5 - 44
CHASREAR SHOCK ABSORBER
EC580000
REAR SHOCK ABSORBER
Extent of removal:1 Rear shock absorber removal
Extent of removal Order Part name Q’ty Remarks
Preparation for removalREAR SHOCK ABSORBER
REMOVAL
Hold the machine by placing the
suitable stand under the engine.
Seat and side covers Refer to “SEAT, FUEL TANK AND SIDE
COVERS” section.
1 Bolt (rear shock absorber-relay
arm)1 Hold the swingarm.
2 Bolt (rear shock absorber-frame) 1
3 Bushing 1 Refer to “REMOVAL POINTS”.
4Rear shock absorber
1
WARNING
Support the machine securely so there is nodanger of it falling over.
1
5 - 47
CHAS
Installation
1. Install:
lRear shock absorber
On frame.
NOTE:
Install the rear shock absorber with its warning
label a facing left side of the machine.
2. Install:
lBolt (rear shock absorber - frame)
lPlain washer 1
lNut 2
NOTE:
Apply the molybdenum disulfide grease on the
bolt (rear shock absorber - frame).
T R..53 Nm (5.3 m · kg, 38 ft · lb)
3. Install:
lBolt (rear shock absorber - relay arm)
lPlain washer 1
lNut 2
NOTE:
Apply the molybdenum disulfide grease on the
bolt (rear shock absorber - relay arm).
T R..35 Nm (3.5 m · kg, 25 ft · lb)
REAR SHOCK ABSORBER
