2001 BMW 325Ci CONVERTIBLE Owner's Manual

49n
IndexDataTechnologyRepairsCar careControlsOverview
The fully automatic convertible top
*
Do not reach into the convertible top
mechanism during opening and closing.
Keep children away from the moving
parts of the convertible top during oper-
ation.
The automatic sequence will be inter-
rupted immediately if you release the
button that operates the top. The
sequence can be continued in the
desired direction by pressing this
button.<
After having been stored for an
extended period of time in the
convertible top compartment Ñ e. g.
during the winter months because the
hardtop
* was being used Ñ you may
have to support the convertible top by
hand when closing it for the first time:
If the convertible top should halt just
before the closing phase is completed,
press against the front section of the
convertible top frame from the outside to
help the closing process along. Continue
pressing the switch while doing so until
the top starts up again on its own.<
Opening and closing1 Closing
2 Opening
Continue pressing the button for oper-
ating the convertible top until the
opening or closing process has ended.
The side windows will lower slightly
while it is being opened. When the top
is being closed, the side windows will
also close if you continue pressing the
button after the convertible top has
finished closing.
The red indicator lamp will light up
while the convertible top is in motion. It
will keep blinking after you release the
button, if the opening or closing proce-
dure was not completed properly.46cus043
The convertible top cannot be moved if
the convertible top compartment panel
is raised. In this case, the yellow indi-
cator lamp will light up and stay on
when the button is pressed, indicating
that it is not possible to complete a
convertible top operation.
Flip down the convertible top compart-
ment panel; see page 41.
If the opening or closing process
has been interrupted, the convert-
ible top will remain in that position for
15 minutes
.
After that, the convertible top can be
moved again and, if it is an emergency
situation, you may need to help the top
along manually. This can also be done
in ignition key position 0.
The luggage compartment cannot be
opened while the convertible top is in
motion.
When operating the convertible top, the
windows will lower slightly when you
press on the switch, and after the
opening operation has finished, they
will move up again if you continue
holding the switch down for more than
2 seconds after the indicator lamp has
gone out.<

50n
The fully automatic convertible top
*
Wind deflector
*
While the convertible top is in
motion, the side windows will
lower slightly. Do not close the side
power windows using the switches if
the convertible top has been inter-
rupted while it is in motion.
In certain cases, the luggage compart-
ment lid cannot be opened if the
opening or closing operation has been
interrupted.
Never store the convertible top while it
is wet to avoid permanent damage from
moisture.
While the convertible top is in motion,
the rear window will move toward the
passenger compartment and will gently
press the heads of the passengers
sitting in the rear forward. Normally, this
is not dangerous. To avoid possibly
being pinched, passengers in the back
seat should lean their heads slightly
forward while the convertible top is in
motion.<
Convenient operation from the
driver-side door lock>To open: with the door closed, turn
and hold the key in the "Unlock" posi-
tion.
>To close: with the door closed, turn
and hold the key to the "Lock" posi-
tion.
Letting go of the key will stop the
motion.
In order to keep the closing process in
view, it is not possible to use the
convenient operation via the remote
control for safety reasons.
At higher speeds, the ensuing
vacuum in the passenger
compartment can cause the convertible
top to begin fluttering. Increase the air
supply via the ventilation controls so
that a vacuum does not occur in the
vehicle.<
The wind deflector keeps air movement
in the passenger compartment to a
minimum, thus providing you with a
pleasant drive, even at higher speeds.
The wind deflector comes in a protec-
tive sleeve, and because of its slim
dimensions, can be easily stored in the
luggage compartment.Installing1 Take the wind deflector out of its
protective sleeve.

51n
IndexDataTechnologyRepairsCar careControlsOverview
Wind deflector
*
2 Flip out both side pieces and lock
into place (arrow).46cde098
Hold the wind deflector so that the
smaller half faces toward the
front.<
3 Guide the mounting pin for the side
piece into the proper opening.
4 Pull back on the mounting pin for the
other side piece by using the slide, so
that the mounting pin can be guided
into the opening provided.
5 Unlock the convertible top compart-
ment lid; see page 45 or 49, and
open the convertible top compart-
ment lid.
6 Flip the back half of the wind
deflector backward, so that the
mounts are lying on the vehicle.
46cde099
7 Close the convertible top compart-
ment lid. The wind deflector is now
attached so that it is theft-proof.
Operate the convertible top
compartment lid from above only
to avoid any pinching.
With the wind deflector in place: never
push the front seats all the way back to
avoid damaging the wind deflector. installing in reverse order.

52n
For your personal safety when adjusting
the seat position, please follow the
instructions below carefully:
Never try to adjust your seat while
driving the vehicle. The seat could
respond with an unexpected move-
ment, and the ensuing loss of vehicle
control could lead to an accident.
Be sure that the safety belt remains
firmly against your body at all times. In
the event of a frontal impact, a loose lap
belt could slide over the hips, leading to
abdominal injury. In addition, the safety
belt's restraint effectiveness is reduced
if the belt is worn loosely.
Never ride with the backrest reclined to
an extreme angle (especially important
for the front passenger to remember),
otherwise, you run the risk of sliding
under the safety belt during an acci-
dent, thus negating the protection the
safety belt provides.<
Correct sitting postureTo reduce strain on the spinal column,
sit all the way back in the seat and rest
your back fully against the backrest.
The ideal sitting posture is achieved
with your head extending from your
spine in a straight line.
For long-distance driving, you may wish
to increase the backrest angle slightly
to reduce muscular tension. You should
be able to grasp the steering wheel at
its highest point with your arms slightly
bent.
1 Backward/Forward adjustment
2 Cushion height
3 Backrest angle
Follow the setting instructions on
this page. Failure to do so could
result in diminished personal safety.<
46cde012
Seat adjustment

53n
IndexDataTechnologyRepairsCar careControlsOverview
Head restraints Front headrests1 Height
Head restraints reduce the risk of
injury to the cervical vertebra in
the event of an accident.
Adjust the head restraint so that its
center is approximately at the height of
your ears.
When moving the headrests up or
down, do not reach between the head-
rest and the upper edge of the backrest
to avoid the possibility of injury.<46cde029
2 Tilt angle
Position the headrest in the preferred
position. 46cde087
Rear headrests
The rear headrests are to be
lowered only if there are no
passengers riding in the back. Raise the
rear headrests before taking on any
passengers in the back.<
To completely lower the headrests in
the back:
1 Press the button (arrow) and hold it
down.
2 Push the headrest down from above.
46cde100

54n
Head restraints BMW sports seat
*
Raising the rear headrestsRaise the headrests until you feel them
click into place.
Do not remove the rear headrests,
as this would damage them.<
For further information, please consult
your BMW center.
Do not use the rear headrests as
storage shelves. Always keep the
travel path clear for the rollover protec-
tion system. Under no circumstances
should you put any kind of protective
cover on the headrests (refer also to the
labeling on the headrests).<
1 Tilt angle
2 Backward/Forward adjustment
3 Cushion height
4 Backrest angle
Please refer to the adjustment
instructions on page 52 to reduce
the risk of personal injury.<46cde013
5 Thigh support
>Pull the lever and adjust the position
of the cushion for thigh support as
desired.46cde040

55n
IndexDataTechnologyRepairsCar careControlsOverview
Entering the rear Lumbar support
*
The seat-integrated safety belt allows
easy access to the rear. You do not
need to adjust the safety belts. They
automatically adapt to various body
sizes.
1 Lift the lever (1) up and tilt the back-
rest forward.
2 Press the switch (2) toward the front
of the car and hold it there until the
seat moves to the desired position.
You can lock a backrest that has
been tilted forward. This makes
sense when, for instance, someone is
climbing into the rear on an incline. To
do this, press against the backrest until
you hear it click into place. To move it
back into place, you do not need to
unlock it by moving the lever (1).<46cus029
If you tilt the backrest back and hold the
switch (2) pressed toward the back of
the vehicle, the seat will return to its
former position.
If you let go of the switch (2)
before the seat has returned to its
former position, it will remain in the
position where you leave it. To move it
back into place, you do not need to
unlock it by moving the lever (1).<
Lock both backrests while driving,
as otherwise there is danger of an
unexpected movement causing an
accident. The indicator lamp in the
instrument cluster flashes if the back-
rest is not locked, refer to page 21.
Then the indicator lamp comes on until
the safety belt is fastened.<
You can adjust the backrest's contour
for additional support in the curvature
of your spine's lumbar region.
The upper hips and spinal column
receive supplementary support to help
you maintain a relaxed, upright posture.
>Press front/rear of switch:
Increase/decrease curvature.
>Press the upper/lower end of the
switch:
Increase the upper/lower curvature.46cde011

56n
Seat and mirror memory*You can store and recall three different
driver's seat and exterior mirror posi-
tions. The illustration shows the buttons
on the driver's seat for making these
adjustments.
The headrest setting is stored in
the memory, but the lumbar
support is not. 2 Set the desired seat, headrest and
exterior mirror positions.
3 Press the
M
EMORY button: the indi-
cator lamp in the button lights up.
4 Press memory button 1, 2 or 3, as
desired: the indicator lamp goes out.
46cde014
To select a stored settingConvenience function:
1 Open the driver's door after
unlocking or turn the ignition key in
position 1.
2 Briefly press memory button 1, 2 or 3,
as desired.
The adjustment cycle is canceled
immediately if you press a seat
adjustment switch or one of the
memory buttons.
Security function:
1 With the driver's door closed and the
ignition key either removed or in posi-
tion 0 or 2.
2 Maintain pressure on the desired
memory button (1, 2 or 3) until the
adjustment process is completed.
If you accidentally press the
M
EMORY
button: press the button again; the
indicator lamp goes out.
Do not select a memory position
while the vehicle is moving. If you
do so, there is a risk of accident from
unexpected seat movement.<
Your BMW center can adjust your
vehicle's systems in such a
manner that your personalized settings
are automatically set for the seat, head-
rest and exterior mirror positions when
you unlock the vehicle with your
personal remote control.<
If you make use of this method of
adjustment, be sure that the foot-
well behind the driver's seat is unob-
structed before unlocking the vehicle.
If you fail to do so, persons or objects
could be injured or damaged if the seat
should move backward.<
