Driving Position Memory System, Seat Heaters

To stop the system's automatic ad- justment; Press any button on the control
panel: MEMO, 1 or 2.
Push any of the adjustment
switches for the seat or steering
wheel. Shift out of Park. Adjust the outside mirrors.
If you select a memorized position
without inserting the key in the ignition switch, only the seat andoutside mirrors will adjust. To get
the system to also adjust the steering
wheel, insert the key in the ignition switch. You will hear two beeps
when it is complete. If desired, you can use the adjust-
ment switches to change the posi-
tions of the seat, steering wheel or outside mirrors after they are in
their memorized position. To keep
this driving position for later use,
you must store it in the driving posi- tion memory. Seat Heaters
Both front seats are equipped withseat heaters. The ignition switch
must be ON (II) to use them. Push
the front of the switch, HI, to rapidly
heat up the seat. After the seat reaches a comfortable temperature,select LO by pushing the back of the
switch. This will keep the seat warm.

CONTINUED

Instruments and Controls
SEAT HEATERS

Power Windows
Your car's windows are electrically- powered. Turn the ignition switch toON (II) to raise or lower any window.
Each door has a switch that controls
its window. To open the window,
push the switch down and hold it. Release the switch when you want
the window to stop. Close the
window by pulling back on the switch and holding it.
DRIVER'S WINDOW SWITCH
MAIN SWITCH

The driver's door armrest has a master power window control panel.
To open any of the passengers' win- dows, push down on the appropriate
switch and hold it down until the
window reaches the desired position.
To close the window, pull back on the window switch. Release theswitch when the window gets to the
position you want.

Instruments and Controls
Closing a power window on
someone's hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

Power Windows, Moonroof

The master control panel also con- tains these extra features:
AUTO — To open the driver's window fully, push the windowswitch firmly down and release it.
The window automatically goes all the way down. To stop the window
from going all the way down, pull back on the window switch briefly.
To open the driver's window only partially, push the window switchdown lightly and hold it. The window
will stop as soon as you release the
switch.

The AUTO function only works to lower the driver's window. To raise
the window, you must pull back on
the window switch and hold it until the window reaches the desired

position.
The MAIN switch controls power to
the passengers'windows. With thisswitch off, the passengers'windows
cannot be raised or lowered. The
MAIN switch does not affect the driv-
er's window. Keep the MAIN switch
off when you have children in the car
so they do not injure themselves by
operating the windows unintentional-
ly. The lights inside the switches
come on when you turn the parking
lights or headlights on.
The power window system has a key- off delay function. The windows willstill operate for up to ten minutes
after you turn off the ignition.
Opening either front door cancels
the delay function. You must turn
the ignition switch ON (II) again
before you can raise or lower the
windows. Moonroof
There are two switches on the ceiling near the front ceiling light.
The ignition switch must be ON (II).
To open the moonroof, pull the OPEN/CLOSE switch backward and
hold it until the moonroof reaches
the desired position.

CONTINUED

Instruments and Controls
OPEN/CLOSE
SWITCH

Parking Brake, Digital Clock

Parking Brake
To apply the parking brake, depress the pedal fully. To release it, pull the
release lever. The parking brake
light on the instrument panel should
go out when the parking brake is
fully released with the engine
running (see page 54). If you try to drive the car without releasing the
parking brake, the ABS indicator
may come on, and the ABS may not
work properly. The VSA system
indicator will also come on along
with the ABS indicator (see page

189).

Driving the car with the parking brake
applied can damage the rear brakes

and axles.
Digital Clock

3.5 RL without Navigation System

The digital clock displays the time with the ignition switch ON (II). To see the time with the ignition off,
press and hold the wide button to the right of the clock.
CONTINUED

Instruments and Controls

NOTICE

RELEASE LEVER

PARKING

BRAKE PEDAL

Digital Clock

To set the clock:
1. Turn the ignition switch ON (II) to display the time.
2. Swing down the front cover of the wide button to the right of theclock display. You will see HOUR,
MIN., and RESET buttons. 3. Press and hold the HOUR button
until the hour advances to the
desired hour.
4. Press and hold the MIN. button until the numbers advance to thedesired time.
You can use the RESET button to
quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing the RESET
button sets the clock back to the previous hour. If the displayed time
is after the half hour, pressing the
RESET button sets the clock for-
ward to the beginning of the next
hour.

For example: 1:06 would RESET to 1:00.
1:52 would RESET to 2:00.

Instruments and Controls

HOUR

MIN.
RESET

Accessory Power Socket

To use the accessory power socket, pull down on the cover. The ignition switch must be in ACCESSORY (I)
or ON (II). This socket is intended to supply
power for 12 volt DC accessories
that are rated 120 watts or less (10
amps).

It will not power an automotive type
cigarette lighter element.
Use the notch in the edge of the
console compartment to route the
wire to the accessory power socket.

Instruments and Controls

ACCESSORY POWER SOCKET

NOTCH

Cigarette Lighter

The cigarette lighter is next to the front ashtray under the ashtray lid.
Open the lid by pushing on it.
The ignition switch must be in
ACCESSORY (I) or ON (II) for the
cigarette lighter to work. To heat up
the lighter, push it in. It will pop out
when it is ready for use. Do not hold
the lighter in while it is heating up,

you could cause it to overheat.

Instruments and Controls CIGARETTE LIGHTER

Push

Courtesy Lights

In addition to the ceiling lights, your
Acura has courtesy lights in each door and the ignition switch.
The door courtesy lights come on whenever you open any door. After all doors are closed tightly, they dim
slightly then fade out in about 10

seconds.
Even if the door is open, the lights
will turn off after three minutes
when the key is not in the ignition switch or the ignition switch is in the
LOCK (0) or ACCESSORY (I)
position, and the light switch is in the
off position.
The door courtesy lights and ceiling lights (with the switch in the center
position) come on when you unlock
the door with the key, lock tab on
the driver's door, master door lockswitch, or remote transmitter (see
page 82). If you relock the driver's door or close the driver's door with
the key in the ignition switch, the lights turn off immediately.Otherwise, they remain on, then fade
out in about 10 seconds. The door courtesy lights and ceiling
lights (with the switch in the center
position) also come on when youremove the key from the ignitionswitch. If you do not open a door,
they stay on, then fade out in about
10 seconds.

The courtesy light in the ignition switch comes on when you open the
driver's door. It remains on about 10 seconds after the door is closed.

Instruments and Controls
