BE±6
± BODY ELECTRICALTROUBLESHOOTING
2307 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
HEADLIGHT BEAM LEVEL CONTROL SYSTEM
SymptomSuspect AreaSee page
Beam axis is not controlled. (It is not initialized.)
Headlight Beam Level Control System does not operate.
1. ECU±IG Fuse
2. Headight Beam Level Control Actuator
3. Headlight Beam Level Control ECU
4. Wire Harness SideBE±21
BE±50
BE±50
±
Beam axis is not controlled. (It is initialized.)
Headlight Beam Level Control System does not operate.1. Height Control Sensor
2. Headlight Beam Level Control ECU
3. Wire Harness SideBE±50
BE±50
±
Controlled angle of head light is unusual.
(The angle is controlled.)
1. Height Control Sensor
2. Headlight Beam Level Control ECU
3. Headlights
4. Wire Harness Side±
BE±50
BE±3
±
Beam axis position is not stable during driving.
1. ABS System
2. Headlights
3. Wire HarnessDI±387
BE±3
±
FOG LIGHT SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Fog light does not light up with light control SW HEAD
(Headlight is normal.)
1. FOG Fuse
2. Fog Light Relay
3. Fog Light Switch
4. Wire Harness
5. Body No.2 ECUBE±21
BE±53
BE±53
±
±
Fog light does not light up with light control SW HEAD
(Headlight does not light).1.*1 Other Parts
2. Wire Harness±
±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
*1: Inspect Headlight System
TURN SIGNAL AND HAZARD WARNING SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. GAUGE Fuse
2. TURN HAZ Fuse
3. Ignitioin Switch
4. Turn Signal Flasher Relay
5. Wire HarnessBE±21
BE±21
BE±31
BE±56
±
Hazard warning light does not light up.
(Turn is normal)1. Hazard Warning Switch
2. Wire HarnessBE±56
±
Turn signal does not light up.
(Hazard is normal)1. Turn Signal Switch
2. Wire HarnessBE±56
±
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE±56
±
Only one bulb does not light up.1. Bulb
2. Wire Harness±
±

BE±8
± BODY ELECTRICALTROUBLESHOOTING
2309 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
BACK±UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back±Up Light does not light up.
1. GAUGE Fuse
2. Ignition Switch
3. Wire Harness
4. BulbBE±21
BE±31
±
±
Back±Up Light remains always on.1. Park/ Neutral Position Switch
2. Wire HarnessDI±372
±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
STOP LIGHT SYSTEM
SymptomSuspect AreaSee page
Stop light does not light up.
1. STOP Fuse
2. Stop Light Switch
3. Light Failure Relay
4. Wire HarnessBE±21
BE±70
BE±92
±
Stop light always lights up.1. Stop Light Switc
2. Wire HarnessBE±70
±
Only one light always lights up.Wire Harness±
Only one light does not light up.1. Bulb
2. Wire Harness±
±
HEADLIGHT CLEANER SYSTEM
SymptomSuspect AreaSee page
ºHeadlight Cleaner Systemº does not operate
(All)
1. H±LP CLN Fuse
2. WASHER Fuse
3. Ignition Switch
4. Headlight Cleaner Switch
5. Headlight Cleaner Relay
6. Headlight Cleaner Motor
7. Headlight Cleaner Nozzle and Hose
8. Wire HarnessBE±21
BE±21
BE±31
BE±73
BE±73
±
±
±
Washer fluid does not spray.Headlight Cleaner Nozzle and Hose±
WIPER AND WASHER SYSTEM
SymptomSuspect AreaSee page
Wipers and washer do not operate.
1. WIP Fuse
2. Wiper Switch
3. Wiper Motor
4. Wire HarnessBE±21
BE±77
BE±77
±
Wipers do not operate in LO, HI or MIST.
1. Wiper Switch
2. Wiper Motor
3. Wire HarnessBE±77
BE±77
±
Wipers do not operate in INT.
1. Wiper Switch
2. Wiper Motor
3. Wire HarnessBE±77
BE±77
±
Washer motor does not operate.
1. WASHER Fuse
2. Washer Switch
3. Washer Motor
4. Wire HarnessBE±21
BE±77
BE±77
±
Wipers do not operate when washer switch ON.
1. WASHER Fuse
2. Washer Switch
3. Wiper Motor
4. Wire HarnessBE±21
BE±77
BE±77
±

BE±10
± BODY ELECTRICALTROUBLESHOOTING
2311 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) Malfunction indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. ECM (2JZ±GE)
5. ECM (1UZ±FE)±
BE±92
±
DI±1
DI±156
Fuel level warning light does not light up.
1. Bulb
2. Fuel level warning sensor
3. Meter Circuit Plate
4. Wire Harness±
±
BE±92
±
ELECTRIC TENSION REDUCER SYSTEM
SymptomSuspect AreaSee page
Tension Reducer does not operate.
(Driver's and Passenger's)1. ECU±IG Fuse
2. Wire HarnessBE±21
±
Tension Reducer does not operate.
(Only one side)1. Buckle Switch
2. Tension Reducer Solenoid
3. Wire HarnessBE±92
BE±92
±
DEFOGGER SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
Rear window defogger does not operate.
1. HTR Fuse
2. DEF M±Fuse
3. Defogger Relay Circuit
4. Defogger Switch (in A/C Panel Switch)
5. Defogger Wire
6. Wire Harness
7. Body No.1 ECUBE±21
BE±21
DI±812
BE±108
BE±108
±
DI±776
Mirror defogger does not operate.
1. MIR±HTR Fuse (Passenger SIde J/B)
2. Mirror Heater Relay
3. Mirror Heater
4. Wire HarnessBE±21
BE±108
BE±108
±
POWER WINDOW CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
SymptomSuspect AreaSee page
All the power windows do not operate.
(Power Door Lock System is normal.)
1. PWS terminal circuit
2. Power Window Master Switch
3. Wire Harness
4. Driver Door ECU
5. Body No.1 ECUDI±818
BE±117
±
DI±856
DI±776
Only the driver's window does not operate.
1. Power Window Master Switch
2. Power WIndow Switch
3. Power Window Motor
4. Wire HarnessBE±117
BE±117
BE±117
±
ºWindow lock functionº does not operate.1. Power Window Master SwitchBE±117
Window does not operate with power window master switch.
(Manual or Automatic operation can be performed.)TROUBLESHOOTING NO.1BE±111
Remote control of all windows (Except driver's) does not functions
with master switch.
(Windows operate normally with each of master switch.)
TROUBLESHOOTING NO.2BE±111

BE±12
± BODY ELECTRICALTROUBLESHOOTING
2313 Author: Date:
2000 LEXUS GS300/GS400 (RM718U) The system does not operate when the ignition switch is turned to
ACC without using a key or transmitter.
1. Ignition Switch
2. Key Unlock Warning Switch
3. Transmitter
4. Wire Harness
5. Body No.1 ECUBE±31
BE±31
BE±157
±
DI±776
Some of the system does not operate.
(Headlight does not light up.)
1. Headlight System
2. Wire Harness
3. Body No.2 ECU
4. Body No.1 ECUBE±3
±
DI±820
DI±776
Some of the system does not operate.
(Taillight does not light up.)
1. Taillight System
2. Wire Harness
3. Body No.2 ECU
4. Body No.1 ECUBE±3
±
DI±820
DI±776
Some of the system does not operate.
(Theft Deterrent Horn or Horn does not sound.)
1. HORN Fuse
2. Theft Deterrent Horn
3. Horn
4. Horn Relay
5. Wire Harness
6. Body No.1 ECUBE±21
BE±150
BE±250
BE±250
±
DI±776
While the warning is given, the system cannot be canceled by
unlocking the door with key or transmitter.1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Body No.1 ECUBE±131
±
DI±776
While the warning is given, the system cannot be canceled by
turning the ignition switch to ACC or ON with key.
1. Ignition Switch
2. Key Unlock Warning Switch
3. RAD NO.2 Fuse
4. ECU±IG Fuse
5. Wire Harness
6. Body No.2 ECU
7. Body No.1 ECUBE±31
BE±31
BE±21
BE±21
±
DI±820
DI±776
The system operates for more than 60 seconds.Body No.1 ECUDI±776
WIRELESS DOOR LOCK CONTROL SYSTEM
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before you proceed with troubleshooting.
HINT:
Troubleshooting of the wireless door lock control system is based on the premise that the door lock
control system is operating normally. Accordingly, before troubleshooting the wireless door lock control
system, first make certain that the door lock control system is operating normally.
If the trouble still reappears even though there are no abnormalities in any of the other circuits, then
check and replace the Wireless Door Lock Control Receiver as the last step.
SymptomSuspect AreaSee page
All functions of wireless door lock control system do not operate.
1. Transmitter
2. Wireless Door Lock Control Receiver
3. Wire Harness
4. Body No.1 ECUBE±157
BE±157
±
DI±776
Wireless door lock operates, but the buzzer does not sound.
(The buzzer does not sound when the customize function prohib-
its.)1. Wireless Door Lock Buzzer
2. Wireless Door Lock Control Receiver
3. Wire HarnessBE±157
BE±157
±

± BODY ELECTRICALTROUBLESHOOTING
BE±15
2316 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
GARAGE DOOR OPENER SYSTEM
SymptomSuspect AreaSee page
The equipment of which code has been registered does not oper-
ate.1. Garage Door Opener Switch
2. Wire Harness
3. *BE±235
±
±
LED does not light up. (Even though either switch is pressed.)1. Garage Door Opener Switch
2. Wire HarnessBE±235
±
LED does not light up. (Only one switch is pressed.)Garage Door Opener SwitchBE±235
* As the GARAGE DOOR OPENER on the vehicle side seems to be normal, check the OPENER on the
equipment side, of which code has been registered.
ENGINE IMMOBILIZER SYSTEM
SymptomSuspect AreaSee page
Engine immobilizer system does not operate.See DIAGNOSIS SYSTEMDI±726
HORN SYSTEM
SymptomSuspect AreaSee page
Horn system does not operate.
1. HORN Fuse
2. Horn Relay
3. Horn Switch
4. Horn
5. Wire HarnessBE±21
BE±250
BE±250
BE±250
±
Horns blow all the time.
1. Horn Relay
2. Horn Switch
3. Wire HarnessBE±250
BE±250
±
One horn operates but the other horn does not operate.1. Horn
2. Wire HarnessBE±250
±
Horns operate abnormally.
1. Horn Relay
2. Horn
3. Wire HarnessBE±250
BE±250
±

BE0H8±04
I10257
Driver Side Junction Block

GAUGE Fuse

TAIL Fuse

Taillight Control Relay

Body ECU No.2
Combination Switch

Light Control Switch

Headlight Dimmer SwitchIgnition Switch
Daytime Running
Light Main Relay
(w/ D.R.L. System) HeadlightsEngine Room No.1 Junction Block

H±LP L LWR Fuse

H±LP R LWR Fuse

H±LP L UPR Fuse (w/o D.R.L System)

H±LP R UPR Fuse (w/o D.R.L System)

Headight Control Relay D.R.L.: Daytime Running Light
Automatic Light Control Sensor
Headlights
Taillights
Engine Room No.2 Junction Block

Headight Dimmer (D.R.L. No.2) Relay

H±LP R UPR Fuse (w/ D.R.L System)

H±LP L UPR Fuse (w/ D.R.L System)
Light Control ECU Light Control ECU
Daytime Running Light No.3 and No.4 Relay
(w/ D.R.L. System)
Daytime Running Light Resister
± BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE±33
2334 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
HEADLIGHT AND TAILLIGHT SYSTEM
LOCATION
The vehicle shown in this illustration is ºGS400º.
All components of ºGS300º other than the ones used for engine are same as ºGS400º.

I04036
1 2
3 41 2 3
4 5 6 Connector ºBº Connector ºAº
A2 B3 B1
A3
A5 A1 B4 B2
I01259
21
3 4
2
41
3
BE±40
± BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
2341 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
8. INSPECT DAYTIME RUNNING LIGHT NO.3 AND NO.4
RELAY CONTINUITY
Tester connectionConditionSpecified condition
A1 ± B3ConstantContinuity
A3 ± A5ConstantContinuity
B3 ± B4ConstantContinuity
A2 ± A5Apply battery positive voltage between
terminals A1 and B3.Continuity
B1 ± B2Apply battery positive voltage between
terminals B3 and B4.Continuity
If continuity is not as specified, replace the relay.
9. INSPECT HEADLIGHT CONTROL RELAY CONTINU-
ITY
ConditionTester connectionSpecified condition
Constant1 ± 2Continuity
Apply B+ between
terminals 1 and 2.3 ± 4Continuity
If continuity is not as specified, replace the relay.
10. INSPECT HEADLIGHT CONTROL RELAY CIRCUIT
(See page DI±847 and BE±21)

I01260
21
3 42
41
3
I01200
2 1
35
2 5
1 3
I04037
Wire Harness Side
h±10±1±A
± BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE±41
2342 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
11. INSPECT HEADLIGHT DIMMER ( DAYTIME RUNNING
LIGHT NO.2) RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant1 ± 4
2 ± 4Continuity
Apply B+ between
terminals 2 and 4.1 ± 3 ± 4Continuity
If continuity is not as specified, replace the relay.
12. INSPECT HEADLIGHT DIMMER (DAYTIME RUNNING
LIGHT NO.2) RELAY CIRCUIT
(See page BE±21)
13. INSPECT TAILLIGHT CONTROL RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant1 ± 2Continuity
Apply B+ between
terminals 1 and 2.3 ± 5Continuity
If continuity is not as specified, replace the relay.
14. INSPECT TAILLIGHT CONTROL RELAY CIRCUIT
(See page DI±845 and BE±21)
15. INSPECT DAYTIME RUNNING LIGHT MAIN RELAY
CIRCUIT
Disconnect the connector from the relay and inspect the con-
nector on the wire harness side.
Tester connectionConditionSpecified condition
2 ± GroundLight control switch OFF or TAILNo continuity
2 ± GroundLight control switch HEADContinuity
4 ± GroundParking brake switch OFF
(Parking brake pedal released)No continuity
4 ± GroundParking brake switch ON
(Parking brake pedal depressed)Continuity
6 ± GroundConstantContinuity
8 ± GroundHeadlight dimmer switch LOW beamNo continuity
