2000 CHEVROLET TRACKER headlamp

4-42

Tie a red cloth to your vehicle to alert police that
you've been stopped by the snow.

Put on extra clothing or wrap a blanket around you.
If you have no blankets or extra clothing, make body
insulators from newspapers, burlap bags, rags, floor
mats
-- anything you can wrap around yourself or
tuck under your clothing to keep warm.
You can run the engine to keep warm, but be careful.
CAUTION:
Snow can trap exhaust gases under your vehicle.
This can cause deadly CO (carbon monoxide) gas
to get inside. CO could overcome you and kill
you. You can't see it or smell it, so you might not
know it is in your vehicle. Clear away snow from
around the base of your vehicle, especially any
that is blocking your exhaust pipe. And check
around again from time to time to be sure snow
doesn't collect there.
Open a window just a little on the side of the
vehicle that's away from the wind. This will help
keep CO out.
Run your engine only as long as you must. This saves
fuel. When you run the engine, make it go a little faster
than just idle. That is, push the accelerator slightly. This
uses less fuel for the heat that you get and it keeps the
battery charged. You will need a well
-charged battery to
restart the vehicle, and possibly for signaling later on
with your headlamps. Let the heater run for a while.

6-38
Bulb Replacement
See ªReplacement Bulbsº in the Index to check the size
and type of bulb you need to use.
Halogen Bulbs
CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.
Headlamps
A. Headlamp
B. Turn Signal

6-39
To replace the headlamp bulb:
1. Open the hood.
2. Remove the rubber
cover and socket from
the headlamp.
3. Release the retainer clip holding the bulb by pressing
down and moving the metal retainer away from you.
4. Pull the bulb out of the fixture.
5. Reverse the steps with a new bulb.

6-49
CAUTION:
Using the wrong replacement wheels, wheel bolts
or wheel nuts on your vehicle can be dangerous.
It could affect the braking and handling of your
vehicle, make your tires lose air and make you
lose control. You could have a collision in which
you or others could be injured. Always use
the correct wheel, wheel bolts and wheel nuts
for replacement.
NOTICE:
The wrong wheel can also cause problems with
bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper
height, vehicle ground clearance and tire or tire
chain clearance to the body and chassis.
See ªChanging a Flat Tireº in the Index for
more information.Used Replacement Wheels
CAUTION:
Putting a used wheel on your vehicle is
dangerous. You can't know how it's been used or
how far it's been driven. It could fail suddenly
and cause an accident. If you have to replace a
wheel, use a new GM original equipment wheel.

6-61 Instrument Panel Fuse Block
This fuse box is under the left side of the instrument
panel. The fuses here protect each separate circuit
including headlamps. If you have electrical failure,
check here first.
Fuse Usage
P/W Power Windows
DOM Dome Light
TAIL License Plate Light, Clearance/Marker
Lights, Instrument Panel Illumination
HAZ Hazard Lights
IG O
2 Sensor Heater, Cruise Control,
Ignition Coil, Meter, G Sensor

6-63
Fuse Usage
1 Accessory Power Outlet
2 Electronic Fuel Injection System
3 Right HeadlampFuse Usage
4 Left Headlamp, High
-Beam Indicator
5 Heater
6 Hazard Lamps, Rear Combination
Lamps, Dome Light, Horn
7 Cigar Lighter, Radio, I.G. Coil, Meter,
Wiper, Washer, Rear Defroster, Turn
Signals, Back
-Up Lamps
8 Anti
-Lock Brake System
9 All Electrical Loads
10 Air Conditioning

6-64
Replacement Bulbs
Lamps Bulb Number. . . . . . . . . . . . . . . . . . . . . . . . .
Back
-up Lamp 921. . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome GM Part No. 96051559. . . . . . . . . . . . . . . . . . .
or equivalent
Front Parking and Turn Signal 1157 NA. . . . . . . . . . .
Headlamp (Halogen)
Right Hand GM Part No. 91174685. . . . . . . . . . . . .
or equivalent
Left Hand GM Part No. 91174687. . . . . . . . . . . . . .
or equivalent
Rear Hazard and Turn Signal 921. . . . . . . . . . . . . . . .
Rear Parking and Stop GM Part No. 91174349. . . . . .
or equivalent
Sidemarker 194. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications
The following approximate capacities are given in
English and metric conversions.
Air ConditioningSee the refrigerant . . . . . . . . . . . .
information label under the hood.Cooling System
1.6L Engine 5.8 quarts (5.5 L). . . . . . . . . . . . . . . . . .
2.0L Engine 6.9 quarts (6.5 L). . . . . . . . . . . . . . . . . .
Crankcase with Filter
1.6L Engine 4.4 quarts (4.2 L)**. . . . . . . . . . . . . . . .
2.0L Engine 5.5 quarts (5.2 L)**. . . . . . . . . . . . . . . .
Fuel Tank
Tw o
-Door Convertible 14.8 U.S. Gallons (56 L). . . . .
Four
-Door Hardtop 17.4 U.S. Gallons (66 L). . . . . . .
Automatic Transmission
Drain and Refill 2.6 quarts (2.5 L)*. . . . . . . . . . . . . .
Manual Transmission
Four
-Wheel Drive 1.6 quarts (1.5 L)*. . . . . . . . . . . .
Tw o
-Wheel Drive 2.0 quarts (1.9 L)*. . . . . . . . . . . .
Differential
Front 1.1 quarts (1.0 L)*. . . . . . . . . . . . . . . . . . . . . . .
Rear 2.3 quarts (2.2 L)*. . . . . . . . . . . . . . . . . . . . . . .
Transfer Case1.8 quarts (1.7 L) . . . . . . . . . . . . . . .
*Recheck fluid level after filling. See ªAutomatic
Transmission Fluidº or ªManual Transmission Fluidº in
the Index.
**When changing the oil filter, additional oil may be
needed. Recheck the oil level after filling. See ªEngine
Oilº in the Index.
