2001 TOYOTA TACOMA Owners Manual (in English)

’01 Tacoma U (L/O 0009)
1072001 TACOMA (OM35766U)
High−Low beamsFor high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to OFF".
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the ON" position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out.
Emergency flashers
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.

’01 Tacoma U (L/O 0009)
1082001 TACOMA (OM35766U)
NOTICE
To prevent the battery from being dis-
charged, do not leave the switch on
longer than necessary when the en-
gine is not running.
Instrument panel light control
To adjust the brightness of the instru-
ment panel lights, turn the knob.
Interior lights
Front light (regular cab models)
Rear light (Xtra−cab and double cab mod-
els)

’01 Tacoma U (L/O 0009)
1092001 TACOMA (OM35766U)
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
ON"Keeps the light on all the time.
OFF"Turns the light off.
DOOR"Turns the light on when any of
the doors are opened. The light goes off
when all the doors are closed.
Vehicles without the power door lock sys-
tem
To prevent the battery from being dis-
charged, the light will automatically turn
off if the door is left open for 30 minutes
with the switch at the DOOR" position.
Vehicles with the power door lock sys-
tem
To prevent the battery from being dis-
charged, the light will automatically turn
off after 30 minutes in the following cases.
The light is left at the ON" position.
The door is left open with the switch
at the DOOR" position.ILLUMINATED ENTRY SYSTEM
With the switch at the DOOR" position,
the light comes on when any door is
opened. After all the doors are closed, the
light remains on for about 15 seconds and
then goes out.
However, in the following cases, the light
goes out immediately:
All the doors are closed when the igni-
tion key is in the ACC" or ON" posi-
tion.
All the doors are closed and locked.
(with power door lock system models
only)
Vehicles with the power door lock sys-
tem
When any door is unlocked or the key is
removed, the light comes on for 15 sec-
onds, even if the door is not opened.
Personal lights
The personal lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
To prevent the battery from being dis-
charged, the light will automatically turn
off after 30 minutes.

’01 Tacoma U (L/O 0009)
11 02001 TACOMA (OM35766U)
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ON" position.Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The INT TIME" band lets you adjust the
wiping time interval when the wiper lever
is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it. To squirt washer fluid, pull the lever
toward you and release it.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see Adding washer fluid" in Section 7−3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ON" position.
Lever position
Speed setting
Position 1Slow
Position 2Fast
For a single sweep of the windshield,
push the lever up and release it.
To squirt washer fluid, pull the lever
toward you and release it.
For instructions on adding washer fluid,
see Adding washer fluid" in Section 7−3.
Windshield wipers and
washer (intermittent type) Windshield wipers and
washer (mist type)

’01 Tacoma U (L/O 0009)
1112001 TACOMA (OM35766U)
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the
glass.

’01 Tacoma U (L/O 0009)
11 22001 TACOMA (OM35766U)

’01 Tacoma U (L/O 0009)
11 32001 TACOMA (OM35766U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Gauges, Meters and Service reminder indicators
Fuel gauge11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Engine coolant temperature gauge 11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 11 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Odometer and two trip meters 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 11 6
. . . . . . . . . . . . . .
SECTION 1− 5

’01 Tacoma U (L/O 0009)
11 42001 TACOMA (OM35766U)
Fuel gauge
With tachometer
Without tachometer
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the
tank.
Nearly fullNeedle at F"
Nearly emptyNeedle at E"
It is a good idea to keep the tank over
1/4 full.
This fuel gauge has a non−return type
needle which remains at the last indicated
position when the ignition switch is turned
off.
If the fuel level approaches E" or the low
fuel level warning light comes on, fill the
fuel tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the fuel gauge
needle may fluctuate or the low fuel level
warning light may come on earlier than
usual.
If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
With tachometer
Without tachometer
Engine coolant temperature
gauge
