± SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
2293 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
1. INSTALL FRONT AIRBAG SENSOR
Install the sensor with bolt and nut, then connect the connector.
Torque: 7.8 N´m (80 kgf´cm, 69 in.´lbf)
NOTICE:

Make sure the sensor is installed to the specified
torque.

If the sensor has been dropped, or there are cracks,
dents or other defects in the case, brackets or con-
nector, replace the removed sensor. Always replace
the set bolt and nut with new ones.

The sensor set bolt and nut have been anti±rust
treated. When the sensor is removed, always replace
the set bolt and nut with new ones.

After installation, shake the sensor to check that
there is no looseness.

The front sensor is equipped with an electrical con-
nection check mechanism. Be sure to lock this mech-
anism securely when connecting the connector. If the
connector is not securely locked, a malfunction code
will be detected by the diagnostic system.
2. INSTALL REMOVED PARTS

RS07Z±01
H02617
Center Pillar Lower Garnish
Front Door Scuff Plate
Rear Door Scuff Plate
Side Airbag
Sensor Assembly
Front Seat
Outer Belt Retractor
41 (420, 30)
7.4 (75, 65 in.´lbf)
20 (200, 14)
: Specified torqueN´m (kgf´cm, ft´lbf)
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
RS±63
2294 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
SIDE AIRBAG SENSOR ASSEMBLY
COMPONENTS

RS080±01
H02619
H02620
RS±64
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
2295 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REMOVAL
NOTICE:
Do not open the cover or the case of the ECU and various
computers unless absolutely necessary.
(If the IC terminals are touched, the IC may be destroyed by
static electricity.)
1. REMOVE THESE PARTS:
(a) Front door scuff plate
(b) Rear door scuff plate
(c) Center pillar lower garnish
2. REMOVE FRONT SEAT OUTER BELT RETRACTOR
(See page BO±124)
(a) w/ Seat Belt Pretensioner:
Disconnect the pretensioner connector.
(b) w/ Seat Belt Warning:
Disconnect the retractor switch connector.
(c) Remove the 2 bolts and retractor.
3. REMOVE SIDE AIRBAG SENSOR ASSEMBLY
(a) Disconnect the connector.
NOTICE:
Remove the connector with the sensor assembly installed.
(b) Using a torx wrench, remove the 4 screws and side airbag
sensor assembly.
Torx wrench: T40 (Part No.09042±00020 or locally
manufactured tool)

RS081±01
H02576
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
RS±65
2296 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSPECTION
1. VEHICLES NOT INVOLVED IN COLLISION
Do a diagnostic system check.
(See page DI±552)
2. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
NOT DEPLOYED
Do a diagnostic system check.
(See page DI±552)
3. VEHICLE INVOLVED IN COLLISION AND AIRBAG IS
DEPLOYED
Replace the airbag sensor assembly.

RS082±01
RS±66
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
2297 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the side airbag sensor assembly.

If the side airbag sensor assembly has been deployed in a collision.

If the side airbag sensor assembly has been found to be faulty in troubleshooting.

If the side airbag sensor assembly has been dropped.
CAUTION:
For removal and installation of the side airbag sensor assembly, see page RS±64 and RS±67.
Be sure to follow the correct procedure.

RS083±01
H02619
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG SENSOR ASSEMBLY
RS±67
2298 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
INSTALLATION
NOTICE:

Never use SRS parts from another vehicle. When re-
placing parts, replace them with new ones.

Never reuse the side airbag sensor assembly in-
volved in a collision when the airbag has deployed.

Never repair a sensor in order to reuse it.
1. INSTALL SIDE AIRBAG SENSOR
(a) Using a torx wrench, install the side airbag assembly with
4 screws.
Torx wrench: T40 (Part No.09042±00020 or locally
manufactured tool)
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
(b) Connect the connector.
NOTICE:

Make sure the sensor assembly is installed to the
specified torque.

If the sensor assembly has been dropped, or there are
cracks, dents or other defects in the case, bracket or
connector, replace the sensor assembly with a new
one.

When installing the sensor assembly, take care that
the SRS wiring does not interfere with other parts and
is not pinched between other parts.

After installation, shake the sensor assembly to
check that there is no looseness.
2. INSTALL FRONT SEAT OUTER BELT RETRACTOR
(See page BO±132)
(a) Install the retractor with 2 bolts.
HINT:
After tightening the upper bolt, tighten the lower bolt.
Torque:
Upper bolt: 7.4 N´m (75 kgf´cm, 65 in.´lbf)
Lower bolt: 41 N´m (420 kgf´cm, 30 ft´lbf)
(b) w/ Seat Belt Warning:
Connect the retractor switch connector.
(c) w/ Seat Belt Pretensioner:
Connect the pretensioner connector.
3. INSTALL THESE PARTS:
(a) Center pillar lower garnish
(b) Rear door scuff plate
(c) Front door scuff plate

RS084±01
H02621
Combination Meter
(Warning Light)
Steering Wheel Pad
(with Airbag)
Spiral CableRH Front Airbag SensorFront Passenger Airbag Assembly
RH Side Airbag
Assembly
RH Side Airbag
Sensor Assembly
RH Seat Belt
Pretensioner
Airbag Sensor Assembly LH Side Airbag
Assembly LH Seat Belt
Pretensioner LH Side Airbag
Sensor Assembly LH Front Airbag
Sensor
RS±68
± SUPPLEMENTAL RESTRAINT SYSTEMWIRE HARNESS AND CONNECTOR
2299 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
WIRE HARNESS AND CONNECTOR
LOCATION

SA0R6±01
F02311
R11097
F02313
SST
SA±10
± SUSPENSION AND AXLEFRONT AXLE HUB
2010 Author: Date:
2000 LEXUS GS300/GS400 (RM718U)
REMOVAL
1. REMOVE FRONT WHEEL
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
2. REMOVE FRONT BRAKE CALIPER AND DISC
(a) Remove the 2 bolts and brake caliper from the steering
knuckle.
Torque: 118 N´m (1,200 kgf´cm, 87 ft´lbf)
(b) Support the brake caliper securely.
(c) Remove the disc.
3. CHECK BEARING BACKLASH AND AXLE HUB
DEVIATION
(a) Using a dial indicator near the center of the axle hub and
check the backlash in the bearing shaft direction.
Maximum: 0.05 mm (0.0020 in.)
If the blacklash exceeds the maximum, replace the bearing.
(b) Using a dial indicator, check the deviation at the surface
of the axle hub outside the hub bolt.
Maximum: 0.05 mm (0.0020 in.)
If the deviation exceeds the maximum, replace the axle hub.
4. REMOVE ABS SPEED SENSOR
Remove the bolt and ABS speed sensor.
Torque: 7.8 N´m (80 kgf´cm, 69 in.´lbf)
5. REMOVE STEERING KNUCKLE
(a) Remove the upper side of the clip and nut.
Torque: 87 N´m (890 kgf´cm, 64 ft´lbf)
(b) Using SST, remove the steering knuckle from the upper
suspension arm.
SST 09610±20012
