EM±96
± ENGINE MECHANICAL (2JZ±GE)CYLINDER BLOCK
1450 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
20. INSTALL OIL FILTER AND BRACKET ASSEMBLY
(a) Install a new O±ring to the oil filter bracket.
(b) Install a new gasket to the union bolt.
(c) Install the oil filter bracket with the union bolt.
Torque: 90 N´m (900 kgf´cm, 65 ft´lbf)
21. INSTALL OIL PRESSURE SWITCH AND KNOCK
SENSORS (See page LU±1, SF±63)
22. INSTALL CYLINDER HEAD (See page EM±52)
23. INSTALL WATER PUMP (See page CO±8)
24. INSTALL NO.2 WATER BYPASS PIPE WITH HOSE
(a) Install the water bypass pipe with the bolt and 2 nuts.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)
(b) Connect the water bypass hose to the hose clamp.
25. INSTALL TIMING PULLEYS AND BELT
(See page EM±23)
26. INSTALL GENERATOR
Install the generator and pipe bracket with the bolt and nut.
Torque: 40 N´m (400 kgf´cm, 30 ft´lbf)
27. REMOVE ENGINE STAND FROM ENGINE

EM0DO±03
A09756

Before installing oxygen sensor, twist
sensor wire counterclockwise 3 and 1/2
turns.

After installing oxygen sensor, check that
sensor wire is not twisted. If it is twisted,
remove oxygen sensor and reinstall it.HINT:
Ring
RingRing BracketHeat Insulator
RH Tailpipe


Heat
Insulator


RingBracketRing Tailpipe
Baffle Gasket
Center Exhaust PIpe
 Gasket
Ring
Heat Insulator
LH Tailpipe
Tailpipe
Baffle
44 (440, 32)
44 (440, 32)
Front Floor
Center Brace
Heated Oxygen Sensor
Heated Oxygen Sensor
(Bank 2 Sensor 2)
Heat InsulatorHeat Insulator
45 (450, 33)
44 (440, 32)
 Gasket
N´m (kgf´cm, ft´lbf) : Specified torque
 Non±reusable partPipe Support Bracket
Front Exhaust Pipe
 Gasket Heat
Insulator
44 (440, 32)
± ENGINE MECHANICAL (2JZ±GE)EXHAUST SYSTEM
EM±97
1451 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
EXHAUST SYSTEM
COMPONENTS

± INTRODUCTIONFOR ALL OF VEHICLES
IN±17
17 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
2. FOR VEHICLES EQUIPPED WITH A CATALYTIC CONVERTER
CAUTION:
If large amount of unburned gasoline flows into the converter, it may overheat and create a fire haz-
ard. To prevent this, observe the following precautions and explain them to your customer.
(a) Use only unleaded gasoline.
(b) Avoid prolonged idling.
Avoid running the engine at idle speed for more than 20 minutes.
(c) Avoid spark jump test.
(1) Perform spark jump test only when absolutely necessary. Perform this test as rapidly as possible.
(2) While testing, never race the engine.
(d) Avoid prolonged engine compression measurement.
Engine compression tests must be done as rapidly as possible.
(e) Do not run engine when fuel tank is nearly empty.
This may cause the engine to misfire and create an extra load on the converter.
(f) Avoid coasting with ignition turned off.
(g) Do not dispose of used catalyst along with parts contaminated with gasoline or oil.
3. IF VEHICLE IS EQUIPPED WITH MOBILE COMMUNICATION SYSTEM
For vehicles with mobile communication systems such as two±way radios and cellular telephones, observe
the following precautions.
(1) Install the antenna as far as possible away from the ECU and sensors of the vehicle's electronic
system.
(2) Install the antenna feeder at least 20 cm (7.87 in.) away from the ECU and sensors of the ve-
hicle's electronic systems. For details about ECU and sensors locations, refer to the section on
the applicable component.
(3) Avoid winding the antenna feeder together with other wiring as much as possible, and also avoid
running the antenna feeder parallel with other wire harnesses.
(4) Check that the antenna and feeder are correctly adjusted.
(5) Do not install powerful mobile communications system.
4. FOR USING OBD II SCAN TOOL OR LEXUS HAND±HELD TESTER
CAUTION:
Observe the following items for safety reasons:

Before using the OBD II scan tool or LEXUS hand±held tester, the OBD II scan tool's instruction
book or LEXUS hand±held tester's operator manual should be read thoroughly.

Be sure to route all cables securely when driving with the OBD II scan tool or LEXUS hand±held
tester connected to the vehicle. (i.e. Keep cables away from feet, pedals, steering wheel and
shift lever.)

Two persons are required when test driving with the OBD II scan tool or LEXUS hand±held tes-
ter, one person to drive the vehicle and the other person to operate the OBD II scan tool or LEX-
US hand±held tester.

F02853
B01549
F02853
IN±18
± INTRODUCTIONFOR ALL OF VEHICLES
18 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
5. FOR VEHICLES EQUIPPED WITH VEHICLE SKID
CONTROL (VSC) SYSTEM
NOTICE:
When using a 2±wheel drum tester such as a speedometer
tester or chassis dynamometer, etc., or jacking up the rear
wheels and driving the wheels, always push in the TRAC &
VSC cut switch and turn the TRAC & VSC system OFF.
(a) Press the VSC OFF switch.
(b) Check that the VSC OFF indicator light comes ON.
HINT:
The VSC OFF indicator light should be always OFF when the
engine is restarted.
(c) Begin measurements.
(d) Press the VSC OFF switch again to change the TRAC &
VSC system to operational condition and check that the
VSC OFF indicator light goes off.
HINT:
The SLIP indicator light blinks when the TRAC system is opera-
tional.

IN04S±10
IN±20± INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMS
20 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
HOW TO TROUBLESHOOT ECU CONTROLLED SYSTEMS
GENERAL INFORMATION
A large number of ECU controlled systems are used in the LEXUS GS400/GS300. In general, the ECU con-
trolled system is considered to be a very intricate system requiring a high level of technical knowledge and
expert skill to troubleshoot. However, the fact is that if you proceed to inspect the circuits one by one, trouble-
shooting of these systems is not complex. If you have adequate understanding of the system and a basic
knowledge of electricity, accurate diagnosis and necessary repair can be performed to locate and fix the
problem. This manual is designed through emphasis of the above standpoint to help service technicians
perform accurate and effective troubleshooting, and is compiled for the following major ECU controlled sys-
tems:
The troubleshooting procedure and how to make use of it are described on the following pages.
SystemPage
1. Engine 2JZ ± GEDI±1
2. Engine 1UZ ± FEDI±156
3. Automatic TransmissionDI±316
4. ABS & Hydraulic Brake Booster Power Supply SystemDI±387
5. Vehicle Skid Control (VSC) & Brake Assist (BA) SystemDI±473
6. Power Tilt and Power Telescopic Steering ColumnDI±517
7. Supplemental Restraint SystemDI±550
8. Power Seat Control SystemDI±683
9. Cruise Control SystemDI±704
10.Engine Immobiliser SystemDI±726
11. Combination Meter SystemDI±744
12.Sliding Roof SystemDI±764
13.Body No. 1 Control SystemDI±776
14.Body No. 2 Control SystemDI±820
15.Driver Door Control SystemDI±856
16.Passenger Door Control SystemDI±889
17.Rear Left Door Control SystemDI±921
18.Rear Right Door Control SystemDI±938
19.Multiplex Communication SystemDI±955
20.LEXUS Navigation SystemDI±1022
21.Air Conditioning SystemDI±1059
FOR USING OBDII SCAN TOOL OR LEXUS HAND±HELD TESTER

Before using the scan tool or tester, the scan tool's instruction book or tester's operator manual should
be read thoroughly.

If the scan tool or tester cannot communicate with ECU controlled systems when you have connected
the cable of the scan tool or tester to DLC3, turned the ignition switch ON and operated the scan tool,
there is a problem on the vehicle side or tool side.
(1) If communication is normal when the tool is connected to another vehicle, inspect the diagnosis
data link line (Bus
line) or ECU power circuit of the vehicle.
(2) If communication is still not possible when the tool is connected to another vehicle, the problem
is probably in the tool itself, so perform the Self Test procedures outline in the Tester Operator's
Manual.

Important Points in the Customer Problem Analysis

What ±±±±± Vehicle model, system name

When ±±±±± Date, time, occurrence frequency

Where ±±±±± Road conditions

Under what conditions? ±±±±± Running conditions, driving conditions, weather conditions

How did it happen? ±±±±± Problem symptoms
(Sample) Engine control system check sheet.
ENGINE CONTROL SYSTEM Check Sheet
Customer's Name
Driver's Name
Data Vehicle
Brought in
License No.
Model and Model
Year
Frame No.
Engine Model
Odometer Reading
km
miles
Problem Symptoms
Engine does
not Start
Difficult to
Start
Poor Idling
Poor
Drive ability
Engine Stall
Others
Engine does not crankNo initial combustionNo complete combustion
Engine cranks slowly
Other
Incorrect first idleIdling rpm is abnormalHigh ( rpm)Low ( rpm)
Rough idling
Other
HesitationBack fireMuffler explosion (after±fire)Surging
Knocking
Other
Soon after startingAfter accelerator pedal depressed
After accelerator pedal released
During A/C operation
Shifting from N to D
Other
Data Problem
ConstantSometimes ( times per day/month)
Inspector's
Name
CUSTOMER PROBLEM ANALYSIS CHECK
IN±22± INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMS
22 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
1. CUSTOMER PROBLEM ANALYSIS
In troubleshooting, the problem symptoms must be confirmed accurately and all preconceptions must be
cleared away in order to give an accurate judgment. To ascertain just what the problem symptoms are, it is
extremely important to ask the customer about the problem and the conditions at the time it occurred.
Important Point in the Problem Analysis:
The following 5 items are important points in the problem analysis. Past problems which are thought to be
unrelated and the repair history, etc. may also help in some cases, so as much information as possible should
be gathered and its relationship with the problem symptoms should be correctly ascertained for reference
in troubleshooting. A customer problem analysis table is provided in Diagnostics section for each system
for your use.

DIAGNOSTIC TROUBLE CODE CHECK PROCEDURE
Diagnostic Trouble
Code Check (Make a
note of and then clear)Confirmation
of SymptomsDiagnostic Trouble
Code CheckProblem Condition
Diagnostic Trouble
Code DisplayProblem symptoms
existSame diagnostic
trouble code is
displayedProblem is still occurring in the diagnostic
circuit
Normal code is
displayedThe problem is still occurring in a place
other than in the diagnostic circuit
(The diagnostic trouble code displayed
first is either for a past problem or it is a
secondary problem)
No problem
symptoms existThe problem occurred in the diagnostic
circuit in the past
Normal Code DisplayProblem symptoms
existNormal code is
displayedThe problem is still occurring in a place
other than in the diagnostic circuit
No problem
symptoms existNormal code is
displayedThe problem occurred in a place other
than in the diagnostic circuit in the past
± INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMSIN±23
23 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
2. SYMPTOM CONFIRMATION AND DIAGNOSTIC TROUBLE CODE CHECK
The diagnostic system in the LEXUS GS400/GS300 fulfills various functions. The first function is the Diag-
nostic Trouble Code Check in which a malfunction in the signal circuits to the ECU is stored in code in the
ECU memory at the time of occurrence, to be output by the technician during troubleshooting. Another func-
tion is the Input Signal Check which checks if the signals from various switches are sent to the ECU correctly.
By using these check functions, the problem areas can be narrowed down quickly and troubleshooting can
be performed effectively. Diagnostic functions are incorporated in the following systems in the LEXUS
GS400/GS300.
SystemDiagnostic Trouble
Code CheckInput Signal Check
(Sensor Check)Diagnostic Test
Mode (Active Test)
Engine (2JZ±GE)
Engine (1UZ±FE)
Automatic Transmission
ABS & Hydraulic Brake Booster Power Supply System
Vehicle Skid Control (VSC) & Brake Assist (BA) System
Power Tilt and Power Telescopic Steering Column
Supplemental Restraint System
Cruise Control System
Engine Immobiliser System
Multiplex Communication System
LEXUS Navigation System
Air Conditioning System(with check Mode)
(with check Mode)
(with check Mode)















In diagnostic trouble code check, it is very important to determine whether the problem indicated by the diag-
nostic trouble code is still occurring or occurred in the past but returned to normal at present. In addition,
it must be checked in the problem symptom check whether the malfunction indicated by the diagnostic
trouble code is directly related to the problem symptom or not. For this reason, the diagnostic trouble codes
should be checked before and after the symptom confirmation to determine the current conditions, as shown
in the table below. If this is not done, it may, depending on the case, result in unnecessary troubleshooting
for normally operating systems, thus making it more difficult to locate the problem, or in repairs not pertinent
to the problem. Therefore, always follow the procedure in correct order and perform the diagnostic trouble
code check.

V07268
VIBRATION METHOD: When vibration seems to be the major cause.
CONNECTORS
WIRE HARNESS
PARTS AND SENSOR1
Slightly shake the connector vertically and horizontally.
Slightly shake the wire harness vertically and horizontally.
The connector joint, fulcrum of the vibration, and body
through portion are the major areas to be checked thorough-
ly.
Apply slight vibration with a finger to the part of the sensor
considered to be the problem cause and check that the mal-
function occurs.Shake Slightly
Swing Slightly
Vibrate Slightly
HINT:
Applying strong vibration to relays may result in open relays.
± INTRODUCTIONHOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMSIN±25
25 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
3. SYMPTOM SIMULATION
The most difficult case in troubleshooting is when there are no problem symptoms occurring. In such cases,
a thorough customer problem analysis must be carried out, then simulate the same or similar conditions and
environment in which the problem occurred in the customer's vehicle. No matter how much experience a
technician has, or how skilled he may be, if he proceeds to troubleshoot without confirming the problem
symptoms he will tend to overlook something important in the repair operation and make a wrong guess
somewhere, which will only lead to a standstill. For example, for a problem which only occurs when the en-
gine is cold, or for a problem which occurs due to vibration caused by the road during driving, etc., the prob-
lem can never be determined so long as the symptoms are confirmed with the engine hot condition or the
vehicle at a standstill. Since vibration, heat or water penetration (moisture) is likely cause for problem which
is difficult to reproduce, the symptom simulation tests introduced here are effective measures in that the ex-
ternal causes are applied to the vehicle in a stopped condition.
Important Points in the Symptom Simulation Test:
In the symptom simulation test, the problem symptoms should of course be confirmed, but the problem area
or parts must also be found out. To do this, narrow down the possible problem circuits according to the symp-
toms before starting this test and connect a tester beforehand. After that, carry out the symptom simulation
test, judging whether the circuit being tested is defective or normal and also confirming the problem symp-
toms at the same time. Refer to the problem symptoms table for each system to narrow down the possible
causes of the symptom.
