2000 TOYOTA LAND CRUISER Owners Manual

L/C 100_U261
2000 L/C 100 (OM60866U)
49. AM1 NO.1 80 A:
Charging system, all
components in ”AM1 NO.2”, ”GAUGE”,
”WIPER”, ”DIFF”, ”A.C” and ”SEAT
HTR” fuses
50. HTR 60 A: Air conditioning system
51. GLOW 80 A: No circuit

L/C 100_U
262 2000 L/C 100 (OM60866U)

L/C 100_U263
2000 L/C 100 (OM60866U) REPORTING SAFETY DEFECTS FOR U.S.
OWNERS AND UNIFORM TIRE QUALITYGRADING
Reporting safety defects for U.S. owners264
. . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading264
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SECTION
9

L/C 100_U
264 2000 L/C 100 (OM60866U)
If you believe that your vehicle has
a defect whi ch coul d cause a cr ash
or could cause injury or death, you
should immediately inform the Na-
tional Highway Traffic Safety Ad-
ministration (NHTSA) in addition to
notifying Toyota Motor Sales,
U.S.A., Inc. (Toll
−free:
1 −800 −331 −4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety de-
fect exists in a group of vehicles, it
may order a recall and remedy
campaign. However, NHTSA cannot
become involved in individual prob-
lems between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc. To contact NHTSA, you may either
call the Auto Safety Hotline toll
−free
at 1 −800 −424 −9393 (or 366 −0123
in Washington. D.C. area) or write
to: NHTSA, U.S. Department of
Transportation, Washington. D.C.
20590. You can also obtain other
information about motor vehicle
safety from the Hotline. Uniform tire quality grading
This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality grades—All passenger ve-
hicle tires must conform to Federal
Safety Requirements in addition to
these grades. Quality grades can be
found where applicable on the tire side-
wall between tread shoulder and maxi-
mum section width. For example: Tread-
wear 200 Traction AA Temperature A.
Reporting safety defects for
U.S. owners

L/C 100_U265
2000 L/C 100 (OM60866U)
Tread wear—
The tread wear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1 −1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Traction AA, A, B, C— The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction. Temperature A, B, C—
The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.

L/C 100_U
266 2000 L/C 100 (OM60866U)

00MY L/C 100(U)
i 2000 L/C 100 (OM60866U)
Foreword
Welcome to the growing group of value −conscious people who drive Toyotas. We
are proud of the advanced engineering and quality construction of each vehicle w e
build.
This Owner ’s Manual explains the features of your new Toyota. Please read it and
follow the instructions carefully so that you can enjoy many years of safe motoring.
When it comes to service, remember that your Toyota dealer knows your v ehicle
best and is interested in your complete satisfaction. He will provide quality mainte-
nance and any other assistance you may require.
Please leave this Owner ’s Manual in this vehicle at the time of resale. T he next
owner will need this information also.
All information and specifications in this manual are current at the time of
printing. However, because of Toyota’s policy of continual product improve-
ment, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment ,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
1999 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, i n whole or in
part, without the written permission of Toyota Motor Corporation.

00MY L/C 100(U)
ii 2000 L/C 100 (OM60866U)
New vehicle warranty
Your new vehicle is covered by the following Toyota
limited warranties: New vehicle warranty
Emission control systems warranty
Others
For further information, please refer to the ”Owner’s
Warranty Information Booklet” or ”Owner ’s Manual Sup-
plement”.
Your responsibility for maintenance
It is the owner ’s responsib ility to make sure the specified
maintenance is performed. Section 6 gives details of
these maintenance requirements. Also included in
Section 6 is general maintenance. For scheduled
maintenance information, place refer to the ”Scheduled
Maintenance Guide” or ”Owner ’s Manual Supplement”.
Accessories, spare parts and
modification of your Toyota
A wide variety of non −genuine spare parts and accesso-
ries for Toyota vehicles are currently available in the
market. You should know that Toyota does not warrant
these products and is not responsible for their perfor-
mance, repair, or replacement, or for any damage they
may cause to, or adverse effect they may have on,
your Toyota vehicle.
This vehicle should not be modified with non −genuine
Toyota products. Modification with non −genuine Toyota
products could affect its performance, safety or durabili-
ty, and may even violate governmental regulations. In
addition, damage or performance problems resulting from
the modification may not be covered under warranty.
