2001 CHEVROLET S10 Owners Manual

6-72
Normal Maintenance Replacement Parts
Replacement part numbers listed in this section are based on the latest information available at the time of printing
and are subject to change. If a part listed in this manual is not the same as the part used in your vehicle when it was
built, or if you have any questions, please contact your GM dealer.
Engine ªVORTECº 2200 L4 ªVORTECº 4300 V6
Oil Filter PF47 PF47
Air Cleaner Filter A1163C A1163C
PCV Valve N/A CV769C
Automatic Transmission Filter Kit 24200796 24200796
Spark Plugs
41
-948 41-932
Fuel Filter GF481 GF481
Windshield Wiper Blades Trico (20 inches/51 cm) Trico (20 inches/51 cm)

6-73 Vehicle Dimensions*
Wheelbase
Reg Cab Short Box 108.3 inches (275.1 cm). . . . . .
Reg Cab Long Box 117.9 inches (299.5 cm). . . . . .
Extended Cab 122.9 inches (312.2 cm). . . . . . . . . .
Crew Cab 122.9 inches (312.2 cm). . . . . . . . . . . . . .
Length
Reg Cab Short Box 189.0 inches (480.1 cm). . . . . .
Reg Cab Long Box 204.9 inches (520.4 cm). . . . . .
Extended Cab 203.6 inches (517.1 cm). . . . . . . . . .
Crew Cab 202.8 inches (515.0 cm). . . . . . . . . . . . . .
Height
2WD Reg Cab 62.1 inches (157.7 cm). . . . . . . . . . .
2WD Ext Cab 62.2 inches (158.0 cm). . . . . . . . . . .
4WD Reg Cab Short Box 63.8 inches (162.1 cm). .
4WD Reg Cab Long Box 65.4 inches (166.1 cm). .
4WD Extended Cab 63.8 inches (162.1 cm). . . . . .
4WD Crew Cab 67.6 inches (171.7 cm). . . . . . . . . .
Width67.9 inches (172.5 cm) . . . . . . . . . . . . . . . . . . Front Tread
2WD
0.0 Wheel Offset 54.5 inches (138.4 cm). . . . . . . . .
-6.4 Wheel Offset 55.0 inches (139.6 cm). . . . . . . .
4WD
15
-inch Tires 57.3 inches (145.4 cm). . . . . . . . . . . .
31 x 10.5 Tires 61.2 inches (155.4 cm). . . . . . . . . . .
Rear Tread
2WD 54.7 inches (138.8 cm). . . . . . . . . . . . . . . . . . . .
4WD
15
-inch Tires 55.1 inches (139.9 cm). . . . . . . . . . . .
31 x 10.5 Tires 59.1 inches (150.0 cm). . . . . . . . . . .
*Figures reflect base equipment only.

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-6 Scheduled Maintenance
7
-8 Short Trip/City Scheduled Maintenance
7
-30 Long Trip/Highway Scheduled Maintenance7
-43 Part B: Owner Checks and Services
7
-48 Part C: Periodic Maintenance Inspections
7
-50 Part D: Recommended Fluids and Lubricants
7
-53 Part E: Maintenance Record

7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in this
manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.

7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you want to get the service information, see ªService
and Owner Publicationsº in the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains
what you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products necessary to help keep
your vehicle properly maintained. These products, or
their equivalents, should be used whether you do the
work yourself or have it done.
ªPart E: Maintenance Recordº is a place for
you to record and keep track of the maintenance
performed on your vehicle. Keep your maintenance
receipts. They may be needed to qualify your vehicle
for warranty repairs.

7-4
Part A: Scheduled
Maintenance Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your
vehicle in good working condition. But we don't know
exactly how you'll drive it. You may drive very short
distances only a few times a week. Or you may drive
long distances all the time in very hot, dusty weather.
You may use your vehicle in making deliveries.
Or you may drive it to work, to do errands or in
many other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.
This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.The proper fluids and lubricants to use are listed in
Part D. Make sure whoever services your vehicle
uses these. All parts should be replaced and all
necessary repairs done before you or anyone else
drives the vehicle.
These schedules are for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Certification/Tire label. See ªLoading Your Vehicleº
in the Index.

are driven on reasonable road surfaces within legal
driving limits.

are driven off
-road in the recommended manner.
See ªOff
-Road Driving With Your
Four
-Wheel-Drive Vehicleº in the Index.

use the recommended fuel. See ªFuelº in the Index.
Selecting the Right Schedule
First you'll need to decide which of the two schedules is
right for your vehicle. Here's how to decide which
schedule to follow:

Scheduled Maintenance
7-5
Short Trip/City Definition
Follow the Short Trip/City Scheduled Maintenance if
any one of these conditions is true for your vehicle:

Most trips are less than 5 to 10 miles (8 to 16 km).
This is particularly important when outside
temperatures are below freezing.

Most trips include extensive idling (such as frequent
driving in stop
-and-go traffic).

Your vehicle has the 2200 L4 (Code 5) flexible
fuel engine and you have used ethanol fuel
(85% Ethanol/E
-85).

You operate your vehicle in dusty areas or
off
-road frequently.

You frequently tow a trailer.

If the vehicle is used for delivery service, police, taxi
or other commercial application.
One of the reasons you should follow this schedule
if you operate your vehicle under any of these conditions
is that these conditions cause engine oil to break
down sooner.
Short Trip/City Intervals
Every 3,000 Miles (5 000 km): Engine Oil and
Filter Change (or 3 months, whichever occurs first).
Chassis Lubrication (or 3 months, whichever occurs
first). Drive Axle Service (or 3 months, whichever
occurs first).
Every 6,000 Miles (10 000 km): Tire Rotation.
Every 15,000 Miles (25 000 km): Engine Air Cleaner
Filter Inspection, if driving in dusty conditions. Front
Wheel Bearing Repack (2WD only) (or at each brake
relining, whichever occurs first). Automatic
Transmission Service (severe conditions only).
Every 30,000 Miles (50 000 km): Engine Air
Cleaner Filter Replacement. Fuel Filter
Replacement (4.3L V6 engine only).
Every 50,000 Miles (83 000 km): Automatic
Transmission Service (normal conditions).
(Continued)

Scheduled Maintenance
7-6
Short Trip/City Intervals
Every 60,000 Miles (100 000 km): Engine Accessory
Drive Belt Inspection.
Every 90,000 Miles (150 000 km): Fuel Filter
Replacement (2200 L4 engine only).
Every 100,000 Miles (166 000 km): Spark Plug Wire
Inspection. Spark Plug Replacement. 4.3L V6 Engine
Only: Positive Crankcase Ventilation (PCV)
Valve Inspection.
Every 150,000 Miles (240 000 km): Cooling System
Service (or every 60 months, whichever occurs first).
These intervals only summarize maintenance services.
Be sure to follow the complete scheduled maintenance
on the following pages.
Long Trip/Highway Definition
Follow this scheduled maintenance only if none of
the conditions from the Short Trip/City Scheduled
Maintenance are true. Do not use this schedule if the
vehicle is used for trailer towing, driven in a dusty area
or used off paved roads. Do not use this schedule if you
have the 2200 L4 (Code 5) flexible fuel engine and you
have used ethanol fuel (85% Ethanol/E
-85). Use the
Short Trip/City schedule for these conditions.
Driving a vehicle with a fully warmed engine
under highway conditions causes engine oil to
break down slower.
