2001 FORD MUSTANG odometer

Odometer
Registers the total
kilometers (miles) of
the vehicle.
Tachometer
Indicates the engine speed in revolutions per
minute.
Driving with your tachometer pointer at the top of
the scale or in the red zone may damage the engine.
²Base instrument
cluster
²Optional instrument
cluster
0
00000 00
4
5
6
7
8 3
2
1RPMX1000
SELECT/RESET
.
0
00000 00
4
5
6
7 3
2
1RPMX1000
SELECT/RESET
.
0
00000 00
4
5
6
7
8 3
2
1RPMX1000
SELECT/RESET
.
Instrumentation
16

Trip odometer
Registers the
kilometers (miles) of
individual journeys.
Press and release the
reset button until a ªTº
appears in the display
(this represents the
trip mode). Press and
hold the button for
three seconds to reset.
Battery voltage gauge
This shows the battery
voltage when the
ignition is in the ON
position. If the pointer
moves and stays outside the normal operating range
(as indicated by arrows), have the vehicle's electrical
system checked as soon as possible.
Engine oil pressure gauge
This shows the engine
oil pressure in the
system. Sufficient
pressure exists as long
as the needle remains in the normal range (the area
between the ªLº and ªHº).
If the gauge indicates low pressure, stop the vehicle
as soon as safely possible and switch off the engine
immediately. Check the oil level. Add oil if needed
(refer toEngine oilin theMaintenance and care
chapter). If the oil level is correct, have your vehicle
checked at your dealership or by a qualified
technician.
0
00000 00
4
5
6
7
8 3
2
1RPMX1000
SELECT/RESET
.
LH
LH
Instrumentation
17

For consistent results when filling the fuel tank:
²Turn the engine/ignition switch to the off position
prior to refueling, an error in the reading will
result if the engine is left running.
²Use the same filling rate setting (low Ð medium
Ð high) each time the tank is filled.
²Allow no more than 2 automatic click-offs when
filling.
²Always use fuel with the recommended octane
rating.
²Use a known quality gasoline, preferably a
national brand.
²Use the same side of the same pump and have
the vehicle facing the same direction each time
you fill up.
²Have the vehicle loading and distribution the
same every time.
Your results will be most accurate if your filling
method is consistent.
Calculating fuel economy
1. Fill the fuel tank completely and record the initial
odometer reading (in kilometers or miles).
2. Each time you fill the tank, record the amount of
fuel added (in liters or gallons).
3. After at least three to five tank fill-ups, fill the
fuel tank and record the current odometer reading.
4. Subtract your initial odometer reading from the
current odometer reading.
5. Follow one of the simple calculations in order to
determine fuel economy:
Multiply liters used by 100, then divide by total
kilometers traveled.
Divide total miles traveled by total gallons
used.
Maintenance and care
187

In Canada:
Customer Relationship Centre
Ford Motor Company of Canada, Limited
P.O. Box 2000
Oakville, Ontario L6J 5E4
1-800-565-3673 (FORD)
In order to help you service your Ford or Lincoln
Mercury vehicle, please have the following
information available when contacting a Customer
Relationship Center:
²Your telephone number (home and business)
²The name of the dealer and the city where the
dealership is located
²The year and make of your vehicle
²The date of vehicle purchase
²The current odometer reading
²The vehicle identification number (VIN)
If you still have a complaint involving a warranty
dispute, you may wish to contact the Dispute
Settlement Board (U.S.) or the Canadian Motor
Vehicle Arbitration Plan (CAMVAP), available in all
of Canada (except Quebec).
In some states (in the U.S.) you must directly notify
Ford in writing before pursuing remedies under your
state's warranty laws. Ford is also allowed a final
repair attempt in some states.
In the United States, a warranty dispute must be
submitted to the Dispute Settlement Board before
taking action under the Magnuson-Moss Warranty
Act, or to the extent allowed by state law, before
pursuing replacement or repurchase remedies
provided by certain state laws. This dispute handling
procedure is not required prior to enforcing state
created rights or other rights which are independent
of the Magnuson-Moss Warranty Act or state
replacement or repurchase laws.
Customer assistance
215

fuel pump shut-off
switch .................... 130
gauge ....................... 14
improving fuel
economy ................ 186
low fuel warning
light .......................... 11
octane
rating ..... 184, 209±210
quality .................... 184
running out of
fuel ......................... 185
safety information
relating to automotive
fuels ....................... 180
Fuses ................ 131±132
G
Gas cap (see
Fuel cap) ........... 11, 182
Gas mileage (see Fuel
economy) ................. 186
Gauges ....................... 14
battery voltage
gauge ....................... 17
engine coolant
temperature
gauge ....................... 15
engine oil pressure
gauge ....................... 17
fuel gauge ................ 14
odometer ................. 16
speedometer ........... 15
tachometer .............. 16
trip odometer .......... 17
GAWR (Gross Axle
Weight Rating) ........ 122
definition ............... 122driving with a heavy
load ........................ 122
location .................. 122
GVWR (Gross Vehicle
Weight Rating) ........ 122
calculating ............. 122
definition ............... 122
driving with a heavy
load ........................ 122
location .................. 122
H
Hazard flashers ....... 130
Head restraints ......... 73
Headlamps ................. 18
aiming .................... 198
bulb specifications 197
daytime running
lights ........................ 18
flash to pass ............ 51
high beam ........... 8, 18
replacing bulbs ..... 193
turning on and off .. 18
warning chime ........ 13
Heating ...................... 20
heating and air
conditioning
system ..................... 20
Hood ........................ 149
I
Ignition ....... 52, 209±210
removing the key .. 122
Infant seats (see Safety
seats) ......................... 95
Inspection/maintenance
(I/M) testing ............ 191
Index
231

M
Manual
transmission ............ 119
fluid capacities ...... 206
lubricant
specifications ........ 209
reverse ................... 121
Mirrors
cleaning ................. 201
side view mirrors
(power) ................... 58
Motorcraft
parts ................. 185, 206
O
Octane rating .......... 184
Odometer ................... 16
Oil (see Engine
oil) ............................ 151
Overdrive ........... 58, 115
P
Panic alarm feature,
remote entry
system ........................ 65
Parking brake .......... 110
Parts (see Motorcraft
parts) ....................... 206
Power distribution box
(see Fuses) ............. 135
Power door locks ...... 57
Power steering ........ 113
fluid, checking and
adding .................... 166fluid, refill
capacity ................. 206
fluid,
specifications 208±209
R
Radio .......................... 24
Relays ...................... 131
Remote entry
system .................. 64±65
illuminated entry .... 66
locking/unlocking
doors .................. 64±65
opening the trunk ... 65
panic alarm ............. 65
replacement/additional
transmitters ............. 66
replacing the
batteries .................. 67
S
Safety belts (see Safety
restraints) ........... 13, 76,
78±81
Safety defects,
reporting .................. 227
Safety restraints ........ 76
, 78±81
belt minder ............. 83
cleaning the safety
belts ................. 87, 204
extension
assembly .................. 82
for adults ........... 78±81
for children ....... 93±94
warning light and
chime ....... 9, 13, 82±83
Index
233

Safety seats for
children ...................... 95
Seat belts (see Safety
restraints) .................. 76
Seats .......................... 73
child safety seats .... 95
cleaning ......... 204±205
easy access/easyout
feature ..................... 75
SecuriLock passive
anti-theft
system .................. 67±69
Servicing your
vehicle ...................... 147
Spark plugs,
specifications ........... 206
, 209±210
Special notice .............. 3
Specification chart,
lubricants ......... 208±209
Speed control ............ 53
Speedometer ............. 15
Starting your
vehicle ...... 103±104, 106
jump starting ........ 141
Steering wheel
tilting ....................... 52
T
Tachometer ............... 16
Tires ......... 137, 175±177
changing ........ 137±138
checking the
pressure ................. 177
replacing ................ 178
rotating .................. 177snow tires and
chains .................... 179
tire grades ............. 176
treadwear .............. 175
Towing ..................... 124
recreational
towing .................... 127
trailer towing ........ 124
wrecker .................. 146
Traction
control ............... 50, 111
active light .............. 12
Traction-lok rear
axle .......................... 122
Transmission
automation
operation ............... 113
fluid, checking and
adding
(automatic) ........... 167
fluid, checking and
adding (manual) ... 170
fluid, refill
capacities ............... 206
lubricant
specifications. 208±209
manual operation .. 119
Trip odometer ........... 17
Trunk ......................... 71
remote release .. 50, 65
Turn signal ............ 8, 51
V
Vehicle
dimensions ............... 210
Vehicle Identification
Number (VIN) ......... 211
Index
234
