2001 CHEVROLET EXPRESS CARGO VAN Owners Manual

3-41
: This button will eject a disc or discs. Do the
following to eject:

Press and release the eject button to eject the disc
that is currently playing, or

to remove all of the discs, press this button for two
seconds, you will hear a beep, and the light will flash
to let you know when a disc is being ejected.
When the eject button is pressed, the receiver will eject
the disc and REMOVE CD will be displayed. You can
either remove the disc or if the disc is not removed, after
25 seconds, the disc will be automatically pulled back
into the receiver. If you try to push the disc back into the
receiver manually, before the 25 second time period is
complete, the receiver will sense an error and will try to
eject the disc several times before stopping. You will be
able to remove the disc at this time. Pressing the
receiver's VOLUME
-PWR knob, off and then on,
will allow the receiver to clear its disc sensing feature.
You may now be able to use the LOAD and eject
features normally. Do not, at any time, press the eject
button more than once, the receiver's 25 second eject
timer will reset at each press of eject, which will cause
the receiver to not eject a disc, until the 25 second time
period has elapsed.REV: Press and hold this button to reverse quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
FWD: Press and hold this button to advance quickly
within a track. Release it to play the passage. You will
hear sound at a reduced volume. The display will show
elapsed time.
RPT: With repeat, you can repeat one track or an entire
disc. To use repeat, do the following:

To repeat the track you are listening to, press and
release the RPT button. RPT will appear on the
display. Press RPT again to turn it off.

To repeat the disc you are listening to, press and hold
the RPT button for two seconds. Press RPT again to
turn if off.

3-42
RDM: With random, you can listen to the tracks in
random, rather than sequential order, on all of the discs
or on one disc. To use random, do the following:

Press and release the RDM button to play the tracks
on all of the discs that are loaded, in random order.
RDM will appear in the display. Press RDM to turn
it off.

To play the tracks on the disc you are listening to in
random order, press and hold RDM for more than
two seconds. You will hear a beep and RDM will
appear on the display. Press RDM again to turn
if off.
AUTO EQ: Press AUTO EQ to select the desired preset
equalization setting while playing a compact disc. The
equalization will be automatically set whenever you
play a compact disc.
SEEK: Press the left arrow while playing a CD to go to
the start of the current track, if more than ten seconds
have played. Press the right arrow to go to the next
track. If you press the button more than once, the
player will continue moving backward or forward
through the disc.SCAN: Press and hold the SEEK button for more than
two seconds until SCAN appears on the display and you
hear a beep. Use SCAN to listen to each track for a few
seconds. The sound will mute while scanning. SCAN
will appear on the display. Press this button, again, to
stop scanning.
DISC SCAN: Press and hold the SEEK button for more
than four seconds until DISC SCAN appears on the
display and you hear a beep. Use DISC SCAN to listen
to the first track, for ten seconds of each disc loaded.
The sound will mute while scanning to the next track.
DISC SCAN will appear on the display. Press the
SEEK button, again, to stop scanning.
RCL: Press this button to see how long the current track
has been playing. To change what is normally shown on
the display (track or elapsed time), press the button until
you see the display you want, then hold the button until
the display flashes.
AM FM: Press this button to play the radio when a disc
is in the player.

3-43
Using Song List Mode
The integrated 6
-disc CD changer has a feature
called song list. This feature is capable of saving
20 track selections.
To save tracks into SONG LIST:
1. The disc player must be on with at least one disc
loaded. See ªLOAD/EJECTº previously for
more information.
2. The disc changer must not be in song list mode.
S
-LIST should not appear on the display. If S-LIST
is present, press SONG LIST to turn it off.
3. Select the desired disc by pressing the numbered
pushbutton and then use the SEEK right arrow
button to locate the track that you want to save.
The track will begin to play.
4. Press and hold SONG LIST for two or more seconds
to save the track into memory. When SONG LIST is
pressed a beep will be heard immediately. After
two seconds of pressing SONG LIST continuously,
two beeps will sound, to confirm that the track has
been saved.
5. Repeat Steps 3 and 4 for saving other selections.To play the SONG LIST:
Press SONG LIST. One beep will be heard and
S
-LIST will appear on the display.
The recorded tracks will begin to play in the order
that they were saved.
You may seek through the song list by using the
SEEK arrows. Seeking past the last saved track will
return you to the first saved track.
To delete tracks from SONG LIST:
1. The disc player must be turned on.
2. Press SONG LIST to turn song list on. S
-LIST will
appear on the display.
3. SEEK to the desired track to be deleted.
4. Press and hold the SONG LIST buttons for
two seconds. When pressing SONG LIST one beep
will be heard immediately. After two seconds of
pressing the SONG LIST button continuously,
two beeps will be heard, to confirm that the track
has been deleted.
After a track has been deleted, the remaining tracks are
moved up the list. When another track is added to the
song list, the tracks will be added to the end of the list.

3-44
To delete the entire SONG LIST:
1. The disc player must be on.
2. Press SONG LIST to turn song list on. S
-LIST will
appear on the display.
3. Press and hold SONG LIST for more than four
seconds. A beep will be heard, followed by two
beeps after two seconds and a final beep will be
heard after four seconds. S
-LIST EMPTY will
appear on the display indicating that the song list
has been deleted.
If a disc is ejected, and the song list contains saved
tracks from that disc, those tracks are automatically
deleted from the song list.
To end SONG LIST mode, press the SONG LIST
button. One beep will be heard and S
-LIST will be
removed from the display.
Theft-Deterrent Feature RDS Radios
(If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOCKED will be displayed.
When the radio and vehicle are turned off, the blinking
red light indicates that THEFTLOCK is armed.
With THEFTLOCK activated, your radio will not
operate if stolen.
Theft-Deterrent Feature Non-RDS
Radios (If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. The feature works automatically by learning a
portion of the Vehicle Identification Number (VIN).
If the radio is moved to a different vehicle, it will not
operate and LOC will be displayed.
With THEFTLOCK activated, your radio will not
operate if stolen.

3-45 Understanding Radio Reception
AM
The range for most AM stations is greater than for
FM, especially at night. The longer range, however, can
cause stations to interfere with each other. AM can pick
up noise from things like storms and power lines. Try
reducing the treble to reduce this noise if you ever get it.
FM Stereo
FM stereo will give you the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km). Tall
buildings or hills can interfere with FM signals, causing
the sound to come and go.
Tips About Your Audio System
Hearing damage from loud noise is almost undetectable
until it is too late. Your hearing can adapt to higher
volumes of sound. Sound that seems normal can be loud
and harmful to your hearing. Take precautions by
adjusting the volume control on your radio to a safe
sound level before your hearing adapts to it.To help avoid hearing loss or damage:

Adjust the volume control to the lowest setting.

Increase volume slowly until you hear comfortably
and clearly.
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Delco Electronics
radio or other systems, and even damage them.
Your vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check Federal rules
covering mobile radio and telephone units.

3-46 Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after every
50 hours of use. Your radio may display CLN to indicate
that you have used your tape player for 50 hours without
resetting the tape clean timer. If this message appears on
the display, your cassette tape player needs to be
cleaned. It will still play tapes, but you should clean it as
soon as possible to prevent damage to your tapes and
player. If you notice a reduction in sound quality, try a
known good cassette to see if it is the tape or the tape
player at fault. If this other cassette has no improvement
in sound quality, clean the tape player.The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealer (GM Part No. 12344789).
When using a scrubbing action, non
-abrasive cleaning
cassette, it is normal for the cassette to eject because
your unit is equipped with a cut tape detection feature
and a cleaning cassette may appear as a broken tape. To
prevent the cleaning cassette from being ejected, use the
following steps.
1. Turn the ignition to RUN or ACCESSORY.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for five
seconds. The tape symbol on the display will flash
for two seconds.
4. Insert the scrubbing action cleaning cassette.
5. Eject the cleaning cassette after the manufacturer's
recommended cleaning time.

3-47
When the cleaning cassette has been ejected, the cut tape
detection feature is active again.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
After you clean the player, press and hold EJECT for
five seconds to reset the CLN indicator. The radio will
display
--- to show the indicator was reset.
Cassettes are subject to wear and the sound quality
may degrade over time. Always make sure the cassette
tape is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the side without writing when
handling discs. Pick up discs by grasping the outer edges
or the edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.

3-48 Fixed Mast Antenna
The fixed mast antenna can withstand most car washes
without being damaged. If the mast should ever become
slightly bent, you can straighten it out by hand. If the
mast is badly bent, as it might be by vandals, you should
replace it.
Check every once in a while to be sure the mast is still
tightened to the fender. If tightening is required, tighten
by hand, then with a wrench one quarter turn.
Chime Level Adjustment
(RDS Radios Only)
The radio is one of the vehicle chime producers. The
chime is produced from the driver's side front door
speakers. To change the volume level, press and hold
pushbutton 6 with the ignition on and the radio power
off. The chime volume level will change from the
normal level to loud, and LOUD will be displayed on
the radio. To change back to the default or normal
setting, press and hold the pushbutton 6 again. The
chime level will change from the loud level to normal,
and NORMAL will be displayed. Each time the chime
volume is changed, three chimes will sound as an
example of the new volume selected. Chime level
adjustment is only available on RDS radios. Removing
the radio and not replacing it with a factory radio or
chime module will alter vehicle chimes.
