2001 CADILLAC DEVILLE light

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-9 Remote Keyless Entry System
2
-13 Trunk
2
-16 Theft
2
-17 Theft-Deterrent System
2
-19 PASS-Key
III
2
-22 New Vehicle ªBreak-Inº
2
-22 Ignition Positions
2
-24 Starting Your Engine
2
-25 Engine Coolant Heater (If Equipped)
2
-26 Automatic Transaxle Operation
2
-31 Parking Brake
2
-33 Shifting Into PARK (P)
2
-36 Shifting Out of PARK (P)
2
-38 Parking Over Things That Burn
2
-39 Engine Exhaust
2
-39 Running Your Engine While You're Parked2
-40 Tilt Wheel
2
-42 Turn Signal/Multifunction Lever
2
-50 Exterior Lamps
2
-55 Interior Lamps
2
-57 Mirrors
2
-61 Storage Compartments
2
-65 Rear Power Sunshade (If Equipped)
2
-66 Cellular Telephone (Option)
2
-67 OnStar
System (If Equipped)
2
-71 Sunroof (Option)
2
-72 HomeLink
Transmitter (If Equipped)
2
-76 The Instrument Panel -- Your
Information System
2
-82 Warning Lights, Gages and Indicators
2
-96 Driver Information Center (DIC)
2
-114 Night Vision System (Option)
2
-117 Navigation (Option)
2
-118 Ultrasonic Rear Parking
Assist (URPA) (Option)

2-3
Power Windows
The power window controls are located on the armrest
near each window. Press the up or down arrows on the
controls to raise or lower the windows.Express
-Down Window
All power windows have this feature. Pressing the
control rearward to the second detent then releasing
it, will lower a window completely. If you want to stop
the window as it is lowering, press the control forward
briefly. Press the control forward again to raise
the window.
Rear Window Lockout
Pressing this button will
disable the rear window
controls and cause the
button to light, indicating
that the feature is in use.
To restore power to the
rear windows, press the
button again.

2-16
Trunk Release Handle (If Equipped)
NOTICE:
The trunk release handle was not designed to be
used to tie down the trunk lid or as an anchor
point when securing items in the trunk. Improper
use of the trunk release handle could damage it.
There is a glow-in-the-dark trunk release handle
located inside the trunk near the latch. This handle will
glow following exposure to light. Pull the release handle
up to open the trunk from the inside.
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transaxle. And remember to lock the doors.

2-17
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your
ignition key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.

Close all windows.

Move the valet lockout switch to ON.

Leave only the valet key.

Take all other keys and the Remote Keyless Entry
transmitter with you.
Theft-Deterrent System
If the ignition is off and
any door is open, the
SECURITY light will flash,
reminding you to activate
the system.
The light will also flash if the battery has been
disconnected and reconnected.
To arm the system, do the following:
1. Open the door.
2. Lock the door using the power door lock or the
remote keyless entry transmitter. The SECURITY
light should come on and stay on.
3. Close all the doors. The SECURITY light should go
off within about 30 seconds.
When the theft
-deterrent system activates, the horn will
sound and the lamps will flash for about 30 seconds
when the door or trunk is opened without the key or the
remote keyless entry transmitter.

2-18
Remember, the theft-deterrent system won't activate if
you lock the doors with a key or use the manual door
lock. It activates only if you use a power door lock
button or the remote keyless entry transmitter.
To avoid activating the alarm by accident,
do the following:

Always unlock a door with a known key or use the
remote keyless entry transmitter. (Using a known
key or pressing the unlock button on the remote
keyless entry transmitter disables the theft
-deterrent
system.) Unlocking a door any other way, such
as using an unknown key, will activate the
alarm system.

The vehicle should be locked with the door key after
the doors are closed if you don't want to activate the
theft
-deterrent system.
If you activate the alarm by accident, unlock the driver's
door with your key. You can also turn off the alarm by
using the unlock button on the remote keyless entry
transmitter or by starting the vehicle with a known key.
The alarm won't stop if you try to unlock a door any
other way.
Testing the Alarm
1. From inside the vehicle, roll down the window, then
get out of the vehicle, keeping the door open.
2. From outside of the vehicle, with the door open, lock
the vehicle using the power door lock or the remote
keyless entry transmitter and close the door. Wait
30 seconds until the SECURITY light goes off.
3. Reach in and unlock the door using the manual lock
lever and open the door. The horn will sound and the
headlamps will flash.
If the alarm does not sound when it should, check to
see if the horn works. The horn fuse may be blown.
To replace the fuse, see ªFuses and Circuit Breakersº
in the Index. If the fuse does not need to be replaced,
you may need to have your vehicle serviced.
To reduce the possibility of theft, always activate the
theft
-deterrent system when leaving your vehicle.

2-20
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
PASS
-Key III uses a radio frequency transponder in the
key that matches a decoder in your vehicle.
When the PASS
-Key III system senses that someone is
using the wrong key, it shuts down the vehicle's starter
and fuel systems. The starter will not work and fuel will
stop being delivered to the engine. Anyone using a
trial
-and-error method to start the vehicle will be
discouraged because of the high number of electrical
key codes.When trying to start the vehicle, if the engine does not
start and the SECURITY light comes on, the key may
have a damaged transponder. Turn the ignition off and
try again.
If the engine does not start, and the key appears to be
undamaged, try another ignition key. At this time, you
may also want to check the fuse (see ªFuses and Circuit
Breakersº in the Index). If the engine still does not start
with the other key, your vehicle needs service. If your
vehicle does start, the first key may be faulty. See your
dealer who can service the PASS
-Key III to have a new
key made.
It is possible for the PASS
-Key III decoder to learn the
transponder value of a new or replacement key. Up to
10 additional keys may be programmed for the vehicle.
This procedure is for learning additional keys only.

2-21
Canadian Owners: If you lose or damage your keys,
only a GM dealer can service PASS
-Key III to have new
keys made. To program additional keys you will require
two current driver's keys (black in color). You must add
a step to the following procedure. After Step 2 repeat
Steps 1 and 2 with the second current driver's key.
Then continue with Step 3.
To program the new key:

Insert the current driver's key (black in color) in the
ignition and start the engine. If the engine will not
start see your dealer for service.

After the engine has started, turn the key to OFF, and
remove the key.

Insert the key to be programmed and turn it to ON
within ten seconds of removing the previous key.
The SECURITY light will turn off once the key has
been programmed. It may not be apparent that the
SECURITY light went on due to how quickly the
key is programmed.

Repeat the Steps 1 through 4 if additional keys are
to be programmed.
If you are ever driving and the SECURITY light comes
on and stays on, you will be able to restart your engine
if you turn it off. Your PASS
-Key III system, however,
is not working properly and must be serviced by your
dealer. Your vehicle is not protected by the
PASS
-Key III system at this time.
If you lose or damage a PASS
-Key III key, see your
dealer to have a new key made.

2-31
Parking Brake
Hold the regular brake
pedal down with your right
foot and push the parking
brake pedal down with
your left foot to set the
parking brake.
If the ignition is on, the BRAKE indicator light on the
instrument panel cluster should come on. If it doesn't,
you need to have your vehicle serviced.
When you move out of PARK (P) or NEUTRAL (N)
and the engine is running, the parking brake should
release. If the parking brake has not been fully released
and you try to drive off with the parking brake on, the
BRAKE indicator light will come on and stay on.If the parking brake doesn't fully release, you can
manually release the lever. Before attempting to
release the lever however, be sure to read the
following paragraphs.
CAUTION:
Always shift to PARK (P) before pulling the
manual release lever. If your hand or arm is in
the way of the pedal you could be hurt. The pedal
springs back quickly. Keep your hand and arm
away when you use the manual release lever.
Before releasing the manual parking brake, be sure
to put the vehicle in PARK (P) and turn the ignition
to OFF.
