od in the life of your engine than the
period between 0 and 1,600 km. For
this reason, you should read the fol-
lowing material carefully.
Since the engine is brand new, do
not put an excessive load on it for the
first 1,600 km. The various parts in
the engine wear and polish them-
selves to the correct operating clear-
ances. During this period, prolonged
full-throttle operation or any condition
that might result in engine overheat-
ing must be avoided.
EAU03093
Tips for reducing fuel
consumptionFuel consumption depends largely on
your riding style. Consider the follow-
ing tips to reduce fuel consumption:
8Thoroughly warm up the engine.
8Avoid high engine speeds during
acceleration.
8Avoid high engine speeds with
no load on the engine.
8Turn the engine off instead of let-
ting it idle for an extended length
of time (e.g., in traffic jams, at
traffic lights or at railroad cross-
ings).
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 41

PERIODIC MAINTENANCE AND MINOR REPAIR
OwnerÕs tool kit.......................................................6-1
Periodic maintenance and lubrication chart............6-3
Removing and installing cowlings and panel..........6-6
Checking the spark plug.......................................6-12
Engine oil..............................................................6-14
Final gear oil.........................................................6-17
Coolant..................................................................6-18
Air filter and V-belt case air filter elements...........6-20
Air flow louver.......................................................6-22
Tires......................................................................6-23
Wheels..................................................................6-25
Adjusting the front and rear brake lever
free play..............................................................6-25
Checking the front and rear brake pads................6-26
Checking the brake fluid level...............................6-27
Changing the brake fluid.......................................6-28
Checking and lubricating the cables.....................6-28
Lubricating the front and rear brake levers...........6-28
Checking and lubricating the
centerstand and sidestand..................................6-29
Checking the front fork..........................................6-29
Checking the steering...........................................6-30
Checking the wheel bearings................................6-31
Removing the battery cover..................................6-31Battery...................................................................6-31
Replacing the fuses..............................................6-33
Replacing a headlight bulb....................................6-34
Replacing a front turn signal light bulb..................6-35
Replacing a rear turn signal light bulb...................6-36
Replacing a tail/brake light bulb............................6-37
Replacing the license plate light bulb....................6-37
Troubleshooting....................................................6-38
Troubleshooting charts.........................................6-39
6
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 43

6-4
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
9
*Wheels¥Check runout and for damage.ÖÖÖÖ
10*Tires¥Check tread depth and for damage.
¥Replace if necessary.
¥Check air pressure.
¥Correct if necessary.ÖÖÖÖ
11*Wheel bearings¥Check bearing for looseness or damage.ÖÖÖÖ
12*Steering bearings¥Check bearing play and steering for roughness.ÖÖÖÖÖ
¥Lubricate with lithium-soap-based greaseEvery 20,000km
13*Chassis fasteners¥Make sure that all nuts, bolts and screws are properly tightened.ÖÖÖÖÖ
14Sidestand/centerstand¥Check operation.
¥Lubricate.ÖÖÖÖÖ
15*Sidestand switch¥Check operation.ÖÖÖÖÖÖ
16*Front fork¥Check operation and for oil leakage.ÖÖÖÖ
17*Rear shock absorber
assemblies¥Check operation and shock absorbers for oil leakage.ÖÖÖÖ
18*Carburetor¥Check starter (choke) operation.
¥Adjust engine idling speed.ÖÖÖÖÖÖ
19Engine oil¥Change when the oil change indicator light comes on. (See
page 3-2 and 6-17.)ÖEvery 3,000 km
20*Engine oil strainer¥Clean.ÖÖÖ
21*Cooling system¥Check coolant level and vehicle for coolant leakage.ÖÖÖÖÖ
¥Change.Every 3 years NO.ITEMCHECK OR MAINTENANCE JOBODOMETER READING (´1,000 km)
ANNUAL
CHECK
110203040
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 47

6-12
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
1
1.Tab (´4)To install the panelPlace the panel in the original posi-
tion, and then install the bolts.
1
To remove the spark plug
1.Remove cowling B. (See page
6-8 for cowling removal and
installation procedures.)
2.Remove the spark plug cap.1.Spark plug cap
EAU03620
Checking the spark plugThe spark plug is an important
engine component, which is easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plug should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plug can reveal the condition of
the engine.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 55

1
3.Remove the spark plug as
shown, with the spark plug
wrench included in the ownerÕs
tool kit.1.Spark plug wrench
6-13PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9To check the spark plug
1.Check that the porcelain insula-
tor around the center electrode
of the spark plug is a medium-to-
light tan (the ideal color when the
scooter is ridden normally).
NOTE:
If the spark plug shows a distinctly
different color, the engine could be
defective. Do not attempt to diagnose
such problems yourself. Instead,
have a Yamaha dealer check the
scooter.2.Check the spark plug for elec-
trode erosion and excessive car-
bon or other deposits, and
replace it if necessary.
a
a.Spark plug gap
Spark plug gap:
0.6Ð0.7 mm
To install the spark plug
1.Measure the spark plug gap with
a wire thickness gauge and, if
necessary, adjust the gap to
specification.
2.Clean the surface of the spark
plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
3.Install the spark plug with the
spark plug wrench, and then
tighten it to the specified torque. Specified spark plug:
DR8EA (NGK)
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 56

6-14
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
NOTE:
If a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is
1/4Ð1/2 turn past finger tight.
However, the spark plug should be
tightened to the specified torque as
soon as possible.4.Install the spark plug cap.
5.Install the cowling. Tightening torque:
Spark plug:
17.5 Nm (1.75 m0kg)
EAU03119
Engine oilThe engine oil level should be
checked before each ride. In addition,
the oil must be changed at the inter-
vals specified in the periodic mainte-
nance and lubrication chart and when
the oil change indicator light comes
on.To check the engine oil level
1.Place the scooter on the center-
stand.
NOTE:
Make sure that the scooter is posi-
tioned straight up when checking the
oil level. A slight tilt to the side can
result in a false reading.2.Start the engine, warm it up for
several minutes, and then turn it
off.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 57

6-15
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
93.Wait a few minutes until the oil
settles, remove the oil filler cap,
wipe the dipstick clean, insert it
back into the oil filler hole (with-
out screwing it in), and then
remove it again to check the oil
level.
NOTE:
The engine oil should be between the
minimum and maximum level marks.
3121
1.Engine oil filler cap
2.Maximum level mark
3.Minimum level mark
4.If the engine oil is below the min-
imum level mark, add sufficient
oil of the recommended type to
raise it to the correct level.
5.Insert the dipstick into the oil filler
hole, and then tighten the oil filler
cap.

1
1.Engine oil drain boltTo change the engine oil
1.Start the engine, warm it up for
several minutes, and then turn it
off.
2.Place an oil pan under the
engine to collect the used oil.
3.Remove the engine oil filler cap
and the engine oil drain bolt to
drain the oil from the crankcase.
5GM-9-E1(No ABS) 9/27/00 2:18 PM Page 58

6-16
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
12
4.Check the washer for damage
and replace it if necessary.
5.Install the washer and the engine
oil drain bolt, and then tighten
the drain bolt to the specified
torque.NOTE:
Make sure that the washer is properly
seated.1.Engine oil drain bolt
2.Washer
Tightening torque:
Engine oil drain bolt:
20 Nm (2.0 m0kg)
6.Add the specified amount of the
recommended engine oil, and
then install and tighten the oil
filler cap.
EC000030
cC8Do not put in any chemical
additives or use oils with a
grade of CD or higher. Also, be
sure not to use oils labeled
ÒENERGY CONSERVING
IIÓ or
higher.
8Be sure no foreign material
enters the crankcase.
Recommended oil:
See page 8-1.
Oil quantity:
Periodic oil change:
1.2 L
Total amount (dry engine):
1.4 L
7.Start the engine, and then let it
idle for several minutes while
checking it for oil leakage. If oil is
leaking, immediately turn the
engine off and check for the
cause.
8.Reset the oil change indicator
light according to the following
procedure.
