PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-6.frame
When installing a spark plug, the gas-
ket surface should always be cleaned
and a new gasket used. Any grime
should be wiped off from the threads
and the spark plug tightened to the
specified torque.
NOTE:
If a torque wrench is not available when
installing a spark plug, a good estimate
of the correct torque is 1/4 to 1/2 turn
past finger tight. The spark plug should
be tightened to the specified torque as
soon as possible.Tightening torque:
Spark plug:
12.5 Nm (1.25 mákg)
1. Level window
2. Maximum level mark
3. Minimum level mark
EAU02938
Engine oil
Oil level inspection
1. Place the motorcycle on the cen-
terstand. Warm up the engine for
several minutes.
NOTE:
Be sure the motorcycle is positioned
straight up when checking the oil level.
A slight tilt toward the side can result in
false readings.
1. Engine oil filler cap
2. With the engine stopped, check
the oil level through the level win-
dow located at the lower part of
the right side crankcase cover.
NOTE:
Wait a few minutes until the oil level
settles before checking.
3. The oil level should be between
the maximum and minimum
marks. If the level is low, fill the en-
gine with sufficient oil to reach the
specified level.

L
6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-6.frame
1. Torque wrench
7. Install the new oil filter and tighten
it to the specified torque with an oil
filter wrench.
NOTE:
When installing the oil filter, tighten it to
the proper torque by using a torque
wrench.
Tightening torque:
Oil filter:
17 Nm (1.7 mákg)
8. Fill the engine with sufficient oil to
reach the specified level. Install
the oil filler cap and tighten it.
EC000066
CAUTION:
lDo not put in any chemical addi-
tives. Engine oil also lubricates
the clutch and additives could
cause clutch slippage.
lBe sure no foreign material en-
ters the crankcase. Recommended oil:
See page 8-1.
Oil quantity:
Total amount:
3.1 L
Periodic oil change:
2.3 L
With oil filter replacement:
2.6 L
9. Start the engine and warm it up for
several minutes. While warming
up, check for oil leakage. If oil
leakage is found, stop the engine
immediately and check for the
cause.
NOTE:
After the engine is started, the oil level
indicator light should go off if the oil is at
the specified level.
EC000067
CAUTION:
If the indicator light flickers or re-
mains on, immediately stop the en-
gine and consult with a Yamaha
dealer.

L
6-13
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-6.frame
EAU00637
Valve clearance adjustment
The correct valve clearance changes
with use, resulting in improper fuel/air
supply or engine noise. To prevent this,
the valve clearance must be adjusted
regularly. This adjustment however,
should be left to a professional
Yamaha service technician.
EAU00647
Tires
To ensure maximum performance,
long service, and safe operation, note
the following:
Tire air pressure
Always check and adjust the tire pres-
sure before operating the motorcycle.
EW000082
Tire inflation pressure should be
checked and adjusted when the
temperature of the tire equals the
ambient air temperature. Tire infla-
tion pressure must be adjusted ac-
cording to total weight of cargo,
rider, passenger, and accessories
(fairing, saddlebags, etc. if approved
for this model), and vehicle speed.
Maximum load* XJ600S: 184 kg
XJ600N: 187 kg
Cold tire pressure Front Rear
Up to 90 kg*200 kPa
(2.00 kg/cm
2,
2.00 bar)225 kPa
(2.25 kg/cm2,
2.25 bar)
90 kg load ~
Maximum load*200 kPa
(2.00 kg/cm
2,
2.00 bar)250 kPa
(2.50 kg/cm2,
2.50 bar)
High speed riding200 kPa
(2.00 kg/cm
2,
2.00 bar)250 kPa
(2.50 kg/cm2,
2.50 bar)
* Load is the total weight of cargo, rider, passenger
and accessories.

L
6-23
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-6.frame
EAU02985
Brake and clutch lever
lubrication
Lubricate the pivoting parts.
Recommended lubricant:
Engine oil
EAU02965
Center and sidestand
lubrication
Lubricate the pivoting and mating
joints.
Check to see that the center and side-
stand move up and down smoothly.
EW000114
If the center and/or sidestand does
not move smoothly, consult a
Yamaha dealer.Recommended lubricant:
Engine oil
EAU00790
Rear suspension lubrication
Lubricate the pivoting parts.
Recommended lubricant:
Molybdenum disulfide grease

R
6-24
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-6.frame
EAU02939
Front fork inspection
Visual checkEW000115
Securely support the motorcycle so
there is no danger of it falling over.
Check for scratches or damage on the
inner tube and excessive oil leakage
from the front fork.
Operation check
1. Place the motorcycle on a level
place.
2. Hold the motorcycle in an upright
position and apply the front brake.
3. Push down hard on the handle-
bars several times and check if the
fork rebounds smoothly.
EC000098
CAUTION:
If any damage or unsmooth move-
ment is found with the front fork,
consult a Yamaha dealer.
EAU00794
Steering inspection
Periodically inspect the condition of the
steering. Worn out or loose steering
bearings may be dangerous. Place a
stand under the engine to raise the
front wheel off the ground. Hold the
lower end of the front forks and try to
move them forward and backward. If
any free play can be felt, ask a Yamaha
dealer to inspect and adjust the steer-
ing. Inspection is easier if the front
wheel is removed.
EW000115
Securely support the motorcycle so
there is no danger of it falling over.

L
6-35
PERIODIC MAINTENANCE AND MINOR REPAIR
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-6.frame
EAU01297
Troubleshooting chart
EW000125
Never check the fuel system while smoking or in the vicinity of an open flame.
Check if there is fuel
in the fuel tank.
1. FuelEnough fuel.
No fuel.Go to compression check.
Supply fuel.
Use the electric starter.
2. CompressionThere is compression.
No compression.Go to ignition check.
Ask a Yamaha dealer to
inspect.
Remove spark
plugs and
check electrodes.
3. IgnitionWet.
Dry.Wipe clean with dry cloth and correct
spark gap or replace spark plugs.
Ask a Yamaha dealer to inspect.
Engine doesnÕt start, go to battery
check.
Open throttle half-way and start
the engine.
Use the electric starter.
4. BatteryEngine turns over
quickly.
Engine turns over
slowly.Battery good.
Check connections or
recharge.
Engine doesnÕt start, ask a Yamaha
dealer to inspect.
Engine doesnÕt start, go to compression check.

L
7-5
MOTORCYCLE CARE AND STORAGE
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/E-7.frame
c. Install the spark plug caps onto the
spark plugs and place the spark
plugs on the cylinder head so that
the electrodes are grounded. (This
will limit sparking during the next
step.)
d. Turn the engine over several times
with the starter. (This will coat the
cylinder walls with oil.)
e. Remove the spark plug caps from
the spark plugs, install the spark
plugs and then the spark plug
caps.
EWA00003
When turning the engine over, be
sure to ground the spark plug elec-
trodes to prevent damage or injury
from sparking.
6. Lubricate all control cables and
the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.7. Check and, if necessary, correct
the tire air pressure, then raise the
motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
8. Cover up the muffler outlets with
plastic bags to prevent moisture
from entering.
9. Remove the battery and fully
charge it. Store it in a cool, dry
place and recharge it once a
month. Do not store the battery in
an excessively cold or warm place
(less than 0ûC or more than 30ûC).
For more information, see ÒBattery
storageÓ in the chapter ÒPERIOD-
IC MAINTENANCE AND MINOR
REPAIRSÓ.
NOTE:
Make any necessary repairs before
storing the motorcycle.

L
INDEX
/Net/layout8/layout_G2/work/Imai_work/OM-PS/AA9156_XJ600SN-E6/English/EEIX.frame
A
Air filter .................................................6-10
B
Battery ..................................................6-25
Brake and clutch lever lubrication ........6-23
Brake and shift pedal lubrication ..........6-22
Brake fluid replacement ........................6-20
Brake light switch adjustment ...............6-17
C
Cable inspection and lubrication ..........6-22
Carburetor adjustment ..........................6-11
Care ........................................................7-1
Center and sidestand lubrication ..........6-23
Checking the front and rear brake
pads ...................................................6-18
Clutch lever ............................................3-9
Clutch lever free play adjustment .........6-15
Controls/Instruments (XJ600N) ..............2-6
Controls/Instruments (XJ600S) ..............2-3
D
Dimmer switch ........................................3-7
Drive chain lubrication ..........................6-21
Drive chain slack adjustment ................6-21
Drive chain slack check ........................6-20
E
Engine break-in ......................................5-5
Engine oil ................................................6-7
Engine stop switch .................................3-9
F
Front brake lever ................................. 3-10
Front fork inspection ............................ 6-24
Front wheel installation ........................ 6-31
Front wheel removal ............................ 6-31
Fuel ...................................................... 3-12
Fuel cock ............................................. 3-13
Fuel tank breather hose
(for Germany only) ............................ 3-12
Fuel tank cap ....................................... 3-11
Fuse replacement ................................ 6-26
G
Give safety the right of way ................... 1-1
H
Handlebar switches ............................... 3-7
Dimmer switch ................................. 3-7
Engine stop switch ........................... 3-9
Hazard switch .................................. 3-8
Horn switch ...................................... 3-8
Lights switch .................................... 3-9
Pass switch ...................................... 3-7
Start switch ...................................... 3-9
Turn signal switch ............................ 3-8
Hazard switch ........................................ 3-8
Headlight bulb replacement
(for XJ600N) ...................................... 6-29
Headlight bulb replacement
(for XJ600S) ...................................... 6-27
Helmet holders ..................................... 3-15
High beam indicator light ....................... 3-3
Horn switch ............................................ 3-8
I
Identification number records ................ 9-1
Idle speed adjustment .......................... 6-12
Indicator lights ........................................ 3-3
High beam indicator light .................. 3-3
Neutral indicator light ....................... 3-3
Oil level indicator light ...................... 3-3
Turn indicator lights .......................... 3-3
Inspecting the brake fluid level ............ 6-19
K
Key identification number
(for XJ600N) ........................................ 9-1
Key identification number
(for XJ600S) ........................................ 9-1
L
Left view (XJ600N) ................................ 2-4
Left view (XJ600S) ................................. 2-1
Lights switch .......................................... 3-9
Luggage strap holders ......................... 3-16
M
Main switch ............................................ 3-1
Model label ............................................ 9-2
N
Neutral indicator light ............................. 3-3
