2001 FORD EXPLORER Owners Manual

Page 185 of 288

FORD EXPLORER 2001 2.G Owners Manual GETTING ROADSIDE ASSISTANCE
To fully assist you should you have a vehicle concern, Ford offers a
complimentary roadside assistance program. This program is separate
from the New Vehicle Limited Warran

Page 186 of 288

FORD EXPLORER 2001 2.G Owners Manual Roadside coverage beyond basic warranty
In the United States, you may purchase additional roadside assistance
coverage beyond this period through the Ford Auto Club by contacting
your Ford or Lincoln

Page 187 of 288

FORD EXPLORER 2001 2.G Owners Manual The fuel pump shut-off switch is
located in the passengers foot well,
by the kick panel.
Use the following procedure to reset the fuel pump shut-off switch.
1. Turn the ignition to the OFF position.

Page 188 of 288

FORD EXPLORER 2001 2.G Owners Manual Always replace a fuse with one that has the specified amperage
rating. Using a fuse with a higher amperage rating can cause
severe wire damage and could start a fire.
Standard fuse amperage rating and

Page 189 of 288

FORD EXPLORER 2001 2.G Owners Manual Passenger compartment fuse panel
The fuse panel is located on the left
hand side of the instrument panel
facing the drivers side door. Pull the
panel cover outward to access the
fuses.
To remove a fu

Page 190 of 288

FORD EXPLORER 2001 2.G Owners Manual The fuses are coded as follows:
Fuse/
Relay
LocationFuse
Amp
RatingPassenger Compartment Fuse Panel
Description
1 7.5A Power Mirror Switch, Power Antenna, Memory
Seat
2 7.5A Blower Motor Relay, Air Ba

Page 191 of 288

FORD EXPLORER 2001 2.G Owners Manual Fuse/
Relay
LocationFuse
Amp
RatingPassenger Compartment Fuse Panel
Description
11 7.5A Instrument Cluster
12 7.5A Washer Pump Relay, Rear Washer Pump Relay
13 20A Brake Pedal Position Switch, Brake P

Page 192 of 288

FORD EXPLORER 2001 2.G Owners Manual Fuse/
Relay
LocationFuse
Amp
RatingPassenger Compartment Fuse Panel
Description
32 10A Heated Mirror
33 15A Headlamps, Daytime Running Lamps (DRL)
Module, Instrument Cluster
34 7.5A Rear Integrated Co
