PERIODIC MAINTENANCE AND MINOR REPAIR
6-13
65. Remove the screw holding the air
filter case cover.
6. Pull out the air filter.7. Tap the air filter lightly to remove
most of the dust and dirt. Blow out
the remaining dirt with com-
pressed air as shown. If the air fil-
ter is damaged, replace it.
8. Reinstall by reversing the removal
procedure.
EC000082
CAUTION:@ l
Make sure the air filter is prop-
erly seated in the air filter case.
l
The engine should never be run
without the air filter installed.
Excessive piston and/or cylin-
der wear may result.
@
1. Screw
2. Air filter case cover
1. Air filter
E_4sv_Periodic.fm Page 13 Tuesday, August 31, 1999 3:45 PM
8-1
8
EAU01038
8-SPECIFICATIONSSpecificationsCS-01E
Model YZF1000R
Dimensions
Overall length 2,085 mm (except for CH, D, DK,
NL, S, SF)
2,170 mm (for CH, D, DK, NL, S,
SF)
Overall width 740 mm
Overall height 1,175 mm
Seat height 815 mm
Wheelbase 1,430 mm
Ground clearance 140 mm
Minimum turning radius 3,100 mm
Basic weight (with oil and full
fuel tank)
224 kg
Engine
Engine type Liquid-cooled 4-stroke, DOHC
Cylinder arrangement Forward-inclined parallel
4-cylinder
Displacement 1,002 cm
3
Bore ´ Stroke 75.5 ´ 56.0 mm
Compression ratio 11.5:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Ty p e
Recommended engine oil
classification API Service SE, SF, SG type or
higher
Quantity
Periodic oil change 3.0 L
With oil filter replacement 3.2 L
Total amount 3.5 L
Air filter
Dry type element
-20˚ -10˚ 0˚
10˚20˚ 30˚
40˚50˚C
SAE 10W/30
SAE 15W/40SAE 20W/40SAE 20W/50
SAE 10W/40
CAUTION:Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled
“Energy Conserving”) contain anti-friction additives which
will cause clutch and/or starter clutch slippage, resulting in
reduced component life and poor engine performance.
E_4sv_Spec.fm Page 1 Tuesday, August 31, 1999 3:47 PM
10-INDEXAAir filter ..................................................6-12BBattery ................................................... 6-27
Brake and clutch lever lubrication........... 6-25
Brake and shift pedal lubrication ............ 6-24
Brake fluid replacement ......................... 6-22
Brake light switch adjustment ................. 6-19CCable inspection and lubrication ............ 6-24
Carburetor adjustment ...........................6-14
Care.........................................................7-1
Checking the front and rear brake
pads ....................................................6-20
Clutch lever .............................................. 3-9
Controls/Instruments ................................2-3
Coolant ..................................................6-11
Coolant temperature gauge ..................... 3-7
Cowling A ................................................6-5
Cowling B ................................................6-5
Cowling C ................................................6-6
Cowling removal and installation .............. 6-5DDiagnosis device......................................3-7
Dimmer switch .........................................3-8
Drive chain lubrication ............................6-24
Drive chain slack adjustment..................6-23
Drive chain slack check.......................... 6-23EEngine break-in........................................ 5-5
Engine oil ................................................. 6-9
Engine stop switch................................... 3-9
EXUP (EXhaust Ultimate Powervalve)... 3-19FFront brake lever ................................... 3-10
Front fork adjustment............................. 3-15
Front fork inspection .............................. 6-26
Front wheel installation .......................... 6-31
Front wheel removal .............................. 6-31
Fuel ....................................................... 3-12
Fuel indicator circuit check....................... 3-5
Fuel indicator light ................................... 3-4
Fuel tank breather hose
(for Germany only) .............................. 3-13
Fuel tank cap ......................................... 3-11
Fuse replacement.................................. 6-28GGive safety the right of way ..................... 1-1HHandlebar switches ................................. 3-8
Dimmer switch ................................... 3-8
Engine stop switch ............................. 3-9
Horn switch ........................................ 3-8
Lights switch ...................................... 3-9
Pass switch ........................................ 3-8
Start switch ........................................ 3-9
Turn signal switch .............................. 3-8
Headlight bulb replacement ................... 6-29
Helmet holder ........................................ 3-14
High beam indicator light ......................... 3-2
Horn switch ............................................. 3-8
IIdentification number records ...................9-1
Idle speed adjustment ............................6-15
Indicator lights ..........................................3-2
Fuel indicator light...............................3-4
High beam indicator light ....................3-2
Neutral indicator light ..........................3-2
Oil level indicator light .........................3-2
Turn indicator light ..............................3-2
Inspecting the brake fluid level ...............6-21KKey identification number .........................9-1LLeft view...................................................2-1
Lights switch ............................................3-9
Luggage strap holders ...........................3-19MMain switch/steering lock .........................3-1
Model label ..............................................9-2NNeutral indicator light ...............................3-2OOil level indicator circuit check .................3-3
Oil level indicator light ..............................3-2PParking.....................................................5-6
Pass switch ..............................................3-8
Periodic maintenance and lubrication .......6-2
Pre-operation check list............................. 4-1
