2000 MERCEDES-BENZ SLK230 Owner's Manual

142 Starting and turning off the enging
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Starting and turning off the engine
Before starting
Ensure that parking brake is engaged and that selector
lever is in position “P” or “N” (gearshift lever in
neutral). Turn key in steering lock to position 2.
Starting
Vehicles with automatic transmission:
Do not depress accelerator. Briefly turn key in steering
lock clockwise to the stop and release. The starter will
engage until the engine is running.
If engine will not run, and the starting procedure stops,
turn key completely to the left and repeat starting the
engine.
After several unsuccessful attempts, have the system
checked at the nearest authorized Mercedes-Benz
Center.Vehicles with manual transmission:
Do not depress accelerator. Fully depress clutch pedal,
otherwise the engine cannot be started due to the
integrated safety interlock.
Turn key in steering lock clockwise to the stop. Release
key only when the engine is firing regularly.
Important!
Due to the installed starter nonrepeat feature, the key
must be turned completely to the left before attempting
to start the engine again.
In areas where temperatures frequently drop below
-4°F(-20°C) we rec omm end tha t a n e ng ine bl ock h eater
be insta lled . You r a ut horized Mercedes-Benz Center will
advise you on this subject, see page 162.
Turning off
Turn the key in the steering lock to position 0 to stop the
engine.
Vehicles with automatic transmission:
The key can only be removed with your foot off the
brake pedal and the selector lever in position “P”.

143 Manual transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Manual transmission
See illustration for gearshift lever positions
corresponding to the individual gears.
Stop the vehicle completely before shifting into reverse;
to shift into reverse, pull the gearshift lever up.
Do not exceed the maximum engine speed in the
individual gears. Refer to tachometer (see page 74) for
engine speeds.Important!
When vehicle is parked, always be sure to engage first
or reverse gear and firmly set parking brake.
When parked on an incline, also turn front wheel
towards the road curb.
Downshifting gears leading to overrevving the engine
can result in transmission damage that is not covered
by the Mercedes-Benz Limited Warranty.
Do not exceed engine speed limits, see page 74.
4 1
6
5
1
3
R
4
R4
6
13
5
2
2
P26.60-2053-26
Wa r n i n g !
On slippery road surfaces as well as high engine
speeds, never downshift in order to obtain braking
action. This could result in drive wheel slip and
reduced vehicle control. Your vehicle’s ESP will not
prevent this type of loss of control.Wa r n i n g !
When leaving the vehicle always remove the key
from the steering lock, and lock the vehicle. Do not
leave children unattended in the vehicle, or with
access to an u nlocked veh ic le. Ch ildren cou ld m ove
the gearshift lever, which could result in an
accident or serious injury.

144 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Automatic transmissionThe automatic transmission selects individual gears
automatically, dependent upon
•Selector lever position
•Program mode selector
•Accelerator position
•Vehicle speed
The gear shifting process is continuously adapted,
dependent on the driving style, the driving situation
and the road characteristics.
Important!
When parking the car or before working on the vehicle
with the engine running, firmly engage the parking
brake and shift the selector lever into “P”.
@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

@@
€€
ÀÀ

yy
P27.60-2102-26

145 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Driving
The selector lever is automatically locked while in
position “P”. To move the selector lever out of
position “P”, the service brake pedal must be firmly
depressed before the shift lock will release.
Shift selector lever to the desired position only when the
engine is idling normally and the service brake is
applied. Do not release the brake until ready to drive.
The vehicle may otherwise start creeping when the
selector lever is in drive or reverse position.Important!
After selecting any driving position from “N” or “P”,
wait a moment to allow the gear to fully engage before
accelerating, especially when the engine is cold.
Accelerator position
Partial throttle = early upshifting = normal acceleration
Full throttle = later upshifting = rapid acceleration
Kickdown (depressing the accelerator beyond full
throttle) = downshifting to a lower gear = maximum
acceleration. Once the desired speed is attained, ease up
on the accelerator – the transmission shifts up again.
Wa r n i n g !
It is dangerous to shift the selector lever out of “P”
or “N” if the engine speed is higher than idle speed.
If your foot is not firmly on the brake pedal, the
vehicle could accelerate quickly forward or in
reverse. You could lose control of the vehicle and
hit someone or something. Only shift into gear
when the engine is idling normally and when your
right foot is firmly on the brake pedal.

146 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Stopping
For brief stops, e.g. at traffic lights, leave the
transmission in gear and hold vehicle with the service
brake.
For longer stops with the engine idling, shift into “N”
or “P” and hold the vehicle with the service brake.
When stopping the vehicle on an uphill gradient, do not
hold it with the accelerator, use the brake. This avoids
unnecessary transmission heat build up.
Maneuvering
To maneuver in tight areas, e.g. when pulling into a
parking space, control the vehicle speed by gradually
releasing the brakes. Accelerate gently and never
abruptly step on the accelerator.
To rock a vehicle out of soft ground (mud or snow),
alternately shift from forward to reverse, while applying
only slight partial throttle.
Rocking a vehicle free in this manner may cause the
ABS or traction system malfunction indicator lamp to
come on. Turn off and restart the engine to clear the
malfunction indication.
Wa r n i n g !
Getting out of your vehicle with the selector lever
not fully engaged in position “P” is dangerous.
Also, when parked on an incline, posi tion “P” alone
may not prevent your vehicle from moving,
possibly hitting people or objects.Always set t he parki ng brake in addi tion to sh ifting
to position “P”, see page 153 for parking brake. When parked on an incline, also turn front wheel
towards the road curb.Wa r n i n g !
When leaving the vehicle always remove the key
from the steering lock, and lock the vehicle. Do not
leave children unattended in the vehicle, or with
access to an u nlocked veh ic le. Ch ildren cou ld m ove
the gear selector lever from position “P”, which
could result in an accident or serious injury.

147 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Selector lever position
The current selector lever position is indicated in the
gear range indicator display. The automatic gear
shifting process can be adapted to specific operating
conditions using the selector lever.Park position
The park position is to be used when parking the
vehicle. Engage only with the vehicle stopped.
The park position is not intended to serve as a
brake when the vehicle is parked. Rather, the
driver should always use the parking brake in
addition to placing the selector lever in park to
secure the vehicle.
Notes:
The key can be removed from the steering lock
only with the foot off the brake pedal and the
selector lever in position “P”. With the key
removed, the selector lever is locked in
position “P”.
With a malfunction in the vehicle’s electrical
system the selector lever could remain locked in
position “P”. To unlock the selector lever
manually, see page 217.
Reverse gear
Shift to reverse gear only with the vehicle
sto p ped .

148 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Dependent on the program mode selector switch
position “S” or “W” the maximum speed in the
reverse gear is different. However, it is not
possible to change the program mode while in
reverse.
Neutral
No power is transmitted from the engine to the
drive axle. When the brakes are released, the
vehicle can be moved freely (pushed or towed). Do
not engage “N” while driving except to coast
when the vehicle is in danger of skidding (e.g. on
icy roads, see page 160 for winter driving
instructions).
Important!
Coasting the vehicle, or driving for any other
reason with selector lever in “N” can result in
transmission damage that is not covered by the
Mercedes-Benz Limited Warranty.
Drive
The transmission automatically upshifts through
5th gear. Position “D” provides optimum driving
characteristics under all normal operating
conditions.Gear selection for special circumstances
The transmission gear ranges for special circumstances
can be selected by pressing the selector lever to the
right or the left with the selector lever in position “D”.
The gear range currently selected is indicated in the
instrum ent clu ster disp lay.
Briefly press selector lever in the ç direction:
The transmission downshifts, one gear at a time, in the
order “4”, “3”, “2”, “1”.
Press and hold selector lever in the ç direction:
The selector lever position display will switch to the
gear range currently selected by the automatic
transmission.
The transmission will only shift down one gear if the
gear range currently selected has already shifted to its
highest possible gear.
Briefly press selector lever in the æ direction:
The transmission will shift from the current gear range
to the next higher gear range. If the transmission is
already in gear range “D”, an additional upshift of one
gear is possible.

149 Automatic transmission
Te ch n ica l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Press and hold selector lever in the æ direction:
The transmission will shift from the current gear
directly to gear range “D”.
Important!
With transmission in gear range “D”, “4” or “3”,
upshifting from 1st to 2nd to 3rd gear is delayed
depending on vehicle speed and engine temperature.
This allows the catalytic converter to heat up more
q uickly to operating temperatures.
During the brief warm-up period this delayed upshift
and increased engine noise might be perceived as a
malfunction. However, neither the engine nor
transmission are negatively affected by this mode of
operation.The delayed upshift is effective with vehicle speeds
below 31 mph (50 km / h) at partial throttle and engine
temperatures below 95°F (35°C).
To avoid overrevving the engine when the selector lever
is moved to a lower gear range, the transmission will not
shift to a lower gear, if the engine’s revolutions per
minute limit would be exceeded. In this case there will
be no downshift, even when the vehicle speed reaches
RPM limit of that gear, e.g. by applying the service
brakes.
To prevent the engine from laboring at low RPM when
driving uphill gradients or with your vehicle heavily
loaded, the automatic transmission will downshift when
necessary to maintain engine RPM within the best
torque range.
Wa r n i n g !
On slippery road surfaces, never downshift in order
to obtain braking action. This could result in drive
wheel slip and reduced vehicle control. Your
vehicle’s ABS will not prevent this type of loss of
control.
