2001 MERCEDES-BENZ C240 Owner's Manual

360 Fuels, coolants, lubricants etc. - capacities
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
will increase due to the lower heat transfer capability of
the solution. Therefore, do not use more than this
amount of anticorrosion / antifreeze.
If the coolant level is low, water and MB anticorrosion /
antifreeze should be used to bring it up to the proper
level (have cooling system checked for signs of leakage).
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If your are not sure about the water
quality, consult your authorized Mercedes-Benz Center.
Anticorrosion / antifreeze
Your vehic le con tain s a n umbe r o f alumi nium parts. The
use of aluminium components in motor vehicle engines
necessitates that anticorrosion / antifreeze coolant used
in such engines be specifically formulated to protect the
aluminium parts. (Failure to use such anticorrosion /
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your vehicle: Mercedes-Benz
anticorrosion / antifreeze agent.Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion / antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Center
for service.
Anticorrosion / antifreeze quantity
Approximately freeze protection
– 35
°F
(– 37°C)– 49
°F
(– 45°C)
4.8 US qt
(4.5 l)5.3 US qt
(5.0 l)

361 Consumer information
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger car tires must conform to federal safety
requirements in addition to these grades.
Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction
The traction grades, from highest to lowest are AA, A, B,
and C. Those grades represent the tire’s ability to stop
on wet pavement as measured under controlled
conditions on specified government test surfaces of
asphalt and concrete. A tire marked C may have poor
traction performance.
Tread wear 200 Traction AA Temperature A
Wa r n i n g !
The traction grade assigned to this tire is based on
straightahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.

362 Consumer information
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Tempera t u re
The temperature grades are A (the highest), B, and C,
representing the tire‘s resistance to the generation of
heat and its ability to dissipate heat when tested under
controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the
material of the tire to degenerate and reduce tire life,
and excessive temperature can lead to sudden tire
failure. The grade corresponds to a level of performance
which all passenger car tires must meet under the
Federal Motor Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of performance on the
laboratory test wheel than the minimum required by
law.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.

364 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Index
AAirbags .............................................................................. 65
ANTILOCK BRAKE SYSTEM
Malfunction and warning message ........................277
Antilock brake system (ABS) .......................................258
Antitheft alarm system ................................................... 38
Ashtrays .......................................................................... 199
Audio system
Button and soft key operation ................................. 163
Cassette mode ........................................................... 169
CD changer ................................................................ 174
CD mode ..................................................................... 173
Operating and display elements ............................. 161
Operating safety ........................................................ 160
Operation ................................................................... 163
Operation Audio and telephone .............................. 160
Radio mode ................................................................ 166
Telephone operation ................................................. 177
Audio systems .................................................................. 98
Cassette player .......................................................... 100
CD Player ...................................................................... 99
Radio ............................................................................. 98Automatic central locking ..............................................34
Automatic climate control ............................................ 146
Activated charcoal filter ........................................... 154
Adjustable air outlets,
rear passenger compartment ............................. 159
Air recirculation ........................................................ 153
Air volume, manual .................................................. 151
Basic setting ............................................................... 150
Defrosting ................................................................... 152
Display and controls ................................................. 148
Dust filter ................................................................... 150
Economy mode .......................................................... 155
Front center console storage
compartment ventilation ..................................... 158
Residual engine heat utilization ............................. 156
Special settings ......................................................... 151
Windows fogged up on the inside .......................... 152
Windows fogged up on the outside ........................ 152
Automatic transmission ............................................... 234
Fluid level ...................................................................301
Transmission selector lever,
manually unlocking ............................................ 325

365 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
BBabySmart
TM airbag deactivation system ..................... 62
Battery ............................................................................. 316
Block heater ....................................................................252
Brake assist system (BAS) ............................................257
CCellular telephone ......................................................... 210
Center console .................................................................. 18
Central locking switch .................................................... 33
Central locking system ................................................... 25
Automatic central locking ......................................... 34
Central locking switch ............................................... 33
Choosing global or selective mode ........................... 27
Doors ............................................................................. 31
General notes ............................................................... 24
Locking and unlocking with remote control .......... 27
Mechanical keys .......................................................... 30
Obtaining replacement keys ..................................... 23
Summer opening/convenience feature ................... 29
Vehicle keys ................................................................. 22
Check regularly and before a long trip ......................266
Checking engine oil level ............................................. 300Climate control ............................................................... 138
Adjustable air outlets,
rear passenger compartment ............................. 159
Air recirculation ........................................................ 144
Basic setting ............................................................... 142
Defrosting ................................................................... 143
Display and controls ................................................. 140
Dust filter ................................................................... 141
Economy mode .......................................................... 145
Front center console storage
compartment ventilation ..................................... 158
Residual engine heat utilization ............................. 145
Special settings ......................................................... 142
Windows fogged up on the inside .......................... 143
Windows fogged up on the outside ........................ 144
COMAND, radio, telephone and two-way radio ......... 218
Combination switch ....................................................... 134
Control and operation of radio transmitters .............. 218
Coolant level ...................................................................301
Coolant temperature gauge ..........................................124
Cruise control ................................................................ 254
Cup holder ....................................................................... 197

366 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
DDashboard ......................................................................... 16
Door control panel ........................................................... 14
Door entry lamps ........................................................... 190
Drive sensibly - Save Fuel ............................................244EEasy-entry/exit feature ................................................... 41
Electronic main key ......................................................... 23
Changing batteries ...................................................332
Synchronizing remote control ................................334
Electronic stability program (ESP) ..............................260
Emergency engine shut-down .....................................334
Emergency operation of sliding/pop-up roof ............335
Emergency tensioning retractor (ETR) ......................... 64
Emergency unlocking in case of accident ................... 34
Engine oil consumption ................................................ 129
Engine oil level indicator .............................................. 128
Enlarged cargo area .......................................................207
ENTRANCE POSITION - malfunction and warning
messages ....................................................................292
Exterior lamp switch ..................................................... 130
Daytime running lamp mode .................................. 132
Exterior lamps ................................................................326Additional turn signals on
the exterior mirror .............................................. 330
Bulbs for high and low beam ................................. 328
Headlamp assembly ................................................. 327
High mounted stop lamp ......................................... 330
License plate lamps ................................................. 330
Parking and standing lamp .................................... 328
Replacing bulbs ........................................................ 326
Taillamp assemblies ................................................ 329
Turn signal lamp ...................................................... 328
Exterior mirror adjustment ............................................ 81
Exterior mirror, front passenger side,
parking position ..........................................................82
FFirst aid kit ..................................................................... 294
Flexible service system (FSS) ......................................125
Front airbags ....................................................................65
Front center console storage
compartment ventilation ......................................... 158
Front seat adjustment .....................................................42
Fuel filler flap, manual release ................................... 335
Fuel reserve warning ..................................................... 271
Fuses ............................................................................... 295

367 Index
Te ch n i c a l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
GGarage door opener ....................................................... 212
Glove box ......................................................................... 194HHazard warning flasher switch ................................... 137
Head restraints
Rear seat ....................................................................... 52
Head restraints, front seats
Removal and installation ........................................... 47
Headlamp cleaning system .......................................... 133
Headlamp mode ............................................................. 131
Heated seats ..................................................................... 50IIdentification labels .......................................................349
Individual settings .......................................................... 111
"CONVENIENCE" ...................................................... 121
"INSTRUMENT CLUSTER" .......................................113
"LIGHTING" ................................................................117
"VEHICLE" ..................................................................119
Infant and child restraint systems ................................ 73Child seat mounts ....................................................... 76
Installation ...................................................................75
Instrument cluster ...........................................................88
Instruments and controls ............................................... 12
Center console ............................................................. 18
Dashboard .................................................................... 16
Door control panel ...................................................... 14
Overhead control panel .............................................. 15
Interior ............................................................................. 193
Interior lighting .............................................................. 189
JJack .................................................................................. 305
Jump starting .................................................................. 318LLighter .............................................................................201
Loading instructions
(Vehicle with enlarged cargo area) ....................... 209
Locator lighting .............................................................. 133
Locking the vehicle with remote control .....................27
