2001 TOYOTA HIGHLANDER mirror controls

'05 HIGHLANDER_U (L/O 0409)
318
2005 HIGHLANDER from Nov. '04 Prod. (OM48570U)
1. Check the area around the vehicle be-
fore entering it.
2. Adjust seat position, seatback angle,
seat cushion angle, seat height, head
restraint height and steering wheel
angle.
3. Adjust the inside and outside rear view
mirrors.
4. Lock all side doors and back door.
5. Fasten seat belts.1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces-
sories.
3. Put the selector lever in Pº. If you
need to restart the engine while the
vehicle is moving, put the selector le-
ver in Nº. A starter safety device will
prevent the starter from operating if the
selector lever is in any drive position.
4. Depress the brake pedal and hold it to
the floor until driving off.Before starting the engine, be sure to fol-
low the instructions in (a) Before crank-
ingº.
Normal starting procedure
The multiport fuel injection system/sequen-
tial multiport fuel injection system in your
engine automatically controls the proper
air- fuel mixture for starting. You can start
a cold or hot engine as follows:
With your foot off the accelerator pedal,
crank the engine by turning the key to
STARTº. Release it when the engine
starts.
Engine should be warmed up by driving,
not in idle. For warming up, drive with
smoothly turning engine until engine cool-
ant temperature is within normal range.
If the engine stalls...
Simply restart it, using the correct proce-
dure given in normal starting.
If the engine will not start...
See If your vehicle will not startº on page
332 in Section 4.
Before starting the engineHow to start the engineÐ
(a) Before cranking(b) Starting the engine

'05 HIGHLANDER_U (L/O 0409)
4
2005 HIGHLANDER from Nov. '04 Prod. (OM48570U)
1. Headlight, turn signal and front fog
light switches
2. Wiper and washer switches
3. Emergency flasher switch
4. Clock
5. Front passenger 's seat belt reminder
light
6. Rear window and outside rear view
mirror defogger and windshield wiper
de- icer switch
7. Air conditioning controls
8. Audio system
9. AIRBAG ONº and AIRBAG OFFº
indicator lights
10. Snow mode button
11. Seat heater switches
12. Cigarette lighter
13. TRAC OFFº switch
(two- wheel drive models)
14. Cruise control switch
15. Ignition switch
16. Tilt steering lock release lever
17. Tire pressure warning system reset
switch
Vehicles with manual air conditioning controls (view B)

'05 HIGHLANDER_U (L/O 0409)
6
2005 HIGHLANDER from Nov. '04 Prod. (OM48570U)
1. Headlight, turn signal and front fog
light switches
2. Wiper and washer switches
3. Emergency flasher switch
4. Clock
5. Front passenger 's seat belt reminder
light
6. Air conditioning controls and
multi- information display
7. Rear window and outside rear view
mirror defogger and windshield wiper
de- icer switch
8. Audio system
9. AIRBAG ONº and AIRBAG OFFº
indicator lights
10. Snow mode button
11. Seat heater switches
12. Cigarette lighter
13. TRAC OFFº switch
(two- wheel drive models)
14. Cruise control switch
15. Ignition switch
16. Tilt steering lock release lever
17. Tire pressure warning system reset
switch
Vehicles with automatic air conditioning controls (view B without navigation system)

'05 HIGHLANDER_U (L/O 0409)
8
2005 HIGHLANDER from Nov. '04 Prod. (OM48570U)
1. Headlight, turn signal and front fog
light switches
2. Wiper and washer switches
3. Emergency flasher switch
4. Clock (See the separate Navigation
System Owner 's Manualº.)
5. Front passenger 's seat belt reminder
light
6. Navigation system including air
conditioning controls (See the separate
Navigation System Owner 's Manualº.)
7. Rear window and outside rear view
mirror defogger switch
8. Audio system (See the separate
Navigation System Owner 's Manualº.)
9. AIRBAG ONº and AIRBAG OFFº
indicator lights
10. Snow mode button
11. Seat heater switches
12. Cigarette lighter
13. TRAC OFFº switch
(two- wheel drive models)
14. Cruise control switch
15. Ignition switch
16. Tilt steering lock release lever
Vehicles with automatic air conditioning controls (view B with navigation system)

'05 HIGHLANDER_U (L/O 0409)
111
2005 HIGHLANDER from Nov. '04 Prod. (OM48570U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Steering wheel and Mirrors
Tilt steering wheel11 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors11 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti- glare inside rear view mirror11 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto anti- glare inside rear view mirror11 5 . . . . . . . . . . . . . . . . . . . . . . . .
Sun visors11 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1- 4

'05 HIGHLANDER_U (L/O 0409)
11 9
2005 HIGHLANDER from Nov. '04 Prod. (OM48570U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals120 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers123 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control123 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights124 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights124 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights125 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light126 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wipers and washer127 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defoggers and windshield
wiper de- icer128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1- 5
