3-12
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction such as leaves. The heater and
defroster will work better, reducing the chance of
fogging your windows.

In cool damp weather, minimize your use of RECIRC
to reduce the chance of fogging your windows.

When you enter a vehicle with the standard system in
cold weather, select FLOOR mode to supply air
through the floor outlets. Then turn the fan on high for
a few moments before driving away. This will blow
moist air from the intake outlets toward the floor, not
the windshield. It reduces the chance of fogging your
windows. If you have the electronic system, the
AUTO setting will do this for you. Manual operation
of the electronic system in the FLOOR mode will also
supply air through the floor outlets.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.
Setting the Clock for Systems with Radio
Data System
Press and hold HR or MIN for two seconds. Then press
and hold HR until the correct hour appears. AM or PM
will appear on the display. Press and hold MIN until the
correct minute appears. The clock may be set with the
ignition on or off.
To set the clock to the time of an FM station
broadcasting Radio Data System (RDS) information,
press and hold HR and MIN at the same time for
two seconds until UPDATED and the clock symbol
appear on the display. If the time is not available
from the station, NO UPDATE will appear on the
display instead.

3-13 AM-FM Stereo with Cassette Tape Player
with Programmable Equalization and
Radio Data System (RDS) (If Equipped)
Playing the Radio
PWR VOL: Press this knob to turn the system on
and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume.SCV: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press this button to select MIN,
MED or MAX. Each choice allows for more volume
compensation at faster vehicle speeds. Then, as you
drive, SCV automatically increases the volume, as
necessary, to overcome noise at any particular speed.
The volume level should always sound the same to you
as you drive. If you don't want to use SCV, select OFF.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK: Press the up or down arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.

3-14
SCAN: Press and hold one of the SEEK arrows for
two seconds until the scan icon appears on the display
and you hear a beep. Use SCAN to listen to stations for
a few seconds. The radio will go to a station, stop for a
few seconds, then go on to the next station. Press one of
the SEEK arrows again to stop scanning. The sound will
mute while scanning.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press EQ to select the desired equalization.
5. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the station you set will return and the
equalization that you selected will also be
automatically selected for that button.
6. Repeat the steps for each pushbutton.PRESET SCAN: Press and hold one of the
SEEK arrows for more than four seconds until the
pscan icon and the preset number appear on the display.
You will hear a double beep. Use PRESET SCAN to
listen to each of your preset stations for a few seconds.
The radio will go to the first preset station stored on
your pushbuttons, stop for a few seconds, then go on to
the next preset station. Press one of the SEEK arrows
again to stop scanning presets.
Preset scan will skip over presets where no station is
being received at that time to prevent hearing static.
Setting the Tone
TONE: Press and release this button until the desired
tone control (BASS, MID or TREB) is found. The
SELECT LED indicator will light to show that the tone
control can be adjusted. When using BASS, MID or
TREB, turn the SELECT knob clockwise to increase.
Turn it counterclockwise to decrease. If a station is weak
or noisy, you may want to decrease the treble.
Pressing and holding the TONE button for at least two
seconds will return all tone settings to flat regardless of
tone selected. FLAT will appear on the display.

3-17
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite Program Types (PTYs).
These buttons have factory PTY presets. You can set up
to 12 PTYs (six FM1 and six FM2) by performing the
following steps:
1. Press PROG TYPE, if it is not already on.
2. Press AM FM to select FM1 or FM2.
3. Turn the SELECT knob to select a PTY.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the PTY you set will return.
5. Repeat the steps for each pushbutton.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a cassette
tape is playing. If the cassette tape is playing, play will
stop for the announcement and resume when the
announcement is finished.ALTERNATE FREQUENCY: This feature allows
the radio to switch to a stronger station with the same
program type. Press and hold AM FM for two seconds
to turn alternate frequency on. AF ON will appear on the
display. The radio may switch to stronger stations. Press
and hold AM FM again for two seconds to turn alternate
frequency off. AF OFF will appear on the display. The
radio will not switch to other stations.
Adjusting the Speakers
BAL FADE: This button adjusts balance and fade.
To adjust balance, press this button until BAL appears
on the display. Turn the SELECT knob clockwise for
the right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers. To adjust fade, press this button
until FAD appears on the display. Turn the SELECT
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers. Press
and hold this button for two seconds to return both fade
and balance to the middle position.

3-18
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
out. If the ignition is on, but the radio is off, the tape can
be inserted and will begin playing. If you hear nothing
but a garbled sound, the tape may not be in squarely.
Press the eject button to remove the tape and start over.
While the tape is playing, use the BAL FADE, TONE,
EQ, SEEK and SCAN controls just as you do for the
radio. The display will show TAPE and an arrow
showing which side of the tape is playing. The tape
player automatically begins playing the other side when
it reaches the end of the tape.
Your tape bias is set automatically when a metal or chrome
tape is inserted. If you want to insert a tape when the
ignition is off, first press the eject button or the RCL knob.
If an error appears on the radio display, the tape won't
play because of an error.
TIGHT TAPE is displayed when the tape is tight and the
player can't turn the tape hubs. Remove the tape. Hold
the tape with the open end down and try to turn the right
hub counterclockwise with a pencil. Turn the tape over and repeat. If the hubs do not turn
easily, your tape may be damaged and should not be
used in the player. Try a new tape to make sure your
player is working properly.
BROKEN TAPE is displayed when the tape is broken.
Try a new tape.
WRAPPED TAPE is displayed when the tape is
wrapped around the tape head. Attempt to get the
cassette out. Try a new tape.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.


(1): Press this button to advance quickly to another
part of the tape. Press the button again to return to play.
The radio will play the last selected station while the
tape advances. You may select stations during forward
operation by using TUNE.
While in forward mode the display will show FREQ and
FWD and two right arrows. If the radio is playing a
RDS station the display will only show FREQ.
 (2): Press this button to play the other side
of the tape.

3-20
CLEAN PLAYER: If this message appears on the
display, the cassette tape player needs to be cleaned. It will
still play tapes, but you should clean it as soon as possible
to prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold the eject button for five seconds
to reset the CLEAN PLAYER indicator. The radio will
display CLEANED to show the indicator was reset.
CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:
1. Turn the ignition to ON or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for
three seconds. The tape symbol on the display will
flash for five seconds and READY will appear on
the display, indicating the feature is active.
4. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until the eject
button is pressed.AM-FM Stereo with Compact Disc Player
with Programmable Equalization and
Radio Data System (RDS) (If Equipped)
Playing the Radio
PWR VOL: Press this knob to turn the system
on and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume.

3-22
PRESET SCAN: Press and hold one of the SEEK
arrows for more than four seconds until the preset scan
icon and the preset number appear on the display.
You will hear a double beep. Use PRESET SCAN to
listen to each of your preset stations for a few seconds.
The radio will go to the first preset station stored on
your pushbuttons, stop for a few seconds, then go on
to the next preset station. Preset scan will only scan the
six presets that are in the band selected. Press one of
the SEEK arrows again to stop scanning presets.
PRESET SCAN will skip over presets where no station
is being received at that time to prevent hearing static.
Setting the Tone
TONE: Press and release this button until the desired
tone control (BASS, MID or TREB) is found. The
SELECT LED indicator will light to show that the tone
control can be adjusted. When using BASS or MID, turn
the SELECT knob clockwise to increase bass. Turn it
counterclockwise to decrease bass. When using TREB,
turn the SELECT knob clockwise to increase treble.
Turn it counterclockwise to decrease treble. If a station
is weak or noisy, you may want to decrease the treble.
To set all of the tone controls to the middle position,
press and hold TONE until FLAT appears on the display.EQ: This feature allows you to choose preset bass, mid
and treble equalization settings designed for different
individual listening tastes. Press EQ to select the desired
preset equalization setting. Each time you press EQ,
another setting will appear on the display.
You can preset up to six equalization settings by
performing the following steps:
1. Turn the radio on.
2. Use the TONE button and the SELECT knob to
select the desired equalization.
3. Press and hold EQ for two seconds. SELECT EQ #
will appear on the display. The EQ icon will flash.
4. Press EQ or turn the SELECT knob to select the
desired EQ number. Each time you press EQ or turn
the SELECT knob, another EQ setting will appear on
the display.
5. Press and hold the EQ button or push the SELECT
knob to store the equalization preset. You will hear a
beep and EQ SAVED will appear on the display.
6. Repeat the steps for each EQ setting. EQ 5 has been
programmed at the factory for use with talk radio,
but it can be preset to a different tone.

3-25
ALTERNATE FREQUENCY: This feature allows
the radio to switch to a stronger station with the same
program type. Press and hold AM FM for two seconds
to turn alternate frequency on. AF ON will appear on the
display. The radio may switch to stronger stations. Press
and hold AM FM again for two seconds to turn alternate
frequency off. AF OFF will appear on the display. The
radio will not switch to other stations.
Adjusting the Speakers
BAL FADE: This button adjusts balance and fade.
To adjust balance, press this button until BAL appears
on the display. Turn the SELECT knob clockwise for
the right speakers and counterclockwise for the left
speakers. The middle position balances the sound
between the speakers. To adjust fade, press this button
until FAD appears on the display. Turn the SELECT
knob clockwise to adjust the sound to the front speakers
and counterclockwise for the rear speakers. The middle
position balances the sound between the speakers. Press
and hold this button for two seconds to return both fade
and balance to the middle position.Playing a Compact Disc
With the ignition on, insert a disc partway into the slot,
label side up. The player will pull it in and the disc should
begin playing. If you want to insert a CD when the
ignition is off, first press the eject button or the RCL knob.
Inserting a CD with the radio off and the ignition on will
start auto play.
When the disc is inserted, the CD symbol will be
displayed. If you select an EQ setting for your CD, it
will be activated each time you play a CD.
As each new track starts to play, the track number will
appear on the display.
If CHECK CD appears on the radio display and the disc
comes out, it could be that:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.
