2001 MERCEDES-BENZ E-Class WAGON MERCEDES-BENZ E-CLASS WAGON 2001 W210 Owner's Manual

326 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Gasoline additives
A major concern among engine manufacturers is carbon
build up caused by gasoline. Mercedes-Benz
recommends the use of only quality gasoline containing
additives that prevent the build up of carbon deposits.
After an extended period of using fuels without such
additives, carbon deposits can build up especially on the
intake valves and in the combustion area, leading to
engine performance problems such as:
•warm-up hesitation,
•unstable idle,
•knocking / pinging,
•misfire,
•power loss.
Do not blend other specific fuel additives with fuel.
They only result in unnecessary cost, and may be
harmful to the engine operation.
Damage or malfunctions resulting from poor fuel
quality or from blending specific fuel additives are not
covered by the Mercedes-Benz Limited Warranty.Coolants
The engine coolant is a mixture of water and
anticorrosion / antifreeze, which provides:
•corrosion protection,
•freeze protection,
•boiling protection (by increasing the boiling point).
The cooling system was filled at the factory with a
coolant providing freeze protection to approximately
-22°F (-30°C) and corrosion protection.
If the antifreeze mixture is effective to -22°F (-30°C), the
boiling point of the coolant in the pressurized cooling
system is reached at approximately 266°F (130°C).
The coolant solution must be used year round to provide
the necessary corrosion protection and increase in the
boil-over protection. You should have it replaced every
3years.
To provide the important corrosion protection, the
solution must be at least 45% anticorrosion / antifreeze
(equals a freeze protection to approx. - 22 °F [- 30 °C]). If
you use a solution that is more than 55% anticorrosion /
antifreeze (freeze protection to approx. - 49 °F [- 45°C]),

327 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index the engine temperature will increase due to the lower
heat transfer capability of the solution. Therefore, do not
use more than this amount of anticorrosion / antifreeze.
If the coolant level is low, water and MB anticorrosion /
antifreeze should be used to bring it up to the proper
level (have cooling system checked for signs of leakage).
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If your are not sure about the water
quality, consult your authorized Mercedes-Benz Center.
Anticorrosion / antifreeze
Your vehicle contains a number of aluminum parts. The
use of aluminum components in motor vehicle engines
necessitates that anticorrosion / antifreeze coolant used
in such engines be specifically formulated to protect the
aluminum parts. (Failure to use such anticorrosion /
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your car: Mercedes-Benz
Anticorrosion / Antifreeze Agent.Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion / antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Center
for service.
Anticorrosion / antifreeze quantity
Approx. freeze protection
– 35 °F
(– 37 °C)– 49 °F
(– 45 °C)
5.3 US qt
(5.0 l)5.8 US qt
(5.5 l)

328 Consumer information
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger car tires must conform to federal safety
requirements in addition to these grades.Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Tread wear 200 Traction AA Temperature A

329 Consumer information
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Traction
The traction grades, from highest to lowest are “AA”,
“A”, “B”, and “C”. Those grades represent the tire’s
ability to stop on wet pavement as measured under
controlled conditions on specified government test
surfaces of asphalt and concrete. A tire marked “C” may
have poor traction performance.Te mp e r a t u r e
The temperature grades are “A” (the highest), “B”, and
“C”, representing the tire’s resistance to the generation
of heat and its ability to dissipate heat when tested
under controlled conditions on a specified indoor
laboratory test wheel. Sustained high temperature can
cause the material of the tire to degenerate and reduce
tire life, and excessive temperature can lead to sudden
tire failure. The grade “C” corresponds to a level of
performance which all passenger car tires must meet
under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Wa r n i n g !
The traction grade assigned to this tire is based on
straightahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.

330
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Index
AABS (Antilock brake system) .......................................225
Malfunction indicator lamp .....................................245
ABS-SYSTEM - malfunction and
warning messages ....................................................250
Adjusting steering wheel ................................................ 81
Air conditioner refrigerant ...........................................324
Air distribution .............................................................. 130
Air volume ...................................................................... 130
Airbag deactivation system ............................................ 67
AIRBAG OFF indicator lamp ........................................246
Airbags .............................................................................. 70
Alarm system .............................................................. 41, 43
Anticorrosion/antifreeze ....................218, 270, 322, 326
Antilock brake system (ABS) .......................................225
Malfunction indicator lamp .....................................245
Antitheft alarm system ................................................... 41
Aquaplaning ................................................................... 215
Armrest, rear bench ...................................................... 161
Ashtrays .......................................................................... 165
Center console, front ................................................ 165
Rear doors .................................................................. 166Audio system .................................................................. 135
Anti-theft system ....................................................... 137
Button and soft key operation ................................. 138
Cassette mode ............................................................143
CD changer .................................................................148
CD mode ..................................................................... 147
Operating and display elements ............................. 136
Operating safety ........................................................ 135
Operation – audio and telephone ........................... 135
Radio mode ................................................................ 141
Telephone operation ................................................. 151
Audio systems ...................................................................97
Cassette player ............................................................99
CD player ......................................................................98
Radio .............................................................................97
Automatic central locking ..............................................37
Automatic climate control ............................................126
Activated charcoal filter ........................................... 132
Air distribution .......................................................... 130
Air recirculation ........................................................ 131
Air volume .................................................................. 130
Basic setting ...............................................................129
Defogging windows ...................................................129
Defrosting ...................................................................129
Display and controls .................................................128
Dust filter ................................................................... 131

331
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex Economy ..................................................................... 129
Front center console
compartment ventilation .................................... 133
Rear passenger compartment
adjustable air outlet ............................................. 134
Rear window defroster ............................................. 130
Residual engine heat utilization (REST) ............... 132
Special settings ......................................................... 129
Automatic transmission ............................................... 201
Emergency operation ...............................................209
Fluid level ...................................................................269
Program mode selector switch ...............................208
Selector lever position ..............................................204
Transmission selector lever,
manually unlocking .............................................290
BBabySmart
TM airbag deactivation system ..................... 67
Self-test ......................................................................... 67
BAS (Brake assist system) ............................................223
Malfunction indicator lamp .....................................245
Battery .............................................................................283
Battery recycling .......................................................284
BATTERY / ALTERNATOR -
malfunction and warning messages ......................249Block heater .................................................................... 218
BRAKE ASSIST -
malfunction and warning messages ..................... 250
Brake assist system (BAS) ........................................... 223
Malfunction indicator lamp .................................... 245
Brake fluid ..................................................................... 324
BRAKE FLUID -
malfunction and warning messages ......................251
BRAKE LINING WEAR -
malfunction and warning messages ......................251
Brake pad wear ...............................................................251
Brake warning lamp ..................................................... 243
Brake fluid low ......................................................... 243
Brakes ................................................... 212, 223, 225, 228
CCapacities
Fuels, coolants, lubricants etc. .............................. 322
Cargo tie-down rings .....................................................177
Catalytic converter ......................................................... 196
Cellular telephone ..........................................................178
Center console .................................................................. 20
Central locking switch .................................................... 36
Central locking system .................................................... 29
Automatic central locking .........................................37

332
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Choosing global or selective mode ........................... 32
Electronic main key .................................................... 25
Electronic reserve key ................................................ 26
Locking and unlocking .............................................. 31
Mechanical keys ................................................... 26, 33
Remote control ............................................................ 25
Summer opening/convenience feature ................... 32
CHECK ENGINE
malfunction indicator lamp .....................................242
Check regularly and before a long trip ......................239
Checking engine oil level
Via engine oil level indicator ...................................117
Via oil dipstick ...........................................................268
Child restraint ..................................................... 59, 67, 78
Cleaning and care of the vehicle .................................308
Clock, setting ...................................................................110
Coin holder in glove box lid ......................................... 162
COMAND, radio and telephone ................................... 184
Combination switch ...................................................... 122
Consumer information ..................................................328
Control and operation of radio transmitters ............. 184
COOLANT (coolant level) -
malfunction and warning messages ......................253
Coolant level ...................................................................269
Adding coolant ..........................................................270
Checking ....................................................................269COOLANT TEMP. -
malfunction and warning messages ..................... 254
Coolant temperature gauge ............................................ 90
Coolants .......................................................................... 326
Anticorrosion/antifreeze quantity ........................ 327
Cruise control ................................................................ 220
Cup holder
In center console ....................................................... 164
In glove box lid .......................................................... 162
In rear bench armrest ............................................... 161
DDaytime running lamps ................................................120
Deep water
Driving instructions ................................................. 219
DISPLAY DEFECTIVE (engine control unit) -
malfunction and warning messages ..................... 248
DISPLAY DEFECTIVE (several systems) -
malfunction and warning messages ..................... 248
Display illumination ........................................................ 89
Doors .................................................................................. 34
Drinking and Driving .................................................... 211
Drive sensibly - Save Fuel ............................................. 211
Driving instructions ...................................................... 211
Driving off ....................................................................... 213

333
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
EELEC. STABIL. PROG. -
malfunction and warning messages ......................260
Electrical outlet ..............................................................265
Electronic main key ......................................................... 25
Changing batteries ...................................................298
Synchronizing remote control ................................300
Electronic stability program (ESP) ..............................228
Control switch ...........................................................230
Malfunction indicator lamp .....................................245
Synchronizing ...........................................................229
Warning lamp ............................................................245
Emergency call
See Tele Aid ............................................................... 186
Emergency engine shut-down .....................................300
Emergency tensioning retractor (ETR) ......................... 69
SRS indicator lamp ...................................................244
Emergency unlocking in case of accident ................... 37
Emission control ............................................................ 197
Emission control label .................................................. 318
Engine compartment .....................................................266
ENGINE FAN -
malfunction and warning messages ......................252
Engine malfunctionCHECK ENGINE
malfunction indicator lamp ............................... 242
Engine oil additives ...................................................... 324
Engine oil consumption ................................................ 118
Engine oil level
Checking ............................................................. 117, 268
Warning ..................................................................... 258
ENGINE OIL LEVEL -
malfunction and warning messages ..................... 258
Engine oil level indicator .............................................. 117
Engine oils ..................................................................... 324
ESP (Electronic Stability Program) ............................ 228
Control switch .......................................................... 230
Malfunction indicator lamp .................................... 245
Synchronizing .......................................................... 229
Warning lamp ........................................................... 245
ETR (Emergency tensioning retractor) .........................69
SRS indicator lamp .................................................. 244
Exterior lamp switch ..................................................... 119
Exterior lamps ................................................................ 291
Additional turn signals on
the exterior mirror .............................................. 297
Headlamp assembly ................................................. 292
High mounted stop lamp ......................................... 297
License plate lamps ................................................. 296
Low and high beam .................................................. 293
