2000 CADILLAC CATERA wipers

ii
Table of Contents
Keys and Door Locks
Remote Keyless Entry (RKE) System
Trunk Release
Automatic Transmission
Windows
Tilt Wheel
Turn Signal/Multifunction Lever
Windshield Wipers
Cruise ControlInterior and Exterior Lamps
Mirrors
Storage Compartments
Convenience Net
Accessory Power Outlet
OnStar® System (If Equipped)
Sunroof (Option)
HomeLink® Transmitter (Option)
Instrument Panel, Warning Lights and Gages Seats and Seat Controls
Safety BeltsAir Bag Systems
Child Restraints
Section
1
Section
2
Seats and Restraint Systems
Features and Controls

2-36 Headlamp High/Low Beam
With the Twilight Sentinel
on or with the lamp control
dial turned to the headlamp position, push the turn
signal lever on the driver's side of the steering wheel
away from you to turn on the high
-beam headlamps.
This light on the
instrument panel cluster
will be on, indicating
high
-beam usage.
Pull the lever back to the original position to return
to low
-beam headlamps. For more information,
see ªHeadlampsº in the Index.
Flash-To-Pass
This feature uses the high-beam headlamps to signal the
driver in front of you that you want to pass. This feature
will work with either the headlamps on or off.
To use, pull the turn signal lever toward you and release.
Windshield Wipers
WIPER: Move the lever on the passenger's side of the
steering wheel up and down to control the wipers.
MIST: Tap the lever up and then release it for a single
wipe cycle. For more cycles, pull and hold the lever.
= (HIGH): Move the lever all the way up for a fast
wiper speed.
- (LOW): The third position up controls the low
wiper speed.
-- (DELAY): This position is for a controlled delay
setting. Turn the control dial on the lever to increase or
decrease the delay between wipe cycles.
o (OFF): This position turns off the wipers.

2-37
Be sure to clear ice and snow from the wiper blades
before using them. If they're frozen to the windshield,
carefully loosen or thaw them. If the blades do
become damaged, replace them with new blades.
See ªWindshield Wiper Blade Replacementº in
the Index.
Heavy snow or ice can overload the wiper motor.
A circuit breaker will stop the motor until it cools.
Clear away snow or ice to prevent an overload.
Windshield Washer
Pull and hold the
washer lever to wash
the windshield. Release
the lever when you have
enough fluid. The wipers
will clear the windshield
and either stop or return
to your preset speed.
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
This light on the instrument
panel cluster will be
displayed when the washer
fluid reaches a low level.
See ªLow Washer Fluid Warning Lightº in the Index for
more information.

2-43
Your vehicle may be equipped with High Intensity
Discharge (HID) headlamps. Your headlamps come on at
a lower intensity and gradually increase to full brightness.
Wiper
-Activated Headlamps
This feature activates the low
-beam headlamps,
parking lamps, sidemarker lamps and taillamps after
the windshield wipers have been in use for about
20 seconds.
The wiper
-activated headlamps light the way in poor
weather and also make your vehicle more visible to
other drivers. If the wipers are on and the ignition switch
is turned off, the headlamps will immediately turn off.
The headlamps will also deactivate if the windshield
wipers have been turned off for about 20 seconds.
Perimeter Lighting
This feature turns on the low-beam headlamps,
parking lamps, sidemarker lamps and taillamps for
about 20 seconds after the unlock button on the
remote keyless entry transmitter is pressed. Perimeter
lighting immediately ends when your vehicle's ignition
is turned to ON or START.
Lamps On Reminder
You will hear a warning chime if you open the door
while leaving the lamps on, if the manual headlamp
control is activated. An exception to this is when
you're using the Twilight Sentinel

.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during the
day. DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
The DRL system will make the high
-beam headlamps
come on at reduced brightness when:

your vehicle's ignition is in ON or START,

the low
-beam headlamps are off (the manual lamp
switch is in the off or park lamp position) and

your vehicle's transmission is shifted out of
PARK (P).
When DRL are on, only the high
-beam headlamps
(at reduced brightness) will be on. No other exterior
lamps such as the parking lamps, taillamps, etc. will be
on when the DRL are being used. The instrument panel
won't be lit up either.

2-44
When the Twilight Sentinel
is on and it's dark enough
outside, the high
-beam headlamps (at reduced intensity)
will change to low
-beam headlamps. When it's bright
enough outside, the regular lamps will go off, and the
high
-beam headlamps change to the reduced brightness
of DRL.
To idle your vehicle with the headlamps off, turn off the
Twilight Sentinel switch and shift the transmission into
PARK (P). Placing your vehicle in PARK (P) disables
the DRL. The DRL will stay off until you shift out of
PARK (P).
If you're not in PARK (P)
and the Twilight Sentinel
system is turned off (and it's
dark enough outside), the
DRL will remain active and
this light on the instrument
panel cluster will appear.This is a reminder that headlamps are required.
The following conditions will override the DRL:

your vehicle's transmission is shifted back into
PARK (P) with the ignition in ON or START,

the low
-beam headlamps are turned on
(using the manual lamp control dial),

the wiper
-activated headlamps are in use
(DRL will come back on 20 seconds after
wipers have turned off),

using the flash
-to-pass feature and

turning on the Twilight Sentinel.
As with any vehicle, you should turn on the regular
headlamp system when you need it.

6-56
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle unless
you check with your dealer first. Some electrical
equipment can damage your vehicle and the
damage wouldn't be covered by your warranty.
Some add
-on electrical equipment can keep other
components from working as they should.
Your vehicle has an air bag system. Before attempting
to add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring has several fuses which are
powered by a MaxiFuse
. An electrical overload will
cause the lamps to go on and off, or in some cases to
remain off. If this happens, have the headlamp wiring
checked right away.
Windshield Wiper Fuses
If the windshield wiper motor overheats due to heavy
snow or ice, the wipers will stop until the motor cools.
If the overload is caused by some electrical problem,
be sure to have it fixed.
Power Windows and Other Power Options
Circuit breakers protect the power windows and other
power accessories. When the current load is too heavy,
the circuit breaker opens and closes, protecting the
circuit until the problem is fixed or goes away.
