2001 DODGE TOWN AND COUNTRY sensor

Component Page
C326............................. 8W-80-41
C327............................. 8W-80-41
C327............................. 8W-80-41
C329 (Diesel)....................... 8W-80-42
C329 (Diesel)....................... 8W-80-42
C330 (Diesel)....................... 8W-80-42
C330 (Diesel)....................... 8W-80-42
C331 (Diesel)....................... 8W-80-42
C331 (Diesel)....................... 8W-80-43
C332 (ATC)........................ 8W-80-43
C332 (ATC)........................ 8W-80-43
Cabin Heater Assist C1 (Diesel)........ 8W-80-43
Cabin Heater Assist C2 (Diesel)........ 8W-80-44
Camshaft Position Sensor (Gas)........ 8W-80-44
Camshaft Position Sensor (Diesel)...... 8W-80-44
CD Changer....................... 8W-80-44
Center Dome Lamp (Base/High Line).... 8W-80-45
Center High Mounted Stop Lamp....... 8W-80-45
Clockspring C1..................... 8W-80-45
Clockspring C2..................... 8W-80-45
Clockspring C3..................... 8W-80-45
Clockspring C4..................... 8W-80-46
Clockspring C5..................... 8W-80-46
Clutch Departure Switch (Diesel)....... 8W-80-46
Clutch Interlock/Upstop Switch (MTX) . . . 8W-80-46
Controller Antilock Brake............. 8W-80-47
Crank Case Ventilation Heater (Diesel) . . 8W-80-47
Crankshaft Position Sensor (Diesel)..... 8W-80-48
Crankshaft Position Sensor (Gas)....... 8W-80-48
Data Link Connector................. 8W-80-48
Diagnostic Junction Port.............. 8W-80-49
Dosing Pump....................... 8W-80-49
Driver Airbag C1.................... 8W-80-49
Driver Airbag C2.................... 8W-80-49
Driver Blend Door Actuator (ATC)...... 8W-80-50
Driver Blend Door Actuator (MTC)...... 8W-80-50
Driver Door Courtesy Lamp........... 8W-80-50
Driver Door Lock Switch.............. 8W-80-50
Driver Heated Seat Back............. 8W-80-50
Driver Heated Seat Cushion........... 8W-80-51
Driver Heated Seat Module C1......... 8W-80-51
Driver Heated Seat Module C2......... 8W-80-51
Driver Heated Seat Module C3......... 8W-80-51
Driver Power Seat Front Riser Motor.... 8W-80-52
Driver Power Seat Horizontal Motor..... 8W-80-52
Driver Power Seat Rear Riser Motor.... 8W-80-52
Driver Power Seat Recliner Motor...... 8W-80-52
Driver Power Seat Switch............. 8W-80-52
Driver Power Window Motor........... 8W-80-53
Driver Power Window Switch (LHD)..... 8W-80-53
Driver Power Window Switch (RHD).... 8W-80-53
Driver Seat Belt Switch.............. 8W-80-54
Driver Seat Belt Tensioner............ 8W-80-54
EGR Solenoid (Diesel)................ 8W-80-54Component Page
EGR Solenoid (Gas)................. 8W-80-54
Electric Wiper De-Icer C1............. 8W-80-54
Electric Wiper De-Icer C2............. 8W-80-55
Engine Control Module C1 (Diesel)...... 8W-80-55
Engine Control Module C2 (Diesel)...... 8W-80-57
Engine Coolant Temp Sensor (Diesel).... 8W-80-57
Engine Coolant Temp Sensor (Gas)...... 8W-80-58
Engine Oil Pressure Sensor (Diesel)..... 8W-80-58
Engine Oil Pressure Switch (Gas)....... 8W-80-58
Engine Oil Temperature Sensor (Diesel) . . 8W-80-58
EVAP/Purge Solenoid (Gas)............ 8W-80-58
Evaporator Temperature Sensor........ 8W-80-59
Floor Console Lamp................. 8W-80-59
Floor Console Power Outlet........... 8W-80-59
Front Blower Module C1 (ATC)......... 8W-80-59
Front Blower Module C2 (ATC)......... 8W-80-59
Front Cigar Lighter................. 8W-80-60
Front Reading Lamps/Switch.......... 8W-80-60
Front Washer Pump Motor............ 8W-80-60
Fuel Heater (Diesel)................. 8W-80-60
Fuel Injector No. 1 (2.4L/3.3L/3.8L)..... 8W-80-60
Fuel Injector No. 1 (Diesel)............ 8W-80-61
Fuel Injector No. 2 (2.4L/3.3L/3.8L)..... 8W-80-61
Fuel Injector No. 2 (Diesel)............ 8W-80-61
Fuel Injector No. 3 (2.4L/3.3L/3.8L)..... 8W-80-61
Fuel Injector No. 3 (Diesel)............ 8W-80-61
Fuel Injector No. 4 (2.4L/3.3L/3.8L)..... 8W-80-62
Fuel Injector No. 4 (Diesel)............ 8W-80-62
Fuel Injector No. 5 (3.3L/3.8L)......... 8W-80-62
Fuel Injector No. 6 (3.3L/3.8L)......... 8W-80-62
Fuel Pressure Sensor (Diesel).......... 8W-80-62
Fuel Pressure Solenoid (Diesel)......... 8W-80-63
Fuel Pump Module.................. 8W-80-63
Generator......................... 8W-80-63
Glove Box Lamp.................... 8W-80-63
Glow Plug Relay (Diesel).............. 8W-80-63
Halo Lamp........................ 8W-80-64
Headlamp Switch................... 8W-80-64
Headlamp Washer Pump Motor
(Built-Up-Export)................. 8W-80-64
High Note Horn.................... 8W-80-64
Hood Ajar Switch................... 8W-80-65
Idle Air Control Motor (2.4L).......... 8W-80-65
Idle Air Control Motor (3.3L/3.8L)....... 8W-80-65
Ignition Coil (2.4L).................. 8W-80-65
Ignition Coil (3.3L/3.8L).............. 8W-80-65
Ignition Switch..................... 8W-80-66
Inlet Air Temperature Sensor.......... 8W-80-66
Instrument Cluster.................. 8W-80-66
Instrument Panel Switch Bank......... 8W-80-67
Intelligent Power Module C1.......... 8W-80-67
Intelligent Power Module C2.......... 8W-80-68
Intelligent Power Module C3 (Diesel).... 8W-80-68
Intelligent Power Module C3 (Gas)...... 8W-80-69
8Wa - 80 - 2 8W-80 CONNECTOR PIN-OUTSRG
ProCarManuals.com

Component Page
Intelligent Power Module C4.......... 8W-80-69
Intelligent Power Module C5.......... 8W-80-69
Intelligent Power Module C6.......... 8W-80-70
Intelligent Power Module C7.......... 8W-80-70
Intelligent Power Module C8.......... 8W-80-71
Intelligent Power Module C9.......... 8W-80-71
Knock Sensor (2.4L)................. 8W-80-71
Knock Sensor (3.3L/3.8L)............. 8W-80-71
Leak Detection Pump
(Except Built-Up-Export)........... 8W-80-72
Left B-Pillar Switch................. 8W-80-72
Left Cinch/Release Motor
(Power Sliding Door)............... 8W-80-72
Left Combination Relay (Trailer Tow).... 8W-80-72
Left Cylinder Lock Switch............. 8W-80-72
Left Door Speaker................... 8W-80-73
Left Fog Lamp..................... 8W-80-73
Left Front Door Ajar Switch (Base)...... 8W-80-73
Left Front Door Lock Motor/Ajar Switch
(Except Base).................... 8W-80-73
Left Front Park/Turn Signal Lamp (Except
Built-Up-Export).................. 8W-80-74
Left Front Wheel Speed Sensor......... 8W-80-74
Left Full Open Switch (Power Sliding Door). 8W-80-74
Left Headlamp (Except Built-Up-Export) . 8W-80-74
Left Headlamp Leveling Motor
(Built-Up-Export)................. 8W-80-74
Left High Beam Lamp (Built-Up-Export) . 8W-80-75
Left Instrument Panel Speaker......... 8W-80-75
Left Liftgate Flood Lamp............. 8W-80-75
Left Low Beam Lamp (Built-Up-Export) . . 8W-80-75
Left Mid Reading Lamp
(Premium/Luxury)................. 8W-80-75
Left Park Lamp (Built-Up-Export)...... 8W-80-76
Left Power Mirror................... 8W-80-76
Left Rear Lamp Assembly............. 8W-80-76
Left Rear Pillar Speaker.............. 8W-80-77
Left Rear Reading Lamp (Luxury)...... 8W-80-77
Left Rear Speaker................... 8W-80-77
Left Rear Vent Motor................ 8W-80-77
Left Rear Wheel Speed Sensor......... 8W-80-77
Left Remote Radio Switch............. 8W-80-78
Left Repeater Lamp (Built-Up-Export) . . . 8W-80-78
Left Seat Airbag.................... 8W-80-78
Left Side Impact Airbag Control Module . . 8W-80-78
Left Sliding Door Control Module C1
(Power Sliding Door)............... 8W-80-78
Left Sliding Door Control Module C2
(Power Sliding Door)............... 8W-80-79
Left Sliding Door Latch Sensing Switch
(Power Sliding Door)............... 8W-80-79
Left Sliding Door Lock Motor
(Power Sliding Door)............... 8W-80-79
Left Sliding Door Lock Motor/Ajar Switch
(Manual Sliding Door).............. 8W-80-80Component Page
Left Sliding Door Motor
(Power Sliding Door)............... 8W-80-80
Left Speed Control Switch............ 8W-80-80
Left Stop/Turn Signal Relay (Trailer Tow) . 8W-80-80
Left Turn Signal Lamp
(Built-Up-Export)................. 8W-80-81
Left Visor/Vanity Lamp
(Premium/Luxury)................. 8W-80-81
License Lamp (Manual Release)........ 8W-80-81
License Lamp (Power Liftgate)......... 8W-80-81
License Lamp (Power Release)......... 8W-80-82
Liftgate Ajar Switch (Manual Release) . . . 8W-80-82
Liftgate Ajar Switch (Power Release).... 8W-80-82
Liftgate Cinch/Release Motor
(Power Liftgate).................. 8W-80-82
Liftgate Cylinder Lock Switch.......... 8W-80-82
Liftgate Left Pinch Sensor
(Power Liftgate).................. 8W-80-83
Liftgate Right Pinch Sensor
(Power Liftgate).................. 8W-80-83
Lift Pump Motor (Diesel)............. 8W-80-83
Low Note Horn..................... 8W-80-83
Manifold Absolute Pressure
Sensor (Gas)..................... 8W-80-83
Mass Air Flow Sensor (Diesel)......... 8W-80-84
Memory Power Seat Switch........... 8W-80-84
Memory Seat/Mirror Module C1........ 8W-80-84
Memory Seat/Mirror Module C2........ 8W-80-85
Memory Seat/Mirror Module C3........ 8W-80-85
Memory Seat/Mirror Module C4........ 8W-80-86
Memory Seat Front Vertical Motor...... 8W-80-86
Memory Seat Front Vertical
Position Sensor................... 8W-80-86
Memory Seat Horizontal Motor......... 8W-80-86
Memory Seat Horizontal
Position Sensor................... 8W-80-86
Memory Seat Rear Vertical Motor....... 8W-80-87
Memory Seat Rear Vertical
Position Sensor................... 8W-80-87
Memory Seat Recliner Motor.......... 8W-80-87
Memory Seat Recliner Position Sensor . . . 8W-80-87
Memory Seat Switch................. 8W-80-87
Message Center (High Line)........... 8W-80-88
Mode Door Actuator (ATC)............ 8W-80-88
Mode Door Actuator (MTC)............ 8W-80-88
Multi-Function Switch............... 8W-80-88
Occupant Restraint Controller......... 8W-80-89
Overhead Console (Except Base)........ 8W-80-89
Oxygen Sensor 1/1 Upstream (Gas)...... 8W-80-90
Oxygen Sensor 1/2 Downstream (Gas) . . . 8W-80-90
Park/Neutral Position Switch (ATX)..... 8W-80-90
Passenger Airbag................... 8W-80-90
Passenger Blend Door Actuator (ATC) . . . 8W-80-90
Passenger Blend Door Actuator (MTC) . . . 8W-80-91
Passenger Door Courtesy Lamp........ 8W-80-91
RG8W-80 CONNECTOR PIN-OUTS8Wa-80-3
ProCarManuals.com

Component Page
Passenger Door Lock Switch........... 8W-80-91
Passenger Folding Mirror Relay
(Built-Up-Export)................. 8W-80-91
Passenger Heated Seat Back........... 8W-80-92
Passenger Heated Seat Cushion........ 8W-80-92
Passenger Heated Seat Module C1...... 8W-80-92
Passenger Heated Seat Module C2...... 8W-80-92
Passenger Heated Seat Module C3...... 8W-80-93
Passenger Power Seat Front Riser Motor . 8W-80-93
Passenger Power Seat Horizontal Motor . . 8W-80-93
Passenger Power Seat Rear Riser Motor . . 8W-80-93
Passenger Power Seat Recliner Motor.... 8W-80-93
Passenger Power Seat Switch.......... 8W-80-94
Passenger Power Window Motor........ 8W-80-94
Passenger Power Window Switch....... 8W-80-94
Passenger Seat Belt Switch........... 8W-80-94
Passenger Seat Belt Tensioner......... 8W-80-95
Power Folding Mirror Switch
(Built-Up-Export)................. 8W-80-95
Power Liftgate Module C1............ 8W-80-95
Power Liftgate Module C2............ 8W-80-96
Power Liftgate Motor................ 8W-80-96
Power Mirror Switch................. 8W-80-97
Power Outlet....................... 8W-80-97
Power Seat Circuit Breaker (30A)....... 8W-80-97
Powertrain Control Module C1
(2.4L/3.3L/3.8L)................... 8W-80-98
Powertrain Control Module C2
(2.4L/3.3L/3.8L)................... 8W-80-99
Power Window Circuit Breaker (25A) . . . 8W-80-100
Radiator Fan No. 1 (Diesel)........... 8W-80-100
Radiator Fan No. 1 (Gas)............ 8W-80-100
Radiator Fan No. 2 (Diesel)........... 8W-80-100
Radiator Fan No. 2 (Gas)............ 8W-80-100
Radiator Fan Relay (Gas)............ 8W-80-101
Radiator Fan Relay No. 1 (Diesel)...... 8W-80-101
Radiator Fan Relay No. 2 (Diesel)...... 8W-80-101
Radiator Fan Relay No. 3 (Diesel)...... 8W-80-102
Radio C1......................... 8W-80-102
Radio C2......................... 8W-80-102
Radio C3......................... 8W-80-102
Radio C4......................... 8W-80-103
Radio Choke...................... 8W-80-103
Rear A/C-Heater Unit (3 Zone HVAC) . . . 8W-80-103
Rear Auto Temp Control Switch (ATC) . . 8W-80-104
Rear Blower Front Control Switch
(3 Zone HVAC).................. 8W-80-104
Rear Blower Motor Power Module
C1(ATC) ....................... 8W-80-104
Rear Blower Motor Power Module
C2(ATC) ....................... 8W-80-104
Rear Blower Rear Control Switch
C1 (3 Zone HVAC)................ 8W-80-105
Rear Blower Rear Control Switch C2
(3 Zone HVAC).................. 8W-80-105Component Page
Rear Dome Lamp (Except Luxury)..... 8W-80-105
Rear Mode Motor (ATC)............. 8W-80-105
Rear Power Outlet................. 8W-80-105
Rear Temperature Motor (ATC)........ 8W-80-106
Rear Washer Pump Motor............ 8W-80-106
Rear Wiper Motor.................. 8W-80-106
Recirculation Door Actuator (ATC)..... 8W-80-106
Recirculation Door Actuator (MTC)..... 8W-80-106
Remote Keyless Entry Antenna
(Japan)........................ 8W-80-107
Remote Keyless Entry Module........ 8W-80-107
Right B-Pillar Switch............... 8W-80-107
Right Cinch/Release Motor
(Power Sliding Door).............. 8W-80-107
Right Combination Relay
(Trailer Tow).................... 8W-80-107
Right Cylinder Lock Switch.......... 8W-80-108
Right Door Speaker................. 8W-80-108
Right Fog Lamp................... 8W-80-108
Right Front Door Ajar Switch (Base).... 8W-80-108
Right Front Door Lock Motor/Ajar Switch
(Except Base)................... 8W-80-108
Right Front Park/Turn Signal Lamp
(Except Built-Up-Export).......... 8W-80-109
Right Front Wheel Speed Sensor...... 8W-80-109
Right Full Open Switch
(Power Sliding Door).............. 8W-80-109
Right Headlamp (Except
Built-Up-Export)................. 8W-80-109
Right Headlamp Leveling Motor
(Built-Up-Export)................ 8W-80-110
Right High Beam Lamp
(Built-Up-Export)................ 8W-80-110
Right Instrument Panel Speaker....... 8W-80-110
Right Liftgate Flood Lamp........... 8W-80-110
Right Low Beam Lamp
(Built-Up-Export)................ 8W-80-110
Right Mid Reading Lamp
(Premium/Luxury)................ 8W-80-111
Right Park Lamp (Built-Up-Export).... 8W-80-111
Right Power Mirror................. 8W-80-111
Right Rear Lamp Assembly........... 8W-80-111
Right Rear Pillar Speaker............ 8W-80-112
Right Rear Reading Lamp (Luxury).... 8W-80-112
Right Rear Speaker................. 8W-80-112
Right Rear Vent Motor.............. 8W-80-112
Right Rear Wheel Speed Sensor....... 8W-80-112
Right Remote Radio Switch........... 8W-80-113
Right Repeater Lamp (Built-Up-Export) . 8W-80-113
Right Seat Airbag.................. 8W-80-113
Right Side Impact Airbag
Control Module.................. 8W-80-113
Right Sliding Door Control Module C1
(Power Sliding Door).............. 8W-80-113
8Wa - 80 - 4 8W-80 CONNECTOR PIN-OUTSRG
ProCarManuals.com

Component Page
Right Sliding Door Control Module C2
(Power Sliding Door).............. 8W-80-114
Right Sliding Door Latch Sensing Switch
(Power Sliding Door).............. 8W-80-114
Right Sliding Door Lock Motor
(Power Sliding Door).............. 8W-80-114
Right Sliding Door Lock Motor/
Ajar Switch (Manual Sliding Door) . . . 8W-80-115
Right Sliding Door Motor
(Power Sliding Door).............. 8W-80-115
Right Speed Control Switch.......... 8W-80-115
Right Stop/Turn Signal Relay
(Trailer Tow).................... 8W-80-115
Right Turn Signal Lamp
(Built-Up-Export)................ 8W-80-116
Right Visor/Vanity Lamp
(Premium/Luxury)................ 8W-80-116
Sentry Key Immobilizer Module....... 8W-80-116
Siren (United Kingdom)............. 8W-80-116
Solenoid/Pressure Switch Assy (EATX) . . 8W-80-117Component Page
Speed Control Servo (Gas)............ 8W-80-117
Speed Sensor-Input (EATX)........... 8W-80-117
Speed Sensor-Output (EATX)......... 8W-80-117
Thatcham Alarm Module C1
(United Kingdom)................ 8W-80-118
Thatcham Alarm Module C2
(United Kingdom)................ 8W-80-118
Throttle Position Sensor (Gas)......... 8W-80-118
Torque Converter Clutch Solenoid
(ATX).......................... 8W-80-118
Traction Control Switch.............. 8W-80-119
Trailer Tow Connector (Except
Built-Up-Export)................. 8W-80-119
Transmission Control Module (EATX) . . . 8W-80-119
Transmission Range Sensor (EATX).... 8W-80-120
TXV Solenoid (ATC)................ 8W-80-121
Vehicle Speed Sensor (MTX/ATX)...... 8W-80-121
Washer Fluid Level Switch........... 8W-80-121
Water In Fuel Sensor (Diesel)......... 8W-80-121
Wiper Module..................... 8W-80-121
RG8W-80 CONNECTOR PIN-OUTS8Wa-80-5
ProCarManuals.com

A/C COMPRESSOR CLUTCH - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C3 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z153 18BK/GY GROUND
A/C-HEATER CONTROL C1 (MTC) - BLACK/RED 20 WAY
CAV CIRCUIT FUNCTION
1 Z24 18BK/OR GROUND
2 C121 20DB/DG SENSOR GROUND
3 C22 20LB/WT (3 ZONE HVAC) REAR TEMPERATURE FEEDBACK SIGNAL
4- -
5 F850 20LB/PK (3 ZONE HVAC) 5 VOLT SUPPLY
6 C900 18LB/VT WIPER DE-ICER DRIVER
7 C32 20DB/TN RECIRCULATION DOOR DRIVER (A)
8 C54 20LB/YL (3 ZONE HVAC) REAR BLEND DOOR DRIVER
9 C34 20DB/LB COMMON DOOR DRIVER (B)
10 D25 20WT/VT PCI BUS
11 - -
12 C121 20DB/DG (3 ZONE HVAC) REAR TEMPERATURE RETURN
13 F504 20GY/PK IGNITION SWITCH OUTPUT (RUN)
14 E12 20OR/GY PANEL LAMPS DRIVER
15 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL
16 C33 20LB/BR PASSENGER BLEND DOOR DRIVER (A)
17 C61 20DB/LG DRIVER BLEND DOOR DRIVER (A)
18 C35 20LB/OR MODE DOOR DRIVER (A)
19 C53 20LB (3 ZONE HVAC) REAR MODE DOOR DRIVER
20 C154 20LB/OR (3 ZONE HVAC) REAR COMMON DOOR DRIVER
A/C-HEATER CONTROL C2 (MTC) - BLACK/BLUE 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 C75 12DB/GY BLOWER MOTOR HIGH DRIVER
3 C74 12DB/WT BLOWER MOTOR M3 DRIVER
4 Z134 12BK/OR GROUND
5 C71 16DB/BR BLOWER MOTOR LOW DRIVER
6- -
7- -
8- -
9 C73 14DB/VT BLOWER MOTOR M2 DRIVER
10 C72 16DB/OR BLOWER MOTOR M1 DRIVER
8Wa - 80 - 6 8W-80 CONNECTOR PIN-OUTSRG
ProCarManuals.com

A/C PRESSURE SENSOR - GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 K900 18DB/DG (GAS) SENSOR GROUND
1 C918 20BK/LB (DIESEL) A/C PRESSURE SENSOR GROUND
2 F855 18PK/YL (GAS) 5 VOLT SUPPLY
2 F851 20LB/PK (DIESEL) SENSOR REFERENCE VOLTAGE B
3 C18 18LB/BR (GAS) A/C PRESSURE SENSOR SIGNAL
3 C18 20LB/BR (DIESEL) A/C PRESSURE SENSOR SIGNAL
4- -
ACCELERATOR PEDAL POSITION SENSOR (DIESEL) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 K4 20BK/LB LOW IDLE POSITION SWITCH GROUND
4- -
5 K151 20WT LOW IDLE POSITION SWITCH SENSE
6- -
7 K22 20OR/DB ACCELERATOR PEDAL POSITION SENSOR SIGNAL
8 K167 20BR/YL ACCELERATOR PEDAL POSITION SENSOR GROUND
9- -
10 F852 20VT/PK ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
AMBIENT TEMP SENSOR (EXCEPT BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G31 18VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
2 G931 18VT/BR AMBIENT TEMPERATURE SENSOR RETURN
ATC REMOTE SENSOR (ATC)-4WAY
CAV CIRCUIT FUNCTION
1 F600 20LB/PK PROTECTED IGNITION
2 D40 20WT/LB KDB NO. 2 CLOCK
3 C905 20BR/LB SENSOR RETURN
4 D18 20WT/YL KDB NO. 2 DATA
RG8W-80 CONNECTOR PIN-OUTS8Wa-80-7
ProCarManuals.com

AUTOMATIC DAY/NIGHT MIRROR (PREMIUM/LUXURY) - BLACK 7 WAY
CAV CIRCUIT FUNCTION
1 F503 20BK/PK IGNITION SWITCH OUTPUT (RUN)
2 Z113 20BK GROUND
3 L1 20BK/WT BACK-UP LAMP FEED
4 P112 20BK/OR (EXCEPT BUILT-UP-
EXPORT)MIRROR B(+)
5 P114 20BK/LB (EXCEPT BUILT-UP-
EXPORT)MIRROR B(-)
6- -
7 L24 20BK/GY (EXCEPT BUILT-UP-EX-
PORT)AUTOMATIC HEADLAMP SWITCH SENSOR
AUTOSTICK SWITCH (EXCEPT BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T55 20YL/VT AUTOSTICK/OVERDRIVE OFF MUX INPUT
2 Z65 20BK/YL GROUND
AUTO TEMP CONTROL C1 - WHITE 13 WAY
CAV CIRCUIT FUNCTION
1 C161 20LB/WT DRIVER BLEND DOOR DRIVER (B)
2 C61 20DB/LG DRIVER BLEND DOOR DRIVER (A)
3 C133 20DB/WT PASSENGER BLEND DOOR DRIVER (B)
4 C33 20LB/BR PASSENGER BLEND DOOR DRIVER (A)
5 C132 20DB/YL RECIRCULATION DOOR DRIVER (B)
6 C32 20DB/TN RECIRCULATION DOOR DRIVER (A)
7 C135 20DB/GY MODE DOOR DRIVER (B)
8 C35 20LB/OR MODE DOOR DRIVER (A)
9 C53 20LB REAR MODE DOOR DRIVER (A)
10 C154 20LB/OR REAR MODE DOOR DRIVER (B)
11 C54 20LB/YL REAR BLEND DOOR DRIVER (A)
12 C169 20DB/OR REAR BLEND DOOR DRIVER (B)
13 - -
8Wa - 80 - 8 8W-80 CONNECTOR PIN-OUTSRG
ProCarManuals.com

AUTO TEMP CONTROL C2 - BLACK 13 WAY
CAV CIRCUIT FUNCTION
1 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL
2 C121 20DB/DG SENSOR GROUND
3 E12 20OR/GY PANEL LAMPS DRIVER
4 A114 20GY/RD FUSED B(+) (I.O.D.)
5 F504 20GY/PK IGNITION SWITCH OUTPUT (RUN)
6 D25 20WT/VT PCI BUS
7 C56 20DB/LB BLOWER MOTOR CONTROL
8 C59 20DB/LB REAR BLOWER MOTOR CONTROL
9 D22 20WT/TN KDB CLOCK
10 D17 20WT/DG KDB DATA
11 Z24 18BK/OR GROUND
12 C200 20LB/DG TXV SOLENOID FEED
13 C900 18LB/VT WIPER DE-ICER DRIVER
AUTO TEMP CONTROL C3-4WAY
CAV CIRCUIT FUNCTION
1 F600 20LB/PK PROTECTED IGNITION
2 D40 20WT/LB KDB NO.2 CLOCK
3 C905 20BR/LB SENSOR RETURN
4 D18 20WT/YL KDB NO. 2 DATA
BACK-UP LAMP SWITCH (MTX) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T2 18DG/WT TRS REVERSE SENSE
2 Z252 18BK/WT GROUND
BATTERY TEMPERATURE SENSOR (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K25 20BR/TN BATTERY TEMPERATURE SENSOR SIGNAL
2 K900 20DB/DG SENSOR GROUND
RG8W-80 CONNECTOR PIN-OUTS8Wa-80-9
ProCarManuals.com
