Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-9 Remote Keyless Entry System
2
-14 Trunk
2
-15 Theft
2
-16 Content Theft-Deterrent (If Equipped)
2
-17 PASS-Key
III
2
-19 New Vehicle ªBreak-Inº
2
-20 Ignition Positions
2
-22 Starting Your Engine
2
-24 Engine Coolant Heater (If Equipped)
2
-25 Automatic Transaxle Operation
2
-28 Parking Brake
2
-29 Shifting Into PARK (P)
2
-32 Shifting Out of PARK (P)
2
-32 Parking Over Things That Burn
2
-33 Engine Exhaust
2
-33 Running Your Engine While You're Parked2
-34 Windows
2
-35 Horn
2
-35 Tilt Wheel
2
-36 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-46 Interior Lamps
2
-50 Mirrors
2
-55 Storage Compartments
2
-56 Ashtrays and Cigarette Lighter
2
-56 Sun Visors
2
-62 The Instrument Panel - Your
Information System
2
-64 Instrument Panel Clusters
2
-67 Warning Lights, Gages and Indicators
2
-77 Head-Up Display (HUD) (If Equipped)
2
-80 Drivers Information Center (DIC)
(If Equipped)

yellowblue
2-5 Central Door Unlocking System
If your vehicle has a theft-deterrent system, all doors will
unlock if the key is held in the unlock position for more
than two seconds. The doors will also unlock if the key is
turned to the unlock position twice in three seconds.
Power Door Locks
With power door locks, you
can lock or unlock all the
doors of your vehicle
using the driver's or front
passenger's door lock switch.
Door Ajar Reminder (If Equipped)
If your vehicle is equipped with the Driver Information
Center (DIC), and a door is not fully closed, the DIC
will display a DOOR AJAR message. See ªDriver
Information Centerº in the Index.
Automatic Door Locks
Close the doors and turn on the ignition. Every time you
move the shift lever out of PARK (P), all of the doors
will lock. And, every time you stop and move the shift
lever into PARK (P), the doors will unlock. If someone
needs to get out while you're not in PARK (P), have that
person use the manual or power lock. When the door is
closed again, it will not lock automatically. Just use the
manual or power lock to lock the door again. If you
need to lock the doors before shifting out of PARK (P),
just use the manual or power lock button.
Personal Choice Programming
You can program the automatic door locks feature to
change to the following modes:
Mode 0: No automatic door lock or unlock.
Mode 1: All doors automatically lock when shifted out
of PARK (P). No automatic door unlock.
Mode 2: All doors automatically lock when shifted out
of PARK (P). Only the driver's door automatically
unlocks when shifted into PARK (P).
Mode 3: All doors automatically lock when shifted out
of PARK (P). All doors automatically unlock when
shifted into PARK (P).

yellowblue
2-21
RUN (D): This is the position the switch returns to after
you start your engine and release the switch. This is the
position for normal driving. Even when the engine is not
running, you can use RUN to operate your electrical
power accessories and to display some instrument panel
warning lights.
START (E): This position starts your engine. When the
engine starts, release the key. The ignition switch will
return to RUN for normal driving.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key; if
so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
Key Reminder Warning
If you leave your key in the OFF ignition position, you will
hear a warning chime when you open the driver's door.
Always leave your key in LOCK. If you leave it in any
other position, you will drain your battery power.
Retained Accessory Power
After you turn the ignition off and remove the key, you
will still have electrical power to such accessories as the
power windows, audio steering wheel controls, clock,
sunroof (if equipped) and the radio for up to 10 minutes.
The instrument cluster lights will stay on for a few
seconds, then will go out. Once you open a door, the
power will shut off.

yellowblue
2-36
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes your:

Turn Signal and Lane Change Indicator

Headlamp High/Low
-Beam Changer and
Passing Signal

Windshield Wipers and Washer
Turn and Lane Change Indicator
To signal a turn, move the lever on the left side of the
steering wheel all the way up or down. The lever returns
automatically when the turn is complete.
An arrow on the instrument
panel will flash in the
direction of the turn or
lane change.
If your vehicle is equipped with the Head
-Up Display
(HUD), an arrow will also appear in the display area
to indicate the direction of the turn or lane change
(See ªHead
-Up Display (HUD)º in Index for
more information).
Raise or lower the lever until the arrow starts to flash to signal
a lane change. Hold it there until the lane change is complete.
The lever will return by itself when you release it.
If the arrows flash very fast as you signal a turn or a lane
change, a signal bulb may be burned out and other
drivers won't see your turn signal.

yellowblue
2-37
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse (see ªFuses and Circuit
Breakersº in the Index) and for burned
-out bulbs.
Turn Signal On Chime
If your turn signal is left on for more than 0.8 miles
(1.3 km), a chime will sound at each flash of the turn
signal. To turn off the chime, move the turn signal lever
to the off position.
Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high beam
or high beam to low beam, pull the turn signal lever
toward you and release it.
When the high beams are
on, this light located on the
instrument panel will
also be on.If your vehicle is equipped with the Head
-Up Display
(HUD), an arrow will also appear in the display area to
indicate the high beams are on (See ªHead
-Up Display
(HUD)º in Index for more information).
Flash-To-Pass
This feature lets you use the high-beam headlamps to
signal the driver in front of you that you want to pass.
It works even if your headlamps are off.
Pull the turn signal lever toward you briefly to
flash
-to-pass.
If the headlamps are off or on low beam, the high
-beam
headlamps will turn on. They'll stay on as long as you
hold the lever toward you and the high
-beam indicator
on the instrument panel cluster will come on. Release
the lever to turn the high
-beam headlamps off.

yellowblue
2-44
To operate the wiper-activated headlamps, the Twilight
Sentinel must be on. If the wiper
-activated headlamps
are on and the ignition switch is turned to RUN, the
wiper
-activated headlamps will continue. When you
turn the key to OFF/UNLOCK, the wiper
-activated
headlamps will immediately turn off. The
wiper
-activated headlamps will also turn off if you
turn off the Twilight Sentinel or the windshield wipers.
Parking Lamps
Press the PARK button to turn on the parking lamps.
Press it again to turn them off. (If the parking lamps
were turned on with the PARK button, they must be
turned off with that button).
When the parking lamps are turned on during the day,
the instrument panel cluster lights and backlighting to
buttons will turn on. At night, the brightness of this
lighting can be adjusted by the instrument panel
intensity/brightness control if the ignition key is turned
to RUN. The radio and climate control displays will also
be on. When it becomes dark outside, the instrument
panel intensity/brightness control will operate all
instrument panel lighting.
Lamps On Reminder
If you leave the manual headlamp or parking lamp
switch on, remove the key from the ignition and open
the driver's door, you will hear a continuous warning
chime. The chime will turn off when the lamps are
turned off.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
A light sensor on top of the instrument panel monitors
the exterior light level for the operation of DRL and
Twilight Sentinel, so be sure it isn't covered.
The DRL system will make your high
-beam headlamps
turn on at reduced brightness in daylight when:

The ignition is on,

the headlamp switch is off and

the transaxle is not in PARK (P).
When the DRL are on, only your high
-beam headlamps
will be on. The parking lamps, taillamps, sidemarker
and other lamps won't be on.

yellowblue
2-51
Mirror Operation
To turn on the automatic dimming feature, press AUTO.
To turn off automatic dimming, press OFF. The green
indicator light will be illuminated when this feature
is active.
Time Delay
The automatic mirror has a time delay feature which
prevents unnecessary switching from the night back to
the day position. This delay prevents rapid changing of
the mirror as you drive under lights and through traffic.
Cleaning the Photocells
Use a cotton swab and glass cleaner to clean the
photocells when necessary.
Electrochromic Day/Night Rearview Mirror
with Compass (If Equipped)
Your vehicle may have an electrochromic inside
rearview mirror with a compass.
When set in the MIRROR position, this mirror
automatically changes to reduce glare from headlamps
behind you. A time delay feature prevents rapid
changing from the day to night positions while driving
under lights and through traffic.
The mirror also includes an eight
-point compass display in
the upper right corner of the mirror face. When on, the
compass automatically calibrates as the vehicle is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray glass
cleaner directly on the mirror as that may cause the liquid
cleaner to enter the mirror housing. Use a cotton swab and
glass cleaner to clean the photocells when necessary.

yellowblue
2-52
Mirror Operation
The right side of the switch located at the bottom of the
mirror turns the electrochromic mirror on and off. To
turn on the automatic dimming feature, press MIRROR.
To turn off automatic dimming, press MIRROR again.
The green indicator light will be illuminated when this
feature is active.
Compass Operation
Press the COMPASS button once to turn the compass
on or off.When the ignition and the compass feature are on, the
compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.
If, after two seconds, the display does not show a compass
heading (ªNº for North, for example), there may be a
strong magnetic field interfering with the compass. Such
interference may be caused by a magnetic antenna mount,
magnetic note pad holder or a similar magnetic item. You
should remove the interference.
Compass Calibration
In order to calibrate, the letter ªCº must be displayed in
the mirror compass window. If ªCº is not displayed,
push the ªCOMPASSº button for approximately
eight seconds. The zone number will come up first and
then the letter ªCº will be displayed.
The compass can be calibrated in one of two ways:

Drive the vehicle in two complete 360 circles at
five mph (8 km/h) or less until the display reads a
direction, or

Drive the vehicle on your everyday routine.
