2001 MAZDA MODEL 626 odometer

Form No. 8P95-EA-00G
Driving Your Mazda5-30050-1AEInstrument Cluster
TachometerTurn signal indicator
Speedometer
Turn signal indicator
Odometer/Trip meter selector Fuel gauge
Water temperature gauge
Warning and indicator lights
Odometer and Trip meter
J94S5002
Warning and indicator lights

Form No. 8P95-EA-00G
Driving Your Mazda
5-31

051-1AE
Gauges Speedometer
The speedometer shows speed in miles
and kilometers per hour.

051-2IE
Odometer/Trip meter
selector
J94A4023 Odometer and Trip Meter
The ignition switch must be in the ON
position. The display mode can be changed
from odometer to trip meter A to trip
meter B and then back to odometer by
pressing the selector. The selected
mode will be displayed.

Form No. 8P95-EA-00G
Driving Your Mazda5-32J16E4064Odometer
When this mode is selected, ODO will
be displayed.
The odometer records the total
distance the vehicle has been driven.
J16E4055Trip meter A
Trip meter B Trip meter
The trip meter can record the total
distance of two trips. One is recorded
in trip meter A, and the other is
recorded in trip meter B. For instance, trip meter A can record
the distance from the point of origin,
and trip meter B can record the distance
from where the fuel tank is filled.
When trip meter A is selected,
pressing the selector again within one
second will change the trip meter to B
mode.
When trip meter A is selected, TRIP A
will be displayed. When trip meter B
is selected, TRIP B will be displayed.
The trip meter records the total
distance the vehicle is driven until the
meter is again reset. Return it to “0.0”
by holding the selector depressed for
more than 1 second.

Form No. 8P95-EA-00G
Index11-5
PagePage Page
GGauges
Fuel 5-34 . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and trip meter 5-31 . . . . . . . . .
Speedometer 5-31 . . . . . . . . . . . . . . . . . .
Tachometer 5-34 . . . . . . . . . . . . . . . . . . .
Water temperature 5-33 . . . . . . . . . . . . . .
Glove Box 5-55 . . . . . . . . . . . . . . . . . . . . . HHalogen Bulb 8-45
. . . . . . . . . . . . . . . . . . .
Hazard Warning Flasher 6-2
. . . . . . . . . . . .
Hazardous Driving 4-10
. . . . . . . . . . . . . . .
Headlight Bulb Replacement 8-45 . . . . . . .
Headlights 5-44
. . . . . . . . . . . . . . . . . . . . .
High-beam indicator light 5-42 . . . . . . . .
Hood Release 3-20
. . . . . . . . . . . . . . . . . . .
Horn 3-33
. . . . . . . . . . . . . . . . . . . . . . . . . . How to Minimize Environmental Paint
Damage
7-2
. . . . . . . . . . . . . . . . . . . . . . . .
Damage caused by bird dropping, insects,
or tree sap 7-3
. . . . . . . . . . . . . . . . . . . . .
Etching caused by acid rain or industrial
fallout 7-2
. . . . . . . . . . . . . . . . . . . . . . . .
Paint chipping 7-4
. . . . . . . . . . . . . . . . . .
Water marks 7-4
. . . . . . . . . . . . . . . . . . .
IIgnition Key Reminder 5-42
. . . . . . . . . . . .
Ignition Switch Positions 5-2
. . . . . . . . . . .
Immobilizer System 3-22, 5-41
. . . . . . . . .
Maintenance 3-24
. . . . . . . . . . . . . . . . . .
Operation 3-23
. . . . . . . . . . . . . . . . . . . .
Warning light 5-41
. . . . . . . . . . . . . . . . .
In Case of Emergency 6-1
. . . . . . . . . . . . .
Indicator Lights Cruise set 5-43
. . . . . . . . . . . . . . . . . . . .
Headlight high-beam 5-42
. . . . . . . . . . . O/D (overdrive) OFF
5-43
. . . . . . . . . . .
Rear window defroster 5-42
. . . . . . . . . .
Security 5-42
. . . . . . . . . . . . . . . . . . . . . .
Traction control system (TCS)
OFF 5-43
. . . . . . . . . . . . . . . . . . . . . . . . .
Inspecting Automatic transaxle fluid level 8-29 . . . .
Brake/clutch fluid level 8-25
. . . . . . . . .
Coolant level 8-21
. . . . . . . . . . . . . . . . . .
Engine oil level 8-17
. . . . . . . . . . . . . . . .
Power steering fluid level 8-27 . . . . . . . .
Washer fluid level 8-33
. . . . . . . . . . . . . .
Instrument Cluster 5-30
. . . . . . . . . . . . . . .
Interior Care 7-12
. . . . . . . . . . . . . . . . . . . .
Interior Light 3-39
. . . . . . . . . . . . . . . . . . .
Interior Overview 1-2
. . . . . . . . . . . . . . . . .
Introduction, Maintenance 8-2
. . . . . . . . . .

Form No. 8P95-EA-00G
Index11-7
PagePage Page
OOdometer and Trip Meter5-31
. . . . . . . . . .
Oil (see Engine)
Outside Mirrors 3-33
. . . . . . . . . . . . . . . . .
Outside the United States and
Canada 9-10
. . . . . . . . . . . . . . . . . . . . . . . .
Overheating 6-2
. . . . . . . . . . . . . . . . . . . . .
Overloading 4-15
. . . . . . . . . . . . . . . . . . . .
Owner Maintenance 8-11
. . . . . . . . . . . . . .
Precautions 8-12
. . . . . . . . . . . . . . . . . . .
Schedule 8-11
. . . . . . . . . . . . . . . . . . . . .
PPaint Damage 7-2
. . . . . . . . . . . . . . . . . . . .
Damage caused by bird dropping,
insects, or tree sap 7-3
. . . . . . . . . . . . . . .
Etching caused by acid rain or
industrial fallout 7-2
. . . . . . . . . . . . . . . .
Paint chipping 7-4
. . . . . . . . . . . . . . . . . .
Water marks 7-4
. . . . . . . . . . . . . . . . . . .
Parking Brake 5-21
. . . . . . . . . . . . . . . . . . .
Power Control Mirror 3-34
. . . . . . . . . . . . .
Power Steering 5-24
. . . . . . . . . . . . . . . . . .
Power Steering Fluid Level 8-27 . . . . . . . .
Power Windows 3-13
. . . . . . . . . . . . . . . . .
Lock switch 3-14
. . . . . . . . . . . . . . . . . .
Master control 3-13
. . . . . . . . . . . . . . . . .
One-touch power window 3-13 . . . . . . .
Passenger door 3-15
. . . . . . . . . . . . . . . .
Pregnant Women 2-25
. . . . . . . . . . . . . . . .
Push-Starting 6-7
. . . . . . . . . . . . . . . . . . . .
RRadio 5-82, 5-83
. . . . . . . . . . . . . . . . . . . .
Radio Reception 5-75
. . . . . . . . . . . . . . . . .
Rear Armrest Box 5-59
. . . . . . . . . . . . . . .
Rear Door Child Safety Lock 3-8 . . . . . . . .
Rear Seat 2-9
. . . . . . . . . . . . . . . . . . . . . . .
Armrest 2-10
. . . . . . . . . . . . . . . . . . . . . .
Rear Seat Belts 2-20
. . . . . . . . . . . . . . . . . .
Rear Window Defroster 5-49
. . . . . . . . . . .
Indicator light 5-42
. . . . . . . . . . . . . . . . .
Rearview Mirror (Day/Night) 3-35 . . . . . .
Remote Trunk Lid Release 3-16
. . . . . . . . .
Repairing Damage to the Finish 7-9 . . . . . .
Replacing
Bulb (Front, Interior) 8-48
. . . . . . . . . . .
Bulb (Rear) 8-49
. . . . . . . . . . . . . . . . . . .
Headlight bulb 8-45
. . . . . . . . . . . . . . . .
Tire 8-43
. . . . . . . . . . . . . . . . . . . . . . . . .
Wheel 8-44
. . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper blade 8-36
. . . . . . . . .
