Bulb Replacement
The headlamp is a semi-sealed beam type which uses a replace-
able halogen bulb. The bulb can be replaced from the engine
compartment side without removing the headlamp body.
+Grasp only the plastic base when handling the bulb.
Never touch the glass envelope.
1. Disconnect the battery cable.
2. Turn the bulb retaining ring counterclockwise until it is free
from the headlamp reflector, and then remove it.
3. Disconnect the harness connector from the back side of the
bulb.
4. Remove the headlamp bulb carefully. Do not shake or rotate
the bulb when removing it.
5. Install in the reverse order of removal.
CAUTION:
Do not leave headlamp reflector without bulb for a long
period of time. Dust, moisture, smoke, etc. entering head-
lamp body may affect the performance of the headlamp.
Remove headlamp bulb from the headlamp reflector just
before a replacement bulb is installed.
Aiming Adjustment
When performing headlamp aiming adjustment, use an aiming
machine, aiming wall screen or headlamp tester. Aimers should
be in good repair, calibrated and operated in accordance with
respective operation manuals.
If any aimer is not available, aiming adjustment can be done as
follows:
For details, refer to the regulations in your own country.
a. Keep all tires inflated to correct pressures.
b. Place vehicle and tester on one and same flat surface.
c. See that there is no-load in vehicle (coolant, engine oil
filled up to correct level and full fuel tank) other than the
driver (or equivalent weight placed in driver's position).
CAUTION:
Be sure aiming switch is set to ª0º when performing aiming
adjustment on vehicles equipped with headlamp aiming
control.
SEL995K
SEL466V
HEADLAMP/WAGON AND HARDTOP MODELS Ð Conventional Type Ð
EL-2035

How to Read Harness Layout
Example:
G2E1B/6: ASCD ACTUATOR
Connector color / Cavity
Connector number
Grid reference
The following Harness Layouts use a map style grid to help locate connectors on the drawings:
+Main Harness
+Engine Room Harness (Engine Compartment)
To use the grid reference
1)Find the desired connector number on the connector list.
2) Find the grid reference.
3) On the drawing, find the crossing of the grid reference letter column and number row.
4) Find the connector number in the crossing zone.
5) Follow the line (if used) to the connector.
CONNECTOR SYMBOL
Main symbols of connector (in Harness Layout) are indicated in the below.
Connector typeWater proof type Standard type
Male Female Male Female
+Cavity: Less than 4
+Relay connector
+Cavity: From 5 to 8
+Cavity: More than 9
ÐÐ
+Ground terminal etc.
Ð
HARNESS LAYOUT
EL-2106

Engine Room Harness/LHD Models
CEL244M
HARNESS LAYOUT/WAGON AND HARDTOP MODELS
EL-2116

CEL245M
HARNESS LAYOUT/WAGON AND HARDTOP MODELS
Engine Room Harness/LHD Models (Cont'd)
EL-2117

PASSENGER COMPARTMENT
CEL246M
HARNESS LAYOUT/WAGON AND HARDTOP MODELS
Engine Room Harness/LHD Models (Cont'd)
EL-2118

CEL247M
HARNESS LAYOUT/WAGON AND HARDTOP MODELS
Engine Room Harness/LHD Models (Cont'd)
EL-2119

A
A/T - Wiring diagram ............................. AT-2003
A/T control ............................................. EC-2021
A/T shift lock system ............................. AT-2013
ABS - Wiring diagram ........................... BR-2003
APS - Wiring diagram ........................... EC-2019
AT/C - Wiring diagram .......................... EC-2021
AUDIO - Wiring diagram ....................... EL-2088
Accelerator position sensor .................. EC-2019
Air bag disposal .................................... RS-2009
Air bag ................................................... RS-2003
Air flow meter - See Mass air flow
sensor ................................................ EC-2006
Anti-lock brake system - Wiring
diagram ............................................. BR-2002
Audio ...................................................... EL-2088
B
BACK/L - Wiring diagram ...................... EL-2047
BOOST - Wiring diagram ...................... EC-2029
Back-up lamp ......................................... EL-2047
Bumper, front ....................................... BT-2003
C
CD/CHG - Wiring diagram ..................... EL-2092
CIGAR - Wiring diagram ....................... EL-2085
COOL/F - Wiring diagram ..................... EC-2010
Cigarette lighter ..................................... EL-2085
Clutch cover .......................................... CL-2005
Clutch damper ....................................... CL-2004
Clutch master cylinder ........................... CL-2004
Clutch operating cylinder ....................... CL-2003
Combination meter ................................ EL-2062
Cool box - Wiring diagram .................... HA-2011
Coolant replacement ............................ MA-2003
Cooling circuit (engine) ......................... LC-2002
Cooling fan control ................................ EC-2010
D
DEICER - Wiring diagram ..................... EL-2086
DTRL - Wiring diagram ......................... EL-2037
Daytime light system ............................. EL-2037
Diagnosis sensor unit ........................... RS-2005
E
ECCS-D control module ............. EC-2027, 2028
ECTS - Wiring diagram ......................... EC-2007
EGR - Wiring diagram .......................... EC-2030
EGR volume control valve .................... EC-2030
Electrical unit ......................................... EL-2136Electrical units location .......................... EL-2103
Electronic fuel injection pump .... EC-2018, 2022,
2023, 2024, 2025, 2026, 2031
Engine control circuit diagram .............. EC-2003
Engine coolant temperature sensor
(ECTS) .............................................. EC-2007
Exterior .................................................. BT-2006
F
F/FOG - Wiring diagram ........................ EL-2048
Fluids .................................................... MA-2002
Flywheel (clutch) ................................... CL-2005
Fog lamp, front ...................................... EL-2048
Front bumper ......................................... BT-2003
Front fog lamp ....................................... EL-2048
Front passenger air bag ....................... RS-2003
Fuel gauge ............................................. EL-2062
Fuse block ............................................. EL-2134
Fuse ....................................................... EL-2135
Fusible link ............................................. EL-2135
G
Gauges .................................................. EL-2062
Grease .................................................. MA-2002
Ground distribution ................................ EL-2014
H
H/LAMP - Wiring diagram ..................... EL-2034
HEAT UP - Wiring diagram .................. EC-2035
HLC - Wiring diagram ............................ EL-2083
HORN - Wiring diagram ........................ EL-2084
Harness layout ............................ EL-2106, 2108
Hazard warning lamp ............................ EL-2050
Headlamp wiper ..................................... EL-2083
Headlamp .................................... EL-2034, 2037
Heat up switch ...................................... EC-2035
Hood ...................................................... BT-2003
Horn ....................................................... EL-2084
I
ILL - Wiring diagram .............................. EL-2055
Illumination ............................................. EL-2054
J
Junction box (J/B) .................................. EL-2134
