2001 BMW 325Ci CONVERTIBLE Owner's Manual

41n
IndexDataTechnologyRepairsCar careControlsOverview
Luggage compartment3 Raise and secure the floor panel by
hanging it from the rubber seal ring
for the run-off gutter (arrow).
Carefully replace the hanger in its
holder when lowering the floor
panel back into place.<46cde032
Enlarging the luggage
compartmentWith the convertible top closed, you
can enlarge the luggage compartment.
To do this, flip the handle outward and
press it down and toward the front of
the car (arrow). The convertible top
compartment panel is now raised and
secured.
To prepare to open the convertible top,
follow the steps in reverse order.
When opening the convertible top,
make sure that the luggage
compartment is set up for this Ñ see
page 45 or 48, otherwise damage may
be caused.<46cde009
To secure your luggage, use the
luggage nets
* or flexible straps that you
can attach to the fittings at the inner
corners of the luggage compartment.
Refer also to "Cargo loading" on
page 114.

42n
Alarm system
*
The conceptThe vehicle alarm system responds:
>When a door, the hood or the
luggage compartment lid is opened.
>To movement inside the vehicle
(interior motion sensor).
>To a change of the vehicle's tilt Ð if
someone attempts to steal the
wheels or tow the vehicle without
authorization, for example.
>If there is an interruption in battery
voltage.
The system responds to unauthorized
vehicle entry and attempted theft by
simultaneously activating the following:
>Sounding an alarm for 30 seconds.
>The hazard warning flashers are acti-
vated for approx. five minutes.
>The high beams flash on and off in the
same rhythm.
To activate and deactivate the
alarm systemWhen the vehicle is locked or unlocked
by using a key or with the remote
control, the alarm system is also simul-
taneously armed or disarmed.
The interior motion sensor and the tilt
alarm sensor are activated approx.
30 seconds after you have finished
locking the vehicle.
If the alarm system has been armed
correctly, the hazard warning flashers
flash once.
You can have a signal set as
acknowledgment for both arming
and disarming the alarm system.<
You can also open the luggage
compartment lid when the system is
armed by pressing button 3 of the
remote control (refer to page 36). When
it is closed, the lid is once again
secured.
Indicator lamp displaysThe indicator lamp is located under the
interior rearview mirror.
>The indicator lamp flashes continu-
ously: the system is armed.
>The indicator lamp flashes while the
system is being armed: the door(s),
the hood or luggage compartment lid
are not completely closed. Even if
you do not close the alerted area(s),
the remaining areas are secure, and
the indicator lamp will flash continu-
ously after 10 seconds. However, the
interior motion sensor is not acti-
vated.
>The indicator lamp goes out when the
system is disarmed: no manipulation
or attempted intrusions have been
detected in the period since the
system was armed.46cus033

43n
IndexDataTechnologyRepairsCar careControlsOverview
Alarm system
*
>The indicator lamp flashes for
10 seconds when the system is
disarmed: an attempted entry has
been detected in the period since the
system was armed.
Following triggering of an alarm, the
indicator lamp will flash continuously.Avoiding unintentional alarms The tilt alarm sensor and interior motion
sensor may be switched off at the same
time. You can do this to prevent a false
alarm from being triggered (in garages
with elevator ramps, for instance, or
when the vehicle is transported by
trailer or train):
Lock the vehicle (= arm the system)
twice. Press button 2 on the remote
control twice in succession or lock the
vehicle twice with the key. Refer to
page 34.
The indicator lamp lights up briefly and
then flashes continuously. The tilt alarm
sensor and the interior motion sensor
are deactivated as long as the system is
armed.
Reset the alarm to reactivate the tilt
alarm sensor and the interior motion
sensor.
Interior motion sensor Transmitter and receiver for the interior
motion sensor are located in the front
area of the center console, invisible to
the driver, and in the back area of the
center console under a rack.
However, be sure to deactivate the
interior motion sensor (see previous
column) if children or animals are to
remain in the vehicle.
For US owners onlyThe transmitter and receiver units
comply with part 15 of the FCC (Federal
Communication Commission) regula-
tions. Operation is governed by the
following:
FCC ID: LTQSDR2G5
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications to
these devices could void the
user's authority to operate the equip-
ment.<

44n
Electric power windowsOpen and close the windowsFrom ignition key position 1:
>Press the switch up to but not past
the pressure point:
The window will lower slightly, as
long as you continue pressing the
switch.
>Press the switch briefly past the pres-
sure point:
The window will move automatically.
Pressing the switch again stops the
opening cycle.
You can close windows in the same
manner by pulling the switch.46cus052
Operate all the side windows>Press the switch up to but not past
the pressure point:
All of the windows will continue to
lower as long as you continue to
press the switch.
>Press the switch briefly past the pres-
sure point:
All windows will move automatically.
Pressing the switch again stops the
opening cycle.
You can close all the windows in the
same manner by pulling the switch.46cus053
After the ignition has been switched off:
You can still use the electric power
windows for up to 15 minutes, as long
as no one opens any of the doors.
Remove the key from the ignition
lock and close the doors when
you leave the vehicle, so that children
cannot operate the power windows and
possibly injure themselves.<
To use the convenience mode via the
door lock, refer to page 34.

45n
IndexDataTechnologyRepairsCar careControlsOverview
The manual convertible top The fabric top offers perfect protection
against weather and one person can
open and close it easily and simply.
So that you will get the most out of your
convertible, here are a few tips: it is
advisable to close the convertible top
when the vehicle is parked. The closed
convertible top not only protects the
passenger compartment from unfore-
seeable damage from the weather, it
also provides a certain degree of theft
protection.
In addition, keep valuables only in the
locked luggage compartment, even
with the convertible top closed.
Never mount a roof-mounted luggage
rack on the convertible top.
To close the electric power
windows while driving: always be
sure to close either the rear wondow
first or all 4 windows at the same time,
otherwise, at high speeds, the windows
may not close completely.<
Open the convertible top
Operate the convertible top only
when the vehicle is stationary.
With the luggage compartment lid
open, you will not be able to unlock the
convertible top compartment lid to
avoid any possible damage.<
1 Flip the locking handle out (see illus-
tration), and turn it up to the end
stop.
2 Raise the convertible top slightly
(release the tension).
46cde064
3 From ignition key position 1 on press
the switch to unlock the convertible
top. The convertible top unlocks and
opens slightly. The side windows
lower slightly.
If the indicatior lamp comes on
while the switch is pressed, the
convertible top can not be released
because the convertible top compart-
ment panel is raised, refer to page 41.
Fold down the convertible top compart-
ment panel, and close the luggage
compartment lid.<46cus042

46n
The manual convertible top4 Position the rear convertible top bow
vertically and grip it firmly.
You can support the rear convert-
ible top bow while lifting it up by
pressing the designated area (arrow).<46cde073
5 Reach into the gap of the slightly
opened convertible top compart-
ment lid and open it all the way by
hand (1).
6 Lay the rear convertible top bow in
the convertible top compartment (2).
Release the rear convertible top
bow before laying down the
convertible top, otherwise the side trim
panel could be damaged.<
7 Lift the top up at the front and move it
toward the rear.
Push the convertible top
completely into the convertible
top compartment. This makes it easier
to close the convertible top compart-
ment lid, especially at lower tempera-
tures.<46cde068
8 Press down slightly on the convert-
ible top compartment lid from above
(arrow). The closing procedure will
then be carried out automatically.
9 Either close the slightly lowered side
windows or move them into the
desired position.
Operate the convertible top
compartment lid from above only
in order to avoid pinching.
If the convertible top compartment lid
has not been closed properly, you will
not be able to open the luggage
compartment lid. This is to avoid any
possible damage.<46cde076

47n
IndexDataTechnologyRepairsCar careControlsOverview
The manual convertible topCentral locking will unlock automati-
cally after the convertible top compart-
ment lid has been closed, i.e., the
luggage compartment lid is no longer
locked and can be opened again.
To avoid permanent damage from
moisture, never store the convert-
ible top when it is wet. Refer to the
chapter "Care," starting on page 156).<
Closing the convertible top.1 Put the ignition key in position 1.
2 Press the switch to unlock it.
The convertible top compartment lid
will be unlocked and the side
windows will lower slightly.
3 Open the convertible top compart-
ment lid completely by hand.
4 Lift the convertible top out by the
lateral guide section (1) and the front
convertible top bow (2), swinging it
forward until you encounter percep-
tible resistance.
Position the rear convertible top
bow vertically only after the
convertible top has been swung toward
the front, otherwise the side trim panel
could be damaged.<46cus037
5 Either close the slightly lowered side
windows or move them into the
desired position.
6 Press down slightly on the convert-
ible top compartment lid from above.
The closing procedure will then be
carried out automatically, refer to
page 46.
Operate the convertible top
compartment lid from above only
in order to avoid pinching.<
After the convertible top compart-
ment lid has been closed, the
central locking system will unlock auto-
matically, i. e. the luggage compartment
lid is no longer locked and can be
opened again.<
7 Holding on to the locking handle, pull
the front part of the convertible top
frame up onto the windshield frame,
and lock the convertible top by
turning the handle until you hear the
convertible top engage.
The rear convertible top bow will auto-
matically be pressed down onto the
convertible top compartment lid and
because of the tension, will close com-
pletely.

48n
The manual convertible top
The fully automatic convertible top
*
At higher speeds, the ensuing
vacuum in the passenger
compartment can cause the convertible
top to begin fluttering. Increase the air
supply via the ventilation controls so
that a vacuum does not occur in the
vehicle.<
The completely automatically operated
convertible top combines assured
protection against the elements
together with simple, convenient
handling. So that you will get the most
out of enjoying your convertible, here
are a few tips:
It is advisable to close the convertible
top when the vehicle is parked. The
closed convertible top not only protects
the passenger compartment from
unforeseeable damage from the
weather, it also provides a certain
degree of theft protection. In addition,
keep valuables only in the locked
luggage compartment, even with the
convertible top closed.
Never mount a roof-mounted luggage
rack on the convertible top.
To prevent damage, do not operate the
convertible top at temperatures below
Ð 10 6.
To conserve the battery, only operate
the top with the engine running if
possible.
The convertible top operation is
completely automatic. You will hardly
ever need to support it by hand, refer to
page 49.
Operate the convertible top only if
the vehicle is parked and do not
start driving while the convertible top is
in motion, because at certain points,
this could possibly interrupt the
process. A partially open convertible
top can possibly lead to damage or
injury.
If you initiated convertible top operation
while the vehicle was standing still, and
then start to drive off, you can complete
the process at a traffic light, for
example, while traveling at a moderate
rate of speed. To do this, keep pressing
the proper switch.
Traffic laws applicable in your area take
precedence when you operate the
convertible top, otherwise you may be
breaking the law.
Before closing the convertible top,
remove any objects from the windshield
frame that could keep the convertible
top from closing properly.
Do not lay objects on the convertible
top, since they will fall off when the
convertible top is in motion and cause
damage or injuries.
To close the electric power windows
while driving, always be sure to close
either the rear windows first, or all
four windows at the same time, other-
wise, at high speeds, the windows may
not close tightly.
