2001 CHEVROLET EXPRESS CARGO VAN Owners Manual

3-33
NEXT (2): Press this button or the right SEEK arrow to
go to the next track. TRACK and the track number will
appear on the display. If you hold the button or the right
SEEK arrow, or press it more than once, the player will
continue moving forward through the disc. The sound
will mute while seeking.
REV (3): Press and hold this button to reverse quickly
within a track. Press and hold this button for less than
two seconds to reverse at six times the normal playing
speed. Press and hold it for more than two seconds to
reverse at 17 times the normal playing speed. Release it
to play the passage. The display will show ET and the
elapsed time.
FWD (4): Press and hold this button to advance quickly
within a track. Press and hold this button for less than
two seconds to advance at six times the normal playing
speed. Press and hold it for more than two seconds to
advance at 17 times the normal playing speed. Release it
to play the passage. The display will show ET and the
elapsed time.
CD (5): With a compact disc in the player and the radio
playing, press this button to play a compact disc. Press
AM FM to return to the radio when a compact disc is
playing. The inactive CD will remain safely inside the
radio for future listening.RDM (6): Press this button to hear the tracks in random,
rather than sequential, order. RDM ON will show on the
display. RDM T and the track number will appear on
the display when each track starts to play. Press RDM
again to turn off random play. RDM OFF will appear on
the display.
SEEK: Press the left arrow to go to the start of the
current or previous track. Press the right arrow to go to
the start of the next track. If either of the buttons is
held or pressed more then once, the player will continue
moving backward or forward through the CD.
DISP: Press this button to see how long the current
track has been playing. ET and the elapsed time will
appear on the display. To change what is normally
shown on the display (track or elapsed time), press the
button until you see the display you want, then hold
the button for two seconds. The radio will produce
one beep.
AM FM: Press this button to play the radio when
a disc is in the player. The disc will stop but remain in
the player.

3-34
TAPE CD: With a CD in the player and the radio
playing, press this button to play a CD. Press AM FM to
return to the radio when a CD is playing. Press TAPE
CD to switch between the tape and compact disc if both
are loaded. The inactive tape or CD will remain safely
inside the radio for future listening.
: Press this button located below the CD slot to
remove the disc. The radio will play. EJT may be
activated with either the ignition or radio off. CDs may
be loaded with the radio and ignition off if this button is
pressed first.
CAL ERR: This message is displayed when the radio
has not been calibrated properly for the vehicle. You
must return to the dealership for service.
LOCKED: This message is displayed when the
THEFTLOCK

system has locked up. You must
return to the dealership for service.
AM-FM Stereo with 6-Disc Compact Disc
Player with Programmable Equalization
and Radio Data System (RDS) (Option)
Playing the Radio
VOLUME
-PWR: Press this knob to turn the system on
and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume.

3-35
AUTO VOL: Your system has a feature called
automatic volume. With this feature, your audio system
adjusts automatically to make up for road and wind
noise as you drive. Set the volume at the desired level.
Press this button to select MIN, MED or MAX. Each
choice allows for more volume compensation at faster
vehicle speeds. Then, as you drive, automatic volume
automatically increases the volume, as necessary, to
overcome noise at any particular speed. The volume
level should always sound the same to you as you drive.
If you don't want to use automatic volume, select OFF.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to select radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press and hold the SEEK button for two seconds
until SC appears on the display and you hear a beep.
Use SCAN to listen to stations for a few seconds. The
radio will go to a station, stop for a few seconds, then
go on to the next station. Press the SEEK button again
to stop scanning. If you press SEEK for more than
four seconds, the radio will change to PRESET SCAN
mode. The sound will mute while scanning.PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2) by
performing the following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO EQ to select the equalization that best
suits the type of station selected.
5. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the station you set will return and the
equalization that you selected will also be
automatically selected for that button.
6. Repeat the steps for each pushbutton.
PRESET SCAN: Press and hold the SEEK button for
more than four seconds, PRESET SCAN will appear on
the display. You will hear a double beep and the P will
blink with the preset number. Use PRESET SCAN to
listen to each of your preset stations for a few seconds.
The radio will go to a preset station stored on your
pushbuttons, stop for a few seconds, then go on to the
next preset station. Press the SEEK button again to stop
scanning presets.

3-36
Setting the Tone
BASS: Press the AUDIO knob until BASS appears on
the display. Turn the knob to increase or decrease bass.
When you use this control, the radio's tone setting will
switch to custom.
To set the bass to the middle position, select BASS and
press and hold the AUDIO knob. The radio will produce
one beep and set the display level to zero. To set all tone
and speaker controls to the middle position, press and
hold the AUDIO knob when no tone or speaker control
is active. The radio will produce one beep and
CENTERED will appear on the display.
MID: Press the AUDIO knob until MID appears on the
display. Turn the knob to increase or decrease mid.
When you use this control, the radio's tone setting will
switch to custom.
To set the mid to the middle position, select MID and
press and hold the AUDIO knob. The radio will produce
one beep and set the display level to zero. To set all tone
and speaker controls to the middle position, press and
hold the AUDIO knob when no tone or speaker control
is active. The radio will produce one beep and
CENTERED will appear on the display.TREB: Press the AUDIO button until TREB appears on
the display. Turn the knob to increase or decrease treble.
When you use this control, the radio's tone setting will
switch to custom. If a station is weak or noisy, you may
want to decrease the treble.
To set treble to the middle position, select TREB and
press and hold the AUDIO knob. The radio will produce
one beep and set the display level to zero. To set all tone
and speaker controls to the middle position, press and
hold the AUDIO knob when no tone or speaker control
is active. The radio will produce one beep and
CENTERED will appear on the display.
AUTO EQ: This feature allows you to choose preset
bass, mid and treble equalization settings designed for
country, jazz, talk, pop, rock and classical stations. The
last setting will appear on the display when you first
press AUTO EQ. Each time you press AUTO EQ,
another setting will appear on the display. Press AUTO
EQ again after TALK appears and CUSTOM will
appear. Tone control will return to the BASS, MID and
TREB. Also, if you alter BASS, MID, or TREB while in
an auto EQ setting, the radio will return to CUSTOM.
CUSTOM will appear on the display.

3-37
Using RDS Mode
Your audio system is equipped with a Radio Data
System (RDS). RDS mode gives you many useful new
features. With RDS, the radio can:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS features are only available for use on FM stations
which broadcast RDS information. The RDS features of
your radio rely upon receiving specific RDS information
from these stations. These features will only work when
the RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, please contact the radio station.
When you are tuned to an RDS station, the station
name will appear on the display, instead of the
frequency. Most RDS stations provide their station
name, the time of day and a Program Type (PTY) for
their current programming.TRAF: Press this button to receive traffic
announcements. The traffic announcement brackets will
appear on the display. TRAF will appear on the display
if the tuned station broadcasts traffic announcements. If
the current tuned station does not broadcast traffic
announcements, the radio will seek to a station that
does. When the radio finds a station that broadcasts
traffic announcements, it will stop. If no station is found,
NONE FOUND will appear on the display.
When a traffic announcement comes on the tuned radio
station or a related network station, you will hear it,
even if the volume is muted or a compact disc is
playing. If the compact disc player was being used, the
compact disc will stay in the player and resume play at
the point where it stopped.
INFO: If the current station has a message, INFO will
appear on the display. Press this button to see the
message. If the whole message does not appear on the
display, parts of the message will appear every three
seconds until the message is completed. To see the parts
of the message faster than every three seconds, press this
button again. A new group of words will appear on the
display. Once the complete message has been displayed,
INFO will disappear from the display until another new
message is received.

3-38
P-TYPE: This button is used to turn on and off
Program Type (PTY) select. PTY and the light next to
the button will turn on. The last selected PTY will
appear on the display for five seconds. Turn the P
-TYPE
knob to select the PTY you want to listen to. Press
SEEK or SCAN to find radio stations of the PTY you
want to listen to. The last PTY selected will be used for
seek or scan modes. If a station with the selected PTY is
not found, NONE FOUND will appear on the display.
If both P
-TYPE and TRAF are on, the radio will
search for stations with traffic announcements and the
selected PTY.
To use the P
-TYPE interrupt feature, press and hold the
P
-TYPE button until you hear a beep on the PTY you
want to interrupt on. When you are listening to a
compact disc, the last selected RDS FM station will
interrupt play if that selected PTY format is broadcast.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite Program Types (PTYs).
These buttons have factory PTY presets. You can set up
to 12 PTYs (six FM1 and six FM2) by performing the
following steps:
1. Press P
-TYPE, if it is not already on.
2. Press AM FM to select FM1 or FM2.3. Turn the SELECT knob to select a PTY.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the PTY you set will return.
5. Repeat the steps for each pushbutton.
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the tuned radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
ALTERNATE FREQUENCY: This feature allows the
radio to switch to a stronger station with the same
program type. Press and hold AM FM for two seconds
to turn alternate frequency on. AF ON will appear on the
display. The radio may switch to stronger stations. Press
and hold AM FM again for two seconds to turn alternate
frequency off. AF OFF will appear on the display. The
radio will not switch to other stations. When you turn
the ignition off and then on again, the alternate
frequency feature will automatically be turned on.

3-39
Adjusting the Speakers
BAL
-FADE: The AUDIO knob adjusts balance and
fade. To adjust balance, press the AUDIO knob until
BAL appears on the display. Turn the knob to adjust the
sound to the left or right speakers. The middle position
balances the sound between the speakers. To adjust fade,
press and hold the AUDIO knob until FAD appears on
the display. Turn the knob to adjust the sound to the
front or rear speakers. The middle position balances the
sound between the speakers.
To set the balance and fade to the middle position, select
balance or fade and press and hold the AUDIO knob.
The radio will beep once and will set the display level to
the middle position. To set all tone and speaker controls
to the middle position, press and hold the AUDIO knob
when tone or speaker controls are not active. The radio
will produce one beep and CENTERED will appear on
the display.Playing a Compact Disc
LOAD: This compact disc player will accommodate up
to six discs.
To insert one disc do the following:
1. Turn the ignition on.
2. Press and release the LOAD button.
3. Wait for the light, located to the right of the slot, to
turn green.
4. Load a disc. Insert a disc partway into the slot, label
side up. The player will pull the disc in.
When the disc is inserted, the CD symbol will be
displayed. If you select an EQ setting for your disc,
it will be activated each time you play a disc.
5. If the radio is on or off, the disc will begin to
play automatically.

3-40
To insert multiple discs do the following:
1. Turn the ignition on.
2. Press and hold the LOAD button for two seconds.
You will then hear a beep and the light, located to the
right of the slot, will begin to flash.
3. Once the light stops flashing and turns green, load a
disc. Insert a disc partway into the slot, label side up.
The player will pull the disc in.
Once the disc is loaded, the light will begin flashing
again. Once the light stops flashing and turns green
you can then load another disc. The disc player takes
up to six discs. Do not try to load more than six.
When a disc is inserted, the CD symbol will be
displayed. If more than one disc has been loaded, a
CD symbol for each disc will be displayed. If you
select an EQ setting for your disc, it will be activated
each time you play a disc.
4. If the radio is on or off, the last disc loaded will
begin to play automatically.
5. To load more than one disc but less than six,
complete steps 1, 2 and 3. When you have finished
loading discs, with the radio on or off, press LOAD
to cancel the loading function. The radio will begin
to play the last CD loaded.As each new track starts to play, the track number will
appear on the display.
If CHECK CD appears on the radio display, it could
be that:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error message, write it down and provide it
to your dealer when reporting the problem.
Playing a Specific Loaded CD: For every CD loaded, a
number will appear on the radio display. To play a
specific CD, first press the CD AUX button to start
playing a CD. Then press the numbered button that
corresponds to the CD you want to play. A small bar
will appear under the CD number that is playing, and the
track number will appear.
